1 Operating Manual
1.1General
Please read the information contained herein so that you can become familiar with your
device quickly and take advantage of the full scope of its functions.
Your Water Dispenser will serve you for many years if you handle it and care for it properly.
We wish you a lot of pleasure in using it!
1.2Information on this manual
These Operating Instructions are a component of the Water Dispenser (referred to hereafter
as the device) and provide you with important information for the initial commissioning,
safety, intended use and care of the device. The Operating Instructions must be available at
all times at the device. This Operating Manual must be read and applied by every person who
is instructed to work with the device:
● Commissioning ● Operation ● Troubleshooting and/or ● Cleaning
Keep the Operating Manual in a safe place and pass it on to the subsequent owner along
with the device.
1.3Warning notices
The following warning notices are used in the Operating Manual concerned here.
Danger
A warning notice of this level of danger indicates a potentially dangerous situation.
If the dangerous situation is not avoided, this can lead to death or serious injuries.
►Observe the instructions in this warning notice in order to avoid the danger of death or
serious personal injuries.
Warning
A warning notice of this level of danger indicates a possible dangerous situation.
If the dangerous situation is not avoided, this can lead to serious injuries.
►Observe the instructions in this warning notice in order to avoid the personal injuries.
Attention
A warning notice of this level of danger indicates a possible dangerous situation.
If the dangerous situation is not avoided, this can lead to slight or moderate injuries.
►Observe the instructions in this warning notice in order to avoid the personal injuries.
#

6
Please note
A notice of this kind indicates additional information, which will simplify the handling of the
machine.
1.4Limitation of liability
All the technical information, data and notices with regard to the installation, operation and
care are completely up-to-date at the time of printing and are compiled to the best of our
knowledge and belief, taking our past experience and findings into consideration.
No claims can be derived from the information provided, the illustrations or descriptions in
this manual. The manufacturer does not assume any liability for damages arising as a result
of the following:
•Non-observance of the manual •Uses for non-intended purposes
•Improper repairs •Technical alterations, modifications of the device
•Use of unauthorized spare parts
Modifications of the device are not recommended and are not covered by the guarantee.
All translations are carried out to the best of our knowledge. We do not assume any liability
for translation errors, not even if the translation was carried out by us or on our instructions.
The original German text remains solely binding.
1.5Copyright protection
This document is copyright protected. Caso Design USA LLC reserves all the rights, including
those for photomechanical reproduction, duplication and distribution using special processes
(e.g. data processing, data carriers, data networks), even partially.
Subject to content and technical changes.
2 Safety
This chapter provides you with important safety notices when handling the device.
The device corresponds with the required safety regulations. Improper use can result in
personal or property damages.
2.1Intended use
This device is only intended for use in households in enclosed spaces for
•Boiling water
Uses for a different purpose or for a purpose which exceeds this description are considered
incompatible with the intended or designated use.
Warning
Danger due to unintended use!
Dangers can emanate from the device if it is used for an unintended use and/or a different
kind of use.

7
►Use the device exclusively for its intended use.
►Observe the procedural methods described in this Operating Manual.
Claims of all kinds due to damages resulting from unintended uses are excluded. The User
bears the sole risk.
2.2General Safety information
Please note
Please observe the following general safety notices with regard to the safe handling of
the device.
►Read all instructions before using.
►Children shall not play with the appliance. Keep the appliance and its cord out of reach of
children.
►Cleaning and user maintenance shall not be made by children.
►Unplug the unit when not in use and before cleaning. Allow unit to cool before cleaning.
►Inspect the unit, its power cord and plug for any damage before using. If there appears to
be any damage or if the unit shows signs of malfunctioning, do not use the appliance.
Return the appliance to the nearest authorized service facility for inspection and repair.
►Only qualified electricians, who have been trained by the manufacturer, may carry out any
repairs that may be needed. Improperly performed repairs can cause considerable
dangers for the user.
►Only customer service departments authorized by the manufacturer may carry out repairs
on the device during the guarantee period, as otherwise the guarantee entitlements will be
null and void in the event of any subsequent damages.
►Defective components must always be replaced with original replacement parts. Only such
parts will guarantee that the safety requirements are fulfilled.
►Do not use accessory attachments that have not been recommended by the manufacturer.
►Do not use outdoors.
►Do not allow cord to touch hot surfaces or hang over sharp edges such as those on
countertops.
►Do not place the unit on or near a hot gas or electric burner, or heated oven.
►Always handle the appliance gently. Do not place it near the edge of the table or counter to
protect against the deform or function damage in case it falls down from the table
accidently.
►Do not use this appliance for any unintended use.
►SAVE THESE INSTRUCTIONS.

8
2.3Danger of burns
Warning
The water heated in the device and the device can become very hot.
Please observe the following safety notices in order not to burn or scald yourself or others.
►When boiling water, the device becomes hot.
►Do not touch the hot surface and not the spout when the device is in operation. Danger of
burns.
►Open the lid of the water tank slowly, to prevent scalding through the escaping steam.
►Always test the temperature of the water before you drink it.
►Pay attention to the hot water steam that is produced during cooking process. Risk of
burns.
2.4Dangers due to electrical power
Danger
Mortal danger due to electrical power!
Mortal danger exists when coming into contact with live wires or subassemblies!
Observe the following safety notices to avoid dangers due to electrical power:
►Do not dip the cable, device or plug into water or other liquid to prevent an electric shock.
►If the connection lead is damaged, you will need to have a special connection lead
installed by an authorized electrician.
►Do not operate this device if its power cable or plug is damaged, if it does not work
properly or if it is damaged or has been dropped. If the power cable is damaged, it will
need to be replaced by the manufacturer or his service agency or a similar qualified
person, to avoid any dangers.
►Do not open the housing on the device under any circumstances. There is a danger of an
electrical shock if live connections are touched and the electrical or mechanical structure is
altered. In addition, functional faults on the device can also occur.
3 Commissioning
This chapter provides you with important safety notices during the initial commissioning of the
device. Observe the following notices to avoid dangers and damages:
3.1Safety information
Warning
Personal and property damages can occur during commissioning of the device!
Observe the following safety notices to avoid such dangers:
►Packaging materials may not be used for playing. There is a danger of suffocation.

9
3.2Delivery scope and transport inspection
As a rule, the Water Dispenser is delivered with the following components:
● Water Dispenser ● Operation Manual ● Water filter
Please note
►Examine the shipment for its completeness and for any visible damages.
►Immediately notify the carrier, the insurance and the supplier about any incomplete
shipment or damages as a result of inadequate packaging or due to transportation.
3.3Unpacking
To unpack the device, proceed as follows:
Remove the device out of the carton and remove the packaging material.
3.4Disposal of the packaging
The packaging protects the device against damages during transit. The packaging
materials are selected in accordance with environmentally compatible and recycling-related
points of view and can therefore be recycled.
Returning the packaging back to the material loop saves raw materials and reduces the
quantities of accumulated waste.
Take any packaging materials that are no longer required to “Green Dot” recycling collection
points for disposal.
3.5Setup location requirements:
In order to ensure the safe and trouble-free operation of the device, the setup location must
fulfil the following prerequisites:
•The device must be set up on a firm, flat, horizontal surface with sufficient load-bearing
capacity for the HW 400.
•Place the device only on a water resistent surface.
•Do not use the device outdoors.
•Do not operate the product near hot gas or hot stove.
•Choose the setup location in such a way that children cannot reach the device.
•The device is not intended to be installed in a wall or a built-in cupboard.
•Do not set up the device in a hot, wet or extremely damp environment or near flammable
material.
•The electrical socket must be easily accessible so that the power lead can be
disconnected easily, in the case of an emergency.
•The installation and assembly of this device in non-stationary setup locations (e.g. on
ships) must be carried out by specialist companies / electricians, provided they guarantee
the prerequisites for the safe use of this device.
3.6Electrical connection
In order to ensure the safe and trouble-free operation of the device, the following instructions
must be observed for the electrical connection:

10
•Before connecting the device, compare the connection data (voltage and
frequency) on the rating plate with those of your electrical network. This data must agree in
order that no damages occur in the device. If in doubt, ask your qualified electrician.
•The electrical outlet must be protected by a 16A safety cut-out switch.
•Make sure that the power cable is undamaged and has not been installed
under the ice maker or over hot or sharp surfaces.
•The electrical safety of the device is only guaranteed if the device is connected
to a properly installed protective conductor system. Operations using an electrical outlet
without a protective conductor are prohibited. If in doubt, have the house installation
checked over by a qualified electrician.
The manufacturer cannot be made responsible for damages that are caused by a missing
or damaged protective conductor.
3.7 Overheating protection & reset
The appliance is equipped with an overheating protection
facility. If the temperature of the appliance exceeds the
critical limit the appliance shuts off further power supply for
safety reasons.
Remove the water tank. You can
see the reset button.
By pressing the reset button (1)
the appliance can be reactivated.
Unplug the device before reset.
When the device is only producing
cold water please press reset
button.
Please use enclosed reset-key for the reset-button.
4 Design and Function
In this chapter, you'll find important information on the design and function of the device.
4.1Overview
Warning
►Warning symbol: hot steam.
►Caution hot steam can escape at device. Risk of burns.

11
1 temperatur control dial
2 lid of watertank
3 watertank
4 body
5 foot
6 drip tray
7 cover of drip tray
8 spout
9 on/off switch
4.2Control panel
Set the desired temperature according to the scale between 000
(normal temperature water) and 212 °F
Switch the device ON, the lamp lights in green.
4.3Rating plate
The rating plate with the connection and performance data can be found beneath the device.
5 Operation and Handling
This chapter provides you with important notices with regard to operating the device. Observe
the following notices to avoid dangers and damages.
Warning
►Do not leave the appliance unsupervised during operation.

12
5.1Before initial use
1. Place the device in a safe location and plug it in.
2. Please do not use the filter at this moment yet.
3. Fill the water tank with approximately 4 cups of water.
4. Remove the drip tray.
5. Place a large bowl in front of the device so that it collects the water that runs out of the
spout.
6. Start the device with maximum temperature setting.
7. Switch the device off, when the lamp lights in red.
8. Remove the plug from the wall outlet and let the device cool down.
9. Refill the water tank again with fresh water. The device is now ready to use.
Filter
Warning
►The filter is only intended to filter tap water. Do not use water of unknown quality or that
has been microbiologically impaired.
1. Remove the filter from all packaging. There may be a small residue of black carbon
particles in the bag or adhering to the cartridge body. This is normal. These particles are
harmless and will be washed off during the preparation process.
2. Soak the filter upright in water for 10 min.
3. Rinse the filter under running water for 10 sec.
4. The filter is now ready for use.
Please note
►The lifetime of the filter lasts about 4-6 weeks of normal use (filtering of approximately 650
cups of water in total).
►Store the replacement filter cartridges in a cool location, out of direct sunlight and away
from heat sources.
5.2Use
1. Fill in water
1. Open the lid, fill the water tank with the desired amount of water.
2. Therefore you can also remove the water tank.
3. Close the lid.
Please note
►The water level must be less than the Max level and be at least at Min level.

13
2. Setting of Temperature
Plug in the power plug and place a cup or similar on the cover of drip tray. Then set the
desired temperature. Switch on the device, the lamp lights up in green.
The water is heated and flows into the cup. Switch the device off, when the desired amount of
water has been dispensed.
Please note
►If device was not used for long periods of time, there could be scale deposits despite water
filter. In this case let 4 fl oz with 212 °F run through the device.
►The ambient temperature changes everyday. This leads to different amounts of water. It
can vary up to +- 15%.
3. Water disposal from the drip tray
1. When the drip tray is full, grasp and stabilize the
appliance by one hand and use the other hand to
lift up the drip tray slightly to remove it.
2. Remove the cover of drip tray.
3. Empty the drip tray, replace cover of drip tray, and
insert it into the original place. Make sure it is
properly inserted.
4. Replacing the filter
1. Open the tank cover and take out the box with the filter.
2. Soak the filter upright in water for 10
min.
3. Rinse the filter under running water
for 10 sec.
4. Remove the old filter and replace it
with a new filter (see fig.). Take out
the filter box, place the new filter and
pull it down from the bottom.

14
1 lid of water tank
2 water tank
3 filter box
4 filter
6 Cleaning and Maintenance
This chapter provides you with important notices with regard to cleaning and maintaining the
device. Please observe the notices to prevent damages due to cleaning the device incorrectly
and to ensure trouble-free operation.
6.1Safety information
Attention
Please observe the safety instructions, before cleaning your device
►Unplug the device when not in use and before any cleaning.
►Never immerse the unit, cord or plug in water or other liquids and do not place in the
dishwasher.
►Do not use iron brush, abrasive cleaning agent or solvent , kitchen cleaner, or sharp
cleaning tool for cleaning.
6.2Cleaning
1. Remove the plug from the outlet and let the
device cool down.
2. To maintain the performance of the device,
descale the appliance at least once a month.
If you use a CASO water filter and change it
as regular as described in chapter 5.1 you do
not need to descale the appliance.
3. Please use a non-toxic detergent such as
citric acid. Add some citric acid into the water
and operate the appliance three times. The
scale will be removed. After that, pour out the
water in the water tank.
4. Do not clean the main machine. Only wipe it
with a damp cloth.
Drainage stopper
After cleaning the appliance, please take out the drainage stopper (A) in order to clean up
waste water. Put the drainage stopper back in after opening it. Make sure it is fastened
properly.

15
6.3Storage
If the appliance is not used frequently, unplug and clean it, then put back into the original
packing box to avoid that the electrical components from getting humidified or damaged.
7 Disposal of the Old Device
Old electric and electronic devices frequently still contain valuable materials.
However, they also contain damaging substances, which were necessary for
their functionality and safety.
If these were put in the non-recyclable waste or were handled incorrectly, they
could be detrimental to human health and the environment.
Therefore, do not put your old device into the non-recyclable waste under any circumstances.
Please note
►Utilize the collection point, established in your town, to return and recycle old electric and
electronic devices. If necessary, contact your town hall, local refuse collection service or
your dealer for information.
►Ensure that your old device is stored safely away from children until it is taken away.
8 Guarantee
12 Months Limited Warranty
Caso Design USA warrants that for a period of 12 months from the date of purchase, this
product will be free from defects in material and workmanship. Caso Design USA at its
option, will repair or replace this product or any component of the product found to be
defective during the warranty period. Replacement will be made with a new or
remanufactured product or component. If the product is no longer available, replacement
may be made with a similar product of equal or greater value. This is your exclusive
warranty. DO NOT attempt to repair or adjust any electrical or mechanical functions on this
product. Doing so will void this warranty.
This warranty is valid for the original retail purchaser from the date of the initial retail
purchase and is not transferable. Keep the original sales receipt. Proof of purchase is
required to obtain warranty performance.
This limited warranty does not cover normal wear of parts or damage resulting from any of
the following: negligent use or misuse of the product, use on improper voltage or current, use
contrary to the operating instructions, disassembly, repair or alteration by anyone other than
Caso Design USA service center. Further this limited warranty does not cover: Acts of God,
such as fire, flood, hurricanes and tornadoes.

16
What are the limits on Caso Design USA’s Liability?
Caso Design USA shall not be liable for any incidental or consequential damages caused by
the breach of any express, implied or statutory warranty or condition.
Except to the extent prohibited by applicable law, any implied warranty or condition of
merchantability or fitness for a particular purpose is limited in duration to the duration of the
above warranty.
Caso Design USA disclaims all other warranties, conditions, or representations, express
implied, statutory or otherwise.
Caso Design USA shall not be liable for any damages of any kind resulting from the
purchase, use or misuse of, or inability to use the product including incidental, special,
consequential or similar damages or loss of profits, or for any breach of contract, fundamental
or otherwise, or for any claim brought against purchaser by any other party.
Some provinces, states or jurisdictions do not allow the exclusion or limitation of the
incidental or consequential damages or limitations on how long an implied warranty lasts, so
the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary
from province to province, state to state, or jurisdiction to jurisdiction.
9 Technical Data
Device Instant Boiler Water Dispenser HW 400
Item No.: 11862
Mains data 120 V, 60 Hz
Power consumption 1800 Watt
Volume 68 fl oz
External measurements (W x H x D): 6.57“ x 12.05“x 10.7“
Net weight 4.49 lbs
