Carpet Pro Hornet CP-HWV User manual

Owner’s
Manual
Electric
Wand
Vacuum
Model
CP-HWV
Model SCBP-1
Backpack Vacuum
Save These Instructions
OPERATING INSTRUCTIONS
COMMERCIAL
BACKPACK VACUUM CLEANERS
CONGRATULATIONS
YOU HAVE JUST ACQUIRED A HIGH QUALITY VACUUM
CLEANER. PLEASE READ THIS MANUAL CAREFULLY,
BEFORE OPERATING YOUR NEW VACUUM CLEANER.
KEEP MANUAL ON HAND FOR FUTURE REFERENCE.

1
The model and serial number of this product may be found on the unit. Register your Carpet Pro vacuum as soon
as possible at CarpetProVacs.com for your protection. Also, note the model and serial numbers of your unit in the
spaces provided below, and retain this book as a permanent record of your purchase.
Model Number ____________________________________________________________________________________
Serial Number _____________________________________________________________________________________
Date Purchased ____________________________________________________________________________________
Your vacuum cleaner is a product of high-quality materials and superior workmanship. We urge you to read these
operating instructions carefully before you use this vacuum cleaner in order to obtain the full performance and
satisfaction it can offer you.
Before you plug in your vacuum cleaner, make sure the voltage indicated on the rating plate located on the
vacuum cleaner is the same as your local supply.
Index
Customer’s Record
Save These Instructions
Important Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Two-Wire Polarized Cord. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Parts Identification and Replacement Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
How to Assemble and Operate the Vacuum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 -7
How to Use the Cleaning Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
How to Empty the Dust Cup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
How to Replace the Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11
How to Remove the Brushroll. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
How to Clean the Brushroll . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
For Best Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2
When using an electrical appliance, basic precautions should always be followed, including
the following:
READ ALL INSTRUCTIONS BEFORE USING THIS
APPLIANCE. FOR HOUSEHOLD USE ONLY.
IMPORTANT: The manufacturer cannot accept responsibility for damage caused
when the appliance is not used according to the instructions, or
for uses other than those for which it was intended.
WARNING: To reduce the risk of fire, electric shock, damage or injury:
SAVE THESE INSTRUCTIONS.
• Fully assemble vacuum before operating.
• Use and store in a dry location.
• Do not use outdoors or on wet surfaces.
• Do not allow to be used as a toy. Close
attention is necessary when used by or near
children.
• Use only as described in this manual. Use only
manufacturer’s recommended attachments.
• Do not pull or carry vacuum by cord, use cord
as a handle, close a door on the cord, or pull
cord around sharp edges or corners. Do not
run appliance over cord. Keep cord away from
heated surfaces.
• Do not unplug vacuum by pulling on cord. To
unplug grasp the plug, not the cord.
• Do not handle vacuum including plug and
charger terminals, with wet hands.
• Do not put any object into openings. Do not
use with any opening blocked; keep free of
dust, lint, hair and anything that may reduce
airflow.
• Keep hair, loose clothing, fingers and all parts
of the body away from openings and moving
parts.
• Do not pick up anything that is burning or
smoking, such as cigarettes, matches or
hot ashes.
• Use extra care when cleaning on stairs.
• Do not use to pick up flammable or
combustible liquids such as gasoline or use in
areas where they may be present.
• Do not leave vacuum unattended when plugged
in.
• Do not use with damaged cord or plug. If vacuum
isn’t working as it should, has been dropped,
damaged, left outdoors or dropped in water,
return to a service center.
• Turn off all controls before unplugging vacuum.
• Turn off vacuum before connecting or
disconnecting the floor brush.
• Do not use without filters in place.
IMPORTANT SAFETY INSTRUCTIONS

3
To reduce the risk of electric shock, the vacuum cord is equipped with a polarized alternating
current line plug (a plug having one blade wider than the other). This plug will fit into the
power outlet only one way. This is a safety feature. If you are unable to insert the plug
fully into the outlet, try reversing the plug. If the plug still does not fit, contact a qualified
electrician to replace the obsolete outlet. Do not defeat the safety purpose of the polarized
plug.
Two-Wire Polarized Cord
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to cause birth
defects or other reproductive harm.

4
• Genuine Carpet Pro Filter Set
Part #HWV-F
Parts Identification
Replacement Filters
On/Off button
Power cord
Exhaust filter
cover release
button
Main body
Top cover release
button (to access
primary filter)
Wand release button
Upper cord hook
Metal wand
Lower cord hook
Floor brush
Floor brush release button
Storage hook
Tool holder
Tool holder
Crevice/dusting tool
Crevice/dusting
tool
Upper dust cup
release button (to
remove dust cup
from the vacuum)
Lower dust cup release
button (to empty contents)
Dusting brush/
upholstery tool
Dusting brush/
upholstery tool

5
How to Assemble and Operate the Vacuum
Fig. 1
Fig. 2
Fig. 3
Handle Assembly
The vacuum, floor brush, wand and accessories
are packed separately.
1. Connect the male end of the metal wand to
the vacuum body (Fig. 1).
2. Connect the female end of the metal wand to
the floor brush (Fig. 2).
4. Attach the tool holder to the metal wand.
Place the crevice tool and dusting brush in the
holder as shown (Fig. 3).
Note: Do not plug in the vacuum until it is completely assembled.

6
Fig. 3
How to Assemble and Operate the Vacuum
Fig. 1
Assembling and Storing the
Power Cord
1. Pull the upper cord hook out and turn it to the
upright position (Fig. 1).
2. Pull the lower cord out and turn it to the downward
position (Fig. 1).
3. Wrap power cord loosely around upper and lower
cord hooks.
4. Lock power cord plug onto the power cord.
Storing the Vacuum
The vacuum body can be conveniently stored
on the storage hook on the wand when not in
use (Fig. 3). This configuration prevents the
vacuum from tipping over when being stored.
Unwinding the Power Cord
1. The upper cord hook rotates for quick access
to the power cord.
2. Pull the upper cord hook out and turn
it downward to release the cord without
unwinding it from the cord hooks (Fig. 2).
Fig. 2

7
How to Assemble and Operate the Vacuum
Using the Floor Brush
Note: As a safety precaution, the floor brush will
not operate when it is not in use on a floor or
other type of surface.
Use to clean tile, hardwood floors and area rugs.
1. After turning on the vacuum, recline the wand by
stepping on top of the floor brush and pulling the
wand toward you (Fig. 2).
2. The floor brush can also be attached directly to
the vacuum body to clean stairs or small spaces
(Fig. 3).
Fig. 1
Fig. 2
Fig. 3
ON/OFF Switch
To turn vacuum cleaner ON or OFF, press
the ON/OFF switch on the handle (Fig. 1).

8
How to Use the Cleaning Tools
Attach any of the cleaning tools to the end of the metal wand or directly to the vacuum
body.
Attachment Cleaning Area
Furniture Between
Cushions
Drapes Stairs
Crevice/dusting tool ✔ ✔ ✔
Dusting brush/upholstery tool ✔ ✔ ✔
Cleaning Tool Uses

9
How to Empty the Dust Cup
1. Press the wand release button and pull the wand
away from the main body (Fig. 1).
2. Hold the dust cup over a trash container.
3. Push the lower dust cup release button to
release the bottom of the dust cup (Fig. 2).
4. The base will drop down and the debris will fall
into the trash container.
5. Shake the dust cup to release any debris that
might be inside the dust cup.
6. When the dust cup is empty of debris, firmly
push the base onto the dust cup until it clicks
and is fully latched (Fig. 3).
Note: Always unplug the power cord from the electrical outlet before performing any
service on the vacuum cleaner.
1. Press the two upper dust cup release buttons to
remove the dust cup from the main body (Fig. 4).
2. Rinse the dust cup with warm water and allow to dry
thoroughly before re-attaching to the main body.
3. Push the dust cup into the main body until it clicks
into place.
How to Remove the Dust Cup
from the Main Body
How to Remove and Replace
the Dust Cup (For Cleaning)
Fig. 1
Fig. 3
Fig. 4
Fig. 2

10
Filter Identification
This model has a primary filter and an exhaust filter that need to be cleaned and/or
replaced on a regular basis.
How to Replace the Filters
Primary Electrostatic Foam Filter Exhaust Filter
1. Turn off and unplug the vacuum cleaner.
2. Remove the wand from the main body.
3. Lift up the top cover release button and
remove the top cover (Fig. 1).
4. Remove the electrostatic foam filter
and rinse with cool water. Allow to dry
thoroughly before replacing it in the
vacuum (Fig. 2).
5. Replace the top cover by lining up the
tab in the front and pressing down on the
cover until it clicks into place (Fig. 3).
How to Clean the Primary Filter
Fig. 2
Fig. 1
Fig. 3
When to Change the Filters
At a minimum, it’s recommended to replace the filters after 6 months of use. If someone in
your household is sensitive to airborne allergens, it is recommended to change the filters
after every three months.

11
How to Replace the Filters
1. Turn off and unplug the vacuum cleaner.
2. Remove the wand by grasping the handle on the
top of the main body. Press the wand release
button (Fig. 1).
3. Press the two exhaust filter cover release buttons
to remove the exhaust filter cover (Fig. 2).
4. Remove the foam filter and rinse with cool water.
Allow to dry thoroughly before replacing it in the
vacuum (Fig. 3).
5. Replace the exhaust filter cover.
How to Clean and Replace the Exhaust Filter
Fig. 1
Fig. 2
Fig. 3
Wash the filter with cool water at least every three (3) months.
Note: When cleaning the filter no longer restores
the vacuum cleaner suction to full power, replace the
filter.
DO NOT operate without filters installed.
DO NOT wash filters in the dishwasher.
DO NOT install damp filters into vacuum cleaner.

12
How to Remove the Brushroll
Note: Always unplug the power cord from the
electrical outlet before performing any service on
the vacuum cleaner.
1. Turn off and unplug the vacuum cleaner.
2. Remove the floor brush from the wand. Turn the
floor brush over (Fig. 1).
3. Use a coin or screwdriver to turn the screw (Fig. 2)
once to the right. Then lift off the brushroll cover.
4. Remove the brushroll to clean (Fig. 3).
4. Replace the brushroll then replace the brushroll
cover (Fig. 4). Tighten the screw by turning once
to the left.
4. Re-attach the floor brush to the wand and
continue to vacuum.
Fig. 1
Fig. 2
Fig. 3
Fig. 4

13
How to Clean the Brushroll
To maintain efficient cleaning, the brushroll
must be kept free of carpet fiber, string,
or hair buildup. After every 7 to 10 uses,
unplug and turn the vacuum cleaner over
and check the brushroll for fiber and hair
buildup.
Use scissors to remove any buildup
entangled around the brushroll (Fig. 1).
Note: Always unplug the power cord from
the electrical outlet before performing any
service on the vacuum cleaner.
Fig. 1

14
Please check each item below if you have trouble with your vacuum.
Unplug the vacuum from the power supply before servicing.
Troubleshooting
PROBLEM CHECK POINT POSSIBLE SOLUTION
Vacuum cleaner
does not work.
1. Unplugged at wall outlet.
2. Tripped circuit breaker/blown fuse
at household service panel.
3. Defective wall outlet.
4. Main body, wand and floor brush
connection
1. Plug in firmly and push ON/OFF
button.
2. Reset circuit breaker or replace
fuse.
3. Check with an electrician to have
outlet properly serviced.
4. Assemble wand and floor brush
correctly to main body.
Poor job of dirt
pickup.
1. Full or clogged dust cup.
2. Worn brushroll.
3. Clogged floor brush.
4. Clogged wand.
5. Wand not inserted fully to body.
6. Motor protection system
activated.
7. Dirty filters.
1. Empty dust cup.
2. Replace brushroll.
3. Check for clogs.
4. Check for clogs.
5. Insert wand fully to body.
6. Check for clogs.
7. Clean or replace as applicable.
Brushroll does not
turn.
1. Floor brush is off the floor or
other surface.
1. Place floor brush on floor or
other surface.
Dirt escaping from
vacuum.
1. Full or clogged dust cup.
2. Filters not installed correctly.
3. Puncture or hole in filter.
1. Empty dust cup.
2. Install filters correctly.
3. Replace filter.
Any other service should be done by an
Authorized Service Representative.
To locate your nearest retailer, visit our website at
www.carpetprovacs.com
For Best Performance
• Keep machine and all accessories clean and in good operating condition.
• Empty dust cup frequently and clean or replace the filters routinely.
• Always use genuine filters and parts, as use of other products may result in poor cleaning
or filtration performance. Carpet Pro filtration products are designed for maximum
performance.
• Store machine carefully in a dry area.
• For optimum cleaning performance and safety, follow your owner’s manual.

15
Warranty
What Is Covered:
This warranty covers any defects in material and workmanship in your new Carpet Pro vacuum.
How Long Coverage Lasts:
Warranty coverage for the Carpet Pro vacuum lasts one year. Household models used
commercially are only warranted for 90 days.
What Is Not Covered:
• Damage to the vacuum that occurs from neglect, abuse, alterations, accident, misuse or
improper maintenance.
• Normal replacement items: disposable filters.
What Carpet Pro Will Do:
This warranty provides, at no cost to you, all labor and parts to keep this vacuum in proper
operating condition during the warranted period.
How to Get Service:
Warranty service can only be obtained by presenting the vacuum to the Carpet Pro service
center. A proof-of-purchase and product serial number will be required before service is
rendered.
THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ANY AND ALL OTHER WARRANTIES
WHETHER WRITTEN, ORAL, EXPRESSED OR IMPLIED, (INCLUDING ANY WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE). THIS WARRANTY
DISCLAIMS LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.
How State Law Applies:
This warranty gives you specific legal rights, and you may also have other rights that vary from
state to state.
Register Your Carpet Pro Vacuum:
Register your Carpet Pro vacuum as soon as possible at CarpetProVacs.com.

CPOM-HWV©2017 Carpet Pro Vacuum Cleaners
CarpetProVacs.com
