Casablanca Seacoast User manual

1

INTRODUCTION

Before You Start 2

Safe Use 2

MOUNTING RECOMMENDATIONS

General Guidelines

.........................................................................................................................................................

3

Sloped Ceiling Installations

............................................................................................................................................

3

FAN INSTALLATION

Getting Started

...............................................................................................................................................................

4

Crossbar Mounting Bracket Installation

.........................................................................................................................

4

Lag Screw Installation

....................................................................................................................................................

5

Canopy Installation

.........................................................................................................................................................

5

Fan Preparation

...............................................................................................................................................................

6

Blade Installation

............................................................................................................................................................

7

Switch Housing Bracket / Cap Installation

....................................................................................................................

8

Hanging the Fan

.............................................................................................................................................................

9

Canopy Electrical Connections

.......................................................................................................................................

8

Canopy Hatch Installation

..............................................................................................................................................

8

VERSA

•

TOUCH2™ CONTROL

Control Bracket Installation

..........................................................................................................................................

10

Remote Operation

.........................................................................................................................................................

11

Changing Transmitter Frequency Setting

.....................................................................................................................

Changing Transmitter Frequency Setting ..................................................................................................................... Changing Transmitter Frequency Setting

11

TROUBLESHOOTING TIPS

..........................................................................................................................................

12

CARE RECOMMENDATIONS

......................................................................................................................................

13

AUTHORIZED SERVICE CENTERS

...........................................................................................................................

14

PRODUCT SPECIFICATIONS

.......................................................................................................................................

16

ASSEMBLY DIAGRAM

...................................................................................................................................................

17

READ AND SAVE THESE INSTRUCTIONS!

SAFETY FIRST: Safety and the proper operation of your Casablanca fan both require a thorough knowledge of the product

and proper installation.  erefore, before attempting to install and operate your Casablanca fan, read this Owner’s Manual

completely and carefully. Retain the manual for future reference

C343010 AA1005

Before You Start 2

Safe Use 2

CONTENTS

OWNER’S MANUAL

2

CIRCUIT BREAKER

Trip the breaker for

the circuit you will

be working on

FUSE BOX

Remove the fuse for

the circuit you will

be working on

SAFE USE

• Inspect the contents of your carton for possible shipping

or handling damage and report any such damage directly

to your authorized Casablanca dealer.

• It is always a good idea to have an assistant to help with

the installation.

•  e blades in each pack are matched for equal weight

to assure smooth fan operation. If more than one fan is

being installed, be careful not to mix blades from diﬀ erent

cartons.

• Never install a fan over a pool or spa.

• For safety reasons, the fan blades must be a minimum of

7 feet above the ﬂ oor.

• In any installation, the tips of the blades must be at least 18

inches from the wall in order to provide suﬃ cient clearance

for the blades.

• Never insert anything into the path of the fan blades while

the fan is in operation.

• When cleaning, painting, or working near your fan, be

very careful of the fan and blades. Always turn the power

OFF to the ceiling fan before servicing it, working on it,

or replacing lightbulbs.

• Never operate a fan that has been damaged in any way.

For assistance in obtaining service, call Casablanca Fan

Company toll-free at 1-888-335-5247 or contact your

local Casablanca Authorized Dealer.

BEFORE YOU START

•

CAUTION: Risk of electrical shock!

All wiring must be in accordance with the National Electric Codes and the appropriate

local electrical codes.  e National Codes require proper grounding as a precaution against electrical shock. A qualiﬁ ed

electrician should be consulted if you are unsure.

•  is fan is designed to be installed on an existing electrical outlet box.  e outlet box must be UL Listed for ceiling fan

installations, if it is not, a new box must be installed. Casablanca extension poles are available for sloped or high ceiling

installations.

•

 is ceiling fan requires a grounded electrical supply of 120 VAC, 60 Hz and a minimum 15 amp circuit.  e maximum

current requirement for the fan with light ﬁ xture is 3.8 amps.  e fan uses about 1 amp or 100 watts. Maximum light

current is 2.8 amps or 340 watts of lighting.

•

Where wire nuts are employed, be sure all bare wires are within the connectors. When installing the canopy hatch, make

sure all wires are within the canopy and that no wires are being pinched.

Unpacking

Before assembling and installing your ceiling fan, remove all parts from the shipping cartons and check them against the parts

listed in the Parts List. Before discarding packaging material, be certain that all parts have been removed.

NOTE: For best performance and for your warranty to be valid, use only genuine Casablanca Fan Company blades, light

ﬁ xtures, and accessories.

INTRODUCTION

18

ʺ

84

ʺ

3

Ceiling Height Pole Length

8

ʹ 0

”

standard

8

ʹ

6

”

standard

9

ʹ

0

”

6

”

9

ʹ

6

”

12

”

10

ʹ

0

”

12

”

11

ʹ

0

”

18

”

12

ʹ

0

”

24

”

13

ʹ

0

”

36

”

14

ʹ

0

”

48

”

Before mounting your Casablanca fan, read the following helpful recommendations.  e location of the fan, air circulation,

and fan size are all important factors to consider before installation.

Location

Ceiling fans have practical uses in almost every room in your home. We suggest you follow these mounting recommendations

as you decide where to install your Casablanca fan.

7

’

minimum

SUGGESTED EXTENSION POLE LENGTHS

When to Use Extension Poles

For best performance and appearance, an extension pole

should be used with your Casablanca fan when installing on

high (cathedral) ceilings or sloped ceilings. Casablanca oﬀ ers

standard poles in increments of 6 inches up to 5 feet. Custom

poles are available in lengths up to 9 feet 9 inches. See your

Authorized Casablanca Dealer for details.

NOTE:

 e fan may wobble or vibrate if the pole length

is not long enough and the inside blade is too close to the

downslope or side wall. Extending the pole length usually

will solve the problem.

Calculation of 32 Degrees

Use the tear-oﬀ Ceiling Angle Template card inserted in

this manual. It provides you with a simple “go” or “no go” for

installing your fan on a sloped ceiling.

Blades must be a

minimum of 7

ʹ

above the ﬂ oor

Extension

Pole

Maximum Angle 32º

This slope is less than 32 degrees.

It is okay to install your fan.

SLOPED CEILING INSTALLATIONS

MOUNTING RECOMMENDATIONS

•  is fan requires a minimum ceiling height of 9 feet.

• Do not locate the fan in a doorway or above a swinging door.

• In bedrooms, fans work best when mounted above the foot of the bed.

• Over pool tables, be sure to provide plenty of clearance to avoid damage from pool cues.

• In kitchens, be sure to allow for open cupboard doors to clear the fan blades.

• Do not install a fan close to, or over, a pool or spa. High humidity combined with corrosive gases will destroy the ﬁ nish

and warp the blades.

Fan Size

Variable fan speed capability permits the use of a full-size 54-inch fan even in smaller rooms. For very large rooms, two fans

may be needed.

Ceiling Height Pole Length

EXAMPLE

1

EXAMPLE

2

EXAMPLE

3

This slope is more than 32 degrees.Your

fan will not hang straight down; an adaptor

is necessary. Contact your local Authorized

Casablanca Dealer to purchase a “Sloped

Ceiling Adaptor.”

This slope is 32 degrees, the maximum

slope that will allow the fan to hang

straight down. It is okay to install

your fan.

GENERAL GUIDELINES

GETTING STARTED

Installing a New Ceiling Fixture Outlet Box

If you do not have an existing ﬁ xture located where you wish

to place your Casablanca fan, an approved ceiling ﬁ xture

outlet box must be installed and wired.

Using Existing Ceiling Fixture Outlet Box

After turning the power OFF at its source (either the circuit

breaker or fuse box), lower the old ﬁ xture and disconnect the

wiring. Check the ceiling ﬁ xture outlet box to be sure that

it is marked “Approved For Ceiling Fan Mounting.” If it is

not, a new box must be installed.

NOTE:  e weight of this fan is 50 pounds.

Wire Nut (4)

ADDITIONAL HARDWARE

2

1

/4

”

x 8-32 Rounded Head Screw (2)

Flat Washer (2)

1

”

x 8-32 Rounded

Head Screw (2)

Large Flat Washer

3

/

8

”

(1)

Crossbar Mounting Bracket

Lag Screw

3

/

8

”

#7 x 5

”

(1)

Joist

Ceiling

Wiring

Crossbar Mounting

Bracket

Green Ground Wire

Ceiling-Fan-Approved

Wiring Box

Ridge side down

NOTE:

After removing the old ﬁ xture, check the outlet box

to ensure it is supported by a joist or beam across its upper

surface. If not, a 2 x 4 stud must be installed.

Step 1a.

Remove the knockout plug in the center of the

outlet box or drill a

1

/

2

-inch hole for the lag screw to pass

through.  en drill a

1

/

4

-inch guide hole into the joist or

beam to a depth of 3 inches.

Step 1b.

Route the outlet box wires through the center

hole of the crossbar mounting bracket. Attach the crossbar

mounting bracket to the outlet box with the screws provided,

ensuring that the outlet box wires are not pinched by the

washer.

CROSSBAR MOUNTING BRACKET INSTALLATION

CEILING HARDWARE

(not to scale)

4

FAN INSTALLATION

APPROVED OUTLET BOX

HARDWARE

CAUTION: To reduce the risk of personal injury,

use only the mounting hardware provided with the

approved outlet box to install the crossbar mounting

bracket.

WARNING: To reduce the risk of fire, electrical

shock, or personal injury, mount to outlet box marked

“Acceptable for Ceiling Fan Support” using the

mounting hardware provided with the outlet box.

WARNING!

Support directly to building structure only.

Step 3.

Attach the canopy to the crossbar mounting bracket

with three of the 8-32 x 2

1

/

1/

1

2

"

long canopy screws and lock

washers provided with your Casablanca fan. Tighten using the

provided screwdriver until snug against the ceiling.

NOTE:

On sloped ceilings, align the canopy opening with

the top or peak of the room.

Canopy Screws

Canopy

Lock Washers

Feed outlet box wires

through canopy opening

Canopy Lock Washer (4)

Canopy Screw (4)

NOTE:

We recommend that the ceiling box be of suﬃ cient

capacity to support the weight of the fan and light ﬁ xture

under any conditions.

Step 2.

With the large washer attached, pass the lag screw

through the center hole of the crossbar mounting bracket and

screw into guide hole. Tighten until outlet box is mounted

ﬁ rmly to beam.  is box must be secured to the ceiling

ﬁ rmly.

Lag Screw

Large Washer

Canopy Hatch

Canopy

LAG SCREW INSTALLATION

CANOPY INSTALLATION

CANOPY HARDWARE

(not to scale)

5

6

Step 4c.

Using the provided Allen wrench, loosen the set

screw several turns to allow installation of the downrod.

 read the downrod into the motor coupling until it stops

turning.  is will take at least four and a half full turns.

Step 4d.

Tighten the set screw securely with the provided

Allen wrench to ensure safe operation of your fan.

Step 4e.

Slide the motor cover down so that it is ﬂ ush against

the top of the fan.

Step 4f.

Using the three provided screws, attach the motor

cover to the motor. Tighten securely with the provided

Phillips screwdriver.

IMPORTANT SAFETY INFORMATION!

Before starting the installation of your ceiling fan, install the threaded

downrod into the motor coupling and lock the assembly

Prepare for fan installation as follows:

Step 4a.

Place the motor cover on the downrod as shown.

Step 4b.

Route the wires from the motor through the

Perma

•

Lock™ downrod and ball assembly.

Tip:  e downrod has a tapered thread that is designed

to lock completely when correctly installed.

CAUTION:

Failure to fully lock in the downrod

before securely tightening the Allen set screw may

cause the fan to separate from the downrod during

normal operation!

Motor

Cover

Motor Wires

Perma•Lock™ Downrod

and Ball Assembly

Motor Coupling

Tapered Thread

Allen Set Screw

FAN PREPARATION

Step 4g.

Unsnap one of the switch housing brackets on

the bottom of the switch housing and set it aside for use

in step 6c.

Step 4h.

To reach the blade holder mounting holes in the

fan motor, the switch housing cap must be removed. Take

out the two 8-32

3

/

8

" screws securing the switch housing cap

and set them aside for use in step 6c.

Mount Screws

8-32 X

3

/

8

"

(2)

Switch

Housing

Cap

Switch

Housing

Bracket

7

Blade Screw and

Washer

Blade

Holder

Blade Holder

Screw

(2 per blade)

Step 5a.

Remove the five shipping blocks attached to

the rotating motor plate using the provided Phillips

screwdriver.

Step 5b.

Attach each blade to a blade holder by first

pressing the blade badge into the blade, then threading four

blade screws into the screwholes and tightening using the

screwdriver.

Repeat for each blade assembly.

Blade Screw

and Washers

(4 per blade)

Blade

BLADE INSTALLATION

Step 5c.

Attach each blade/bladeholder assembly to the motor

by threading two blade holder screws through the matching

holes in the blade holder and the motor. Using the screwdriver,

tighten the screws loosely.

After all ﬁ ve blade assemblies have been installed, tighten the

screws securely using the screwdriver.

Blade Holder Screws

(2 per blade)

Blade

Holder

BLADE HARDWARE

(not to scale)

8

Step 6b.

Line up the two clearance holes in the cap with the

two threaded holes on the raised rim of the switch housing.

Press the cap onto the switch housing to seat the guide pins

into the alignment holes of the switch housing.

Step 6c.

Using the two 8-32

3

/

8

ʺ

screws removed in Step 4h,

install the cap onto the switch housing. Tighten the screws

securely using the Phillips screwdriver.

NOTE:

If you have purchased an accessory light ﬁ xture for

this fan, please refer to the instructions included with the

light ﬁ xture. If not, continue with Step 6b.

Switch Housing

Mount Screw

(Removed in Step 10)

8-32 X

3

/

8

(2)

Switch Housing Cap

SWITCH HOUSING BRACKET/ CAP INSTALLATION

Switch Housing Bracket

(2)

Step 6a.

Take the two switch housing bracket you removed

in step 4g and snap it into the holes in the switch housing.

 is is to prevent any wires getting pushed down near the

motor. Make sure no wires are in the way or pinched in these

SWITCH HOUSING BRACKET/CAP HARDWARE

(not to scale)

9

Canopy Washer

Canopy Screw

Canopy Hatch

Step 9a.

Tuck the wires into the canopy

with the wire nuts pointed upwards so

that the WHITE and BLACK wires are

on opposite sides of the canopy and all

wires are clear of the canopy opening.

Step 9b.

Install the canopy hatch with the

last canopy screw and lock washer using

the provided Phillips screwdriver. To do

this, tilt the fan body away from the hatch

opening. Tighten the screws ﬁ rmly.

Step 9c.

Straighten the fan, then check

to ensure that there is no movement

between the canopy and the ceiling or

the Perma•Lock™ downrod and the ball

assembly.

CANOPY HATCH INSTALLATION

Step 8

. Attach the fan wires to the ceiling ﬁ xture outlet box

wiring by placing the bare ends of the wires side by side and

then securing with a wire nut. Test that the connection is

secure by pulling on the wire nut. Connect in this order:

• GREEN leads from mounting plate and downrod assembly

of fan to GROUND conductor of power source. Secure

with wire nut.

• WHITE wire from fan to white NEUTRAL wire in

ceiling ﬁ xture outlet box. Secure with wire nut.

• BLACK power wire from fan to BLACK power wire in

ceiling outlet box. Secure with wire nut

NOTE:

If the color of your ceiling wires diﬀ ers from that

described, consult an electrician.

2 White Wires

2 Black Wires

Wire Nut

3 Green Wires

Step 7a.

To hang the fan body in the canopy, hold the fan body

ﬁ rmly and insert the ball into the canopy opening. Check that

no wires were pinched. Rotate the fan body until the slot in

the ball ﬁ ts into the pin opposite the canopy opening.

Step 7b.

Trim excess motor wires, leaving at least 6 inches

above the downrod. Strip

1

/

2

-inch insulation from the end

of each wire using a wire stripper (available at your local

hardware store).

Slot

Ball

HANGING THE FAN

CANOPY ELECTRICAL CONNECTIONS

Tilt away from

hatch opening

10

SAFETY FIRST: To reduce the risk of electrical shock, this fan must be installed with an isolating

wall control/switch.

SAFETY FIRST: To reduce the risk of electrical shock, this fan must be installed with an isolating

wall control/switch.

SAFETY FIRST: To reduce the risk of electrical shock, this fan must be installed with an isolating

Screw

6-32 X 1"

(2)

Screw

6-32 X

3

/

8

"

(2)

Wood

Screw

1" (2)

Drywall

Anchor

6-32 (2)

12v Battery

W-73

Control

Holder

Standard Light Switch

Step a.

Remove the two screws holding the switch cover plate.

Do not remove the cover plate.

Step b.

Orient the control bracket as shown and line up the

two inner mounting holes with those on the switch.

Step C. Install and tighten screws using the provided Phillips

screwdriver.

Inner

Mounting

Holes

Control Bracket

Standard

Toggle

Switch

Cover

Plate

Outer

Mounting

Holes

Control

Bracket

Rocker

Type

Light

Switch

Cover

Plate

Wall Installation

Step a.

Locate a 2x4 wall stud

in a convenient location.

Step b.

Orient the control

bracket as shown over the

2x4 stud.

Step C. Use the 1" wood

screws in either the inner

or outer mounting holes.

Install and tighten screws

using the provided Phillips

screwdriver.

Decor Ovalhead Screw

6-32 X 1"

Anchor

Panhead

Screw

Drywall Anchor

NOTE:

 e wall anchors and 6-32 x 1" screws may

be used in situations where mounting to a stud is not

possible. Use the inner mounting holes. After securing

the anchor, discard the anchor’s pointed screws and use

the 6-32 decor ovalhead screws supplied.

CAUTION! Do not use with wall dimmer.

Wood

Screw 1"

CONTROL BRACKET INSTALLATION

W-73

Tabs

VERSA•TOUCH2™ INSTALLATION

VERSA•TOUCH2™ INSTALLATION HARDWARE

(not to scale)

Rocker Light Switch

Step A. Break oﬀ the two tabs by pushing outward.

Step B. Remove the two screws holding the switch cover

plate. Do not remove the cover plate.

Step C. Orient the control bracket as shown and line up the

two inner mounting holes with those on the switch.

Step D. Install and tighten screws removed in Step B by

hand

only.

Casablanca Seacoast User manual

Popular Fan manuals by other brands
