CASTLE PHOENIX EDGE ESC User manual

www.modellmarkt24.ch
EDGE ESC LOCK HARNESS AND KEY
Mounting
The socket my be
instlled through 
pnel or secured inside 
fuselge.
Wiring Diagram
Connect the white wire to the Aux Line (white wire) on
n Edge ESC.
Connect the red “+” wire to ny servo wire with  Y
hrness.
Warning
Edge Arm Lock mode is intended s 
secondry sfety device. It is not intended
to replce sfe prctices or creful hndling
of your RC power system, vehicle, nd
trnsmitter.
Edge Arm Lock is only opertionl if you
hve successfully configured the Edge ESC
using Cstle Link softwre.
Edge Arm Lock requires tht the AUX LIE
of the Edge ESC receives  voltge between
1.8V nd 8.4V to rm. Filure of the power
source (0 volts) will cuse the ESC to enter
Arm Lock mode.
Operation
Key in socket OR disconnected wire in socket hrness
= AR LOCKED.
A properly progrmmed nd wired Edge will be
incpble of rming when the key is in the socket.
If the key is plced in the socket or the rm lock socket
loses power, the ESC will go into  locked stte - even
if it is running.
Key removed + power to socket = AR ULOCKED. ESC
must receive low throttle signl to rm nd run.
www.modellmarkt24.ch

www.modellmarkt24.ch
ARM LOCK
SOCKET AND KEY
™
™
Before completing any of the
following steps, make sure
that the Edge ESC’s Aux line
mode is set to “Arm Lock
Key”. This setting can be
found on the “OTHER” tab in
the Castle Link software.
© 2013 Cstle Cretions, Inc. P/: 095-0230-00 Revision Dte - 03/2013
