Car Solutions CAR DVR User manual
Model No. : CAR DVR
Instruction Manual
Smart View System
Competitive Accident Recorder
TV
car-solutions.com
car-solutions.com
CONTENTS
Introduction ....................................................................... 1
Features............................................................................ 1
The VehicleView Camera System Kit ................................ 1
Testing Before Installation ................................................. 2
Caution.............................................................................. 2
Installation...................................................................... 3-6
Operation ....................................................................... 7-8
Congurations................................................................... 9
Specications.................................................................. 10
Recording Filer................................................................ 10
Note .................................................................................11
car-solutions.com
car-solutions.com
~ 1 ~
VehicleView Camera
Introduction
The Smart View System DVR is designed with continuous, manual
recording plus auto recording by G sensor. The MJPEG DVR is built with
SD card slot for storage.
Features:
Support 400TV Line camera
When a triggering "event" happens-an accident ,hard acceleration,stop,or
turn-images are saved.
Forward-Facing View
This unit can be mounted inside the vehicle,in the center of the windshield.
Rear-Facing View
The unit built-in up/down switch, the real view function is optional.
G sensor recording with 20 seconds (15 seconds before and 5 seconds after
collision)
when accident detected by G sensor and up to 36 les overwrite function for
256MB SD card
Overwrite recording function with 40 seconds
High image quality of AVI recording by MJPEG engine.
Support up to 2G SD card (SD card doesn't support SDHC format)
The VehicleView camera system kit
Standard accessories:
Standard optional:
ManualCamera
ModeNo. : CAR DVR
InstructionManual
Smart View System
Competitive Acc ident Record er
Acetabula Screw pack
car-solutions.com
car-solutions.com
VehicleView Camera
~ 2 ~
Testing before installation
It's recommended to determine the best position before permanent instal-
lation.
Caution
Do not attempt to remove the cover. Removing the cover can cause
components damage, and invalidate the warranty. Always disconnect the
power before installation.
Rivet
Mirror Switch
Lock Screw
Cable
3M Sticky Tape
Lens
Red LED Blue LED
Mode Switch
SD Card
SD card lock
Record Button
Bracket
Acetabula
car-solutions.com
car-solutions.com
~ 3 ~
VehicleView Camera
Installation I
uTear off the 3M sticky tape.
Fix the DVR as shown on the
picture.
vInsert the SD card to the slot.
a:Format the SD Card rst,then save
the FAT formatted text.
b:Set the current time and the cong
to SD Card.
wFix DVR to the bracket with
screw.
car-solutions.com
car-solutions.com
VehicleView Camera
~ 4 ~
xConnect the DC 12V cable to
the cigarette lighter socket.
yWhen you determined the best
position for your camera,you can
x the screw.
car-solutions.com
car-solutions.com
~ 5 ~
VehicleView Camera
uSecure the cupule bracket onto
DVR body with screws
vInsert the SD card to the slot.
a:Format the SD Card rst,then
save the FAT formatted text.
b:Set the current time and the
cong to SD Card.
wFix DVR to the bracket with
screw.
Installation II
car-solutions.com
car-solutions.com
VehicleView Camera
~ 6 ~
xConnect the DC 12V cable to
the cigarette lighter socket.
yWhen you determined the best
position for your camera,you can
x the screw.
car-solutions.com
car-solutions.com
~ 7 ~
VehicleView Camera
uInsert the SD card. Turn the
knob to lock the card.
(Note: When the SD card is not
inserted, the red LED will turn on
continuously and the DVR is
not in operation.)
vConnect to the power.
wRecord Mode:
1. 40 seconds cycle recording
mode
Set the DVR to 40 seconds
cycle recording. The recorded les
will be stored in a folder named with
YYYYMMDD under the "CYCLE"
folder after recording.
Operation
SD
car-solutions.com
car-solutions.com
VehicleView Camera
~ 8 ~
Push
Record
2. Manual recording mode:
Set the DVR to the record-
ing mode to 20 seconds manual
recording. The blue LED will turn
on continuously and in standby
mode.
Press the Record button to begin
recording. The blue LED will ash
2 times/second with the “Beep
Beep” sound. The recorded les
will be stored in a folder named
with YYYYMMDD under the
"MANUAL" folder after recording.
3. 20 seconds G sensor recording
mode:
Auto recording by G sensor. The
blue LED on DVR will ash
on 2 times/second with the “Beep
Beep” sound. The blue LED will
turn off after 5 seconds, and turn
on again to the standby mode.
The recorded les will be stored
in a folder named with YYYYMM-
DD under the "GSENSOR" folder
after recording.
car-solutions.com
car-solutions.com
~ 9 ~
VehicleView Camera
Set customized time
Set as system current time
Set the image format
Set the G sensor sensibility
Set the maximum files in
each recording mode
Select the playback file
Playback
File overwritten
Congurations:
uUse computer to read the
SD card
vRun the “OPCam.exe”
Take out the SD card, make sure DVR power off, then insert SD card to
DVR.. DVR will read the new setting automatic cally
car-solutions.com
car-solutions.com
VehicleView Camera
~ 10 ~
Specication
ITEM DESCRIPTION
Model CAR DVR
Image Sensor 1/4” VGA CMOS Sensor ,10 bit RGB
Number of Effective Pixels 640(H)x480(V)
S/N Ratio / Dynamic Range 45dB / 60dB
Resolution 400 TV Lines
View Angle In
Computer(Fov) 108°x83°x144°(H*V*D)
Up/down Picture Yes (by setting)
White Balance(WB) Automatic on chip
AE Control Automatic on chip
Video/Still Image Format AVI / MJPEG
Frame rate per second
Recording AVI le when G-sensor trigger/ Manu
records, AVI le is 15fps(30fps) and contain 15
seconds before trigger and 5 seconds after trigger
(Total 20 seconds) with VGA (QVGA) resolution
Recording AVI le when Overwrite recording, AVI
le is 6.375fps and contain 40 seconds with VGA
resolution
File Format FAT
G sensor level and range Range 0.1g - 2.0g ( Default setting 0.4g)
Extra Alarm IN Yes
Power DC 12V
Dimensions 46mmx27.5mmx105mm
Weight 128g±5g
Recording Filer
SD Card
G-Sensor trigger 36 files 72 files 144 files 288 files
14 min 28 min 56 min 112 min
35 files 70 files 140 files 280 files
Overwrite recording
Manual recording
256M 512M 1G 2G
Subject to change without prior notice.
car-solutions.com
car-solutions.com
~ 11 ~
VehicleView Camera
Note:
uIt takes 900mA/10sec when power on.
vUnder 40 seconds cycle recording mode,there would be a few seconds
interval,between each recording for saving each vedio to the SD card.
