Carel humiSteam Basic User manual

Integrated Control Solutions & Energy Savings
humiSteam Basic
humidifiers
User manual

3
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
WARNINGS
The CAREL humidifiers are advanced products, whose operation is specified in
the technical documentation supplied with the product or can be downloaded,
even prior to purchase, from the website www.carel.com. Each CAREL S.p.A.
product, in relation to its advanced level of technology, requires setup/
configuration/programming/commissioning to be able to operate in the best
possible way for the specific application.The failure to complete such operations,
which are required/indicated in the user manual, may cause the final product to
malfunction; CAREL accepts no liability in such cases.
The customer (manufacturer, developer or installer of the final equipment)
accepts all liability and risk relating to the configuration of the product in order
to reach the expected results in relation to the specific final installation and/or
equipment. CAREL may, based on prior agreements, act as a consultant for the
installation/commissioning/use of the unit, however in no case does it accept
liability for the correct operation of the humidifier and the final installation if the
warnings or suggestions provided in this manual or in other product technical
documents are not heeded. In addition to observing the above warnings and
suggestions, the following warnings must be heeded for the correct use of the
product:
• DANGER OF ELECTRIC SHOCK
The humidifier contains live electrical components. Disconnect the mains power
supply before accessing inside parts or during maintenance and installation.
• DANGER OF WATER LEAKS
The humidifier automatically and constantly fills/drains certain quantities of
water. Malfunctions in the connections or in the humidifier may cause leaks.
• DANGER OF BURNS
The humidifier contains high temperature components and delivers steam at
100°C/ 212°F.
Important
Important:
• The installation of the product must include an earth connection, using the
special yellow-green terminal available in the humidifier.
• The environmental and power supply conditions must conform to the values
specified on the product rating labels.
• The product is designed exclusively to humidify rooms either directly or
through distribution systems (ducts).
• Only qualified personnel who are aware of the necessary precautions and able
to perform the required operations correctly may install, operate or carry out
technical service on the product.
• Only water with the characteristics indicated in this manual must be used for
steam production.
• All operations on the product must be carried out according to the instructions
provided in this manual and on the labels applied to the product. Any uses
or modifications that are not authorised by the manufacturer are considered
improper. CAREL S.p.A. declines all liability for any such unauthorised use.
• Do not attempt to open the humidifier in ways other than those specified in
the manual.
• Observe the standards in force in the place where the humidifier is installed.
• Keep the humidifier out of the reach of children and animals.
• Do not install and use the product near objects that may be damaged when in
contact with water (or condensate). CAREL S.p.A. declines all liability for direct
or indirect damage following water leaks from the humidifier.
• Do not use corrosive chemicals, solvents or aggressive detergents to clean the
inside and outside parts of the humidifier, unless specifically indicated in the
user manual.
• Do not drop, hit or shake the humidifier, as the inside parts and the linings may
be irreparably damaged.
CAREL S.p.A. adopts a policy of continual development. Consequently, CAREL
reserves the right to make changes and improvements to any product described
in this document without prior warning. The technical specifications shown in
the manual may be changed without prior warning.
The liability of CAREL in relation to its products is specified in the CAREL S.p.A.
general contract conditions, available on the website www.carel.com and/or by
specific agreements with customers; specifically, to the extent where allowed by
applicable legislation, in no case will CAREL S.p.A., its employees or subsidiaries
be liable for any lost earnings or sales, losses of data and information, costs of
replacement goods or services, damage to things or people, downtime or any
direct, indirect, incidental, actual, punitive, exemplary, special or consequential
damage of any kind whatsoever, whether contractual, extra-contractual or
due to negligence, or any other liabilities deriving from the installation, use
or impossibility to use the product, even if CAREL S.p.A. or its subsidiaries are
warned of the possibility of such damage.
DISPOSAL
The humidifier is made up of metal parts and plastic parts. In reference to
European Union directive 2002/96/EC issued on 27 January 2003 and the related
national legislation, please note that:
1. WEEE cannot be disposed of as municipal waste and such waste must be
collected and disposed of separately;
2. the public or private waste collection systems defined by local legislation
must be used. In addition, the equipment can be returned to the distributor
at the end of its working life when buying new equipment;
3. the equipment may contain hazardous substances: the improper use or
incorrect disposal of such may have negative effects on human health and
on the environment;
4. the symbol (crossed-out wheeled bin) shown on the product or on the
packaging and on the instruction sheet indicates that the equipment has
been introduced onto the market after 13 August 2005 and that it must be
disposed of separately;
5. in the event of illegal disposal of electrical and electronic waste, the penalties
are specified by local waste disposal legislation.
Warranty on the materials: 2 years (from the date of production, excluding
consumables).
Approval: the quality and safety of CAREL S.P.A. products are guaranteed by the
ISO 9001 certified design and production system, as well as by the
mark.

5
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
Contents
CONTENT
1. INTRODUCTION AND ASSEMBLY 7
1.1 humiSteam basic (UEY*).................................................................................. 7
1.2 Dimensions and weights .................................................................................. 7
1.3 Opening the packaging .................................................................................... 7
1.4 Positioning............................................................................................................ 7
1.5 Wall-mounting..................................................................................................... 7
1.6 Removing the front cover................................................................................. 8
1.7 Fitting the front cover ........................................................................................ 9
1.8 Components and accessories.......................................................................... 9
2. WATER CONNECTIONS 10
2.1 Supply water ..................................................................................................... 12
2.2 Drain water........................................................................................................ 12
2.3 Drain tempering............................................................................................... 12
3. STEAM DISTRIBUTION 13
3.1 CAREL jet distributors (SDPOEM00**) ....................................................... 13
3.2 CAREL linear distributors for air ducts (DP***DRU) ............................... 13
3.3 CAREL steam blowers (VSDU0A*, models UE001 to UE018 only) ..... 13
3.4 Steam hoses...................................................................................................... 14
3.5 Condensate drain hose ................................................................................ 14
4. ELECTRICAL CONNECTIONS 15
4.1 Preparing the electric cableways .................................................................. 15
4.2 Power cable connection ................................................................................ 15
4.3 Steam production control signals (M2.1 - M2.7) ............................................ 15
4.4 Alarm contact (M5.1 - M5.2) ......................................................................... 16
4.5 Auxiliary contact: production request present, external fan control) (M14.1 -
M14.3)........................................................................................................................ 16
5. REMOTE TERMINAL AND SUPERVISORY NETWORK 17
5.1 Remote display terminal..................................................................................17
5.2 RS485 supervisory network (M1.1-M1.3).....................................................17
6. STARTING AND USER INTERFACE 18
6.1 Starting................................................................................................................ 18
6.2 Stopping............................................................................................................. 18
6.3 Display................................................................................................................ 18
6.4 Keypad ............................................................................................................... 18
6.5 Main display ..................................................................................................... 18
6.6 Disabling ............................................................................................................ 18
6.7 Recalling the manufacturer defaults ............................................................ 19
6.8 Visualization release Software...................................................................... 19
6.9 Match digit (match between the softwares of board and terminal) .... 19
6.10 Reset cylinder hour counters ................................................................. 19
6.11 Parameters: Saving/recalling the user settings ....................................... 19
6.12 Manually drain the water in the cylinder .................................................. 19
7. CONFIGURATION PARAMETERS 20
7.1 Accessing and setting the parameters..........................................................20
7.2 Basic parameters...............................................................................................20
7.3 Advanced parameters......................................................................................20
7.4 Serial connection parameters ........................................................................20
7.5 Read-only parameters......................................................................................20
8. ALARMS 21
9. MAINTENANCE AND SPARE PART 23
9.1 Spare parts for models UE001 to UE018.....................................................23
9.2 Spare parts for models UE025 to UE065 ...................................................25
9.3 Cleaning and maintenance of the cylinder ................................................27
9.4 Mechanically draining the water in the cylinder .......................................27
9.5 Cylinder connection, three-phase models UE025 to UE065 .................28
9.6 Cleaning and maintenance of the other components.............................28
10. WIRING DIAGRAMS 29
10.1 Diagram of single-phase models UE001 to UE009 (208-230V)..........29
10.2 Diagram of three-phase models UE003 to UE018 (208-230-460-575V)
30
10.3 Diagram of three-phase models UE025 (208-230-460-575V) and UE045
(460-575 V).............................................................................................................. 31
10.4 Diagram of three-phase models UE045 (208-230 V) and UE065(460-
575V) .........................................................................................................................32
11. GENERAL FEATURES AND MODELS 33
11.2 Technical specifications ................................................................................35
11.3 Models of steam hoses .................................................................................36
11.5 Models of linear distributors and typical installations............................ 37
11.6 Table of parameter b1...................................................................................39
11.6 Table of parameter b1................................................................................... 41
11.7 CONTROLLING THE BOARD VIA NETWORK.............................43
11.8 Controlling production using variables I62 and I63 ...............................44
11.9 Read alarm log via the network...................................................................44
11.10 Loss of network communication ...............................................................44
11.11 Modbus® protocol on the UEY boards..................................................44
11.12 Exceptions managed....................................................................................44
12. ADVANCED FUNCTIONS 45
12.1 Operating principle ........................................................................................45
12.2 Control principles...........................................................................................45
12.3 Supply water conductivity ............................................................................45
12.4 Automatic draining.........................................................................................45
12.5 Automatic insufficient supply water management .................................46
12.6 Alarm relay switching ....................................................................................46
12.7 Auxiliary contact management (active fan request)...............................46
12.8 Manual procedure..........................................................................................46
12.9 LEDs on the control board...........................................................................46

UE xxx x x x 0 1
1 2 3 4 5 6 7
1 ID prefix;
2 rated instant steam
production
in kg/h / lbr/h:
mod. production
001 1.5/3.3
003 3/6.6
005 5/11
008 8/17.6
009 9/19.8
010 10/22
015 15/33
018 18/39.7
025 25/55.1
035 35/77.2
045 45/99.2
065 65/143.3
3 type of control: Y= UEY basic
4 type - power supply: type V
U= 208 1~N
D= 230 1~N
W= 208 3~
K= 230 3~
M= 460 3~
N= 575 3~
5 option: 0= standard cylinder
1= cylinder for low conductivity
6 U= UL certified version for the American market
7 level revision
Table 1.a

7
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
1. INTRODUCTION AND ASSEMBLY
1.1 humiSteam basic (UEY*)
Range of isothermal immersed electrode humidifiers with backlit display for
the control and distribution of steam.
Models available (identifiable from the code shown on the product):
• UE001, UE003, UE005, UE008, UE009, UE010, UE015, UE018 with steam
production capacity up to 18 kg/h (39.7 lb/h), water connections under the
base of the humidifier;
• UE025, UE035, UE045, UE065 with steam production capacity from 25 to 65 kg/h
(55.1 to 144.3 lb/h), water connections on the side of the humidifier.
1.2 Dimensions and weights
Models UE001 to UE018 Models UE025 to UE065
BB
A
C
A
C
Fig. 1.a
UE001 to
UE008
UE009 to
UE018
UE025 to
UE045
UE045** to
UE065
dimensions
mm (“)
A 365 (14.4) 545 (21.5) 635 (25.0)
B 275 (10.8) 375 (14.8) 465 (18.3)
C 712 (28.0) 815 (32.0) 890 (35.0)
weights kg
(lb)
packaged 16 (35.3) 20 (44.0) 39 (86.0) 51 (112.4)
empty 13,5 (29.8) 17 (37.5) 34 (74.9) 44 (97.0)
installed* 19 (41.9) 27 (59.5) 60,5 (133.4) 94 (207.2)
Tab. 1.a
*: in operating conditions, filled with water
**: 230 Vac model
1.3 Opening the packaging
 make sure the humidifier is intact upon delivery and immediately notify
the transporter, in writing, of any damage that may be due to careless or
improper transport;
 move the humidifier to the site of installation before removing from the
packaging, grasping the neck only from underneath the base;
 open the cardboard box, remove the protective material and remove the
humidifier, keeping it vertical at all times.
1.4 Positioning
• the unit is designed to be mounted on a wall that is strong enough to
support the weight in normal operating conditions (see Wall-mounting
below). Models UE025 to UE065 can stand on the floor;
• to ensure correct steam distribution, position the humidifier near the point
of steam distribution;
• make sure the humidifier is level, allowing the minimum clearances (see
Fig. 1.b) for maintenance operations.
Important
Important: during operation the metal casing heats up and the rear
part resting against the wall may reach temperatures in excess of 60 °C
(140 °F) .
Distances from walls
Models UE001 to UE018 Models UE025 to UE065
≥ 500
(16.4”)
<0,5°
≥ 200
(7.9”)
≥ 200
(7.9”)
≥ 200
(7.9”)
≥ 400
(15.7”)
≥ 200
(7.9”)
≥ 200
(7.9”)
≥ 700
(27.6”)
≥ 700
(27.6”)
Fig. 1.b
1.5 Wall-mounting
Fit the humidifier on the wall using the support bracket and the screw kit
supplied (for the dimensions in mm/inches see Fig. 1.d).
Assembly instructions:
1. unscrew the wall bracket from the humidifier bracket;
2. fasten the wall bracket (see Fig. 1.c), checking horizontal position with a
spirit level; if installed on a masonry wall, the plastic anchor plugs (dia. 8
mm/0.31”) and screws (dia. 5 mm x L= 50 mm/ 0.19”x L= 1.97” ) supplied
can be used;
3. hang the appliance to the bracket using the slot on the top edge of the
rear of the appliance;
4. secure the appliance to the wall through the hole in the centre on the
rear of the unit. For the weights and dimensions see Tab.1.a.
Models UE001 to UE065
bracket
X
Fig. 1.c

8
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
Spacing of the holes on the wall
Models UE001 to UE018
bracket
X
X
Y
Z Z’
==
Fig. 1.d
Models UE025 to UE065
distance mm
(“)
Models
UE001 to
UE018
UE009 to
UE018
UE025 to
UE045
UE045* to
UE065
X 270 (10.7) 270 (10.7) 445 (17.5) 535 (21.0)
Y 580 (22.8) 655 (25.8) 730 (28.7)
Z 107 (4.2) 107 (4.2) 250 (9.8) 340 (13.4)
Z’ 163 (6.4) 163 (6.4) -- --
* 230 Vac models only
1.6 Removing the front cover
Models UE001 to UE018:
1
2
3
4
5
Fig. 1.e
1. turn oval-shaped label with the Carel logo, revealing the head of the
earth screw below;
2. remove the screw using a screwdriver;
3. hold the cover by the sides and tilt;
4. remove the cover by moving to the bottom;
5. remove the protective film
Models UE025 to UE065:
1
3
2
4
Fig. 1.f
1. remove the screws from the top of the humidifier using a screwdriver;
2. hold the cover/covers from the top and lift it around 20 mm (0.79”);
3. remove the cover/covers by moving it/them forwards;
4. remove the protective film (on all the outside surfaces of the
humidifier).
bracket
X
X
Y
Z
=
==
=
Models UE025 to UE065

9
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
1.7 Fitting the front cover
Models UE001 to UE018:
1
3
4
2
Fig. 1.g
1. turn the red oval-shaped plate with the CAREL logo, revealing the
fastening hole below;
2. slip the cover onto the frame (keeping it slightly oblique), until it rests on
the rear edges, paying attention to the positioning holes on the side;
3. tighten the earth screw using a screwdriver;
4. turn the red oval-shaped plate with the CAREL logo until covering the
fastening hole below7.
Models UE025 to UE065:
1
2
Fig. 1.h
1. slip the cover/covers onto the frame (keeping it/them slightly raised
and tilted), until it rests on the rear edges;
2. tighten the screws on the top of the humidifier using a screwdriver.
Important
Important: in models UE025 to UE065 open the electrical
compartment on the humidifier using the lock with slot.
Fig. 1.i
1.8 Components and accessories
Once having opened the packaging and removed the front cover of the
humidifier, make sure the following are included::
□kit of screws with plugs for
wall-mounting
□kit code 98C615P003
of connectors for the
electronic board.
models UE001 to UE018
use fill hose connection
FWH3415000, and models
UE025 to UE65 use code
FWHDCV0000 non-return
valve with connection pipe
for fill water and use code
FWH3415000 for inlet drain
temperening.
□models UE025 to UE065
only: angular plastic hose
(drain water connection).

10
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
2. WATER CONNECTIONS
Important: before proceeding, disconnect the humidifier from
the power supply.
Models UE001 to UE018 Models UE025 to UE065
1
1
4
5
3
4
6
5
4
6
7
2
2
3
Fig. 2.a
Water connections:
□1. install a manual valve upstream of the installation (to be able
to shut off the water supply);
□2. connect the humidifier to the water supply. On models
UE001 to UE0018, use a hose with 3/4’’G fittings (see par.
11.2 “Technical specifications” , compatible CAREL hose: code
FWH3415000). On models UE025 to UE065 connect the hose
with the non-return valve supplied (code FWHDCV0000) to
prevent the water inside the humidifier from coming into
contact with the mains water;
□3. install a mechanical filter to trap any solid impurities (to be
connected downstream of the manual valve);
□4connect a section of non-conductive pipe or hose for draining
(resistant to temperatures of 100 °C (212 °F) and with a
minimum inside diameter of 40 mm/1.6” up to UE018, and 50
mm/ 1.9”for models UE025 to UE065);
□5prepare a funnel to interrupt continuity in the drain line funnel
for required air gap, can be composed of a piping reducer;
□6connect a drain trap to prevent the return of bad odours
(minimum inside diameter of 40 mm/1.6” up to UE018, and 50
mm/ 1.9”for models UE025 to UE065);
□7in models UE025 to UE0065: connect a drain hose ( minimum
inside diameter 15 mm ( 0.59” )) from the bottom tank of the
humidifier (this can run into the drain funnel).
□8in models UE025 to UE065: connect the hose code
FWH3415000 for the drain tempering valve.
Important
Important: when installation is completed, flush the supply hose for
around 30 minutes by piping water directly into the drain, without
sending it into the humidifier. This will eliminate any scale or processing
residues that may block the drain pump and cause foam when boiling.

11
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
Fittings provided for the water connections:
Models UE001 to UE018 Models UE025 to UE065
B
A
A
B
C
D
Key:
A. supply water inlet
B. drain water outlet
C. bottom tank drain water outlet (models
UE025 to UE065 only)
D. supply water inlet drain tempering valve
Fig. 2.b
Hydraulic interfaces dimensions
Interfaces dimensions drain/fill
dimensions mm (in) UE001 to UE018
D72.6 (28.6)
D’ 125.4 (49.4)
E52.6 (20.7)
E’ 107.5 (42.3)
Interfaces dimensions
steam outlet and condensed drain
dimensions mm (in) UE001 to UE018
F126.7 (50.0)
F’ 224 (88.2)
G137.9 (54.3)
G’ 21.7 (8.6)
Interfaces dimensions drain/fill
dimensions
mm (in)
UE025 to UE045 UE045* to UE065
I40 (15.8)
I’ 72 (28.3)
I’’ 10.2 (4.0)
L123.2 (48.5)
L’ 231.2 (91.0)
L’’ 49.1 (19.3)
L’’’ 678 (26.7) 752(29.6)
Interfaces dimensions
steam outlet and condensed drain
dimen.
mm (in)
UE025 to UE045 UE045* to UE065
M172 (67.7) 223.7 (88.1)
M’ 30.2 (11.9) 30.2 (11.9)
N181 (71.3) 181 (71.3)
N’ --- 100 (39.4)
N’’ 55 (21.7) 61 (24.0)
* 230 Vac models only

12
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
installatoreutenteassistenza
2.1 Supply water
Only use mains water with:
• pressure between 0.1 and 0.8 MPa (14.5 and 116 PSI), temperature
between 1 and 40 °C (33.8 and104 °F) and an instant flow-rate no lower
than the rated flow of the fill solenoid valve, the connection is G3/4M (see
par. “11.2 Technical specifications”);
• range hardness 10° to 40 °f (equal to 400 ppm of CaCO3), conductivity:
75 to 1250 µS/cm;
• no organic compounds.
supply water
characteristics
unit of
measure
normal
water
water with low
salt content
min. max. min. max.
Hydrogen ions (pH) 7 8.5 7 8.5
Specific conductivity at
20°C (σR, 20 °C)
µS/cm 300 1250 75 350
Total dissolved solids (cR) mg/l (1)(
1)( 1)( 1)
Dry residue at 180°C (R180) mg/l (1)(
1)( 1)( 1)
Total hardness (TH) mg/l CaCO3100 (2) 400 50 (2) 150
Temporary hardness mg/l CaCO360 (3) 300 30 (3) 100
Iron + Manganese mg/l Fe+Mn = 0,2 = 0,2
Chlorides ppm Cl = 30 = 20
Silica mg/l SiO2=20 = 20
Residual chlorine mg/l Cl- = 0,2 = 0,2
Calcium sulphate mg/l CaSO4= 100 = 60
Metallic impurities mg/l 0 0 0 0
Solvents, thinners,
detergents, lubricants
mg/l 0 0 0 0
Tab. 3.a
(1)= values depend on the specific conductivity; in general:
CR0.65 * σR, 20 °C; R180 0.93 * σR, 20 °C
(2) = not less than 200% of the chloride content in mg/l CL
(3) = not less than 300% of the chloride content in mg/l CL-
There is not reliable relationship between hardness and conductivity of the
water
Important:
Important:
• do not treat the water with softeners, this may cause the entrainment of
foam, affecting the operation of the unit;
• do not add disinfectants or anticorrosive compounds to the water, as
these are potential irritants;
• the use of well water, industrial water or water from cooling circuits and,
in general, any potentially chemically or bacteriologically contaminated
water is not recommended.
2.2 Drain water
this contains the same substances dissolved in the supply water, however
in larger quantities;
• it may reach a temperature of 100 °C (212 °F);
• it is not toxic and can be drained into the sewerage system.
2.3 Drain tempering
The unit is fitted with a tempering valve that, opening at the same time as
the drain valve, adds cold water to the drain line, thus ensuring a maximum
temperature of the drain water of 60°C/140°F.
Note: The use of the drain tempering option, increase the flow rate of the
drain water.

13
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
3. STEAM DISTRIBUTION
3.1 CAREL jet distributors (SDPOEM00**)
These can be fitted horizontally or vertically (hole facing upwards).
See page 31 for the models of distributors.
Assembly instructions (see Fig.3.a):
• make a series of holes on the wall according to the distributor drilling
template;
• insert the distributor;
• fasten the flange using 4 screws.
31,5 (1.2”)
50 (1.9”)
57,5(2.3”)
100 (3.9”)
C
C
A
B
A
B
50 (1.9”)
50 (1.9”)
31,5 (1.2”)
31,5 (1.2”)
31,5 (1.2”)
56(2.2”)
5(0.2”)
30 (1.2”)
22 (0.9”)
8(0.3”)
30 (1.2”)
22 (0.9”)
8(0.3”)
D
Fig. 3.a
Key:
A. steam inlet
B. condensate drain
C. steam outlet.
the dimensions of the hole vary depending on the models of
distributor:
model SDPOEM0000: hole made manually, up to 30 mm (1.2”) in
diameter);
Ddrilling template
Note: if steam hoses with an inside diameter of 30 mm (1.2”) are
used, remove the 22 mm (0.9”) steam inlet section.
3.2 CAREL linear distributors for air ducts
(DP***DRU)
Install away from obstacles (curves, branches, changes in cross-section, grills,
filters, fans).
Minimum distance between the distributor and the obstacle: 1/1.5 m
(3.3/4.9 ft). Increase the distance if:
• the air speed increases in the duct,
• the relative humidity of the air increases before and after humidification,
• the turbulence decreases.
See page 33 for installation examples.
Assembly instructions (see Fig.3.b):
• make a series of holes on the wall according to the distributor drilling
template (included in the packaging with the distributor);
• insert the distributor with the steam holes facing upward;
• fasten the flange using 4 screws.
A 22 30 40
B 10 10 10
Y 58 68 89
35 45 60
X 68 77 99
dimensioni in mm
B
Y
X
A
X
°2
1
2
3
4
56
87
Fig. 3.b
Key:
1“L”-shaped mounting support (where featured)
2flange gasket
3steam inlet (ØA)
4condensate drain (ØB)
5screw diameter (see the instruction sheet supplied with the distributor)
6length (depending on the model of distributor, see par.“10.5”page 38)
7angle (around 2°) for draining the condensate.
8diameter of the hole on the wall (ØY)
Dimensions in mm (in)
CAREL linear distributors
DP***D22RU DP***D30RU DP***D40RU
ØA 22 (0.9”) 30 (1.18”) 40 (1.57”)
ØB 10 (0.4”) 10 (0.4”) 10 (0.4”)
ØY 58 (2.3”) 68 (2.7”) 89 (3.5”)
Ø35 (1.4”) 45 (1.8”) 60 (2.4”)
X 68 (2.7”) 77 (3.0”) 99 (3.9”)
Tab. 3.a
Important:
Important:
1. fit the distributor at a slight incline (at least 2°, to prevent the return of
condensate);
2. the “L”-shaped mounting support (see part 1 Fig. 3.c) is supplied with
steam distributor models from DP085* to DP205*. For shorter lengths,
the support can be supplied as an option (code 18C478A088).
3.3 CAREL steam blowers (VSDU0A*, models
UE001 to UE018 only)
Steam distributors for humidifiers with flow rates up to 18 kg/h (39.7 lb/h).
Can be connected on top of the humidifier, or separately in another location
(see the figure below).
A
B
C
D
E
F
G
DIMENSIONS (m) A B C D
>0,5 >5 ≥2,1 >1
DIMENSIONS (m) E F G
>0,5 >5 >1
Fig. 3.c
Important:
Important:
For correct distribution of the steam, observe
For correct distribution of the steam, observe the distance
shown in the figure above.

14
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
3.4 Steam hoses
• Use CAREL hoses (max. 4 m long, see “Models of steam hoses”, page 30).
Rigid pipes may break and cause steam leaks;
• avoid the formation of pockets or traps (causes of condensate);
• avoid choking the hose due to tight bends or twisting;
• fasten the end of the hose to the connectors on the humidifier and the
steam distributor using metal clamps, so that these do not detach due to
the high temperature;
• avoid situations that cause stress on the outlet of the steam cylinder.
3.5 Condensate drain hose
During the operation of the humidifier some of the steam may condense,
causing a decline in efficiency and noise (gurgling).
To drain the condensate, connect a drain hose with a drain trap and a
minimum slope of 5° to the bottom of the humidifier (see Fig. 3.d). CAREL
condensate drain hoses: code 1312353APG
Important
Important: he drain trap in the condensate drain hose must be
filled with water before starting the humidifier.
Example of correct and incorrect installation of the steam hose and
condensate drain hose.
Final checks
□the steam outlet hoses run upwards and the distributor has a minimum
incline of 2° upwards (see Fig. 3.c);
□the ends of the hose are tightened to the fittings with metal clamps;
□the curves in the tubing are sufficiently wide (radius > 300 mm / 11.8”) so
as to not cause bending or choking;
□the steam hose has no pockets or traps for condensate to form;
□the paths of the steam and condensate hoses are as described in this
chapter (see Fig. 3.d);
□the length of the steam hose is no greater than 4 metres (13.1 feet);
□the incline of the steam hose is sufficient to allow correct draining of
the condensate (> 20° for the upward sections, > 5° for the downward
sections);
□the incline of the condensate hose is at least 5° at every point;
□the condensate hose always follows a downwards path and features a
drain trap (filled with water before starting operation) to avoid steam
being released.
YES
>5°
H≤2m (6.6 feet )
>20°
D>200mm (7.9”)
R>300mm ( 11.8”)
YES
>20°
>5°
D>200mm (7.9”)
R>300mm (11.8”)
1
All UE models Models UE25 to UE65
(1) extend the hose inside the humidifier to the bottom tank.
YES
>20°
>5°
D>200mm (7.9”) R>300mm (11.8”)
NO
NO
Models UE001 to UE025
(1): connection with fill tank All UE models
Fig. 3.d

15
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
4. ELECTRICAL CONNECTIONS
4.1 Preparing the electric cableways
Models UE001 to UE018
outside unit, bottom view inside unit, top view
1
3
2
1
2
3
Fig. 4.a
Models UE025 to UE065
outside unit, side view
3
2
1
Fig. 4.b
Key to Figs. 4.a & 4.b:
1. power cable inlet;
2. optional utility cable inlet (after drilling).
3. probe cable inlet. On models UE001 to UE018, remove the plastic “tab”
and use it to secure the cable (held in place by the screws provided).
4.2 Power cable connection
Before making the connections, ensure that the machine is
disconnected from the mains power supply.
Check that the power supply voltage of the appliance corresponds to
the value indicated on the rating plate inside the electrical panel. Insert
the power and ground connection cables into the electrical panel
compartment using the tear-proof cable gland supplied, or through the
cable gland with cable stop, and connect the ends to the terminals (see
Fig. 4.c). The humidifier power line must be fitted, by the installer,
with a disconnecting switch and fuses protecting against short circuits.
Table 11.a lists the recommended cross-sections of the power supply
cable and the recommended fuse ratings; note, however, that this data
is purely a guide and, in the event of non-compliance with local
standards, the latter must prevail.
Note: to avoid unwanted interference, the power cables should be
kept apart from the probe signal cables.
Single-phase models Three-phase models
humiSteam
humiSteam
GND
L1 L2 L3
GND
LN
Fig. 4.c (view inside unit, electrical compartment)
Important
Important:connect the yellow-green cable to the earth point
(GND).
1In the 400 V three-phase models, also connect the neutral (N)
4.3 Steam production control signals (M2.1 - M2.7)
Depending on the type of signal used, steam production can be enabled
and/or managed in different ways (ON/OFF or modulating)..
Steam production is enabled by keeping terminals M2.4 and M2.5 closed.
1. Enable steam production using:
HUMIDISTAT (ON/OFF action)
• connect inputs M2.2 and M2.3 (production request) to a humidistat;
• jumper inputs M2.4 and M2.5 (enable);
• set parameter A0=0 to enable the ON/OFF action.
M.2.1M.2.2 M.2.3 M2.4 M.2.5 M.2.6 M.2.7
Fig. 4.d

16
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
HUMIDISTAT and REMOTE CONTACT (ON/OFF action)
• connect inputs M2.2 and M2.3 (production request) to a humidistat;
• connect inputs M2.4 and M2.5 (enable) to a remote contact (e.g.: switch,
timer,…)
• set parameter A0=0 to enable the ON/OFF action.
M.2.1M.2.2 M.2.3 M2.4 M.2.5 M.2.6 M.2.7
Fig. 4.e
2. Enable and control steam production using:
PROPORTIONAL EXTERNAL CONTROLLER (modulating action)
• jumper inputs M2.4 and M2.5 (enable)
• connect outputs M2.2 and M2.3 (production request) to an external
controller
• iset parameter A0=1 to enable the modulating action (see chap. 7)
and parameter A2 depending on the signal chosen (0 to 10 V, 2 to 10V,
0..20mA, 4 to 20 mA) (see chap. 7).
M.2.1M.2.2 M.2.3 M2.4 M.2.5 M.2.6 M.2.7
OUT
REF
Fig. 4.f
PROPORTIONAL EXTERNAL CONTROLLER and REMOTE CONTACT
(modulating action)
• connect inputs M2.4 and M2.5 to a remote contact (enable)
• connect outputs M2.2 and M2.3 (request) to an external controller
• set parameter A0=1 to enable the modulating action (see chap. 7) and
parameter A2 depending on the signal chosen (0 to 10V, 2 to 10V, 0…20V,
4 to 20 mA) (see chap. 7).
M.2.1M.2.2 M.2.3 M2.4 M.2.5 M.2.6 M.2.7
OUT
REF
Fig. 4.g
Note: in industrial environments (IEC EN61000-6-2) the signal cables
running from the unit must not exceed 10 m (33 ft)(1) in length: steam
production signal cable (terminals M2.1...M2.3), remote on/off input
(terminals M2.4...M2.5) and cable shields for RS485 communication.
4.4 Alarm contact (M5.1 - M5.2)
Contact available for the remote signalling of one or more alarms.
M.5.1M.5.2
Fig. 4.h
Electrical specifications: 250 Vac; Imax: 2 A resistive 2 A inductive.
Note: use clamps on the relay terminal blocks (alarm, utilities) to
prevent the cables from being detached.
4.5 Auxiliary contact: production request
present, external fan control) (M14.1 - M14.3)
Relay contact that indicates the presence of the steam production request. It
can also be used to control an external fan (see chap. 12.7)
M.14.1 M.14.2
M.14.3
Electrical specifications: 250 Vac; Imax: 8 A resistive 2 A inductive.
Final checks
The following conditions represent correct electrical connection:
□the rated voltage of the appliance corresponds to the rated supply
voltage;
□the fuses installed are suitable for the line and the power supply
voltage;
□a mains disconnect switch has been installed to disconnect power to the
humidifier when required;
□the humidifier has been correctly earthed;
□the power cable is fastened using the tear-proof cable gland;
□terminals M2.4 and M2.5 are jumpered or connected to an enable-
operation contact;
□if the humidifier is controlled by an external control device, the earth of
the signal is electrically connected to the controller earth.

17
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
installatoreutenteassistenza
5. REMOTE TERMINAL AND SUPERVISORY NETWORK
5.1 Remote display terminal
The display terminal can be detached from the humidifier and moved up
to 30 m (98 feet) away.
21 21 3 21
M6
32
M7
12 12
M8
12
M5
21
M3
21
M9
COM
R Y G
M12
M10 M11
321
M14
M1 M2
123 1234 567
J1
JS6
UEY
controller
2
1
3
2
drain
esc
Fig. 5.a
Key:
1telephone cable 6 wires (up to 10 m (33 ft)(1 distance);
2 two EMC filters (code 0907858AXX) to be applied to the ends of the
telephone cable;
3 remote display terminal.
Note: to fill the empty space left by the display terminal on the
humidifier, use CAREL kit code HCTREW0000.
(1) For lengths greater than 10 m (33 ft) use shielded cable with the shield
connected to PE both on the terminal side and the controller side
5.2 RS485 supervisory network (M1.1-M1.3)
M.1.1 M.1.2 M.1.3
+-G0
per modelli
UEY*000/UEY*100
Rx- / Tx - Rx+ / Tx + per modelli UEY*200
Fig. 5.b
Important: for the RS485 connections in household (IEC EN 55014-1)
and residential (IEC EN 61000-6-3) environments, use shielded cable
(with shield connected to PE both on the terminal side and the controller
side) with maximum shielded cable length: specified by the EIA RS485
protocol, equivalent to European stan-dard CCITT V11, using shielded
twisted pair cable, AWG26, 485 input stage impedance 1/8 unit-load (with
this configuration, a maximum of 256 devices can be connected) laid in
separate conduits from the power cables

18
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
6. STARTING AND USER INTERFACE
3 digits, after 999 the display shows to indicate 1000 (only
three digits plus point - between the first and the second
digit- are displayed).
steam production in progress
cylinder filling in progress
foam in the cylinder
presence water in the cylinder
cylinder water drain in progress
6.4 Keypad
key function
return to the previous display
from the main screen: pressed for 5 seconds disables/
enables the humidifier
UP from the main screen: display the humidification values
(current, conductivity,....), see the following paragraph
from the list of parameters: circular navigation of the
parameters and set the values
DOWN from the main screen: display the humidification values
(current, conductivity,....)
from the list of parameters: circular navigation of the
parameters and set the values
ENTER
(PRG)
for 2 seconds: access the list of parameters
from the list of parameters: select and confirm (like the
“Enter”key on a computer keyboard)
6.5 Main display
The display on the humidifier normally shows the current steam production
(kg/h, basic display).
To display other values, press UP or DOWN and scroll the following list:
• input signal (0-100%, or ON/OFF if A0=0)
• access alarm log (HYS ) (**)
• set maximum steam production (parameter P0) (*)
• current (A)
• conductivity (S/cm)
• cylinder hour counter (h)
To return to the basic display, press ESC.
Parameter C0 (see chap. 7) can be used to change the value of the basic
display (default: current steam production).
(*) To modify the maximum steam output (P0) press:
• ENTER (display: )
• UP or DOWN to set the value percentage of production (from 20 to
100%)
• ENTER to confirm the new value
Press ESC to return to the main screen
Parameter P0 can also be accessed from the list of parameters (see chap. 7).
(**) To display the alarm log (HYS ) press:
• ENTER (the most recent alarm is shown)
• UP or DOWN to scroll the list of alarms in chronological order
press ESC to return to the main screen
To delete the list of alarms press UP and DOWN for 5 seconds (inside the
alarm log), when the list has been reset the display will show ‘res’.
6.6 Disabling
The humidifier can be disabled in 3 different ways:
• Opening contact M2.4 and M2.5 (enable) : the display shows C--
• From serial (see Chap. 7 Digital 2) : the display shows S--
• From terminal (see ESC button) : the display shows t--
Before starting the humidifier, check:
□water connections: chap. 2. In the event of water leaks do not start the
humidifier before having resolved the problem;
□steam distribution: chap. 3 and electrical connections chap. 4 .
6.1 Starting
1
1
0
ON
2if the cylinder is new, run a pre-wash cycle by pressing ENTER +
DOWN for 5 sec. (the cylinder is filled and emptied three times,
cleaning the inside walls from impurities).
A display shows the symbol PRE Cln
6.2 Stopping
1empty the water in the cylinder to avoid stagnation (see paragraph 6.6
“Manually drain the water in the cylinder”).
2
1
0
OFF
6.3 Display
humiSteam
basic
esc
μS/cm
Fig. 6.a
Key:
manually drain the cylinder (see paragraph 6.6)
power supply (green LED)
humidifier operating (yellow LED)
Flashing: steam production not yet in steady operation
Steady: steam production in steady operation
alarm (red LED, not flashing)
Alarm activated: LED flashing and buzzer active
If an alarm is active pressing ESC mutes the buzzer and the
LED comes on steady, pressing ESC again resets the alarms
(see Chap. 8)
conductivity value
time in seconds
instant current value in Amperes
real hour counter
steam flow-rate (Imperial system)
steam production as a percentage of rated capacity
steam flow-rate (international system, default)
parameter programming in progress (parameter setup)
maintenance request (alarm active) or display alarm log (HYS)
on steady: external fan or steam production active.
Flashing: external fan or steam production awaiting start/
stop

19
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
installatoreutenteassistenza
6.7 Recalling the manufacturer defaults
From the main screen press ENTER until the password screen is shown:
• Enter the password 50
• The message dEF is displayed, flashing
Confirm by pressing ENTER or exit by pressing ESC
If no button is pressed for 30 seconds, the display returns to the main
screen.
6.8 Visualization release Software
1) when swith-on the unit to display “rel. x.y“(example rel. 1.0)
2) during operation
a) to display: by main mask press ESC and UP appear in sequence: the size
dell’umidificatore, the voltage, the number of phases and the software
release
b) the network by means of variable whole 81. Es. format = # # #. # “(eg., 12
= release 1.2)”
6.9 Match digit (match between the softwares
of board and terminal)
humiSteam basic verifies the matching between the softwares of the
controller and the terminal at the start-up. The 8th digits for board and 9th
for terminal of both codes must be equal.
If there is no match, on power-up after displaying the software release, and
in normal operation when pressing UP+PRG, the red LED will remain on for 5
seconds, and the following error message will be displayed:
“X – Y”, where“X”and“Y” are the 2 different 8th digits. Refer to the after-sales
service.
6.10 Reset cylinder hour counters
• Access parameter ‘da’ (see chap. 7)
• press UP and DOWN for 5 seconds
When the counter has been reset, the display shows ‘res’.
6.11 Parameters: Saving/recalling the user
settings
From the main screen, a copy of the user settings can be saved at any time,
and then later recalled.
To save the settings::
From the main screen press:
• ENTER for 2 seconds,
• enter the password 51 using the UP or DOWN button and press ENTER, the
message UbP (Backup User parameters)
• press ENTER: the message -L- is displayed, flashing
• press UP or DOWN, the message–S- (Save) is displayed, flashing,
• press ENTER to save a copy of the user settings, or press ESC to cancel the
operation
NOTE: the copy of the user parameters saved previously will be overwritten
with current user settings.
To recall the settings::
From the main screen press:
• ENTER for 2 seconds,
• enter the password 51 using the UP or DOWN button and press ENTER,
the message UbP (Backup User parameters)
• press ENTER: the message -L- (Loading) is displayed flashing,
• press ENTER to recall the previously saved copy of the user settings, or
press ESC to cancel the operation.
If no button is pressed for 30 seconds, the display returns to the main
screen, without performing the operation.
6.12 Manually drain the water in the cylinder
Total drain in operation
Press UP and DOWN together for 2 seconds (the message‘dr’on the display
alternating with ‘tot’ indicates the function has been activated). Press UP
and DOWN again for 2 seconds to stop the drain cycle. The drain cycle in
any case ends automatically.

20
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
7. CONFIGURATION PARAMETERS
7.1 Accessing and setting the parameters
The configuration parameters are used to select and control the functions and the status of
the humidifier.
From the main screen press:
• ENTER for 2 seconds,
• enter the password 77 using UP or DOWN,
• ENTER to confirm and access the list of parameters,
• UP or DOWN to scroll the list cyclically,
• ENTER to select a parameter (display: ‘set’),
• UP to modify (increase) the value of the parameter. To scroll the values faster press UP
together with DOWN,
• DOWN to modify (decrease) the value of the parameter. To scroll the values faster press
DOWN together with UP,
• ENTER to save the new value and return to the list of parameters, or ESC to return to the
list without saving the new value,
Press ESC to return to the main screen.
7.2 Basic parameters
Parameter UOM range def notes
P0 maximum production (also see paragraph 6.5) % 20 to 100 100
A0 operating mode
0= ON/OFF control
1= proportional
-0to11
A1 unit of measure
0= kg/h; 1= lb/h
-0to10
A2 type of production request signal (the parameter can be displayed when A0=1)
1=0...10 V; 2= 2...10 V; 3= 0...20 mA; 4= 4...20 mA
-1to41
A6 Relay M14 activation delay for signalling presence of steam production request / activating external
fan
s 0 to 300 0 Visible only if function activated
(parameter b1, see par 11.6)
A7 Relay M14 deactivation delay for signalling presence of steam production request / deactivating
external fan
s 0 to 300 180 Visible only if function activated
(parameter b1, see par 11.6)
C0 value normally displayed
1= input/control signal; 2= steam prod.; 3= hour counter; 4= conductivity; 5= current
-1to52
7.3 Advanced parameters
Parameter UOM range def notes
b1 optional functions (see paragraph 11.6) - 0 to 127 0
b2 delay time when shutting down s 0 to 120 0
b4 Override conductivity of the water
0= automatic measurement
µS/cm 0 to 1250 0 Visible only if function activated
(parameter b1, see par 11.6)
b5 conductivity pre-alarm threshold (*) µS/cm 0 to 2000 1500
b6 conductivity alarm threshold (*) µS/cm 0 to .2000 2000
b7 foam threshold setting
0= no foam detection; 1= max. foam detection sensitivity; 100= min. foam detection sensitivity
% 0 to 100 50
b8 conductivity setting inside the cylinder in steady operation compared to rated value % 50 to 200 100
b9 duration of the drain to dilute cycle % 50 to 200 100
bb cylinder maintenance limit time (in hours)
0= the cylinder life alarm “Cy” and maintenance required alarm “Mn”are not shown (*)
h 0 to 4000 3000
bE time limit between two periodical drain cycles (if periodical drain is enabled, b1 = 64) h 1 to 240 24
bf days delay for drain due to inactivity (if the drain due to inactivity has been disabled, 8 set for b1) days 1 to 199 3
(*) after 999 the display shows to indicate 1000 (only three digits plus point
- between the first and the second digit- are displayed).
7.4 Serial connection parameters
Parameter UOM range def notes
C3 serial address - 1 to 207 1
C4 baud rate: 0= 9,600; 1= 19,200 - 0 to 1 0
C5 supervisor: frame (character bits, parity, stop bits)
0=8,N,2 1=8,N,1 2=8,E,2 3=8,E,1 4=8,O,2 5=8,O,1
6=7,N,2 7=7,N,1 8=7,E,2 9=7,E,1 10=7,O,2 11=7,O,1
0 to 11 0
C6 serial response transmission delay ms 0 to 199 0
C7 protocollo: 0= supervisione CAREL; 1=Modbus® - 0...1 0
C8 maximum time with no data (sent to controller) over RS485 to generate stop production and “SU”
alarm
0.1s
(ex: 50=5s)
0 to 300.0 5.0 see variable “I”62
7.5 Read-only parameters
Parameter UOM range def notes
d1 display signal measured by external controller (only if A0=1) % 0.0 to 199 -
d3 display steam production (instant value) kg/h 0.0 to 199 -
d5 conductivity of the supply water (*) S/cm 0 to 1500 -
d6 current A 0.0 to 199 -
d7 display maximum production (releated to P0 set range) kg/h 0.0 to 199 -
d9 rated steam production kg/h 0.0 to 199 -
da cylinder hour counter ( resettable ) h
db unit hour counter ( read only ) h
(*) after 999 the display shows to indicate 1000 (only three digits plus point
- between the first and the second digit- are displayed).
