Casio CELVIANO PX-770 User manual

PX-770/PX-870/AP-270/AP-470/PX-2000GP
MIDI Implementation
CASIO COMPUTER CO., LTD.
Contents
I Overview 3
1 Product Configuration as a MIDI Device 3
1.1 SystemSection.......................................... 3
1.2 Performance Controller Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 SoundGeneratorSection .................................... 3
2 Conditions that Disable Message Send and Receive 5
II Channel Message 6
3 Note Off 6
4 Note On 7
5 Control Change 7
5.1 BankSelect(00H,20H) ..................................... 7
5.2 Modulation(01H) ........................................ 8
5.3 PortamentoTime(05H) ..................................... 8
5.4 DataEntry(06H,26H)...................................... 8
5.5 Volume(07H) .......................................... 8
5.6 Pan(0AH) ............................................ 8
5.7 Expression(0BH) ........................................ 9
5.8 Hold1(40H) ........................................... 9
5.9 PortamentoOn/Off(41H).................................... 9
5.10 Sostenuto(42H) ......................................... 9
5.11 Soft(43H) ............................................ 10
5.12 ReleaseTime(48H) ....................................... 10
5.13 AttackTime(49H)........................................ 10
5.14 VibratoRate(4CH)....................................... 10
5.15 VibratoDepth(4DH) ...................................... 11
5.16 VibratoDelay(4EH) ...................................... 11
5.17 PortamentoControl(54H).................................... 11
5.18 High Resolution Velocity Prefix (58H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5.19 ReverbSend(5BH) ....................................... 12
5.20 ChorusSend(5DH) ....................................... 12
5.21 NRPN(62H,63H) ........................................ 12
5.22 RPN(64H,65H) ......................................... 12
1

5.23 AllSoundOff(78H)....................................... 14
5.24 ResetAllControllers(79H)................................... 14
5.25 AllNotesOff(7BH)....................................... 14
5.26 OmniOff(7CH) ......................................... 14
5.27 OmniOn(7DH) ......................................... 14
5.28 Mono(7EH) ........................................... 14
5.29 Poly(7FH)............................................ 15
6 Program Change 15
7 Channel After Touch 15
8 Pitch Bend 15
III System Message 16
9 Active Sensing 16
10 System Exclusive Message 16
10.1 Universal Real Time System Exclusive Message . . . . . . . . . . . . . . . . . . . . . . . . 16
10.2 Universal Non Real Time System Exclusive Message . . . . . . . . . . . . . . . . . . . . . 19
IV Setting Values and Send/ Receive Values 20
11 Setting Value Tables 20
11.1 Off/OnSettingValueTable................................... 20
11.2 Sustain Pedal Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
11.3 –64 - 0 - +63 Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
11.4 PanSettingValueTable..................................... 20
11.5 Fine Tuning Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
11.6 Reverb Type Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
11.7 Chorus Type Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
V MIDI Implementation Notation 22
12 Value Notation 22
12.1 HexadecimalNotation...................................... 22
12.2 BinaryNotation ......................................... 23
2

Part I
Overview
1 Product Configuration as a MIDI Device
As a MIDI device, this Instrument consists of the System Section, Sound Generator Section, and Per-
formance Controller Section described below. Each of these sections can send and receive specific MIDI
Messages in accordance with its function.
1.1 System Section
The System Section manages the Instrument status.
1.2 Performance Controller Section
The Performance Controller Section performs generates performance messages in accordance with key-
board play and pedal operations, etc. Basically, generated performance messages are sent to external
destinations while also being transmitted to the Sound Generator Section. The channel number of the
sent channel message is in accordance with the Instrument’s part number.
1.3 Sound Generator Section
The Sound Generator Section mainly performs receive of performance information and sound source
setting information. It consists of a common part that does not depend on the channel and a musical
instrument part that is independent of each channel.
1.3.1 Sound Generator Common Block
The common block consists of system effects, master control, etc. These can be controlled by general
universal system exclusive messages, or the Instrument’s system exclusive messages or all.
1.3.2 Instrument Part Block
The instrument part section consists of a total of 32 instrument parts. The settings of each part can be
changed using channel messages or Instrument’s system exclusive messages or all. The functions assigned
to each part are shown below. The MIDI send channel and MIDI receive channel can be changed using
the Instrument’s MIDI settings.
3

Part Number Part Name MIDI Receive Ch MIDI Send Ch Assigned
Function
Description
00 A01 - 01(Note1) Keyboard Upper1(Main)/
(Right-side
keyboard in the
Duet Mode)
01 A02 - 02 Keyboard Upper2(Layer)
02 A03 - 03 Keyboard Lower1(Split)/
(Left-side
keyboard in the
Duet Mode)
03 A04 - - -
04 A05 - 05 Recorder Play Track1 main
05 A06 - 06 Recorder Play Track1 layer
06 A07 - 07 Recorder Play Track1 split
07 A08 - - Metronome/
Count
08 A09 - -
09 A10 - -
10 A11 - -
11 A12 - -
12 A13 - -
13 A14 - -
14 A15 - 04 Recorder Play Track2
15 A16 - – - -
16 B01 01 - MIDI/Song Play Ch.01
17 B02 02 - MIDI/Song Play Ch.02
18 B03 03 - MIDI/Song Play Ch.03 (Left hand
track)
19 B04 04 - MIDI/Song Play Ch.04 (Right
hand track)
20 B05 05 - MIDI/Song Play Ch.05
21 B06 06 - MIDI/Song Play Ch.06
22 B07 07 - MIDI/Song Play Ch.07
23 B08 08 - MIDI/Song Play Ch.08
24 B09 09 - MIDI/Song Play Ch.09
25 B10 10 - MIDI/Song Play Ch.10
26 B11 11 - MIDI/Song Play Ch.11
27 B12 12 - MIDI/Song Play Ch.12
28 B13 13 - MIDI/Song Play Ch.13
29 B14 14 - MIDI/Song Play Ch.14
30 B15 15 - MIDI/Song Play Ch.15
31 B16 16 - MIDI/Song Play Ch.16
Note1: Can be changed by Keyboard Channel setting.
4

2 Conditions that Disable Message Send and Receive
No MIDI messages at all can be sent or received while “Please Wait ...” is on the display.
5

Part II
Channel Message
Instrument Velocity Resolution The upper seven bits of the 14-bit resolution correspond to the
Note On/Off message, while the lower seven bits correspond to the High Resolution Velocity Prefix
message.
Note On/Off High Resolution Velocity Prefix
Upper 7 bits Lower 7 bits
14bits
The initial default value for the lower 7 bits is 00H. Receipt of a High Resolution Prefix message
causes the lower seven bits to be set, but note on/off is not performed.
Receipt of a Note On/Off message causes the upper seven bits to be set with note on/off performed
with 14-bit resolution Velocity.
The High Resolution Velocity Prefix message corresponds the message immediately following the Note
On/Off message, and the lower seven bits are cleared to 00H immediately following note on/off by the
Note On/Off message. 7-bit resolution note on/off using only the Note On/Off message also continues
to be supported.
For details about each message, see ” 3 Note Off”, ”4 Note On”, and ”5.18 High Resolution Velocity
Prefix”.
3 Note Off
Format
Message Format: 8nH kkH vvH
9nH kkH 00H(receive only)
n: MIDI Channel Number
kk: Key Number
vv: Velocity
Transmit Sent when something is played on the keyboard. The key number changes in accordance
with on the Transpose function and Octave Shift function.
Receive Receipt stops a note being sounded by a note on message.
When a High Resolution Velocity Prefix message is received immediately prior to the Note Off message
and the lower seven bits of the 14-bit Velocity are set, the 14-bit resolution note off of the note being
sounded is performed.
For information about the relationship between the Note On/Off message and High Resolution Ve-
locity Prefix message, see ”Instrument Velocity Resolution” at the beginning of part II.
Note off by making the Note On Velocity 00H is identical to note off by the combination of High
Resolution Velocity prefix message 40H and Note Off Message 40H.
6

Note: This Instrument has a function that assumes connection of an external device that sends Note Off Velocity as a fixed
value. Note Off Velocity 00H is replaced with 40H until a Note Off message with a Velocity value other than 00H is received. This
function is enabled when the Instrument is turned on, and disabled by receipt of a Note Off message with a Velocity value other
than 00H.
4 Note On
Message Format: 9nH kkH vvH
n: MIDI Channel Number
kk: Key Number
vv: Velocity
Transmit Sent when something is played on the keyboard. The key number changes in accordance
with on the Transpose function and Octave Shift function.
Receive Receipt sounds a note of the corresponding instrument part.
When a High Resolution Velocity Prefix message is received immediately prior to the Note On message
and the lower seven bits of the 14-bit Velocity are set, the 14-bit resolution note on is performed.
For information about the relationship between the Note On/Off message and High Resolution Ve-
locity Prefix message, see ”Instrument Velocity Resolution” at the beginning of part II.
5 Control Change
Message Format: BnH ccH vvH
n: MIDI Channel Number
cc: Control Number
vv: Value
For details about messages, see each section of this manual that covers them.
5.1 Bank Select (00H,20H)
Message Format: BnH 00H mmH (MSB)
BnH 20H llH (LSB)
n: MIDI Channel Number
mm: MSB Value(Note1)
ll: LSB Value(Transmit:00H, Receive:Ignored)
Note1: For details about the relationship between the MSB value and the tone, see the Tone List that comes with the
Instrument.
Transmit Sent when a tone number is selected. For information about numbers, see the Tone List in
the User’s Guide.
Receive Receipt causes a change in the tone bank number stored in Instrument memory, but the
tone is not actually changed until a Program Change message is received. For details, see “6 Program
Change”.
7

5.2 Modulation (01H)
Message Format: BnH 01H vvH
n: MIDI Channel Number
vv: Value
Receive Receipt adds, to the tone being sounded, modulation of a depth specified by the value. In
the case of a tone that already has modulation applied, receipt of this message increases the modulation
depth. The modulation effect differs according to the tone being used.
5.3 Portamento Time(05H)
Message Format: BnH 05H vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the portamento application time.
5.4 Data Entry (06H,26H)
Message Format: BnH 06H mmH (MSB)
BnH 26H llH (LSB)
n: MIDI Channel Number
mm: MSB Value
ll: LSB Value
Transmit Sent when there is a change to the parameter assigned to RPN. For details about information
assigned to parameters that correspond to RPN, see ”5.22 RPN”. This Instrument does not have a
parameter that corresponds to NRPN.
Receive Receipt changes the parameter assigned to RPN.
5.5 Volume (07H)
Message Format: BnH 07H vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when layer balance or lower volume is adjusted.
Receive Receipt changes the part volume.
5.6 Pan (0AH)
Message Format: BnH 0AH vvH
n: MIDI Channel Number
vv: Value(Note1)
8

Note1: For information about the relationship between setting values and send/receive values, see “11.4 Pan Setting Value
Table” in “IV Setting Values and Send/Receive Values”.
Transmit Sent when Music Library play is stopped.
Receive Receipt changes the pan of the corresponding part.
5.7 Expression (0BH)
Message Format: BnH 0BH vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the Expression value.
5.8 Hold1 (40H)
Message Format: BnH 40H vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when a pedal that has a sustain (damper) function is operated.
Receive Receipt performs an operation equivalent to a sustain pedal operation.
5.9 Portamento On/Off(41H)
Message Format: BnH 41H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “11.1 Off/On Setting
Value Table” in “IV Setting Values and Send/Receive Values” of this document.
Receive Receipt changes the portamento on/off setting.
5.10 Sostenuto (42H)
Message Format: BnH 42H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “11.1 Off/On Setting
Value Table” in “IV Setting Values and Send/Receive Values” of this document.
9

Transmit Sent when a pedal that has a sostenuto function is operated.
Receive Receipt performs an operation equivalent to a sostenuto pedal operation.
5.11 Soft (43H)
Message Format: BnH 43H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “11.1 Off/On Setting
Value Table” in “IV Setting Values and Send/Receive Values” of this document.
Transmit Sent when a pedal that has a soft function is operated.
Receive Receipt performs an operation equivalent to a soft pedal operation.
5.12 Release Time (48H)
Message Format: BnH 48H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “11.3 –64 - 0 - +63
Setting Value Table” in “IV Setting Values and Send/Receive Values” of this document.
Receive Receipt makes a relative change in the time it takes for a note to decay to zero after a key is
released.
5.13 Attack Time (49H)
Message Format: BnH 49H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “11.3 –64 - 0 - +63
Setting Value Table” in “IV Setting Values and Send/Receive Values” of this document.
Receive Receipt makes a relative change in the time it takes for a note to rise to its maximum level.
5.14 Vibrato Rate (4CH)
Message Format: BnH 4CH vvH
n: MIDI Channel Number
vv: Value (Note1)
10
