Casio Privia PX-150 Manual

PX-150/350M/750/850/1200GP
AP-250/450/650M
MIDI Implementation
CASIO COMPUTER CO., LTD.
Contents
I MIDI Message Overview 5
1 Product Configuration as a MIDI Device 5
1.1 SystemSection.......................................... 5
1.2 SoundGeneratorSection .................................... 5
1.3 Performance Controller Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2 Conditions that Disable Message Send and Receive 8
3 Timbre Type Specific Operation 8
II Channel Message 9
4 Channel Message Overview 9
4.1 SendChannel........................................... 9
4.2 ReceiveChannel ......................................... 9
4.3 Instrument Velocity Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5 Note Off 10
6 Note On 10
7 Polyphonic Key Pressure 11
8 Control Change 11
8.1 BankSelect(00H) ........................................ 11
8.2 Modulation(01H) ........................................ 12
8.3 PortamentoTime(05H)..................................... 12
8.4 DataEntry(06H,26H)...................................... 12
1

8.5 Volume(07H) .......................................... 12
8.6 Pan(0AH) ............................................ 13
8.7 Expression(0BH) ........................................ 13
8.8 General Use Controllers 1 through 8 (10H through 13H, 50H through 53H) . . . . . . . . 13
8.9 Hold1(40H) ........................................... 14
8.10 PortamentoSwitch(41H).................................... 15
8.11 Sostenuto(42H) ......................................... 15
8.12 Soft(43H) ............................................ 16
8.13 VibratoRate(4CH) ....................................... 16
8.14 VibratoDepth(4DH) ...................................... 16
8.15 VibratoDelay(4EH) ...................................... 17
8.16 PortamentoControl(54H) ................................... 17
8.17 High Resolution Velocity Prefix (58H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
8.18 ReverbSend(5BH) ....................................... 18
8.19 ChorusSend(5DH) ....................................... 18
8.20 NRPN(62H,63H) ........................................ 18
8.21 RPN(64H,65H) ......................................... 19
9 Mode Message 20
9.1 AllSoundOff(78H)....................................... 20
9.2 ResetAllControllers(79H)................................... 20
9.3 AllNotesOff(7BH)....................................... 21
9.4 OmniOff(7CH) ......................................... 21
9.5 OmniOn(7DH) ......................................... 22
9.6 Mono(7EH) ........................................... 22
9.7 Poly(7FH)............................................ 22
10 Program Change 22
10.1 AboutTimbreType....................................... 23
10.2 DSP Assignments during Tone Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
11 Channel Aftertouch 24
12 Pitch Bend Change 24
III System Message 25
13 Active Sensing 25
2

14 System Exclusive Message 25
14.1 Universal Realtime System Exclusive Message . . . . . . . . . . . . . . . . . . . . . . . . 25
14.2 Instrument-Specific System Exclusive Messages . . . . . . . . . . . . . . . . . . . . . . . . 29
IV Instrument-Specific System Exclusive Messages 30
15 Format 30
15.1 MessageClassifications ..................................... 30
15.2 BasicMessageStructure..................................... 30
15.3 FieldFormats .......................................... 31
16 Parameter Transfer 34
16.1 Two-wayCommunication.................................... 35
16.2 One-wayCommunication .................................... 35
V Parameter List 36
17 System Parameters 36
17.1 System Information Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
18 Setup Parameter 36
18.1 MIDIParameter ......................................... 36
19 Patch Parameters 37
19.1 MasterTuneParameters .................................... 37
19.2 MasterMixerParameters.................................... 37
19.3 SystemChorusParameters ................................... 37
19.4 SystemReverbParameters ................................... 38
19.5 BrillianceParameters ...................................... 38
19.6 PartParameters ......................................... 38
20 Tone Parameters 39
20.1 BasicParameters......................................... 39
20.2 LFOParameters......................................... 40
20.3 DSPParameters ......................................... 40
21 Music Library Parameters 41
VI DSP Parameter List 42
3

22 Tone with DSP List 42
22.1 PX-150,PX-750,PX-850,AP-250,AP-450 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
22.2 PX-1200GP............................................ 42
22.3 PX-350M,AP-650M....................................... 43
23 DSP Algorithm ID Tables 43
23.1 DSPAlgorithmList ....................................... 43
24 DSP Parameter Set Types 44
24.1 Tremolo/AutoPan........................................ 44
24.2 EQ3Band ............................................ 44
24.3 Compressor............................................ 44
24.4 Limiter .............................................. 44
24.5 EarlyReflection ......................................... 44
24.6 Rotary .............................................. 44
24.7 DriveRotary........................................... 45
24.8 Enhancer ............................................. 45
24.9 CompressorEnhancer ...................................... 45
VII Setting Values and Send/ Receive Values 46
25 Setting Value Tables 46
25.1 Off/OnSettingValueTable................................... 46
25.2 Damper Pedal Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
25.3 Slow/Fast Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
25.4 Rotate/Brake Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
25.5 –64 - 0 - +63 Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
25.6 PanSettingValueTable..................................... 47
25.7 Master Fine Tuning Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
25.8 Reverb Type Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
25.9 Chorus Type Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
25.10 Equalizer Frequency Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
25.11 Brilliance Gain Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
25.12 DSP Equalizer Gain Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
VIII MIDI Implementation Notation 51
26 Value Notation 51
26.1 HexadecimalNotation ..................................... 51
26.2 BinaryNotation......................................... 51
4

Part I
MIDI Message Overview
1 Product Configuration as a MIDI Device
As a MIDI device, the instrument consists of the System Section, Sound Generator Section, and Per-
formance Controller Section described below. Each of these sections sends and receives specific MIDI
Messages in accordance with its function.
•System Section
–Device settings
–Function status
•Sound Generator Section
–Common
∗Sound generator common section
∗System effects
∗Brilliance adjustment function
∗Mixer master
–Parts
∗Sound generator instrument parts
∗DSP (insertion effects)
∗Mixer channel
•Performance Controller Section
–Keyboard
–Pedal and other real-time controllers
–Auto play function
–Auto Accompaniment(PX-350M, AP-650M)
1.1 System Section
The System Section consists of a sound generator (sound source), a performance controller part (per-
formance), and functions that are not directly related to Instrument play. In addition to manipulating
Instrument setting parameters, this section is also used to exchange information.
1.2 Sound Generator Section
The Sound Generator Section consists of a common part that does not depend on the channel and a part
that is specific to each channel. Mainly it receives performance information and performs operations.
1.2.1 Sound generator common section
The common section consists of sound generator setting blocks that do not depend on the sound generator
part, such as system effects, mixer master control, etc. These can be controlled by system exclusive
messages that are basically exclusive to this particular Instrument, but several parameters also can be
controlled by general universal system exclusive messages.
5

1.2.2 Parts
The settings of the sound generator parts can be changed using Instrument-specific system exclusive
messages. This Instrument consists of 32 parts. Of these, channel messages can be used to perform
note on operations and to change settings of only the B Group (B01 through B16). The relationships
between the channel message receive channel and part number are fixed, as shown in ”1.2.3 Part
Assignments(PX-150,PX-750,PX-850,PX-1200GP, AP-250,AP-450)” and ”1.2.4 Part Assignments(PX-
350M, AP-650M)”.
1.2.3 Part Assignments(PX-150,PX-750,PX-850,PX-1200GP, AP-250,AP-450)
Part Number Part Name MIDI Receive Ch MIDI Send Ch Assigned Function Description
00 A01 - 01(Note1) Keyboard Upper1(main)/(Right-
side keyboard in the
Duet Mode)
01 A02 - 02 Keyboard Upper2(Layer)
02 A03 - 03 Keyboard Lower1(Split)/(Left-
side keyboard in the
Duet Mode)
03 A04 - - -
04 A05 - 05 Recorder Play Track1 main
05 A06 - 06 Recorder Play Track1 layer
06 A07 - 07 Recorder Play Track1 split
07 A08 - - Metronome/Count
08 A09 - -
09 A10 - -
10 A11 - -
11 A12 - -
12 A13 - -
13 A14 - -
14 A15 - 04 Recorder Play Track2
15 A16 - – - -
16 B01 01 - MIDI/Song Play Ch.01
17 B02 02 - MIDI/Song Play Ch.02
18 B03 03 - MIDI/Song Play Ch.03 (Left hand
track)
19 B04 04 - MIDI/Song Play Ch.04 (Right hand
track)
20 B05 05 - MIDI/Song Play Ch.05
21 B06 06 - MIDI/Song Play Ch.06
22 B07 07 - MIDI/Song Play Ch.07
23 B08 08 - MIDI/Song Play Ch.08
24 B09 09 - MIDI/Song Play Ch.09
25 B10 10 - MIDI/Song Play Ch.10
26 B11 11 - MIDI/Song Play Ch.11
27 B12 12 - MIDI/Song Play Ch.12
28 B13 13 - MIDI/Song Play Ch.13
29 B14 14 - MIDI/Song Play Ch.14
30 B15 15 - MIDI/Song Play Ch.15
31 B16 16 - MIDI/Song Play Ch.16
Note1 :Can be changed by the Keyboard Channel setting.
6

1.2.4 Part Assignments(PX-350M, AP-650M)
Part Number Part Name MIDI Receive Ch MIDI Send Ch Assigned Function Description
00 A01 - 01 (Note1) Keyboard Upper1(main)/(Right-
side keyboard in the
Duet Mode)
01 A02 - 02 Keyboard Upper2(Layer)
02 A03 - 03 Keyboard Lower1(Split)/(Left-side
keyboard in the Duet
Mode)
03 A04 - 08 Keyboard Harmonize (DSP not
supported.)
04 A05 - 05 Recorder Play System track main
05 A06 - 06 Recorder Play System track layer
06 A07 - 07 Recorder Play System track split
07 A08 - - Metronome/Count
08 A09 - 09 Accompaniment Percussion (DSP not
supported.)
09 A10 - 10 Accompaniment Drum (DSP not
supported.)
10 A11 - 11 Accompaniment Bass (DSP not
supported.)
11 A12 - 12 Accompaniment Chord 1 (DSP not
supported.)
12 A13 - 13 Accompaniment Chord 2 (DSP not
supported.)
13 A14 - 14 Accompaniment Chord 3 (DSP not
supported.)
14 A15 - 15 Accompaniment Chord 4 (DSP not
supported.)
15 A16 - 16 Accompaniment Chord 5 (DSP not
supported.)
16 B01 - 01 (Note2) Recorder/Song
Play/MIDI
Ch.01
17 B02 - 02 (Note2) Recorder/Song
Play/MIDI
Ch.02
18 B03 - 03 (Note2) Recorder/Song
Play/MIDI
Ch.03 (Left hand track)
19 B04 - 04 (Note2) Recorder/Song
Play/MIDI
Ch.04 (Right hand
track)
20 B05 - 05 (Note2) Recorder/Song
Play/MIDI
Ch.05
21 B06 - 06 (Note2) Recorder/Song
Play/MIDI
Ch.06
22 B07 - 07 (Note2) Recorder/Song
Play/MIDI
Ch.07
23 B08 - 08 (Note2) Recorder/Song
Play/MIDI
Ch.08
24 B09 - 09 (Note2) Recorder/Song
Play/MIDI
Ch.09
25 B10 - 10 (Note2) Recorder/Song
Play/MIDI
Ch.10
26 B11 - 11 (Note2) Recorder/Song
Play/MIDI
Ch.11
27 B12 - 12 (Note2) Recorder/Song
Play/MIDI
Ch.12
28 B13 - 13 (Note2) Recorder/Song
Play/MIDI
Ch.13
29 B14 - 14 (Note2) Recorder/Song
Play/MIDI
Ch.14
30 B15 - 15 (Note2) Recorder/Song
Play/MIDI
Ch.15
31 B16 - 16 (Note2) Recorder/Song
Play/MIDI
Ch.16
Note1 :Can be changed by the Keyboard Channel setting.
7

Note2 :Sent during recorder play only. When there is no data recorded in the applicable recorder track, the MIDI
information of the functions of parts with the same send channel (A01 through A16) is sent.
1.3 Performance Controller Section
The Performance Controller Section consists of keyboard, pedal and other real-time controllers, as well
as blocks that generate auto accompaniment, auto performance, and other performance information.
These messages are transmitted to the sound generator in accordance with operations, while they are
also being sent out as MIDI messages. The channel number of the sent message is in accordance with
Instrument s part number.
1.3.1 Auto Accompaniment and Auto Performance MIDI Send
This document what operation is sent by a message in the case of each message type. However, since
there are so many messages sent by an auto accompaniment operation when auto performance and
Accomp MIDI Out is turned on(PX-350M, AP-650M), those messages are not covered here.
2 Conditions that Disable Message Send and Receive
The main conditions when MIDI message send and receive are disabled by the Instrument are those
described below.
•During storage of registration data(PX-350M, AP-650M)
•While storage is selected as the USB device mode(PX-850,PX-1200GP, AP-450,PX-350M, AP-
650M)
3 Timbre Type Specific Operation
The operation that is performed for a received message depends on the current Timbre Type setting (see
10.1 About Timbre Type ), which is the operation mode of each sound generator part. Applicable
information is provided in the explanations for each message.
8

Part II
Channel Message
4 Channel Message Overview
4.1 Send Channel
For information about the MIDI channels of the channel messages that are sent when this Instrument is
played, see1.2.3 Part Assignments(PX-150,PX-750,PX-850,PX-1200GP, AP-250,AP-450)and1.2.4
Part Assignments(PX-350M, AP-650M) . Note, however, that the MIDI channel of the performance
information that corresponds to the keyboard main part can be changed by the Keyboard Channel
setting value.
4.2 Receive Channel
For information about the MIDI channel numbers of channel messages received by each part, see1.2.3
Part Assignments(PX-150,PX-750,PX-850,PX-1200GP, AP-250,AP-450)and1.2.4 Part Assignments(PX-
350M, AP-650M) . The MIDI channel number of a channel message that changes DSP settings also
coincides with the MIDI channel of the part using the DSP. A channel message is not received by a part
that is turned off by the Part Enable Parameter value explained under19.6 Part Parameter .
4.3 Instrument Velocity Resolution
The upper seven bits of the 14-bit resolution correspond to the Note On/Off message, while the lower
seven bits correspond to the High Resolution Velocity Prefix message. (Note1)
Note On/Off High Resolution Velocity Prefix
Upper 7 bits Lower 7 bits
14bits
The initial default value for the lower 7 bits is 00H. Receipt of a High Resolution Prefix message
causes the lower seven bits to be set, but note on/off is not performed.
Receipt of a Note On/Off message causes the upper seven bits to be set with note on/off performed
with 14-bit resolution Velocity.
The High Resolution Velocity Prefix message corresponds the message immediately following the Note
On/Off message, and the lower seven bits are cleared to 00H immediately following note on/off by the
Note On/Off message. 7-bit resolution note on/off using only the Note On/Off message also continues
to be supported.
For details about each message, see ”5Note Off”, ”6Note On”, and ”8.17 High Resolution Velocity
Prefix”.
Note1 :The PX-150,PX-750, AP-250, and PX-350M do not support Note Off Velocity. For these models, Velocity for send
Note Off messages is a fixed value (40H). Velocity for receive Note Off messages is ignored. The High Resolution Velocity Prefix
message is not sent or received for a Note Off message.
9

5 Note Off
Format
Message Format: 8nH kkH vvH
9nH kkH 00H(receive only)
n: MIDI Channel Number
kk: Key Number
vv: velocity
Send Sent when a key is released.(Note1)
The key number changes in accordance with on the Transpose function and Octave Shift function.
Note1 :The PX-150,PX-750, AP-250, and PX-350M do not support Note Off Velocity. For these models, Velocity for send
Note Off messages is a fixed value (40H). The High Resolution Velocity Prefix message is not sent for a Note Off message.
Receive Receipt stops a note being sounded by a note on message. (Note1)
When a High Resolution Velocity Prefix message is received immediately prior to the Note Off message
and the lower seven bits of the 14-bit Velocity are set, the 14-bit resolution note off of the note being
sounded is performed.
For information about the relationship between the Note On/Off message and High Resolution Ve-
locity Prefix message, see ”4.3 Instrument Velocity Resolution”.
Note off by making the Note On Velocity 00H is identical to note off by the combination of High
Resolution Velocity prefix message 40H and Note Off Message 40H.
Note :This Instrument has a function that assumes connection of an external device that sends Note Off Velocity as a fixed
value. Note Off Velocity 00H is replaced with 40H until a Note Off message with a Velocity value other than 00H is received. This
function is enabled when the Instrument is turned on, and disabled by receipt of a Note Off message with a Velocity value other
than 00H.
Note1 :The PX-150,PX-750, AP-250, and PX-350M do not support Note Off Velocity. Velocity for receive Note Off
messages is ignored. The High Resolution Velocity Prefix message is not received for a Note Off message.
6 Note On
Format
Message Format: 9nH kkH vvH
n: MIDI Channel Number
kk: Key Number
vv: Velocity
Send Sent when a key is pressed. The key number changes in accordance with on the Transpose
function and Octave Shift function.
Receive Receipt sounds a note of the corresponding part.
When a High Resolution Velocity Prefix message is received immediately prior to the Note On message
and the lower seven bits of the 14-bit Velocity are set, the 14-bit resolution note on is performed.
For information about the relationship between the Note On/Off message and High Resolution Ve-
locity Prefix message, see ”4.3 Instrument Velocity Resolution”.
10

7 Polyphonic Key Pressure
Format
Message Format: AnH kkH vvH
n: MIDI Channel Number
kk: Key Number
vv: Pressure Value
Send This message is not sent by this Instrument.
Receive This message is not received by this Instrument.
8 Control Change
Format
Message Format: BnH ccH vvH
n: MIDI Channel Number
cc: Control Number
vv: Value
Send Sent when a pedal or another controller operation is performed, when settings are changed,
when the tone is changed, or when an auto performance, Auto Accompaniment(PX-350M, AP-650M),
or other operation is performed.
Receive Receipt changes the controller and settings that correspond to the control number.
8.1 Bank Select (00H)
Format
Message Format: BnH 00H mmH (MSB)
BnH 20H llH (LSB)
n: MIDI Channel Number
mm: Value
ll: Send:00H, Receive:Ignored
Send Sent when a tone is selected. For information about numbers, see the Tone List in the User s
Guide.
Receive Receipt switches the tone bank number stored in Instrument memory. Note, however, that
the tone is not changed until a Program Change message is received.
For details, see 10 Program Change . For information about numbers, see the Tone List in the
User s Guide.
11

8.2 Modulation (01H)
Format
Message Format: BnH 01H vvH
n: MIDI Channel Number
vv: Value
Send This message is not sent by this Instrument.
Receive Receipt adds, to the voice being sounded, modulation of a depth specified by the value. In
the case of a tone that already has modulation applied, receipt of this message increases the modulation
depth. The modulation effect differs according to the tone being used.
8.3 Portamento Time (05H)
Format
Message Format: BnH 05H vvH
n: MIDI Channel Number
vv: Value
Send This message is not sent by this Instrument.
Receive Receipt changes the time it takes until pitch reaches the target portamento effect pitch.
8.4 Data Entry (06H,26H)
Format
Message Format: BnH 06H vvH (MSB)
BnH 26H vvH (LSB)
n: MIDI Channel Number
vv: Value
Send Sent when there is a change in the parameters assigned to NRPN and RPN. For details about
information assigned to parameters that correspond to NRPN and RPN, see8.20 NRPN and8.21
RPN .
Receive Receipt changes the parameter assigned to RPN. This Instrument does not have a parameter
that corresponds to NRPN.
8.5 Volume (07H)
Format
Message Format: BnH 07H vvH
n: MIDI Channel Number
vv: Value
12

Send Sent when layer balance is adjusted.
Receive Receipt changes the volume of the corresponding part.
8.6 Pan (0AH)
Format
Message Format: BnH 0AH vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1 :For information about the relationship between setting values and send/receive values, see 25.6 Pan Setting
Value Table in VII Setting Values and Send/Receive Values .
Send Sent in the following cases.
•When Accomp MIDI Out is on(PX-350M, AP-650M)
•When Music Library play is stopped
Receive Receipt changes the pan setting of the corresponding part.
8.7 Expression (0BH)
Format
Message Format: BnH 0BH vvH
n: MIDI Channel Number
vv: Value
Send Sent in the following cases.
•When Accomp MIDI Out is on(PX-350M, AP-650M)
Receive Receipt changes the Expression value.
8.8 General Use Controllers 1 through 8 (10H through 13H, 50H through
53H)
These messages are used to control DSP operation
Format
13

Message Format: BnH 10H vvH DSP Parameter7[0]
BnH 11H vvH DSP Parameter7[1]
BnH 12H vvH DSP Parameter7[2]
BnH 13H vvH DSP Parameter7[3]
BnH 50H vvH DSP Parameter7[4]
BnH 51H vvH DSP Parameter7[5]
BnH 52H vvH DSP Parameter7[6]
BnH 53H vvH DSP Parameter7[7]
n: MIDI Channel Number
vv: Value
Send This message is not sent by this Instrument.
Receive Receipt change the value of Parameter7 [0-7] (7-Bit Parameter) explained under20.3 Tone
Dsp Parameter . Any message received that corresponds to the parameter of a number not being used
by the currently selected DSP is ignored.
Received values and parameter setting values The range of the value of each DSP Parameter 7
array element depends on the selected DSP or array number. Unlike manipulation of a DSP parameter
using a System Exclusive Message, a value received by this control change message is always in the range
of 0 to 127, but the range is changed in accordance with the setting range of the applicable parameter
setting. Because of this, it is impossible for a value to be outside of the range. Conversion to the
parameter setting value from the value received with the message can be represented in general terms
by the expression shown below.
Parameter Setting Value =Parameter Minimum Value + (Parameter Maximum Value −Parameter Minimum Value)∗„Received Value
127 «
For details about Parameter 7 of each DSP, see the explanations underVI DSP Parameter List .
8.9 Hold1 (40H)
Format
Message Format: BnH 40H vvH
n: MIDI Channel Number
vv: Value
Send Sent in the following cases.
•When a pedal that has a sustain (damper) function is operated
•When Accomp MIDI Out is on(PX-350M, AP-650M)
Receive Receipt performs an operation equivalent to a sustain (damper) pedal operation.
14

Timbre Type Specific Operation This operation differs in accordance with the Timbre Type (see
10.1 About Timber Type ) setting.
•Timbre Type: Melody
Sustain off/on control is performed in accordance with the value of the received message. For
information about the relationship between setting values and send/receive values, see the25.1
Off/On Setting Value Table inVII Setting Values and Send/Receive Values .
•Timbre Type: Piano
Continuous control of the following is performed in accordance with the value of the received
message.
–Piano note decay rate
For information about the relationship between setting values and send/receive values, see25.2
Damper Pedal Setting Value Table inVII Setting Values and Send/Receive Values. 
•Timbre Type: LM (Linear Morphing) Piano
Continuous control of the following is performed in accordance with the value of the received
message.
–Piano note decay rate
–Resonance characteristics and decay rate of Damper Resonance effect resonance note
see25.2 Damper Pedal Setting Value TableinVII Setting Values and Send/Receive Values.
•Timbre Type: Drum
The received message does not affect sound source operation.
8.10 Portamento Switch (41H)
Format
Message Format: BnH 41H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1 :For information about the relationship between setting values and send/receive values, see the 25.1 Off/On
Setting Value Table in VII Setting Values and Send/Receive Values .
Send This message is not sent by this Instrument.
Receive Receipt can be use to switch portamento between enabled (On) and disabled (Off).
8.11 Sostenuto (42H)
Format
Message Format: BnH 42H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1 :For information about the relationship between setting values and send/receive values, see the 25.1 Off/On
Setting Value Table in VII Setting Values and Send/Receive Values .
15

Send Sent when a pedal that has a sostenuto function is operated.
Receive Receipt performs an operation equivalent to a sostenuto pedal operation.
8.12 Soft (43H)
Format
Message Format: BnH 43H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1 :For information about the relationship between setting values and send/receive values, see the 25.1 Off/On
Setting Value Table in VII Setting Values and Send/Receive Values .
Send Sent when a pedal that has a soft function is operated.
Receive Receipt performs an operation equivalent to a soft pedal operation.
8.13 Vibrato Rate (4CH)
Format
Message Format: BnH 4CH vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1 :For information about the relationship between setting values and send/receive values, see 25.5 64 - 0 - +63
Setting Value Table in VII Setting Values and Send/Receive Values of this document.
Send This message is not sent by this Instrument.
Receive Receipt changes the vibrato rate of the tone that is currently selected by the applicable part.
8.14 Vibrato Depth (4DH)
Format
Message Format: BnH 4DH vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1 :For information about the relationship between setting values and send/receive values, see 25.5 64 - 0 - +63
Setting Value Table in VII Setting Values and Send/Receive Values of this document.
Send This message is not sent by this Instrument.
Receive Receipt changes the vibrato auto depth of the tone that is currently selected by the applicable
part.
16

8.15 Vibrato Delay (4EH)
Format
Message Format: BnH 4EH vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1 :For information about the relationship between setting values and send/receive values, see 25.5 -64 - 0 - +63
Setting Value Table in VII Setting Values and Send/Receive Values of this document.
Send This message is not sent by this Instrument.
Receive Receipt changes the vibrato auto delay of the tone that is currently selected by the applicable
part.
8.16 Portamento Control (54H)
Format
Message Format: BnH 54H vvH
n: MIDI Channel Number
kk: Source Note Number
Send This message is not sent by this Instrument.
Receive Receipt of this message first stores the Source Note Number for the next note. When the
next Note On is received, the portamento effect is applied to the note using this Source Note Number as
the pitch start point and the Note On event key number as the end point. If there already is a note being
sounded by Source Note Number at this time, the new note on is not performed and the portamento
effect is applied to the pitch of the note being sounded. That is to say that legato play is performed.
8.17 High Resolution Velocity Prefix (58H)
Format
Message Format: BnH 58H vvH
n: MIDI Channel Number
vv: Value
Send Sends the lower seven bits of 14-bit Velocity when a key is pressed or released. (Note1)
Receive Receipt is handled, in combination with the following Note On/Off message, as the lower
seven bits of 14-bit Velocity. (Note1)
For information about the relationship between the Note On/Off message and High Resolution Ve-
locity Prefix message, see ”4.3 Instrument Velocity Resolution”.
17

Note1 :The PX-150,PX-750, AP-250, and PX-350M do not support Note Off Velocity. For these models, Velocity for send
Note Off messages is a fixed value (40H). Velocity for receive Note Off messages is ignored. The High Resolution Velocity Prefix
message is not sent or received for a Note Off message.
8.18 Reverb Send (5BH)
Format
Message Format: BnH 5BH vvH
n: MIDI Channel Number
vv: Value
Send Sent when a GM tone is selected.(PX-350M, AP-650M only)
Receive Receipt changes Reverb Send.
8.19 Chorus Send (5DH)
Format
Message Format: BnH 5DH vvH
n: MIDI Channel Number
vv: Value
Send This message is sent at initialization, when the panel tone selection is changed, and when a
chorus on/off operation is performed.
Receive Receipt changes Chorus Send.
8.20 NRPN (62H,63H)
Format
Message Format: BnH 62H vvH (LSB)
BnH 63H vvH (MSB)
n: MIDI Channel Number
vv: Value
Send This message is not sent by this Instrument.
Receive This message is not received by this Instrument.
8.20.1 Assignable Functions to NRPN
This Instrument does not assign any parameters to NRPN.
18

8.21 RPN (64H,65H)
Format
Message Format: BnH 64H vvH (LSB)
BnH 65H vvH (MSB)
n: MIDI Channel Number
vv: Value
The following are the parameters assigned to RPN by this Instrument.
8.21.1 Pitch Bend Sensitivity
Format
Message Format: BnH 64H 00H 65H 00H 06H mmH 26H llH
n: MIDI Channel Number
mm: Value 0 - 24
ll: Send:00H,Receive:Ignored
Send Sent when the pitch bend range is changed.(PX-350M)
Receive Receipt changes Pitch Bend Sensitivity.
8.21.2 Fine Tune
Format
Message Format: BnH 64H 01H 65H 00H 06H mmH 26H llH
n: MIDI Channel Number
mm: Value MSB
ll: Value LSB
Send This message is not sent by this Instrument.
Receive Receipt changes Channel Fine Tune.
8.21.3 Coarse Tune
Format
Message Format: BnH 64H 02H 65H 00H 06H mmH 26H 00H
n: MIDI Channel Number
mm: Value
Send This message is not sent by this Instrument.
Receive Receipt changes Channel Coarse Tune.
19

8.21.4 Modulation Depth
Format
Message Format: BnH 64H 05H 65H 00H 06H mmH 26H 00H
n: MIDI Channel Number
mm: Value
Send This message is never sent.
Receive Receipt changes the Vibrato Modulation Depth for the tone that is currently selected by the
applicable part.
8.21.5 Null
Format
Message Format: BnH 64H 7FH 65H 7F
n: MIDI Channel Number
Send This message is never sent.
Receive Receipt deselects RPN.
9 Mode Message
9.1 All Sound Off (78H)
Format
Message Format: BnH 78H 00H
n: MIDI Channel Number
Send Mainly sent in the following cases.
•When USB memory is accessed(PX-350M, AP-650M)
•When repeat playback of the USER SONG/SONG RECORDER is started(PX-350M, AP-650M)
•When a SONG RECORDER FF, REW or PAUSE process is performed(PX-350M, AP-650M)
Receive Receipt stops all voices that are sounding.
9.2 Reset All Controllers (79H)
Format
Message Format: BnH 79H 00H
n: MIDI Channel Number
20
