Catalyst 210-R User manual

C O N T E N T S
01 – BILL OF MATERIAL
02 – REQUIRED TOOLS
03 – BUILD PREPARATION
04 – ASSEMBLY PROCESS
05 – OPTIONAL HD CAMERA MOUNT INSTALL
06 – LIPO INSTALLATION

SECTION 01
BILL OF MATERIAL

QUANTITY PART DESCRIPTION
1 Top Fuselage Plate (1.5mm CF)
1 Main Frame Plate (3mm CF)
1 FPV Camera Cage Top Plate (3mm CF)
2 FPV Camera Cage, Side Plate (1.5mm CF)
1 PDB Bay Cover Plate (1.5mm CF)
1 PDB Bay Guard (Black 3D Printed ABS Plastic)
1AntennaMount(Black 3D Printed TPU)
2 Antenna Tubes (Blue Plastic 1/8” Diameter)
1FPVCameraAdjustmentMount(Black 3D Printed ABS Plastic)
2 Standoff (Black aluminum M3 thread x 32mm long)
4 Standoff (Black aluminum M3 thread x 18mm long)
4 Standoff (Black aluminum M3 thread x 12.5mm long)
1 XT60 Passthrough Grommet (Black Rubber)
1 Velcro Lipo Strap – Catalyst Machineworks
1 FPV PRO Power Distribution Board – Catalyst Machineworks *If purchased your frame with PDB*
4 Flight Controller Hex Standoff (Black plastic M3 thread x 10mm long)
4 Flight Controller Nut (Black plastic M3 thread)
4 Flight Controller/FC Mount Screw (Black plastic M3 thread x 10mm long)
4 PDB Spacer (Black plastic M3 hole)
4 PDB Guard Inserts (Silver Aluminum M3 Hole x 4.5mm OD x 6mm long)
2 Antenna Mount Inserts (Silver Aluminum M3 Hole x 4.5mm OD x 5mm long)
2 FPV Camera Mount Adjustment Screw (Phillips head #4 x 3/8” long x stainless steel)
2 FPV Camera Mount Screws (Phillips head #2 x 3/8” long x stainless steel)
20 Washer (M3 x aluminum)
4 Socket Head Screw (M3 x 10mm long x blue 7075 aluminum)

8 Socket Head Screw (M3 x 8mm long x blue 7075 aluminum)
4 Socket Head Screw (M3 x 16mm long x blue 7075 aluminum)
2 Button Head Screw (M3 x 6mm long x blue 7075 aluminum)
2 Socket Head Screw (M3 x 12mm long x blue 7075 aluminum)
16 Socket Head Screw (M3 x 6mm long x blue 7075 aluminum)
4Nut(M3xblue 7075 aluminum)
2 Set Screw (M3 x 10mm long x steel)
1 GoPro Camera Mount (Black 3D Printed TPU) *Optional - Not Included. Sold separately*
1 Xiaomi Yi Camera Mount (Black 3D Printed TPU) *Optional - Not Included. Sold separately*
1 Mobius / Runcam Camera Mount (Black 3D Printed TPU) *Optional - Not Included. Sold separately*

SECTION 02
REQUIRED TOOLS

QUANTITY TOOL DESCRIPTION
1 File (not required but suggested)
1 Sandpaper (not required but suggested)
1 2mm allen driver or allen wrench
1 2.5mm allen driver or allen wrench
1 5.5mm socket driver
1 Small phillips head screw driver
1 Needle Nose Pliers
1 Open face wrenches (5.5mm) and (6.5mm), or adjustable
1 Loctite
3 Adult beverage of choice or apple juice if you are under 21

SECTION 03
BUILD PREPARATION

Build preparation involves rounding off the corners of the large interior 'PDB hole' in the main frame plate. This is not absolutely necessary to fly your
Speed Addict 210-R or 180-R, but it is highly recommended and standard practice among top builders and racers. Catalyst Machineworks carbon
fiber plate parts are cut by state of the art CNC machines. Cutting the raw material could leave a sharp edge on parts and it is possible this sharp
edge could rub against wiring insulation, resulting in wiring shorts against the frame. Rounding the edges is quite easy to do, but does take some time
as the process must be done with caution. Take your time and do it right, scratches on the flat surface will show. Keep that carbon fiber looking
good!
To round the edge of the carbon fiber simply take a file or sanding block and hold the sanding edge at a 45º angle to the sharp edge. Work the
sanding surface along the edge of the part until the sharp edge is gone. You want a smooth, rounded edge along the entire interior perimeter of
the hole. Below is a picture of the PDB hole.

SECTION 4
ASSEMBLY PROCESS

Note: This assembly manual applies to both the Speed Addict 210-R and 180-R. The 180-R has shorter arms and a
slightly shorter fuselage. Assembly steps will be identical.
STEP 1
Parts Required:
1 X Main Frame Plate (3mm CF)
8 X Socket Head Screw (M3 x 8mm long x blue 7075 aluminum)
2 X Standoff (Black aluminum M3 thread x 32mm long)
4 X Standoff (Black aluminum M3 thread x 18mm long)
2 X Standoff (Black aluminum M3 thread x 12.5mm long)
Assembly Process:
Join the standoffs to the Main Frame Plate as shown below. Use one screw per standoff.

STEP 2
Parts Required:
4 X Outrunner Brushless Motor (Sold Separately)
16 X Socket Head Screw (M3 x 6mm long x blue 7075 aluminum)
16 X Washer (M3 x aluminum)
Assembly Process:
Join your motors to the Main Frame Plate as shown below. Use 4 screws and 4 washers per motor. Included in your kit
are M3 screws for this purpose. But, the main frame plate will accept M2 screws for use on smaller 1806 or similar sized
motors. We do not include this size motor mount screw in your kit. You will need to source these on your own. Orient the
motor such that it's wire lead runs straight down the arm.

STEP 3
Parts Required:
4 X Electronic Speed Controller (Sold Separately)
Assembly Process:
Please note the ESC's are represented below by the blue rectangles. See our product page for ESC selection
requirements or email us for more information as to what ESC type is best for your 210-R/180-R build. Mount the ESC's
using double sized stick tape. Locate the ESC's so their interior edge is 7mm from the hole shown below. Soldier the
motor to the ESC. But, leave the positive and negative power leads uncut and unsoldiered at this step.
