Model Size
Normal
Flow
Maximum
Flow
750MRS
¾" 10 GPM ¼ - 20 GPM
1000MRS 1" 25 GPM
¾ - 50 GPM
150MRS
1½" THREADED 50 GPM 1½-100 GPM
200MRS
2" THREADED 80 GPM 2 - 160 GPM
11/15
METER CAPACITIES
Note: All meter ends have straight threads, not tapered.
*For complete specifications, visit www.carlonmeter.com
Installation and
E-mail: [email protected]
Operating Instructions
Model MRS®
Industrial Series Water Meter
¾" thru 2" sizes
Ph: (616) 842-0420
Fax: (616) 842-1265
Leaders in water measurement and control
1710 Eaton Drive
Website: www.carlonmeter.com
Grand Haven, MI 49417
CARLON METER, INC. • PRODUCT WARRANTY
Carlon Meter, Inc.(hereinafter Carlon or “the company”) warrants products of its manufacture to be free of
defects in material or workmanship. Liability under this warranty extends for twelve (12) months from the
date of purchase. Liability is limited to repair or replacement of any failed product or assembly proven to be
defective in material or workmanship upon manufacturer’s examination. Removal and installation costs are
not included under this warranty. Manufacturer’s liability shall never exceed selling price of the meter or
assembly in question. Carlon disclaims all liability for damage its products caused as the result of improper
installation, maintenance, use or attempts to operate products beyond their intended functionality,
intentionally or otherwise. Carlon is not responsible for damages, injuries or expenses incurred through the
use of its products. The above warranty is in lieu of all other warranties, either expressed or implied. No
agent of the company is authorized to alter or otherwise revise this warranty.
METER MAINTENANCE
The only suggested maintenance is to annually remove the meter from the
water line and gently back flush the meter to remove particles that may
have been trapped by the strainer. Back flushing is running the water into
the meter from the outlet side instead of the normal flow direction. If some
unusual evidence of meter performance is observed during maintenance,
please contact the factory.
A broken tamperproof wire & seal indicates the meter has been
disassembled.
1. Flush the line thoroughly after plumbing changes to eliminate the
possibility of foreign contaminants reaching the meter. GPC GPC GPC GPC
0.1 1 10 100
2. Install meter horizontally with the register facing up and the inlet port 750MRS X X X X
facing the supply water line. 1000MRS X X X X
150MRS N/A X X X
3. Using the insulated 18/20 gauge two wire cable provided, connect 200MRS N/A X X X
the reed switch on the register to the meter input leads on the
controlling device. N/O Reed Switch rated at 100 mA, 24V AC/DC.
Note: GPC setting to determine frequency of operation.
CFPC CFPC CFPC CFPC
4. Operating pressure maximum of 150 psi. 0.01 0.1 1 10
750MRS X X X X
5. It is recommended that if there is any possibility the water supply 1000MRS N/A X X X
contains foreign contaminants, a Carlon strainer be installed between 150MRS N/A X X X
the water supply and the meter. 200MRS N/A X X X
6. It is not recommended that the meter be run for long periods of
time at the maximum flow rating as excess wear will result and
the life of the meter will be reduced. LPC LPC LPC LPC
110 100 1000
7. To reduce potential harmful effects to equipment from water 750MRS X X X X
hammer caused by quick closing valves, it is suggested that you 1000MRS N/A X X X
purchase and install a Carlon slow-closing solenoid valve. 150MRS N/A X X X
200MRS N/A X X X
8. Protect the meter from freezing and from heat in excess of 120° F.
9. Protect meter from any backflow of water opposite indicated direction
of flow.
Dry Contact Reed Switch Output
10. For outdoor installation, protect meter from direct exposure to the
elements. Output Switch Ratings: 24V AC/DC maximum
100 mA maximum
■The straight, unobstructed pipe section in front of the meter
should be as follows:
Inlet Path - One Bend = 10 x Diameter of pipe
Valves (check, gate, etc.) = 12 X Diameter of pipe
Two Bends or One Tee and one bend(s) at random =
25 X Diameter of pipe
■Straight, unobstructed pipe section downstream of meter =
5 X Diameter of Pipe
MRS®Multi-Jet Meter Installation Instructions
Gallon Contact Settings Available:
Electrical Specifications:
MRS®Contact Settings Available
Model Number
Model Number
Model Number
Cubic Foot Contact Settings Available:
Liter Contact Settings Available:
