Casio 5412 User manual

User’s Guide 5412 (OC)
MA1610-EC © 2014 CASIO COMPUTER CO., LTD.
E-7B
xEven if you are unable to perform a GPS signal and/or time calibration signal receive operation for
some reason, the watch will keep time with average monthly accuracy of ±15 seconds.
Important!
xIf the current time and day setting is wrong after you perform one of the procedures under “Time
Calibration Signal Auto Receive”, “GPS Signal Auto Receive”, or “Receiving GPS Time Information”, try
acquiring position information (GPS) and then perform the time/day setting procedure again.
xIf you feel that the current time and/or day indicator are not in the correct positions, you can adjust
their alignment. For details, see the Operation Guide available at the CASIO website.
xTime calibration signal reception is normally possible in the areas below.
Japan, China, North America, Europe
For details, see the Operation Guide available at the CASIO website.
xFor details about the following operations, see the Operation Guide available at the CASIO website:
Confi
guring Home City (time zone), summer time, current time, and current day settings manually.
http://world.casio.com/support/
E-6 B
Timekeeping (Current Time and Day Adjustment)
● After purchasing the watch, perform the procedure under “Acquiring GPS Position Information”
(page E-9).
● To set the current time and day, normally use the procedure under “Time Calibration Signal Auto
Receive” (page E-13). In areas where a time calibration signal cannot be received for some reason,
set the current time and day using the procedure under “GPS Signal Auto Receive” (page E-11).
xLate night (between midnight and 5:00 a.m.): The receive operation starts at regular intervals until
receive is successful (Time Calibration signal).
xDaytime (between 6:00 a.m. and 10:00 p.m.): The receive operation will start automatically when
the watch is continually expose to light (GPS).
xOnce a time calibration or GPS signal receive operation is successful, no more Auto Receive
operations are performed that day.
●● If the current time setting is not correct, perform the procedure under “Receiving GPS Time
Information” (page E-10).
● If you move into another time zone, perform the procedure under “Acquiring GPS Position
Information”. Next, perform one of the procedures under “Time Calibration Signal Auto
Receive”, “GPS Signal Auto Receive”, or “Receiving GPS Time Information” to set the current
time and day.
xGPS and time calibration signal reception is not possible when the watch’s temperature is less
than approximately –10°C (14°F) or greater than approximately 60°C (140°F).
E-5
xIf timekeeping stops, you will need to expose the watch to light for anumber of hours before it will
restart.
xThe watch will not charge if its temperature is –10°C (14°F ) or lower, or around 60°C (140°F ) or
higher.
xIf the watch is not charged for more than about three months after it stops running due to low power,
over-discharge will occur, which may make recharging impossible.
E-4
Charging the Watch
xWhile wearing the watch, take care so your sleeve does not block its face
(solar panel) from light. Charging efficiency may be reduced if the face (solar
panel) is blocked from light, even partially.
xWhen you are not wearing the watch, leave it where its face (solar panel) is
exposed to bright light for charging.
xTo help ensure stable operation, expose the face of the watch to about a half
day of direct sunlight each week to charge it.
Caution
xThe case of the watch may become extremely hot when charging. Guard against burn injury.
Important!
xIf the watch is not exposed to light for long periods, it will disable some functions and eventually stop
timekeeping.
xThe second hand will jump at two-second or five-second intervals to indicate that battery power is low,
and stop completely when the battery is dead. Note that the watch also has a power saving function.
For details, see the Operation Guide available at the CASIO website.
E-3
Contents
Features .............................................................................................................................................. E-2
Charging the Watch............................................................................................................................ E-4
Timekeeping (Current Time and Day Adjustment) ............................................................................. E-6
Timekeeping (Based on GPS Signals)................................................................................................ E-8
Appropriate Signal Reception Location (GPS Signal) ..................................................................... E-8
Performing a GPS Signal Receive Operation Manually................................................................... E-9
GPS Signal Auto Receive ........................................................................................................... E-11
Timekeeping (Based on a Time Calibration Signal) ......................................................................... E-12
Appropriate Signal Reception Location (Time Calibration Signal).................................................. E-12
Time Calibration Signal Auto Receive.......................................................................................... E-13
Mode Reference Guide..................................................................................................................... E-14
Using the Watch in an Aircraft (Airplane Mode)............................................................................ E-16
Using the Crown........................................................................................................................ E-17
Specifications ................................................................................................................................... E-18
E-2
Features
Your watch provides you with the features and functions described below.
◆Solar powered operation........................................................................................Page E-4
The watch generates electrical power from sunlight and other types of light, and uses it to charge a
battery that powers operation.
◆Accurate timekeeping.............................................................................................Page E-6
Timekeeping is kept accurate using GPS signals and time calibration signals.
◆Current time in cities around the globe...............................................................Page E-14
View the current time in 40 time zones around the globe.
◆Stopwatch..............................................................................................................Page E-15
The stopwatch measures elapsed time up to 24 minutes in 0.05-second increments.
E-1B
ENGLISH
Congratulations upon your selection of this CASIO watch.
xKeep the watch’s face exposed to light as much as possible (page E-4).
xFor details about how to use this watch and for troubleshooting information, go to the website below.
http://world.casio.com/support/
xDo not try to remove the rechargeable battery from this watch. Always be sure to request rechargeable
battery replacement from your retailer. Use of a non-specifi
ed battery type and/or incorrect
replacement creates the risk of burn injury and fi
re due to explosion, overheating, ignition, etc.
Important!
xFor details about how to adjust the current time zone, time, and day settings, see “Timekeeping
(Current Time and Day Adjustment)” (Page E-6).
Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or loss suffered by
you or any third party arising through the use of your watch or its malfunction.

User’s Guide 5412 (OC)
E-15
C
xHolding down Cfor two seconds in any mode returns to the Timekeeping Mode.
Stopwatch Mode

xStart
xStop
Stopwatch
1/20 (0.05)-second hand
Stopwatch second
hand
xReset
Stopwatch minute hand (0 to 24 minutes)
Points to STW
E-14
Mode Reference Guide
xUse Cto navigate between modes.
Timekeeping Mode
C
xIn the Timekeeping Mode (not in the Airplane Mode), the mode hand will point to the
current day of the week.
xIn the Airplane Mode, the day of the week hand points to the airplane ( ) mark instead
of the day of the week.

Minute hand
Day of the
week hand
World Time hour hand
24-hour hand
Hour hand
Second hand
Day Indicator
Crown
World Time
minute hand
CB
A
xTo check the last receive result,
press Bonce.
xHolding down Bfor about one
second will start a GPS time
information receive operation.
xHolding down Bfor about three
seconds will start a GPS position
information acquisition operation.
xPress Conce to enter the
Stopwatch Mode.
E-13
Time Calibration Signal Auto Receive
Important!
xTo perform time calibration signal auto receive, the watch must be in the Timekeeping Mode (not in the
Airplane Mode). See “Mode Reference Guide” (page E-14).
● Leave the watch in a location that is appropriate for time calibration signal reception between
the hours of midnight and 5:00 a.m. See “Appropriate Signal Reception Location (Time
Calibration Signal)” (page E-12).
xThe second hand will point to RC while time calibration signal reception is in progress.
xReception normally takes anywhere from about two to ten minutes, but it can take as long as
20minutes.
xWhen the receive operation is successful, the time and day settings will be adjusted automatically.
E-12
Timekeeping (Based on a Time Calibration Signal)
Appropriate Signal Reception Location (Time Calibration Signal)
xKeep the watch away from metal and position it so its 12 o’clock side is
facing a window. Avoid moving the watch as much as possible and do
not perform any watch operations while a signal receive operation is in
progress.
● You may experience time calibration signal reception problems in
the areas described below.
-Among or near buildings
-While riding in a vehicle
-Near household appliances, office machines, mobile phones, etc.
-On a construction site, in an airport, or any other location where radio
wave interference occurs
-Near high-voltage lines
-In mountainous areas or behind a mountain
xAlways check the time setting on the day there should be switch between
standard time and summer time (DST). If the setting is not correct (due to
signal reception failure), turn DST on or off manually as required.
12 o’clock
E-11C
GPS Signal Auto Receive
Important!
xPerform the signal receive operation in the Timekeeping Mode (not in the Airplane Mode). See “Mode
Reference Guide” (page E-14).
● GPS signal time information is received automatically whenever all of the conditions described
below are satisfied.
-The current time is between 6:00 a.m. and 10:00 p.m.
-The face of the watch has been exposed continuously for about one or two minutes to light
equivalent to the brightness near a window on a clear day.
-All time calibration signal receive operations performed during the previous night were unsuccessful.
E-10
◆Receiving GPS Time Information
Perform this operation when you suspect that the time normally indicated by the watch is not correct.
xIf the GPS signal time information receive operation is successful the watch will automatically adjust
the current time and day settings of the Home City (time zone).
Important!
xPerform this operation in the Timekeeping Mode (not in the Airplane Mode). See “Mode Reference
Guide” (page E-14).
1. Move to a location appropriate for signal reception and orient the
watch so its display is pointed straight up at the sky. See “Appropriate
Signal Reception Location (GPS Signal)” (page E-8).
2. Hold down Bfor at least one second. Release the button as soon as
the second hand points to T(TIME).
xReception normally takes anywhere from seven seconds to one
minute. It can take as long as 13 minutes.
xWhen the receive operation is successful, the watch will adjust its
current time and day settings automatically.
xThis operation requires large amounts of power. Perform it only
when necessary.

Second hand
E-9
Performing a GPS Signal Receive Operation Manually
◆Acquiring GPS Position Information
When position information is acquired successfully, the watch is able to determine its current location
and adjust its time and day setting accordingly.
Important!
xPerform this operation in the Timekeeping Mode (not in the Airplane Mode). See “Mode Reference
Guide” (page E-14).
1. Move to a location appropriate for signal reception and orient the watch so its face is pointing straight
upwards.
xSee “Appropriate Signal Reception Location (GPS Signal)” (page E-8).
2. Hold down Bfor at least three seconds until the second hand moves
to T+P. If the second hand moves to any other position besides T+P,
keep Bdepressed until it moves to T+P.
xPosition information reception takes anywhere from about 30
seconds to two minutes. It can take as long as 13 minutes.
xSuccessful acquisition of position information will automatically
display the time and day for the resulting location.
xIn the normal (not Airplane Mode) Timekeeping Mode, the mode
hand indicates the current day of the week.
xPosition information acquisition requires large amounts of power.
Perform the acquisition operation only when it is required.

Second hand
Mode hand
E-8
Timekeeping (Based on GPS Signals)
Appropriate Signal Reception Location (GPS Signal)
When performing GPS signal reception, move the watch outside where there is a clear view of the sky
above, with no obstructing buildings, trees, or other objects.
Note
xIf you experience signal reception problems, keep the
watch still and point its display straight up at the sky.
xWhile a receive operation is being performed, take care
to avoid covering the watch face with your sleeve.
xYou may experience GPS signal reception problems in
the areas described below.
-Where the view of the sky above is narrow
-Near trees or buildings
-Near a train station, airport, or other congested areas
xGPS signal reception is not possible in the areas described below.
-Where the sky is not visible
-Underground or in a tunnel
-Indoors (Reception may be possible near a window.)
-Near wireless communication equipment or other devices that generate magnetism

User’s Guide 5412 (OC)
E-19
Other: Power Saving; Low battery alert; Auto Correction of Hand Home Positions
Power Supply: Solar panel and one rechargeable battery
Approximately 7 months
Not exposed to light under the conditions below.
GPS time information receive: 1 operation (approximately 10 seconds) every 2 days
GPS position information receive: 1 operation (approximately 36 seconds)/month
E-18 C
Specifications
Accuracy at normal temperature: ±15 seconds a month (no adjustment by signal information)
Timekeeping : Hour, minutes, seconds, 24-hour, day, day of the week
Calendar system: Full Auto-calendar pre-programmed from the year 2000 to 2099
Other: Home City (Time Zone) and World Time City (Time Zone) can be assigned one of 40 time zones
and Coordinated Universal Time; Daylight Saving Time (summer time)/Standard Time auto
switching
Signal receive function: GPS signal auto receive, manual receive
Time calibration signal auto receive
Auto transmitter selection (for JJY, MSF/DCF77)
Receivable call signs: JJY (40 kHz/60 kHz), BPC (68.5 kHz), WWVB (60 kHz), MSF (60 kHz),
DCF77(77.5 kHz)
Last reception result display
Manual and auto standard time/summer time switching
Stopwatch: Measuring capacity: 23'59.95"
Measuring unit: 1/20 (0.05) seconds
Measuring modes: Elapsed time
E-17B
Using the Crown
xYou can change the following settings by operating the watch’s crown: World Time City (time zone),
Home City (time zone), summer time (DST), and current time.
xFor details about crown operations, see the Operation Guide available at the CASIO website.
http://world.casio.com/support/
Important!
xIn order to prevent loss of water resistance and damage due to impact, make sure that the crown is
fully pushed in to its normal position when using the watch.
E-16
Using the Watch in an Aircraft (Airplane Mode)
xSwitch to the Airplane Mode whenever you are inside an aircraft or in any other area where radio wave
reception is prohibited or restricted.
xEntering the Airplane Mode disables GPS signal and time calibration signal reception.
xWhile in the Timekeeping Mode, you can enter or exit the Airplane Mode by holding down Cfor at
least four seconds. If you are in another mode, the watch will enter the Timekeeping Mode about
two seconds after you hold down C. Keep the button depressed and the watch will enter or exit the
Airplane Mode.
Normal Timekeeping Airplane Mode
Mode hand
Hold down Cfor
4 seconds.
Mode hand
