CAR-connect LAC.11-1 User manual

Operating manual
IC-CPD AC charging cable LAC.11-1
42.CC.2210.2713_BA_V02_EN

Legal notice
2
42.CC.2210.2713_BA_V02_EN
Legal notice
Legal notice
Manufacturer CAR-connect GmbH
Am Egelingsberg 8
38542 Leiferde, Germany
Phone: [phone]
Fax: [phone]
[e-mail]
www.car-connect.cc
Reproduction Reproduction or reprinting, whether in whole or in part, always requires the written
permission of the manufacturer.
Copyright TRANSLATION OF THE ORIGINAL OPERATING MANUAL
All rights reserved.
All text, images and graphics are subject to copyright and other intellectual property laws.
Copyright 2020 CAR-connect GmbH.
Image sources Symbols for warnings, prohibitions, mandatory actions and standards are taken from publicly
accessible sources, such as the Internet. CAD product images and product photos are
provided by the manufacturer. Images showing the product in use are provided with a
reference to the source.
Revision Date Reason
V00 13.10.2020 First edition
V01 12.01.2021 Adaptation to target group
V02 26.01.2021 Chapter revision:
- “Technical data”

Das verknüpfte Bild kann nicht angezeigt werden. Möglicherweise wurde die Datei verschoben, umbenannt oder gelöscht. Stellen Sie sicher, dass die Verknüpfung auf die korrekte Datei und den korrekten Speicherort zeigt.
Contents
42.CC.2210.2713_BA_V02_EN
3
Contents
Contents .............................................................................................................................3
1Introduction ...............................................................................................................5
1.1 Preliminary information.............................................................................................................. 5
1.2 Validity of the declaration of conformity .................................................................................. 5
1.3 Manufacturer specifications ...................................................................................................... 5
2Safety..........................................................................................................................6
2.1 Warning levels ............................................................................................................................. 6
2.2 Important safety instructions..................................................................................................... 7
2.3 Intended use ................................................................................................................................ 8
2.4 Requirements for the target group............................................................................................ 9
2.5 Duties of the operator................................................................................................................. 9
2.6 Note to the grid operator ............................................................................................................ 9
3Product description ................................................................................................10
3.1 Scope of delivery ...................................................................................................................... 10
3.2 Design ........................................................................................................................................ 11
3.3 Symbols and connections........................................................................................................ 12
3.3.1 Nameplate......................................................................................................................... 12
3.3.2 “Flash codes” sticker......................................................................................................... 13
3.4 Status display............................................................................................................................ 14
3.5 Technical data ........................................................................................................................... 15
4Operation .................................................................................................................16
4.1 Checking the power supply connection ................................................................................. 16
4.2 Startup........................................................................................................................................ 17
4.3 Starting charging ...................................................................................................................... 18
4.4 Finishing charging .................................................................................................................... 19
4.5 Troubleshooting........................................................................................................................ 20
4.6 Cleaning ..................................................................................................................................... 22
4.7 Disposal ..................................................................................................................................... 22

Contents
4
42.CC.2210.2713_BA_V02_EN
Contents
4.8 Maintenance............................................................................................................................... 22
4.9 Storage ....................................................................................................................................... 22
5Help ..........................................................................................................................23
5.1 Warranty..................................................................................................................................... 23
5.2 Customer service ...................................................................................................................... 23

Das verknüpfte Bild kann nicht angezeigt werden. Möglicherweise wurde die Datei verschoben, umbenannt oder gelöscht. Stellen Sie sicher, dass die Verknüpfung auf die korrekte Datei und den korrekten Speicherort zeigt.
Introduction
42.CC.2210.2713_BA_V02_EN
5
1 Introduction
1.1 Preliminary information
Read through this operating manual carefully before using the product.
The product is delivered with a USB stick containing the operating manual in various
languages. You can find the current version and additional languages on our homepage.
There is a QR code on the product. You can scan this QR code with a device that is
connected to the internet to go directly to the download area for your product.
The operating manual is an essential part of the product and must be kept together with
the product. If you sell or transfer ownership of the product, the operating manual must be
handed over to the new operator.
In addition to this operating manual, all the relevant regulations for charging traction
batteries in electric vehicles are binding. They include but are not limited to: instructions
from the vehicle manufacturer and the operator, company-specific safety requirements and
the latest engineering standards for working with electric vehicles.
1.2 Validity of the declaration of conformity
The declaration of conformity applies to the product described in the operating manual. Any
changes, modifications or extensions shall void the declaration of conformity and the risk
assessment.
1.3 Manufacturer specifications
CAR-connect GmbH
Since its founding, our company has focused on groundbreaking solutions for
electromobility. CAR
-
connect develops and produces custom solutions for the automotive
industry, repair shops and special vehicle fleets.
Our core business is developing and producing innovative high
-
voltage charging
technology
for electric vehicles. Our portfolio also includes measurement and diagnostic
technology for the entire vehicle and battery analysis equipment.
With extensive experience in software and hardware development, CAR
-
connect is your
dependable partner at
every production stage, from prototyping to series production.
CAR-connect GmbH – Experience, Expertise and Innovation – MADE IN GERMANY
