Carson CSF262W User manual
595 x 530 x 840(mm)
1700W
220-240V�
32Kg
6.0Kg
(D clothes)
50Hz
USE AND CARE GUIDE
MODEL NO. : CSF262W
Safety
Blank page
Contents
Safety Inrmation
3
Safety Inrmation
4
When using electrical appliances, in order to reduce the risk of fire, electric shock, and/
or injury to persons, basic safety precautions should always be followed.
Read all instructions carefully, even if you are quite familiar with the appliance.
•Do not attempt to repair, disassemble or
modify this appliance. The warranty will be
void if not serviced or repaired by a
authorised person.
•Do not excessively bend, stretch, twist or
bind the electrical cord or place heavy
objects on it.
•This appliance is to be serviced by a
qualified persons only. There are no user-
serviceable parts inside.
•Do not use an extension cord with this
appliance.
•Do not install the appliance in a close fitting
cabinet.
Do not overload the appliance.
•The door window may be hot after a drying
cycle. Ensure children are kept away from
the appliance.
•If the appliance is not wall mounted, place it
on a flat, firm and level surface. If
required, use the adjustable front feet to
assist in leveling the appliance. Do not
place the appliance on any soft material
such as foam or plastic.
•Do not use flammable or combustible
materials such as gas, petrol, alcohol or
lacquer in the appliance.
•After switching the appliance OFF, wait at
least 2 minutes before switching ON again.
•Remove all transport packaging prior to
using the appliance.
•If the electrical cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order
to avoid a hazard.
•This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
•Young children should be supervised to
ensure that they do not play with the
appliance.
•INDOOR USE ONLY - this appliance is not
intended for outdoor use.
•Do not place naked flame sources, such as
candles, on the appliance.
•Do not locate the appliance or electrical cord
near heat sources such as radiators,
heaters, air ducts or direct sunlight.
•Do not block any of the ventilation openings.
Ensure that vents are not covered or
obstructed in any way, etc.
•Do not run the electrical cord under floor
coverings. Ensure that it is not a trip hazard.
•To disconnect the appliance, switch the
appliance OFF, switch OFF power at the
electrical outlet, then remove the plug from
the power outlet.
•Do not misuse the electrical cord. Never
carry or move the appliance by the cord, or
pull the cord to disconnect it from the
electrical outlet. Always use the plug to
disconnect.
•Do not operate the appliance if it has a
damaged cord or plug; if the appliance
malfunctions; or has bean dropped or
damaged in any way.
WARNING: Risk of fire/
flammable materials
Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a clothes dryer. The items
become warm, causing an oxidation reaction in the oil.
Oxidation creates heat. If the heat cannot escape, the items
can become hot enough to catch fire.
•If it is unavoidable that fabrics that are contaminated with flammable substances (for
example, oils, solvents, petrol etc) be placed in the appliance, they should first be
washed in hot water with extra detergent - this will reduce, but not eliminate, the hazard.
•Do not dry unwashed items.
•Fabric softeners, or similar products, should be used in accordance with the
manufacturer's instructions.
•Items such as foam rubber (latex), plastic, rubber backed articles, and clothes or pillows
containing foam rubber should not be dried in a clothes dryer.
•The final part of the drying cycle does not use heat (cool down cycle) to ensure that
the items are at a comfortable handling temperature when removed.
•WARNING: Never stop the appliance before the end of the drying cycle. If it is
necessary to do so, remove all items quickly and spread them out so that the heat
dissipates.
•Remove all objects from pockets such as paper, coins etc.
•The appliance should not be used if industrial chemicals have been used for cleaning the
clothes.
•The lint filters must be cleaned after every use.
•Do not allow lint to accumulate around the appliance.
•Adequate ventilation must be provided when the appliance is in use.
•Ensure that carpet or other soft floor coverings does not obstruct any ventilation
openings in the base of the appliance.
•Exhausted air from the appliance must not be discharged into a flue that is used for
exhausting fumes from appliances burning gas or other fuels.
Correct disposal of this product:
This marking indicates that this product should not be disposed of with household
waste. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the sustainable
reuse of material resources.
Save These Instructions
Safety
1
6
Installation before use
�
Notices:
5
+
Do not attempt to dry extremely wet
clothing
-
allow to drip dry etc before
completing the drying process using
the dryer.
(
)
area that has adequate space around
the dryer.
pao�
6
Components Pre-Installation Check List
Power Source and Grounding
The appliance requires a properly grounded 240VAC / 50Hz mains electrical
supply. If you are in any doubt about the electrical supply or grounding, contact a
qualified electrician for assistance.
+
+
>)_,4
L /
D B D
7
Simple Installation
Step 1:
The dryer should be placed in a well-ventilated area with
no less than 10cm distance to any wall from the rear,
sides and top of the appliance. It is recommended that
there are no obstacles within 1.5m of the front of dryer.
Step 2:
Ensure that the appliance is level. If it is not
level (or within approximately 2° of level), it may
vibrate excessively which may lead to faults or
appliance damage.
>IOcm
Notice:
•Do NOT install the dryer in the open or places easily exposed to water.
•Do NOT place the rear of dryer near curtains or other obstacles.
•Do NOT place the dryer near gas, fuel or flammable materials.
8
+
Unsuitable Fabrics - Prior to loading the dryer, check that items do not have the
following symbols anywhere on them. If they do, do not tumble dry these items.
Installation
Operation explanation
n
H
n n
n H
Max d
time
11
Operation explanation 0
n n nn
12
y
P
Troubleshooting
Step 2: Turn the dryer over so it is upside-down. Insert the plastic
supports into the holes in the rear panel, and rotate them 90° to lock
them in position.
Wall mounting slots
1
5
Step 3: Carefully raise the dryer and position it so the bracket
hooks enter the slots in the rear of the dryer. Gently lower the
dryer so it is supported by the brackets and the plastic
supports are resting against the wall.
Step 4: Replace the panel sticker with the supplied inverted sticker.
1
6
Wall Mounting
Step 1: Fix the 2 mounting brackets to the wall using suitable
fasteners (not supplied). The brackets must be mounted at the
same height (that is, they must be level), and the distance
between the brackets hooks must be 544mm.
CAUTION: The wall must be of sufficient strength to support the
dryer weight. The dryer weighs in excess of 30kg - 2 or more
persons are required to wall mount it.
