CASE CONSTRUCTION CX55B User manual

PrintedinU.S.A.
Copyright © 2011 CNHAmerica LLC. All Rights Reserved.
CaseisaregisteredtrademarkofCNH America LLC.
Racine Wisconsin 53404 U.S.A.
Part number S5PS0002E01
English
October 2011
SERVICE MANUAL
CX55B
Tier 4
Crawler Excavator
from PIN PS02-00101 and above

SHOP
MANUAL model
INDEX
HYDRAULIC EXCAVATOR
SPECIFICATIONS
MAINTENANCE
SYSTEMDISASSEMBLING
TROUBLESHOOTING
E/GOPT.
1
2
3
4
5
6
7
SPECIFICATIONS SECTION
MAINTENANCE SECTION
SYSTEM SECTION
DISASSEMBLY SECTION
TROUBLESHOOTING
ENGINE SECTION
PROCEDURE OF INSTALLING
OPTIONS SECTION
Book Code No. S5PS0002E01
0-1
CX55B

0-2
GENERAL SAFETY INFORMATION
Do not operate or perform any maintenance on this
machine until all instructions found in the OPERA-
TOR’S MANUAL and this MANUAL have been thor-
oughly read and understood.
Improperoperationormaintenanceofthismachine
may cause accidents and could result in serious in-
jury or death.
Always keep the manual in storage.
If it is missing or damaged, place an order with an
authorized Distributor for a replacement.
If you have any questions, please consult an autho-
rized Distributor.
(1) Most accidents, which occur during operation, are
due to neglect of precautionary measures and safe-
ty rules. Sufficient care should be taken to avoid
these accidents. Erroneous operation, lubrication
or maintenance services are very dangerous and
may cause injury or death of personnel. Therefore
all precautionary measures, NOTES, DANGERS,
WARNINGS and CAUTIONS contained in the man-
ual and on the machine should be read and under-
stood by all personnel before starting any work with
or on the machine.
(2) Operation, inspection, and maintenance should be
carefully carried out, and safety must be given the
first priority. Messages of safety are indicated with
marks. The safety information contained in the
manual is intended only to supplement safety
codes, insurance requirements, local laws, rules
and regulations.
(3) Messages of safety appear in the manual and on
the machine: All messages of safety are identified
by either word "DANGER", "WARNING" and
"CAUTION".
1) DANGER- Indicates an imminently hazardous
situation which, if not avoided, will result in
death or serious injury and is represented as
follows:
2) WARNING- Indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury and is represented as
follows:
3) CAUTION- Indicates a potentially hazardous
situation which, if not avoided, may result in mi-
nor or moderate injury. It may also be used to
alert against possible damage to the machine
and its components and is represented as fol-
lows:
(4) It is very difficult to forecast every danger that may
occur during operation. However, safety can be en-
sured by fully understanding proper operating pro-
cedures for this machine according to methods
recommended by the Manufacturer.
(5) While operating the machine, be sure to perform
work with great care, so as not to damage the ma-
chine, or allow accidents to occur.
(6) Continue studyingthe manual until all Safety, Oper-
ation and Maintenance procedures are completely
understood by all persons working with the ma-
chine.

0-3
SAFETY PRECAUTIONS
The proper and safe lubrication and maintenance
for this machine, recommended by the Manufactur-
er, are outlined in the OPERATOR’S MANUAL for
the machine.
Improper performance of lubrication or mainte-
nance procedures are dangerous and could result
in injury or death. Read and understand the MAN-
UAL before performing any lubrication or mainte-
nance.
The serviceman or mechanic may be unfamiliar with
many of the systems on this machine. This makes it
importantto usecautionwhenperformingservice work.
A knowledge of the system and or components is im-
portant before the removal or disassembly of any com-
ponent.
Because of the size of some of the machine compo-
nents, the serviceman or mechanic should check the
weights noted in this manual. Use proper lifting proce-
dures when removing any components. Weight of com-
ponents table is shown in the section,
SPECIFICATIONS.
The following is a list of basic precautions that must al-
ways be observed.
(1) Read and understand all Warning plates and
decals on the machine before Operating,
Maintaining or Repairing this machine.
(2) Always wear protective glasses and protective
shoes when working around machines. In particu-
lar, wear protective glasses when using hammers,
punches or drifts on any part of the machine or at-
tachments. Use welders gloves, hood/goggles,
apron and the protective clothing appropriate to the
welding job being performed. Do not wear loose fit-
ting or torn clothing. Remove all rings from fingers,
loose jewelry, confine long hair and loose clothing
before working on this machinery.
(3) Disconnect the battery and hang a "Do Not Oper-
ate" tag in the Operators Compartment. Remove
ignition keys.
(4) If possible, make all repairs with the machine
parked on a firm level surface. Block the machine
so it does not roll while working on or under the ma-
chine. Hang a "Do Not Operate" tag in the Opera-
tors Compartment.
(5) Do not work on any machine that is supported only
by lift, jacks or a hoist. Always use blocks or jack
stands, capable of supporting the machine, before
performing any disassembly.
Do not operate this machine unless you have
read and understand the instructions in the OP-
ERATOR’S MANUAL. Improper machine opera-
tion is dangerous and could result in injury or
death.
(6) Relieve all pressure in air, oil or water systems be-
fore any lines, fittings or related items are discon-
nected or removed. Always make sure all raised
components are blocked correctly and be alert for
possible pressure when disconnecting any device
from a system that utilizes pressure.
(7) Lower the bucket, dozer, or other attachments to
the ground before performing any work on the ma-
chine.If thiscannotbedone,make surethebucket,
dozer, ripper orother attachment is blocked correct-
ly to prevent it from dropping unexpectedly.
(8) Use steps and grab handles when mounting or dis-
mountingamachine. Cleananymudordebrisfrom
steps, walkways or work platforms before using.
Alwaysfacethemachinewhenusingsteps,ladders
and walkways. When it is not possible to use the
designed access system, provide ladders, scaf-
folds, or work platforms to perform safe repair oper-
ations.
(9) To avoid back injury, use a hoist when lifting com-
ponents which weigh 20 kg (45 lbs) or more. Make
sure all chains, hooks, slings, etc., are in good con-
dition and are the correct capacity. Be sure hooks
are positioned correctly. Lifting eyes are not to be
side loaded during a lifting operation.
(10)To avoid burns, be alert for hot parts on machines
which have just been stopped and hot fluids in
lines, tubes, and compartments.
(11)Be careful when removing cover plates. Gradually
back off the last two capscrews or nuts located at
opposite ends of the cover or device and carefully
pry cover loose to relieve any spring or other pres-
sure, before removing the last two capscrews or
nuts completely.
(12)Becarefulwhen removingfillercaps,breathersand
plugs on the machine. Hold a rag over the cap or
plug to prevent being sprayed or splashed by liq-
uids under pressure. The danger is even greater if
the machine has just been stopped because fluids
can be hot.

Thanks very much for your reading,
Want to get more information,
Please click here, Then get the complete
manual
NOTE:
If there is no response to click on the link above,
please download the PDF document first, and then
click on it.
Have any questions please write to me:
[e-mail]

0-4
(13)Always use the proper tools that are in good condi-
tion and that are suited for the job at hand. Be sure
youunderstandhow touse thembefore performing
any service work.
(14)Reinstall all fasteners with the same part number.
Do not use a lesser quality fastener if replacements
are necessary.
(15)Repairs which require welding should be per-
formed only with the benefit of the appropriate ref-
erence information and by personnel adequately
trained and knowledgeable in welding procedures.
Determine type of metal being welded and select
correct welding procedure and electrodes, rods or
wire to provide a weld metal strength equivalent at
least to that of the parent metal. Make sure to dis-
connect battery before any welding procedures are
attempted.
(16)Do not damage wiring during removal operations.
Reinstall the wiring so it is not damaged nor will be
damaged in operation of the machine by contacting
sharpcorners,orbyrubbingagainst someobjector
hot surface. Do not connect wiring to a line contain-
ing fluid.
(17)Be sure all protective devices including guards and
shields are properly installed and functioning cor-
rectly before starting a repair. If a guard or shield
must be removed to perform the repair work, use
extra caution and replace the guard or shield after
repair is completed.
(18)The maintenance and repair workwhileholding the
bucket raised is dangerous due to the possibility of
a falling attachment. Don’t fail to lower the attach-
ment and place the bucket to the ground before
starting the work.
(19)Loose or damaged fuel, lubricant and hydraulic
lines,tubesandhosescan causefires. Donotbend
or strike high pressure lines or install ones which
have been bent or damaged. Inspect lines, tubes
and hoses carefully. Do not check for leaks with
your hands. Very small (pinhole) leaks can result in
a high velocity oil stream that will be invisible close
to the hose. This oil can penetrate the skin and
cause personal injury. Use card-board or paper to
locate pinhole leaks.
(20)Tighten connections to the correct torque. Make
sure that all heat shields, clamps and guardsare in-
stalled correctly to avoid excessive heat, vibration
or rubbing against other parts during operation.
Shields that protect against oil spray onto hot ex-
haust components in event of a line, tube or seal
failure must be installed correctly.
(21)Do not operate a machine if any rotating part is
damaged or contacts any other part during opera-
tion. Any high speed rotating component that has
been damaged or altered should be checked for
balance before reusing.
(22)Be careful when servicing or separating the tracks
(crawlers). Chips can fly when removing or install-
ing a track (crawlers) pin. Wear safety glasses and
long sleeve protective clothing. Tracks (crawlers)
can unroll very quickly when separated. Keep away
from front and rear of machine. The machine can
move unexpectedly when both tracks (crawlers)
are disengaged from the sprockets. Block the ma-
chine to prevent it from moving.

0-5
51
42
33
43
25
34
11
44
31
32
1
2
3
12
13
22
23
24
Index
No.
Title
Book Code No.
DistributionYear–Month
S5PS0202E01
2010-09
S5PA0105E01
2010-09
S5PS0302E01
2010-09
S5PJ1131E02
2010-09
S5PS1201E01
2010-09
S5PS1302E01
2010-09
S5PS2202E01
2010-09
S5PS2301E01
2010-09
S5PS2401E01
2010-09
S5PS2501E01
2010-09
S5PA3105E01
2010-09
_
_
S5PS3202E01
2010-09
S5PS3301E01
2010-09
_
_
_
S5PS4201E01
2010-09
S5PS4301E01
2010-09
S5PW4431E02
2010-09
S5PW5131E02
2010-09
_
PS02-00101~
S5PS3402E01
2010-09
STANDARD MAINTENANCE
TIME TABLE
MAINTENANCE STANDARD
AND TEST PROCEDURE
GENERAL DISASSEMBLY
& ASSEMBLY
UPPER SLEWING
STRUCTURE
2
1
3
11
12
13
22
23
24
25
31
32
33
34
42
43
44
51
OUTLINE
SPECIFICATIONS
ATTACHMENT DIMENSIONS
TOOLS
HYDRAULIC SYSTEM
ELECTRIC SYSTEM
COMPONENTS SYSTEM
AIR-CONDITIONER SYSTEM
ATTACHMENT
TRAVEL SYSTEM
HYDRAULIC SYSTEM
ENGINE
ELECTRICAL SYSTEM
ENGINE
APPLICABLE MACHINES
SPECIFICATIONS
MAINTENANCE
SYSTEMDISASSEMBLING
TROUBLESHOOTING
E/G
INDEX CX55BMSRCASE-NA

0-6
NOTE:
This Manual is prepared as technical material in which
the information necessary for the maintenance and re-
pairing services of our hydraulic excavators are collect-
ed, and is categorized into 7 Chapters, Specification,
Maintenance, System, Disassembly, Troubleshooting,
Engine, and Installation Procedures for Optional At-
tachment.
• The Chapter "Specification" describes the specifi-
cations for entire machine and material, which are
instructive for replacement and repairing of attach-
ments.
• TheChapter"Maintenance"describesthe material,
whichishelpfulformaintenance serviceand adjust-
ments for entire machine.
• The Chapter "System" describes the operating sys-
tem like hydraulic system, electric system, compo-
nents, and so on.
• The Chapter "Disassembly" describes the removal
andinstallingofan assemblymountedonthe upper
structure and undercarriage, and the assembling
and disassembling of the associated hydraulic
equipment.
• The Chapter "Troubleshooting" describes how to
find the equipment fault.
• The Chapter "Engine" describes the engine, mak-
ing use of the "Maintenance Manual" provided by
the suppliers.
• The Chapter "Installation Procedures for Optional
Attachment" describes the supplements added on
request as required.
This Manual may be properly revised due to the im-
provement of products, modification of specifications,
etc. And there are cases where the system on actual
machine and a part of the contents of this manual may
differ due to the variations of specification by countries.
For the section in which the description is hardly under-
stood, contact our distributor.
A number is assigned to every part handled in this Man-
ual on account of the description, but the parts cannot
be supplied as service parts. Therefore, the order must
be placed with respective formal number with due con-
firmation on the Parts Manual for the applicable ma-
chine.

1. OUTLINE
1-1
1
Book Code No. S5PA0105E01
1. OUTLINE
TABLE OF CONTENTS
1.1 GENERAL PRECAUTIONS FOR REPAIRS ........................................................1-3
1.1.1 PREPARATION BEFORE DISASSEMBLING ..............................................1-3
1.1.2 SAFETY IN DISASSEMBLING AND ASSEMBLING ...................................1-3
1.1.3 DISASSEMBLING AND ASSEMBLING HYDRAULIC EQUIPMENT ..........1-4
1.1.4 ELECTRICAL EQUIPMENT ........................................................................1-6
1.1.5 HYDRAULIC PARTS ....................................................................................1-7
1.1.6 WELDING REPAIR ......................................................................................1-7
1.1.7 ENVIRONMENTAL MEASURE ...................................................................1-7
1.2 INTERNATIONAL UNIT CONVERSION SYSTEM (Based on MARKS' STANDARD
HANDBOOK FOR MECHANICAL ENGINEERS) ................................................1-8

1. OUTLINE
1-2
Issue Date of Issue Applicable Machines Remarks
First Edition September, 2010 CX55B: PS02-00101~ ↑
(CASE-NA)

1. OUTLINE
1-3
1
1.1 GENERAL PRECAUTIONS FOR REPAIRS
1.1.1 PREPARATION BEFORE DISASSEMBLING
(1) Understanding operating procedure
Read OPERATOR'S MANUAL carefully to understand the operating procedure.
(2) Cleaning machines
Remove soil, mud, and dust from the machine before the machine enters the service shop to prevent loss of work
efficiency, damage of parts, and difficulty in rust prevention and dust protection while reassembling.
(3) Inspecting machines
Identify the parts to be disassembled before starting work, determine the disassembling procedure and the
workshop situations etc., and request procurement of necessary parts in advance.
(4) Recording
Record the following items for communication and prevention of recurring malfunctions.
1. Inspection date and place.
2. Model name, applicable machine number, and hour meter read.
3. Trouble condition, place and cause.
4. Visible oil leakage, water leakage and damage.
5. Clogging of filters, oil level, oil quality, oil contamination and loosening of connections.
6. Result of consideration if any problem exists based on the operation rate per month calculated from the hour
meter indication after the last inspection date.
(5) Arrangement and cleaning in service shop
1. Tools required for repair work.
2. Prepare space to place the disassembled parts.
3. Prepare oil containers for draining oil etc.
1.1.2 SAFETY IN DISASSEMBLING AND ASSEMBLING
(1)Wear appropriate clothes with long sleeves, safety shoes, safety helmet and protective glasses.
(2)Suspend warning tag "DO NOT OPERATE" from the doorknob or the operating lever, and have a preliminary
meeting before starting work.
(3)Stop the engine before starting inspection and maintenance to prevent personal injury.
(4)Identify the location of a first-aid kit and a fire extinguisher, and also where to make contact in an emergency.
(5)Choose a hard, level and safe place, and place the attachment on the ground securely.
(6)Use a hoist or crane to remove heavy parts (20 kg [45 lbs] or more) from the machine.
(7)Use proper tools, and replace or repair defective tools.
(8)Support the machine and attachment with supports or blocks if the work is performed with any section of the
machine raised off the ground.
Read Operator's Manual
before disassembling

WARNING

1. OUTLINE
1-4
1.1.3 DISASSEMBLING AND ASSEMBLING HYDRAULIC EQUIPMENT
(1) Removing Hydraulic Equipment
1. Before disconnecting pipes, release the hydraulic pressure of the system, or open the return side cover and
take out the filter.
2. Carefully drain oil from the removed pipes into containers without spilling on the floor.
3. Apply plugs or caps on the pipe and fitting ends to avoid oil spillage and dust intrusion.
4. Clean off the external surface of the equipment before disassembling, and drain hydraulic and gear oil before
placing it on the workbench.
(2) Disassembling Hydraulic Equipment
1. Do not disassemble, reassemble or modify the hydraulic equipment without the permission of the manufacturer.
The manufacturer is not responsible for the performance and function of the machine components after
modification.
2. When disassembling and reassembling for unavoidable reason, refer the work to qualified personnel who have
the specific knowledge or completed the parts service training.
3. Provide matching marks to facilitate reassembling work.
4. Before starting the work, read the manual for the disassembling procedure, if it is provided, and decide whether
the work can be performed by yourself.
5. Always use the special jigs and tools if they are specified.
6. If it is hard to remove a part according to the procedure, do not try it by force, investigate the cause.
7. Place the removed parts in order and attach tags for easier reassembling.
8. Note the location and quantity of parts when disassembling.
(3) Inspecting Parts
1. Ensure the disassembled parts are free from seizure, interference and uneven contact.
2. Measure and record the wear condition of parts and clearance.
3. If the problem is found in a part, repair or replace it with a new one.
(4) Reassembling Hydraulic Equipment
1. Turn ON the ventilation fan or open windows to maintain good ventilation begore cleaning parts.
2. Perform rough and finish cleaning before assembling.
3. Remove washing oil by with pressurized air and apply clean hydraulic or gear oil for assembling.
4. Always replace the removed O-rings, backup rings and oil seals with new ones by applying grease in advance.
5. Remove dirt and moisture from and perform degreasing on the surfaces where liquid gaskets are applied.
6. Remove rust preventive agent from the new parts before use.
7. Fit bearings, bushings, and oil seals using special jigs.
8. Assemble the parts utilizing matching marks.
9. Ensure all the parts are completely assembled after the work.

1. OUTLINE
1-5
1
(5) Installing Hydraulic Equipment
1. Ensure hydraulic oil and lubricant are properly supplied.
2. Perform air bleeding when:
a. Hydraulic oil is changed.
b. Parts of suction side piping is replaced.
c. Hydraulic pumps are installed.
d. Slewing motor is installed.
e. Travel motor is installed.
f. Hydraulic cylinder is installed.
3. Perform air bleeding of the hydraulic pump and slewing motor after loosening the upper drain plug, starting the
engine and running the engine at low idle.
Complete the air bleeding when seeping of hydraulic oil is recognized, and then tightly plug.
4. Perform air bleeding of the travel motor and the hydraulic cylinders by running the engine for more than 5
minutes at low speed without load.
5. Perform air bleeding of the pilot line by performing a series of digging, slewing and travel.
6. Check hydraulic oil level after placing the attachment to the oil check position, and replenish oil if necessary.
Operation of the hydraulic equipment without filling hydraulic oil or lubricant or without performing air bleeding will
result in damage to the equipment.
Do not allow the hydraulic cylinder to bottom out on the stroke end just after the maintenance.
Level gauge Oil level lines (Level
located between the
two lines shows
appropriate amount
of oil)

1. OUTLINE
1-6
1.1.4 ELECTRICAL EQUIPMENT
(1)Do not disassemble electrical equipment.
(2)Handle electrical equipment carefully. Do not drop and/or shock electrical equipment.
(3)Turn the key OFF prior to connecting and disconnecting work.
(4)Disconnect the connector by holding it and pressing the lock. Do not pull the wire to apply force to the caulking
portion.
(5)Connect the connector and ensure it is completely locked.
(6)Turn the key OFF prior to touching the terminal of the starter or generator.
(7)Remove the ground (earth) terminal from the battery when handling tools around the battery or its relay.
(8)Do not splash water on the electrical equipment and connectors during machine washing.
(9)Check for moisture adhesion inside the waterproof connector after pulling it out, since it is hard to remove
moisture from the connector.
If moisture adhesion is found, dry it completely before the connection.
Battery electrolyte is hazardous.
Battery electrolyte is dilute sulfuric acid. Exposure to skin or eyes from this liquid will cause burning or loss of
eyesight.
If the exposure occurs, take the following emergency measures and seek the advice of a medical specialist.
When skin is exposed: Wash with water and soap sufficiently.
When eyes are exposed: Immediately wash away with water continuously for more than 10 minutes.
When a large amount of the liquid flows out: Neutralize with sodium bicarbonate or wash away with water.
When swallowed: Drink a large amount of milk or water.
When clothes are exposed: Immediately undress and wash.

1. OUTLINE
1-7
1
1.1.5 HYDRAULIC PARTS
(1) O-ring
• Ensure O-rings have elasticity and are not damaged before use.
• Use the appropriate O-rings. O-rings are made of various kinds of materials having different hardness to apply
to a variety of parts, such as the part for moving or fixed applications, subjected to high pressure, and exposed
to corrosive fluid, even if the O-ring size is same.
• Fit the O-rings without distortion and bend.
• Always handle floating seals as a pair.
(2) Flexible Hose (F hose)
• Use the appropriate parts. Different parts are used depending on the working pressure even if the size of the
fitting and the total length of the hose is same.
• Tighten the fitting at the specified torque.
Ensure no kink, tension, interference or oil leakage is recognized.
1.1.6 WELDING REPAIR
(1)Refer repair welding to qualified personnel according to the appropriate procedure.
(2)Disconnect the ground (earth) cable of the battery before starting the repair.
Failure to do so will cause damage to the electrical equipment.
(3)Move away the articles in advance that may cause fire if exposed to sparks.
(4)Before starting the repair of the attachment, do not fail to cover the plated surface of the piston rod with a
flameproof sheet to prevent it from being exposed to sparks.
1.1.7 ENVIRONMENTAL MEASURE
(1)Run the engine in a place that is sufficiently ventilated.
(2)Industrial waste disposal
Dispose of the following parts according to the relevant regulations:
Waste oil and waste container
Battery
(3)Precautions for handling hydraulic oil
Exposure of eyes to hydraulic oil will cause inflammation. Wear protective glasses before handling to avoid an
accident. If an eye is exposed to the oil, take the following emergency measures:
When an eye is exposed: Immediately wash away with city water sufficiently till stimulative feeling vanishes.
When swallowed: Do not vomit, and receive medical treatment immediately.
When skin is exposed: Wash with water and soap sufficiently.
(4)Others
Use replacement parts and lubricants authorized as the manufacturer's genuine parts.

1. OUTLINE
1-8
1.2 INTERNATIONAL UNIT CONVERSION SYSTEM (Based on MARKS'
STANDARD HANDBOOK FOR MECHANICAL ENGINEERS)
Introduction
Although this manual includes the International System of
Units and Foot-Pound System of Units, if you need SI unit,
refer to the following international system of units.
Given hereinafter is an excerpt of the units that are related
to this manual.
1. Etymology of SI Unites
French: Le Systeme International d' Unites
English: International System of Units
2. Construction of SI Unit System
SI unit
system
Prefixes of SI
(n-th power of 10, where n is an integer)
Table 1- 5
SI units
Base units
Table 1-1
Supplemen
tary units
Table 1-2
Derived units
of base units
Table 1-3
Derived units
bearing peculiar
designations
Table 1-4
Derived
units
(1) Base units
(2) Supplementary units
(3) Derived Units
(4) Derived Units bearing Peculiar Designations
Table 1-1
QUANTITY UNIT SYMBOL
Length meter m
Mass kilogram kg
Time second s
Electric current ampere A
Thermodynamic
temperature kelvin K
Amount of
substance mol mol
Luminous
intensity candela cd
Table 1-2
QUANTITY UNIT SYMBOL
Plane angle radian rad
Solid angle steradian sr
Table 1-3
QUANTITY UNIT SYMBOL
Area square meter m2
Volume cubic meter m3
Velocity meter per second m/s
Acceleration meter per second squared m/s2
Density kilogram per cubic meter kg/m3
Table 1-4
QUANTITY UNIT SYMBOL FORMULA
Frequency hertz Hz 1/s
Force newton N kg • m/s 2
Pressure and
Stress pascal Pa N/m2
Energy, Work
and Quantity of
heat
joule J N•m
Power watt W J/s
Quantity of
electricity coulomb C A•s
Electric
potential
difference,
Voltage, and
Electromotive
force
volt V W/A
Quantity of
static electricity
and Electric
capacitance
farad F C/V
Electric
resistance ohm V/A
Celcius
temperature
celcius
degree or
degree
C(t+273.15)K
Illuminance lux lx l m/m2

1. OUTLINE
1-9
1
(5) Prefixes of SI (6) Unit Conversion
*1 Units that are allowed to use.
Table 1-5
PREFIX SYMBOL MULTIPLICATION FACTORS
giga G 10
9
mega M 10
6
kilo k 10
3
hecto h 10
2
deca da 10
deci d 10
–1
centi c 10
–2
milli m 10
–3
micro μ 10
–6
nano n 10
–9
pico p 10
–12
Table 1-6
QUANTITY Gravitational SI CONVERSION FACTOR
Mass kg kg
Force kgf N 1 kgf=9.807 N
Torque kgf•m N•m kgf•m=9.807 N•m
Pressure kgf/cm
2
MPa 1 kgf/cm
2
=0.09807 MPa
Motive
Power PS kW 1 PS=0.7355 kW
Revolution rpm min
–1
r/min *1

1. OUTLINE
1-10

2. SPECIFICATIONS
2-1
2
Book Code No. S5PS0202E01
2. SPECIFICATIONS
TABLE OF CONTENTS
2.1 COMPONENTS NAME ........................................................................................2-3
2.2 MACHINE DIMENSIONS .....................................................................................2-4
2.3 SPECIFICATIONS AND PERFORMANCE ..........................................................2-6
2.4 MACHINE & COMPONENTS WEIGHT (DRY) ....................................................2-8
2.5 TRANSPORTATION .............................................................................................2-10
2.6 TYPE OF CRAWLER SHOES .............................................................................2-13
2.7 TYPE OF BUCKET ..............................................................................................2-14
2.8 ENGINE SPECIFICATIONS .................................................................................2-15
2.8.1 SPECIFICATIONS .......................................................................................2-15
2.8.2 ENGINE PERFORMANCE CURVE .............................................................2-16

2. SPECIFICATIONS
2-2
Issue Date of Issue Applicable Machines Remarks
First Edition September, 2010 CX55B: PS02-00101~ S5PS0202E01
(CASE-NA)
