Carlisle OPTIMIZER ADD6 Installation guide

OPTIMIZER™ ADJUSTABLE DISH DOLLY
ASSEMBLY INSTRUCTIONS
P.O. Box 53006
Oklahoma City, Oklahoma 73152-3006
[phone] • FAX [phone]
1-800-654-8210
Web Site: www.carlislefsp.com
#104803213 - 1/05
European Distribution Center:
Edisonstraat 84, P.O. Box 110
6900 AC Zevenaar, The Netherlands
Tel [phone] • Telex 45642
FAX [phone]
1. Following the layout for the size of plate/platter that you are using (see the back of this page),
place a divider (with the bolt on the bottom) into one of the slots (see Figure 1). In order to
secure the plates/platters properly, make sure the divider is facing the correct way shown in the
layout (see other side).
2. Place a single plate/platter between the divider and the wall of the dish dolly (see Figure 2).
3. Reaching under the cart, place a washer and knob onto the divider bolt and twist a few turns (see
Figure 1). While pushing the bottom of the divider lightly against the plate/platter, turn the knob
until the divider is tight (see Figure 2).
4. Repeat steps 1 through 3 for each of the remaining stack positions illustrated in the layout.
5. Fill each position with plates/platters.
Many other combinations can be created when combining
different size plates/platters. For these combinations,
follow these steps:
1. Determine the best layout by placing plates/platters in
the dolly and placing dividers loosely in the slots. Move
the plates/platters and dividers around to create the best
fit. Usually, the divider will be turned so that the wider
side of the divider is against the plate/platter.
2. After determining the best layout, secure the dividers as
in step 3 above.
3. Fill each position with plates/platters.
PRODUCT NUMBERS: ADD4 & ADD6
Figure 2
Figure 1
cutaway showing slot
ADD4 Layout for
9-7/8" to 10-5/8" plates

OPTIMIZER™ADJUSTABLE DISH DOLLY
ASSEMBLY INSTRUCTIONS
P.O. Box 53006
Oklahoma City, Oklahoma 73152-3006
[phone] •FAX [phone]
1-800-654-8210
Web Site: www.carlislefsp.com
#104803213 - 1/05
The following diagrams show the standard layouts for plates from 5-1/2”to 12-1/2”and platters
from 9-1/2”by 7-1/4”to 13-1/2”by 10-1/2”. Locate the desired plate/platter size(s) in the ranges
below each layout. Many other options are available if different plate/platter sizes are used together
(see the bottom of the instructions on the other side of this page).
NOTE: When setting up the dish dolly, be sure to turn the dividers as indicated in each layout.
Layout for 11-3/8" to
12-1/2" plates and 13-1/2" by
10-1/2" platters
Layout for 10-3/4" to
11-1/4" plates Layout for 9-7/8"
to 10-5/8" plates
Layout for 8-3/8" to
9-3/4" plates Layout for 12" by 9-1/4" to
9-1/2" by 7-1/4" platters
Layout for 8" to
8-1/4" plates Layout w/2 Additional Dividers
for 5-1/2" to 7-7/8" plates
