Casio DQS-30 User manual

USER’S GUIDE DQS-30
1
MA0212-A
SNOOZE
ON
UP
DOWN OFF
SET RESET
LIGHT
SNOOZE
•A sticker is affixed to the glass of this clock when you purchase it. Be sure to remove the sticker before using the
clock.
•Before using this clock for the first time, note the insulation sheet sticking out of the battery compartment. Pull out
the insulation sheet in the direction indicated by the arrow before using the clock.
•After removing the insulation sheet, press the RESET button (55
55
5).
•Depending on the clock model, the configuration of your clock may differ somewhat from that shown in the
illustration.
Alarm Off Alarm On
Current time
(Hour, minutes, seconds) Alarm on indicator
PM indicator
Day of the week
Snooze on indicator
Alarm time
DATE (month - date)
GENERAL GUIDE
11
11
1SNOOZE button
Pressing this button while the alarm is sounding stops the alarm.
22
22
2LIGHT button
Press to turn on the backlight.
33
33
3Alarm Time Set button
Use this button to change the alarm time or current time setting.
44
44
4SET button
Use this button when setting the current time.
55
55
5RESET button
Press to reset the clock after replacing the battery.
66
66
6Alarm Switch
Use this switch to turn the alarm on and off, and to turn on the snooze alarm.
77
77
7Solar panel
88
88
8Insulation sheet
Pull out the insulation sheet in the direction indicated by the arrow before using the clock.
After removing the insulation sheet, press the RESET button (55
55
5).
SETTING THE TIME
1. Press the SET button (44
44
4)to cycle through the setting screens as shown below.
Month and Day Setting Screen Time Setting Screen
Normal Timekeeping Screen
Year Setting Screen 12-hour/24-hour Timekeeping Screen

USER’S GUIDE DQS-30
2
2. While the screen you want is on the display, use the Alarm Time Set button (33
33
3) to change the digits that are
flashing.
UP
DOWN
•Holding down UP or DOWN changes the flashing digits at high speed.
•You can set the year in the range of 2000 to 2039. The day of the week is set automatically in accordance with
the date setting.
•Pressing UP or DOWN while the Time Setting Screen is on the display causes the seconds count to be reset
to 00.
•Each press of UP or DOWN while the 12-hour/24-hour Timekeeping Screen is on the display toggles between
12-hour and 24-hour timekeeping.
3. After making the settings you want, use the SET button (44
44
4) to display the Normal Timekeeping Screen.
•The clock automatically returns to the Normal Timekeeping Screen if you leave a setting screen on the display
for about three minutes without performing any operation.
USING THE ALARM
The alarm sounds and the backlight turns on when the alarm time you set is reached. You can also use the Alarm
Switch (66
66
6) to select the snooze alarm feature.
Setting the Alarm Time
Use the Alarm Time Set button (33
33
3) to set the alarm time.
Pressing the Alarm Time Set button (33
33
3) causes the alarm time to appear in place of the date on the display.
UP
DOWN
•Holding down UP or DOWN changes the digits at high speed.
Turning the Alarm On and Off
Use the Alarm Switch (66
66
6) on the right side of the clock to turn the alarm on and off, and to select the snooze
feature.
Description
The alarm sounds at the preset time for one
minute, and seven more times every five
minutes thereafter. Even if you stop the alarm
sound by pressing the SNOOZE button (11
11
1),
the alarm operation is performed again five
minutes later.
•The indicator Zz flashes on the display to
indicate that the snooze feature is activated.
The alarm sounds at the preset time for one
minute.
The alarm does not sound.
Alarm Switch Setting
SNOOZE ON
Zz
ALARM ON
( )
OFF
( )
Press DOWN to decrease
the flashing digits.
Press UP to increase the
flashing digits.
Press to change the alarm
time setting (UP).
Press to change the alarm
time setting (DOWN).
•The alarm time appears in place of the date on the display whenever the alarm switch is set to ON or SNOOZE.
•The backlight also turns on for the first four seconds that the alarm sounds.
•The alarm sound changes over five levels as it sounds.
Stopping the Alarm
•When alarm is sounding, press the SNOOZE button (11
11
1) to stop it. When the snooze feature is turned on, the
alarm will sound again in about five minutes.
•To turn off the snooze feature, slide the Alarm Switch (66
66
6) to OFF.
USING THE LIGHT
Pressing the LIGHT button (22
22
2)turns on the light and illuminates the display for easy reading in the dark.
Important!
•Overuse of the light can shorten battery life.
BATTERY REPLACEMENT
Replace the battery whenever the display of the clock becomes dim and difficult to read.
•Always have the battery replaced at your nearest dealer.
