CASABREWS CM5418BC-UL User manual

HOUSEHOLD USE ONLY
Please read all instructions carefully before using the product
[email protected]
INSTRUCTION MANUAL
Espresso Coee Machine
Model: CM󾋼󾋻󾋸󾋿BC-UL

Contents
IMPORTANT SAFEGUARDS ..................................................................................................... 
SAVE THESE INSTRUCTIONS ..................................................................................................... 
SPECIFICATION: ........................................................................................................................... 
KNOW YOUR COFFEE MAKER ................................................................................................... 
BEFORE THE FIRST USE ............................................................................................................... 
MAKING ESPRESSO .................................................................................................................. 
MAKING HOT WATER .................................................................................................................. 
FROTHING MILK/ MAKING CAPPUCCINO .......................................................................... 
PROGRAMMING THE CUP SIZE ................................................................................................. 
AUTO SHUT OFF FUNCTION ...................................................................................................... 
CLEANING AND MAINTENANCE ........................................................................................... 
DESCALING THE APPLIANCE .................................................................................................... 
TROUBLESHOOTING ........................................................................................................... 

Before using this appliance, please ensure to follow these basic precautions:
01. Read all instructions and keep them for future reference.
02. Before using the appliance, check that the voltage of the wall outlet corresponds to the voltage marked on the
rating plate.
03. This appliance is supplied with a grounded plug.
04. To protect against fire, electric shock, and injury do not immerse the power cord or plug in water or other liquids.
05. Remove the plug from the wall outlet before cleaning and when not in use. Allow the appliance to cool down
completely before removing or attaching components, or before cleaning.
06. Do not operate any appliance with a damaged power cord or plug, after the appliance has malfunctioned, or is
dropped or damaged in any way. Take the appliance to the nearest authorized service facility for examination,
repairs or adjustments.
07. The use of accessory attachments not recommended by the appliance manufacturer may result in fire, electric
shock or injury.
08. Place the appliance on a flat surface or table. Do not hang the power cord over the edge of the table or counter.
09. Ensure the power cord does not touch the hot surface of the appliance.
10. Do not place the coee maker on a hot surface or next to an open flame.
11. To disconnect the appliance, turn it OFF, then remove the plug from wall outlet. Always hold by the plug, never pull
on the cord.
12. Do not use the appliance other than for the intended use.
13. Always supervise closely when the appliance is used by or near children.
14. Take care when using the appliance, as steam may escape and pose a risk of getting scalded.
IMPORTANT SAFEGUARDS
[email protected] | 1

2 | [email protected]
15. Do not touch any hot surface of the appliance (including the steam wand and the steel mesh). Only use the handle
or knobs.
16. Do not let the coee maker operate without water.
17. Removing the water tank during the brewing cycle poses a risk of getting scalded.
18. Do not remove the filter holder when in use or when steam or hot water escape from the holder.
19. Release pressure through the steam wand before removing the water tank cover or filter holder.
20. This appliance is not intended for use by children or any individuals with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given adequate instruction concerning
the use of the appliance and/or are under supervision by a responsible adult.
21. Children should be supervised to ensure that they do not play with the appliance.
22. This appliance is intended to be used in household and similar applications
such as:
– sta kitchen areas in shops, oces and other working environments;
– farm houses;
– bed and breakfast type environments.
Do notuse outdoors.
Do notplace on or near a hot gas or electric burner, or in a heated oven.

Model: CM󾋼󾋻󾋸󾋿BC-UL
Voltage: 󾋸󾋹󾋷V~ 󾋽󾋷Hz
Power: 󾋸󾋺󾋼󾋷W
Capacity of Water Tank: 󾋺󾋻OZ
Accessories: 󾋸Single Filter, 󾋸Double Filter, 󾋸Portfilter, 󾋸Coee Spoon
SPECIFICATION:
NOTE REGARDING THE PLUG
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is
intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.
NOTE REGARDING THE CORD
a ) A short power supply cord (or detachable power supply cord) is provided in order to reduce the risk of becoming
entangled in or tripping over a longer cord.
b ) Longer detachable power supply cords or extension cords are available and may be used if care is exercised in their
use.
c ) If a longer detachable power supply cord or extension cord is used, please note the following:
( 1 ) The marked electrical rating of the detachable power supply cord or extension cord should be at least as great
as the electrical rating of the appliance;
( 2 ) The cord should be arranged so that it will not drape over the counter top or table top where children can pull
on it, or people could trip over it;
( 3 ) If the appliance is of the grounded type, the cord or extension cord should be a grounding-type 󾋺-wire cord.
SAVE THESE INSTRUCTIONS
[email protected] | 3

(Product may be subject to change without prior notice)
KNOW YOUR COFFEE MAKER
Water Tank Cover
Handle
Water tank
Knob
Steam handle
Steam wand
Power Button/Indicator
Single Espresso Button/Indicator
Brewing filter
Filter Holder
Portafilter
Drip plate
Drip tray
Measuring spoon
Double Espresso Button/Indicator
Steam Button/Indicator
4 | [email protected]

01. Remove the portafilter by turning it clockwise. Place the brewing filter into filter holder, making sure it fits properly.
02. Using the measuring spoon, add ground coee to the brewing filter (a spoonful of ground coee will make about
one cup of top-grade coee) then tamp the ground coee down tightly with the measuring spoon.
03. Align the portafilter with the “LOCK” mark and turn it counter-clockwise to the “CLOSE” position.
04. Place a cup on the drip plate.
05. Select single cup (“󾋸CUP”) or double cup (“󾋹CUP”). The brewing will begin shortly.
MAKING ESPRESSO
To ensure the first cup of coee tastes excellent, please prepare the coee maker as follows:
01. Remove the plug at the bottom of the tank.
02. Fill the water tank. Do not exceed the “MAX” mark. Close the tank cover.
03. Place the brewing filter without any ground coee into the filter holder.
04. Place a cup/mug on the drip plate. Make sure the knob is in the horizontal (o) position.
05. Connect the appliance to a power source, press the “ON/OFF” button. The power indicator will be illuminated and
all indicators will briefly flash.
06. The appliance will start to pre-heat. When the indicators stop flashing, the pre-heating process is finished. Press
the “󾋹CUP” button and wait for a moment; the brewing cycle will begin and water will flow out.
07. When the appliance stops pumping water, the process is complete. Discard the used water.
BEFORE THE FIRST USE
[email protected] | 5
NOTE:
There may be a noise when the appliance pumps the water out the first time. This is normal, the
appliance is releasing some air in the system. After about 󾋹󾋷s, the noise should stop.

Cappuccino is made by preparing a single espresso, and adding hot frothing milk. Traditionally, it should be made up of
󾋸⁄󾋺espresso, 󾋸⁄󾋺steamed milk and 󾋸⁄󾋺milk foam.
NOTE:
A jug with a diameter minimum 󾋾󾋷󾋾󾋼mm is recommended. Please bear in mind that the milk
doubles in volume, so make sure the jug has sucient height.
When using the steamer, the portafilter must be assembled in position.
NOTE:
FROTHING MILK/ MAKING CAPPUCCINO
Before frothing the milk, release steam for 10 seconds.
Method:
01. Press the “STEAM” button - the steam indicator light will flash. When the steam indicator light is continuously lit,
the pre-heating is finished.
02. Prepare espresso first.
03. When the espresso is ready, fill a jug with about 100ml/󾋺󾋻fl.oz of milk per cappuccino to be prepared. Using cold,
whole milk is recommended.
07. To remove the filter after brewing, turn the portafilter clockwise.
WARNING Do not leave the coee maker unattended during brewing.
6 | [email protected]
06. The appliance will stop automatically once the brewing process is finished.
Place a cup or mug under the steam wand. Turn the knob to “ ” position and hot water will dispense from the steam
wand. Turn knob to “o” when done.
MAKING HOT WATER

[email protected] | 7
NOTE:
After using the steam wand, you can press the “Single cup” or “Double cup” button immediately to
brew coee again, provided that you have added fresh coee grounds to the filter.
The coee indicator will flash quickly if the temperature is too high. If this happens, you need to turn the knob to the “Hot
water” setting “ ”, so that hot water will dispense in order to bring the temperature down. When the temperature goes
down, the pump will stop automatically. Turn the knob to “o”, then you can brew coee again.
NOTE:
Clean the steam nozzle with a damp sponge or cloth immediately after use, but do so carefully as the
wand will be hot!
WARNING Take care when operating the steam wand. Steam may result in burns or injury.
If you do not want to brew coee when the high-temperature warning occurs, you can press the “Single cup” or “Double
cup” button again to cancel.
06. Pour the frothy milk into the prepared espresso. The cappuccino is now ready. Sweeten to taste and if desired,
sprinkle the froth with a little cocoa powder.
The steam wand can be used to froth milk, dispense hot water, or make hot chocolate.
05. Turn knob to “o”.
04. Insert the steam wand about two millimetre into the milk, then turn the knob to the “ ” position. Steam will
come out from the steam outlet. Froth the milk by moving the jug up and down.

Turn the knob to OFF and allow the coee maker to cool down completely before cleaning.
Regularly clean the casing of the coee maker with a damp sponge, then clean the water tank, drip tray and drip plate and
dry them.
CLEANING AND MAINTENANCE
8 | [email protected]
If no operation is selected after 󾋹󾌀 minutes of being powered on, the unit will power o automatically.
If no operation is selected after 󾋹󾋸󾋼ml󾋾󾋺fl.oz of water are pumped out, the pump will stop automatically.
If no operation is selected after 󾋸󾋿󾋷 seconds of frothing milk, the pump will stop automatically.
AUTO SHUT OFF FUNCTION
To make a single cup
Press the “Single cup” button. The coee will start to dispense and the “Single cup” indicator will flash at the same
time. When the desired amount is reached, press the “Single cup” button again and the coee will stop dispensing. You
have now programmed the coee maker to the size of a single cup as per your preferences, and this will be saved for
future use. The adjustable dispensing amount for a single cup ranges between 󾋹󾋼ml/󾋿󾋼fl.oz and 󾋽󾋷ml/󾋹fl.oz.
To make a double cup
Press the “Double cup” button. The coee will start to dispense and the “Double cup” indicator will flash at the
same time. When the desired amount is reached, press the “Double cup” button again and the coee will stop
dispensing. You have now programmed the coee maker to the size of a double cup as per your preferences, and this will
be saved for future use. The adjustable dispensing amount for a single cup ranges between 󾋾󾋷󾋹󾋻fl.oz and
󾋸󾋸󾋷ml/󾋺󾋾floz.
To restore factory setting
Simultaneously press and hold the “Single cup” or “Double cup” buttons for 󾋺seconds to restore to default
dispensing amounts.
PROGRAMMING THE CUP SIZE

Do not clean with alcohol or solvent cleanser. Never immerse the housing in water to clean.
NOTE:
Clean filter holder with cleanser or warm water.
Clean all the attachments and dry thoroughly.
[email protected] | 9
To make sure your coee maker operates eciently, to clean the internal pipes, and to preserve the flavor of your coee,
the coee machine needs to be descaled, cleaned and maintained periodically. After 󾋼󾋷󾋷 brew cycles, a descaling
warning will be shown. All indicator lights will flash 󾋼times to indicate it is time to descale the machine. The descaling
warning will appear at every time start-up if you do not cancel it.
01. Fill the water tank with water plus a descaling agent (󾋻parts water to 󾋸part descaling agent) to the MAX level.
Please also refer to the instructions on the descaling agent. Please use a household descaling agent, or you can use
citric acid instead of a commercial descaling agent – in this case use 󾋸󾋷󾋷 parts of water to three parts of citric acid.
02. Place a cup/mug or other suitable receptacle on the drip tray and press the “Double cup” button once to start the
brewing cycle. Allow the machine to drip about 󾋸󾋷󾋷ml/󾋺󾋻fl.oz of water into the cup. Then turn of the appliance
and
leave the descaling solution in the appliance for 󾋼minutes.
03. Turn on the appliance again and repeat the previous step three more times.
04. Next, repeat the process two more times using only CLEAN TAP WATER without any descaling agent.
05. After you have finished the descaling, you need to cancel the descaling warning: simultaneously press and hold the
“Single cup” button, “Double cup” button and “Steam” button for 󾋺seconds.
DESCALING THE APPLIANCE

TROUBLESHOOTING
Steam indicator light is blinking
rapidly. The knob was not reset after 180s of making steam. Reset the knob to the “o” position.
“Single cup” AND “Double cup”
indicator lights are blinking
rapidly.
The knob was not reset after
dispensing hot water or cooling
down.
Reset the knob to the “o” position.
The jug is too big or the shape is not
suitable.
You have used low fat or skim milk.
Use whole milk (󾋺󾋹󾋼%) or reduced fat (󾋹%) milk.
Use a tall and narrow jug.The frother is not working.
The white indicator light is not
illuminated. The steam wand can be used to froth only when the white indicator light is illuminated.
The coee maker suddenly
stops working. The power cord is not plugged in well. Plug the power cord into a wall outlet correctly. If the appliance still does not
work, please contact an authorized service
facility for repair.
Coee tastes acidic
(like vinegar).
Water leaks out of the side of
the filter. There are coee grounds on the filter edge.
Ground coee was stored in a hot,
wet place for a long time. Use fresh coee grounds, and ensure to store ground coee in a cool, dry place.
After opening a pack of coee, reseal it
tightly and store it in a refrigerator to
maintain its freshness.
Improper cleaning of mineral
deposits. Repeat the instructions on page 5 (“Before the first use”) several times.
Wipe the filter edge clean.
PROBLEM CAUSE SOLUTION
Water leaks from the bottom of
the coee maker.
The drip tray is full.
The coee maker is malfunctioning. Contact an authorized service facility for
repair.
Empty the drip tray.
10 | [email protected]

[email protected] | 11
ALL indicators flash 5 times
simultaneously.
“Single cup”, “Double cup” AND
“Steam” indicator lights are
blinking rapidly.
The machine is turned on, but the
knob was not reset.
The machine needs to be descaled. Follow the instructions on page 9
(“Descaling the appliance”).
Reset the knob to the “o” position.
“Single cup” OR “Double cup”
indicator light is blinking
rapidly.
Boiler temperature is too high. Turn the knob to “ ” position, perform
cooling operation.

󾋸󾋺󾋽󾋷 S Valley Vista Dr.,Suite󾋸󾋷󾋿
Diamond Bar, California 󾌀󾋸󾋾󾋽󾋼
United States of America
[e-mail]
www.casabrews.com
CASABREWS BRANDS INC.
Rev 󾋸󾋷
