AF-1000C/AF-2000C MANUAL
Room Air Filter
3

FOR TECHNICAL SUPPORT CALL 1800 658 111
2
AF-1000C/AF-2000C
Carbatec has been a trusted brand for woodworking enthusiasts
and professionals across Australia and New Zealand, since 1987.
Our quality woodworking products are designed and built to oer
value and performance, making the latest features and technological
advancements more accessible to Aussie woodworkers.
Backed by our no-fuss after-sales care and warranty support,
you can trust Carbatec to keep you woodworking, as promised.
We look forward to sharing in your woodworking journey!
If you have any questions about our products or service,
please call us on 1800 658 111 or email us at [e-mail]
Find us on social media
facebook.com/Carbatec
instagram.com/Carbatec
youtube.com/CarbaTecToolsForWood
V2
THANK YOU
FOR CHOOSING

CARBATEC.COM.AU
3
AF-1000C/AF-2000C
If you cannot nd an item on this list, carefully
check around and inside the machine and
components. Often, these items get lost in
packaging materials. Remove all packing from the
carton and re-check.
!
DO NOT use acetone, gasoline or lacquer thinner
to remove any protective coatings.
1. Remove parts from all of the cartons
and lay them on a clean work surface.
2. Remove any protective materials and
coatings from all of the parts of the cyclone
dust extractor. The protective coatings can
be removed by spraying WD-40 on them and
wiping it o with a soft cloth. This may need
to be redone several times before all of the
protective coatings are removed completely.
3. Compare the items above to verify that all
items are accounted for before discarding
the shipping box.
D
C
A. Main unit with lters
B. Hanger eye bolts
C. Hardware
D. Remote batteries (AAA)
E. Remote control
F. Hook and loop for remote control mount
G. Low prole hanger bracket
H. Adhesive feet
I. Allen key
The following items are provided in one package.
WHAT’S IN THE BOX
WELCOME
A
BI
E
G
F
H
A
B
C
D
E
F
AF-1000C package contents AF-2000C package contents

FOR TECHNICAL SUPPORT CALL 1800 658 111
4
AF-1000C/AF-2000C
DATE OF PURCHASE:
SERIAL NUMBER:
Record the serial number and date of purchase
in your manual for future reference.
3
Made in for:
CARBATEC PTY LTD
Brisbane - Australia
Model:
Voltage
Freq:
Phase:
Amp:
kW:
Speed:
Lot No.:
Serial No.:
Date:
QUALITY INSPECTED
Key information can be found on the inspection
panel, found on the rear of the machine.
IMPORTANT

CARBATEC.COM.AU
5
AF-1000C/AF-2000C
NOTE: The specifications, photographs, drawings and information in this manual represent
the current machine model when the manual was prepared. Changes and improvements
may be made at any time, with no obligation on the part of Carbatec to modify previously
delivered units. Reasonable care has been taken to ensure that the information in this
manual is correct, to provide you with the guidelines for the proper safety, assembly and
operation of this machine.
Introduction 2
What’s in the box 3
Key information 4
Safety instructions - General 6-9
Safety instructions - Air Filter 9-10
Safety instructions - Electrical 11
Overview 12-13
Specications 14
Assembly 15-19
Operation 20–21
Maintenance 22-24
Parts diagrams/Parts list 25-27
Troubleshooting 28-29
Wiring diagram 30
Warranty 31
CONTENTS
CONTENTS

FOR TECHNICAL SUPPORT CALL 1800 658 111
6
AF-1000C/AF-2000C
A safety alert symbol Indicates DANGER, WARNING, or CAUTION.
May be used in conjunction with other symbols or pictographs.
Indicates an imminently hazardous situation, which, if not avoided,
will result in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided,
could result in minor or moderate injury.
(Without Safety Alert Symbol) Indicates a situation that may result
in property damage.
Carbatec products bearing the Regulatory Compliance Mark (RCM) have been
tested in accordance with applicable Australian/New Zealand Standards
to ensure their compliance with all mandatory standards and regulations
(applicable at time of original sale). Carbatec Pty Ltd are registered as a
responsible supplier with relevant Australian government departments and
our products are registered on the EESS & ACMA database.
!
!
!
!
SYMBOL MEANING
IMPORTANT! Safety is the single most important consideration in the operation of this
equipment. The following instructions must be followed at all times. Failure to follow all
instructions listed below may result in electric shock, re, and/or serious personal injury.
There are certain applications for which this tool was designed. We strongly recommend
that this tool not be modied and/or used for any other application other than that for
which it was designed. If you have any questions about its application, do not use the tool
until you have contacted us and we have advised you.
The purpose of safety symbols is to attract your attention to possible dangers. The safety
symbols and the explanations with them deserve your careful attention and understanding.
The symbol warnings do not, by themselves, eliminate any danger. The instructions and
warnings they give are no substitutes for proper accident prevention measures.
!
Be sure to read and understand all safety instructions in this manual, including all safety
alert symbols such as “DANGER,” “WARNING,” and “CAUTION” before using this tool.
Failure to following all instructions listed below may result in electric shock, re, and/or
serious personal injury.
SAFETY INSTRUCTIONS

CARBATEC.COM.AU
7
AF-1000C/AF-2000C
Operating a power tool can be dangerous if
safety and common sense are ignored. The
operator must be familiar with the operation of
this machine. Read this manual to understand this
machine. DO NOT OPERATE this machine IF YOU
DO NOT FULLY UNDERSTAND the limitations of
this tool. DO NOT MODIFY this machine in any way.
BEFORE USING
THIS MACHINE
!
To avoid serious injury and damage to the tool,
read and follow all of the Safety and Operating
Instructions before operating the machine.
!
1. SOME DUST CREATED BY USING
POWER TOOLS CONTAINS CHEMICALS
known to cause cancer, birth defects, or
other reproductive harm. Some examples of
these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement, and
other masonry products.
• Arsenic and chromium from chemically
treated lumber
Your risk from these exposures varies,
depending on how often you do this type
of work. To reduce your exposure to these
chemicals: work in a well ventilated area
and work with approved safety equipment,
such as those dust masks that are specially
designed to lter out microscopic particles.
2. READ this entire manual. LEARN how to use
the tool for its intended applications.
3. GROUND ALL TOOLS. If the tool is supplied
with a 3-prong plug, it must be plugged into
a 3-contact electrical receptacle. The third
prong is used to ground the tool and provide
protection against accidental electric shock.
4. AVOID A DANGEROUS WORKING
ENVIRONMENT. Do not use electrical tools in
a damp environment or expose them to rain.
5. DO NOT USE electrical tools in the presence
of FLAMMABLE liquids or gases.
6. ALWAYS KEEP THE AREA CLEAN, well lit,
and organized. Do not work in an environment
with oor surfaces that are slippery from
debris, grease, and wax.
7. KEEP VISITORS AND CHILDREN AWAY. Do
not permit people to be in the immediate
work area, especially when the electrical tool
is operating.
8. DO NOT FORCE THE TOOL to perform an
operation for which it was not designed. It
will do a safer and higher quality job by only
performing operations for which the tool was
intended.
9. WEAR PROPER CLOTHING.
Do not wear loose clothing, gloves, neckties,
or jewellery. These items can get caught in
the machine during operations and pull the
operator into the moving parts. The user
must wear a protective cover on their hair, if
hair is long, to prevent it from contacting any
moving parts.
10. CHILDPROOF THE WORKSHOP AREA by
removing switch keys, unplugging tools from
the electrical receptacles, and using padlocks.
GENERAL SAFETY
SAFETY INSTRUCTIONS

FOR TECHNICAL SUPPORT CALL 1800 658 111
8
AF-1000C/AF-2000C
11. ALWAYS UNPLUG THE TOOL FROM THE
ELECTRICAL RECEPTACLE
when making adjustments, changing parts or
performing any maintenance.
12. KEEP PROTECTIVE GUARDS IN PLACE AND
IN WORKING ORDER.
13. AVOID ACCIDENTAL STARTING. Make sure
that the power switch is in the “OFF” position
before plugging in the power cord to the
electrical receptacle.
14. REMOVE ALL MAINTENANCE TOOLS from
the immediate area prior to turning “ON”
the machine.
15. USE ONLY RECOMMENDED ACCESSORIES.
Use of incorrect or improper accessories
could cause serious injury to the operator
and cause damage to the tool. If in doubt,
check the instruction manual that comes with
that particular accessory.
16. NEVER LEAVE A RUNNING TOOL
UNATTENDED. Turn the power switch to the
“OFF” position. Do not leave the tool until it
has come to a complete stop.
17. DO NOT STAND ON A TOOL. Serious injury
could result if the tool tips over, or you
accidentally contact the tool.
18. DO NOT STORE ANYTHING ABOVE OR
NEAR the tool where anyone might try to
stand on the tool to reach it.
19. MAINTAIN YOUR BALANCE. Do not extend
yourself over the tool. Wear oil resistant
rubber soled shoes. Keep oor clear of
debris, grease, and wax.
20. MAINTAIN TOOLS WITH CARE. Always
keep tools clean and in good working order.
Keep all blades and tool bits sharp, dress
grinding wheels and change other abrasive
accessories when worn.
21. EACH AND EVERY TIME, CHECK FOR
DAMAGED PARTS PRIOR TO USING THE
TOOL. Carefully check all guards to see that
they operate properly, are not damaged, and
perform their intended functions. Check for
alignment, binding or breaking of moving
parts. A guard or other part that is damaged
should be immediately repaired or replaced.
22. DO NOT OPERATE TOOL WHILE TIRED,
OR UNDER THE INFLUENCE OF DRUGS,
MEDICATION OR ALCOHOL.
23. SECURE ALL WORK. Use clamps or jigs to
secure the work piece. This is safer than
attempting to hold the work piece with
your hands.
24. STAY ALERT, WATCH WHAT YOU ARE
DOING, AND USE COMMON SENSE WHEN
OPERATING A POWER TOOL. A moment of
inattention while operating power tools may
result in serious personal injury.
GENERAL SAFETY

CARBATEC.COM.AU
9
AF-1000C/AF-2000C
25. ALWAYS WEAR A DUST MASK TO
PREVENT INHALING DANGEROUS DUST
OR AIRBORNE PARTICLES, including wood
dust, crystalline silica dust and asbestos
dust. Direct particles away from face and
body. Always operate tool in well ventilated
area and provide for proper dust removal. Use
dust extraction system wherever possible.
Exposure to dust may cause serious and
permanent respiratory or other injury,
including silicosis (a serious lung disease),
cancer, and death. Avoid breathing dust, and
avoid prolonged contact with dust. Allowing
dust to get into your mouth or eyes, or lay on
your skin may promote absorption of harmful
material. Always use properly tting AS/NZS
approved respiratory protection appropriate
for the dust exposure, and wash exposed
areas with soap and water.
SAFETY INSTRUCTIONS
26. USE A PROPER EXTENSION CORD IN GOOD
CONDITION. Use of extension cords should
be avoided where possible. When using an
extension cord, be sure to have a cord heavy
enough to carry the current your product will
draw, and with compatible pin conguration
and connections. NEVER use an extension
cord rated at less than your machine.
Longer run extensions will need heavier
duty extension cords. Only connect your
extension cord or machine to a receptacle
that accepts your plug and never modify your
plug to suit a receptacle.
AIR FILTER SAFETY
INTENDED USE
This Air Filter is designed to assist the removal
of very ne dust particles from the air within an
enclosed workshop. They are not designed as a
primary dust collection device, (which is designed
to collect dust at the point it is created) and does
not supersede the need for proper PPE (personal
protective equipment) to prevent respiratory
damage from hazardous dust.
HAZARDOUS DUST
Dust created while using machinery may cause
cancer, birth defects, or long-term respiratory
damage. Be aware of dust hazards associated
with each work piece material, and always wear a
AS/NZS-approved respirator to reduce your risk.
DUST ALLERGIES
Dust from certain woods may cause an allergic
reaction in people and animals. Make sure you
know what type of wood dust you will be exposed
to in case there is a possibility of an allergic
reaction.
WEAR A RESPIRATOR
Fine dust that is too small to be caught in the lter
will be blown into the ambient air during operation.
Always wear a AS/NZS-approved respirator during
operation and for a short time after to reduce your
risk of permanent respiratory damage.

FOR TECHNICAL SUPPORT CALL 1800 658 111
10
AF-1000C/AF-2000C
REGULAR CLEANING
Regularly check/empty the collection lters to
avoid the buildup of ne dust that can increase
the risk of re. Make sure to regularly clean the
surrounding area where the machine is operated–
excessive dust buildup on overhead lights,
heaters, electrical panels, or other heat sources
will increase the risk of re.
!
No list of safety guidelines can be complete.
Every shop environment is dierent. Accidents
are frequently caused by lack of familiarity or
failure to pay attention. Use this machine with
respect and caution to lessen the possibility of
operator injury. If normal safety precautions are
overlooked or ignored, serious personal injury
may occur.
AIR FILTER SAFETY
EMPTYING DUST
When emptying dust from the air lter, wear a
respirator and safety glasses. Empty dust away
from ignition sources and into an approved
container.
DISCONNECT POWER
SUPPLY
Turn the switch o, disconnect the dust collector
from the power supply, and allow the impeller
to come to a complete stop before leaving
the machine unattended or doing any service,
cleaning, maintenance, or adjustments.
SUSPENDED DUST
PARTICLES AND IGNITION
SOURCES
Do not operate the air lter in areas where
explosion risks are high. Areas of high risk include,
but are not limited to, areas near pilot lights, open
ames, or other ignition sources.
FIRE SUPPRESSION
Only operate the air lter in locations that
contain a re suppression system or have a re
extinguisher nearby.
IMPELLER HAZARDS
Do not place your hands or tools into an open
cabinet during operation for any reason. The
suction could easily cause accidental contact with
the impeller, which will cause serious personal
injury or damage to the machine. Always keep
small animals and children away from open dust
collection inlets.
OPERATING LOCATION
To reduce respiratory exposure to ne dust, locate
permanently installed air lters away from the
working area. Do not operate the air lter in rainy
or wet locations. Exposure to water may create a
shock hazard or decrease the life of the machine.

CARBATEC.COM.AU
11
AF-1000C/AF-2000C SAFETY INSTRUCTIONS
FIG. BFIG. A
!
This tool must be grounded while in use to
protect the operator from electric shock. IN THE
EVENT OF A MALFUNCTION OR BREAKDOWN,
grounding provides the path of least resistance
for electric current and reduces the risk of electric
shock. This tool may be equipped with an electric
cord that has an equipment grounding conductor
and a grounding plug. The plug MUST Be plugged
into a matching electrical receptacle that is
properly installed and grounded in accordance
with ALL local codes and ordinances.
DO NOT MODIFY THE PLUG PROVIDED.
If it will not t the electrical receptacle, have the
proper electrical receptacle installed by a
qualied electrician.
IMPROPER ELECTRICAL CONNECTION of the
equipment grounding conductor can result in
risk of electric shock. The conductor with the
green insulation (with or without yellow stripes)
is the equipment grounding conductor. DO NOT
connect the equipment grounding conductor to a
live terminal if repair or replacement of the electric
cord or plug is necessary.
CHECK WITH A QUALIFIED ELECTRICIAN
or service personnel if you do not completely
understand the grounding instructions, or if you
are not sure the tool is properly grounded.
Use only a 3-wire extension cord that has a
3-prong grounding plug and a 3-pole receptacle
that accepts the tool’s plug. Replace a damaged
or worn cord immediately.
Power tools and machinery are intended for use
on a circuit that has an electrical receptacle as
shown in FIGURE A that shows a 10 Amp 3-wire
electrical plug and corresponding electrical
receptacle that has a grounding conductor.
If this particular tool has been designed and tted
with a two prong electrical plug, ensure it displays
the ‘Double Insulated’ logo shown in FIGURE B,
before connecting to a 3- wire receptacle.
!
Never modify the standard tted electrical
plugs to t your receptacle.
ELECTRICAL SAFETY

FOR TECHNICAL SUPPORT CALL 1800 658 111
12
AF-1000C/AF-2000C
A. Control panel
B. Exhaust port
C. Primary lters (not shown)
D. Fuse holder
E. On/o & timer control
F. Speed buttons
G. Remote speed control
H. Remote on/o control
I. Remote timer control
J. Eye bolt mounting points
AF-1000C ROOM AIR FILTER OVERVIEW
CA
OVERVIEW
B
D
E
F
G
I
H
J

CARBATEC.COM.AU
13
AF-1000C/AF-2000C OVERVIEW
AF-2000C ROOM AIR FILTER OVERVIEW
C
A
OVERVIEW
E
F
G
I
H
D
A. Control panel
B. Exhaust port
C. Primary lters (not shown)
D. Fuse holder
E. On/o & timer control
F. Speed buttons
G. Remote speed control
H. Remote on/o control
I. Remote timer control
J. Eye bolt mounting points
B
J

FOR TECHNICAL SUPPORT CALL 1800 658 111
14
AF-1000C/AF-2000C
CODE AF-1000C AF-2000C
MOTOR 123W (HP) 250W (HP)
LOW FILTER RATE 450CFM 800CFM
MEDIUM FILTER RATE 550CFM 1200CFM
HIGH FILTER RATE 600CFM 1600CFM
AVERAGE WORKSHOP
CYCLES PER HOUR
(6M×6M×2.4M)
12 30
FILTER EFFICIENCY
(@5MICRON) 99.90% 99.90%
FILTER EFFICIENCY
(@1MICRON) 85% 85%
WORKSHOP FOOTPRINT
(W×D×H)
770mm ×610mm ×
310mm
1120mm ×620mm ×
510mm
WEIGHT 17.6/25kg 50/50kg
SPECIFICATIONS
770mm
310 mm
1120mm
510 mm

CARBATEC.COM.AU
15
AF-1000C/AF-2000C ASSEMBLY
• The Carbatec Room Air Filter comes pre-
assembled, however before installing the
machine or performing a test run, please
remove the lters and check for any packing
materials that may be inside the unit. After
unpacking, the machine must be installed.
• Transport the Room Air Filter in its packing
to a place near its nal installation site
before unpacking it.
• If the packaging shows signs of possible
transport damage, take the necessary
precautions not to damage the machine
when unpacking.
• If any damage is discovered, the carrier
and/or shipper must be notied of this fact
immediately to establish any claim which
might arise.
A. PLACEMENT LOCATION
Consider anticipated workpiece sizes and
additional space needed for auxiliary stands,
storage, or other machinery when establishing
a location for this machine in the shop. See
dimensions on page 14, for reference.
ASSEMBLY
!
The machine is heavy.
DO NOT over-exert yourself while mounting the
machine. A minimum of two people are required
to safely mount this machine.

FOR TECHNICAL SUPPORT CALL 1800 658 111
16
AF-1000C/AF-2000C
ASSEMBLY
Fig. BB. GOOD AIR CIRCULATION
1. Place the air lter in a location that will
promote circular air motion as shown.
Fig. B
2. Try to mount the unit so that it will
be running in line with the natural air
currents within your workshop. The
natural air currents can be seen on a
bright sunny day, when there are a lot of
ne dust particles in the air. Mounting
the unit this way will increase eciency.
3. When an air lter is placed too close to
any obstructions, such as walls, much of
the room will be unltered as circulation
is diminished when the velocity of the air
is lost. There must be a clearance of at
least 1m from any obstructions in front
or at the back of the unit.
4. Multiple units can be installed in various
locations to improve this circulation.

CARBATEC.COM.AU
17
AF-1000C/AF-2000C ASSEMBLY
C. MOUNTING TIPS
1. Mount the unit somewhere where it will
be easy to access for any cleaning
and maintenance
2. Place the Air Filter in an area where
sanding will likely take place, or close to
the source of ne dust.
3. Ensure that an appropriate powerpoint
is available at the location you select for
the Air Filter to plug into.
4. Ensure that the Air Filter can be installed
high enough that there is enough
clearance under it for people to walk
and operate machinery and workpieces
safely without bumping it.
D. MOUNTING THE AIR FILTER
5. The Air Filter can only be secured from
the mounting hooks installed on the top
of the unit.
6. The Air Filter can be placed horizontally
or vertically on a secure, at surface in
lieu of hanging. Optimal height is 2.1m.
7. (AF-2000C only) If placing on a at
surface, use the 4 supplied adhesive
feet on the 4 corners on the underside.
This will help with access to the side
panel for lter removal.
NOTE: When hanging, the air filter must be supported by hanging off joists which are
capable of supporting the weight of the air filter. Refer to page 14 for the weight information.

FOR TECHNICAL SUPPORT CALL 1800 658 111
18
AF-1000C/AF-2000C
Fig. E2
Fig. E1
E. HANGING THE ROOM
AIR FILTER
1. If you are suspending the unit from a
ceiling, remove four screws from the top
of the cabinet.
2. Thread the four locking nuts onto the
four eye bolts.
Fig. E1
3. Screw the eye bolt into the hole and
tighten lock nut against the cabinet top.
Hold the eye bolt to prevent it spinning
while tightening the nut.
4. Repeat steps for remaining
three eye bolts.
5. (AF-1000C ONLY)
The AF-1000C is also supplied with 4 x
low prole mount brackets, which can
allow the unit to be mounted almost
ush with a ceiling.
Attach the 4 brackets each with 2
hex bolts, and mount on your desired
position through the holes.
Fig. E2
Note: Ensure that you use the
appropriate fasteners for each unit
and check mounting location.
6. Ensure unit is suspended with at least
2.1m clearance underneath.
7. Remove all plastic packaging from the
unit (including any that may be on the
lter cartridges), before operating.
ASSEMBLY

CARBATEC.COM.AU
19
AF-1000C/AF-2000C ASSEMBLY
A. Charcoal lter B. Primary lter C. Inner lter
G. OPTIONAL ACCESSORIES
F. MACHINE TESTING
Once assembly is complete, test run the machine to ensure it is properly connected to power
and safety components are functioning correctly. If you nd an unusual problem during
the test run, immediately stop the machine, disconnect it from power, and x the problem
BEFORE operating the machine again.
DO NOT start machine until all preceding setup instructions have been performed.
Operating an improperly set up machine may result in malfunction or unexpected results
that can lead to serious injury, death, or machine/property damage.
1. Ensure machine is either mounted in nal position or on a stable surface.
2. Connect the Air Filter to the power supply.
3. Press ON button to turn the lter on. Press ON/SPEED to cycle through LO, MID and HI
speeds, listening that the motor runs smoothly at each speed with no unusual noises
or vibrations.
4. Press OFF button to turn o the machine.
5. Using the remote control, press the ON button to turn the Air Filter on.
6. Press TIMER button to verify auto-shuto cycles through each option (1H, 2H)
7. Press OFF button to turn the Air Filter o.
A B C

FOR TECHNICAL SUPPORT CALL 1800 658 111
20
AF-1000C/AF-2000C
OPERATION
H. OPERATION
The purpose of this overview is to provide the novice machine operator with a basic
understanding of how the machine is used during operation.
!
If you are not experienced with this type of machine, we strongly recommend that
you seek additional training outside of this manual. Read books, magazines or get
formal training before beginning any projects.
When you rst tun on your Air Filter, the fan motor starts on Hi before settling on your
selected speed.
Unltered air is drawn into the lter and the resulting clean, ltered air is circulated
back into your workshop.
When used in conjunction with an eective dust collection system, this Room Air Filter
removes most ne wood particles up to 1micron from the air.
