Carrier Performance TP-NHP User manual

Owner's Manual

YOU WILL LOVE THIS THERMOSTAT.
You have the Edge _) thermostat. This unique device's state-of-the-art technology
makes it easier than ever for you to keep your home comfortable. And with an
ultra-thin profile and a selection of attractive faceplates, it is easily the most
decorator-friendly thermostat available. Designed to be as smart - and
smart-looking - as any of the other electronics in your home, your new Edge
thermostat offers three different "Touch 'N' Go" comfort settings to fit your
lifestyle - not anybody else's. Let this manual show you how easy it is to enjoy the
newest experience in home comfort.
Designed and Assembled
in the USA.

TABLE OF CONTENTS
BUTFON IDENTIFICATION ....................................... 6
ON-SCREEN INDICATORS ......................................... 8
QUICK START
Setting or changing the temperatures for heating and cooling .............. 10
Understanding Touch 'N' Go ...................................... 11
OPERATING THE THERMOSTAT
Using the Touch 'N' Go feature .................................... 12
Setting the home temperature ...................................... 14
Setting the away temperature ...................................... 16
Setting the sleep temperature ..................................... 18
Using the fan .................................................. 20
Changing the humidity level ...................................... 21

TABLE OF CONTENTS
Using normal humidify .......................................... 21
Using auto humidify ............................................. 22
How to turn off the humidify or dehumidify feature .................... 24
Using emergency heat (heat pump systems only) ...................... 25
Using the thermostat to turn the heating and cooling system off ........... 26
ADVANCED OPTIONS
Advanced options display codes chart ............................... 27
Clearing the reset reminders ....................................... 28
Changing from Fahrenheit to Celsius ................................ 30
Adjusting or turning off the continuous backlighting ................... 31
Keypad lockout ................................................ 32
Unlocking the keypad ........................................... 33

TABLE OF CONTENTS
SPECIAL FEATURES
Hybrid Heat (heat pump systems only) ............................... 34
Service reminders .............................................. 34
Outdoor temperature display ....................................... 35
Auto changeover ............................................... 35
WHAT IF...
"Aux heat on" is displayed (heat pump systems only) .................. 36
"Em heat" is displayed (heat pump systems only) ...................... 36
There is a power outage .......................................... 36
You get a service reminder message ................................. 37
You get a system error message .................................... 37

TABLE OF CONTENTS
COMMON TERMS AND WHERE TO FIND THEM
Auto changeover ................................................ 38
Auxiliary heat (heat pump systems only) ............................ 38
Backlighting ................................................... 38
Dehumidify .................................................... 38
Emergency heat (heat pump systems only) ........................... 39
Hybrid heat .................................................... 39
Humidify ...................................................... 39
Mode ......................................................... 40
Service reminders ............................................... 40
WARRANTY .................................................... 41

BUTTON IDENTIFICATION
÷--© mode
fan
off m
Em00_
heat 00_
oux,_,__0_,_0m_Joo_oo,
heat J_j_j outsidetemp] O0 om
on2 dehumidify setat
fan checkUVlight checkfiker
auto checkhumpad
fan
on _' T T
,, ?\

BUTTON IDENTIFICATION
a. FAN Selects whether the fan operates continuously (on) or only when
needed for heating or cooling (auto)
b. MODE Selects whether thermostat is set for heating, cooling, emergency
heat. auto (heat and cool as needed), or off
c. UP Increases the temperature or adjusts the screen selection up when
setting advanced features
d. DOWN Decreases the temperature or adjusts the screen selection down
when setting advanced programming features
e. SLEEP Activates heating and cooling settings for the sleep program
period
f. DONE Saves settings
g. AWAY Activates heating and cooling settings for the away program
period
h, FEATURES Provides access to advanced options
i. HOME Activates heating and cooling settings for the home program
period

ON-SCREEN INDICATORS
© ©
features done

ON-SCREEN INDICATORS
1. Programming option: indicates which settings are being adjusted
2. Fan mode - on or auto
3. Filter, UV lamp, humidifier pad reminders
4. Indicates whether setting humidify or dehumidify preferences
5. System is in auxiliary (supplemental) mode
6. Heating set point
7. Current system mode - heating, cooling, emergency heat, heat/cool (auto),
off
8. Current temperature
9. Indicates humidify or dehumidify settings
10. Fahrenheit or Celsius
11. Keypad is locked (no padlock means unlocked)
12. Selected cooling set point: cooling on
13. Outdoor temperature: also displays other information during programming

QUICK START
Setting or changing the temperatures for heating and cooling
Your thermostat is installed with pre-set heating and cooling temperature settings,
You can use these or change them so your home is as warm or as cool as you would
like it to be, These steps will hold the temperature where you set it until you make
another change,
1, Open the door, You will see the word heat or cool on the
screen next to the pre-set temperature, depending on the o •
mode your system is in. (If the thermostat is in "auto"
mode, you will see both the heating and cooling set o o
points. If it's the first time you've used the thermostat, the
mode will say heat.).
2. To change the displayed temperature, press the up or o o
down button located on the right side until you reach the
desired setting, o o
3. To change the other temperature setting, press the mode
button on the left. The screen will display the word cool
or heat and the pre-set temperature.
4. Press the up or down button to change the displayed setting. Stop on the
desired setting.
5. Close the door.

QUICK START
Understanding Touch 'N' Go
The unique Touch 'N' Go feature on your thermostat is a revolutionary tool that lets
you use asimpler programming option - literally, touch and go -tohelp you get
the maximum comfort control from the entire comfort system.
With the touch of one Touch 'N' Go button - home. away or o o
sleep - you can tell your thermostat where you'll be. It's the
ideal solution for somebody who prefers different comfort o ©
settings for different times of the day.
The three Touch 'N' Go buttons are preset at the factory for typical heating and
cooling temperature settings. You can change these temperature settings easily.

OPERATING THE THERMOSTAT
Using the Touch 'N' Go feature
The Touch 'N' Go feature on your thermostat involves the homo, away and sloop
buttons immediately under the display. You can either accept the preset temperature
settings for when you are home, away or asleep, or set your own Touch 'N' Go
heating and cooling temperature settings. And, because these buttons and their
comfort settings aren't linked to specific times of the day, you are free to use any
button and its settings whenever it suits your lifestyle needs. Just touch the button
you want to use when you are away from home, return, or go to sleep. It's easier
than manually re-setting the temperature several times a day.
Here are the temperature settings that are pre-set for your homo, away and sloop
buttons.
Home
Away
Sleep
68 74
60 85
66 78

OPERATING THE THERMOSTAT
Use this blank grid to determine how warm or cool you want your home to be when
you're home. away or asleep.
Home
Away
Sleep

OPERATING THE THERMOSTAT
Setting the home temperature
1. Open the door.
2. Press the home button located under the display on the o_------_o
left. You will see a triangle icon (V) above the home o_jo
button. This icon will always tell you whether you're in
the home, away or sleep setting, o o
3. You will see the heating and cooling temperatures that e_ °
were set at the factory. To use these, just close the door. o[___Io4. To change the heating setting, press the mode button on
the left until you see the word heat on the screen on the o o
left.
5. Press the up or down button until you reach the desired
temperature setting. The arrow pointing to the home oil tle
button will disappear, o_ •
6. Press and hold the home button for about three seconds, o o
The home arrow will be displayed, indicating that the
thermostat has saved your settings.
7. To change the cooling temperature setting, press the
mode button repeatedly until you see the word cool on
the screen on the right.

OPERATING THE THERMOSTAT
8. Press the up or down button until you reach the desired
temperature setting.
9. Press and hold the home button for about three seconds. The home arrow
will be displayed, indicating that the thermostat has saved your settings.

OPERATING THE THERMOSTAT
Setting the away temperature
1. Press the away button located under the display in the ot_to
center. You will see a triangle icon (V) above the away o_o
button. o o
2. You will see the heating and cooling temperatures that
were set at the factory. To use these, just close the door.
3. To change the heating settings, press the mode button
until you see the word heat on the screen on the left.
4. Press the up or down button on the right until you reach o_-------_o
the desired temperature setting. The arrow pointing to o_o
the away button will disappear.
5. Press and hold the away button for about three seconds, o o
The away arrow will be displayed, indicating that the
thermostat has saved your settings.
o_ •
6. To change the cooling temperature setting, press the o •
mode button repeatedly until you see the word cool on
the screen on the right, o o

OPERATING THE THERMOSTAT
7. Press the up or down button until you reach the desired temperature set-
ting.
8. Press and hold the away button for about three seconds. The away arrow
will be displayed, indicating that the thermostat has saved your settings.

OPERATING THE THERMOSTAT
Setting the sleep temperature
1. Press the sleep button located under the display in the ot_Io
center. You will see a triangle icon (V) above the sleep o_jo
button. o o
2. You will see the heating and cooling temperatures that
were set at the factory. To use these, just close the door.
3. To change the heating setting, press the mode button
until you see the word heat on the screen on the left.
4. Press the up or down button on the right until you reach e_--------]o
the desired temperature setting. The arrow pointing to o_o
the away button will disappear.
5. Press and hold the sleep button for about three seconds, o o
The sleep arrow will be displayed, indicating that the
thermostat has saved your settings.
o_ o
6. To change the cooling temperature setting, press the o •
mode button repeatedly until you see the word cool on
the screen on the right, o o

OPERATING THE THERMOSTAT
7. Press the up or down button until you reach the desired temperature set-
ting.
8. Press and hold the sleep button for about three seconds. The sleep arrow
will be displayed, indicating that the thermostat has saved your settings.
9. Close the door.
