Casual Home Lucia 646-4X User manual

Parts List
Hardware
Assembly Instruction
Item# 646-4X
Lucia Nightstand with USB Port
RF10052
Screw JCB M6x30
x 6
x 2
x 1
x 1
RF40170
Knob
RF40005
Allen Key
A
BC
A
B
C
Top
Left Panel
Right Panel
1 pc.
1 pc.
1 pc.
USB Adapter Specifications
Input Voltage AC 100-240V 50/60Hz
Input Current ≤350mA @ 220V AC w/ full load
Output Voltage 5.0V ± 0.25V
Load Regulation -0.5% (Max)
Output Current 3.1A Max
Output Ripple < 400mV p-p
Efficiency > 75% @ 220V AC
Output Plug USB Type A x 4
Over Power ≈17W @ 220V AC
Short Protection Auto Recovery
USB Port

Diagram 1.
RF10052
x 6
Diagram 2.
Step1:
Invert the Top (A) on a soft surface.
Attach Left (B) and Right Panel (C) into the Top (A)
by using screws (RF10052) as per diagram 1.
Step2:
Upright the unit. Attach the 2 Knobs (RF40170)
into the each front’s drawers as per diagram 2
.
A
C
B
RF40170
x 2
Step3:
Attach supplied AC cable from underneath
the table and plug into a standard wall
outlet. Unit is now ready to accept the
supplied 3-in-1 cable.
*After multiple devices are charged simultaneously,
please disconnect them in the reverse order.
USB 1 & 2 PORTS
Fast charging ports for devices that
require higher current, ideal for iPads
and Android tablets, while also
compatible with other mobile devices.
USB 3 & 4 PORTS
Standard USB ports, ideal for
smartphones and other mobile devices.
ON
OFF
1 2 3 4 i i G G
