Users’Manual for HG600 Mobile Humidity Generator
Turfschipper 114 | 2292 JB Wateringen | Tel. [phone] | www.catec.nl | [e-mail] 114 | 2292 JB Wateringen | Tel. [phone] | www.catec.nl | [e-mail]
MEETINSTRUMENTATIE

TM TM
ZOGLAB , HG are
Limited Warranty and Responsibilities
Guarantee that ZOGLAB products have no imperfection in its materials and workmanship within one year from the purchase date, but
the replaceable battery or the products damaged by accident, negligence, misuse, or application in unusual circumstances, are all not
included. The warranty period has not been extended for distributors specially from ZOGLAB. If any repairs are required within the
warranty period, please send defective devices together with the problem notice to the dealer you purchased from.
This warranty is the only compensation for you. Except this, ZOGLAB makes no express or implied warranties(eg. to guarantee the
suitability for a particular purpose). In no event shall ZOGLAB be liable for any special, indirect, incidental or consequential damages
or losses arising from any cause or conjecture. As certain regions or countries do not allow limitations on implied warranties and
incidental or consequential damages, the above scope of liability and provisions may not be relevant to you.
Special Note: Due to product upgrades or other reasons, the pictures in the manual, mechanical size and physical differences, please
in kind prevail. The document may not be allowed to be reproduced or transmitted in any form or by any means, including electronic
and mechanical, for any purpose, without the written permission of ZOGLAB. The Company reserves the right of final interpretation.
Marks Explanation
This mark contains the warning information, please read carefully to prevent equipment damage.
This mark refers to the function details, please read carefully before using the equipment.
registered trademarks of ZOGLAB Microsystem Co., Ltd. No any company or individual may reproduce or transmit in any form without
written permission.
China Patent Number: 201530567115.4 Appearance patent Counterfeiting not allowed
For more information, please visit our website http://www.zoglab.cn
All rights reserved Ripping not allowed 2002-2022 ZOGLAB Microsystem Co., Ltd

----------------------------------------------------------------- 5
------------------------------------------ 6
------------------------------------------------------------- 6
-------------------------------------------- 7
----------------------------------------------------- 8
------------------------------------ 9
-------------------------------------- 10
--------------------------------------------------- 10
---------------------------------- 11
------------------------------------- 12
------------------------------ 13
CHAPTER 1 Safety and Cautions
Safety and Cautions
CHAPTER 2 About HG600
--------------------------------------------------------- 2
Content
About HG600
Structure and Function Description
Overall View
Overall Function Description
Interface Area View
Interface Area Function Description
LCD Display and Function Description
Main Interface View
Main Interface Function Description
Humidity Function Interface View
Humidity Function Interface Description

---------------------------------------------- 14
------------------------------ 15
-------------------------------- 16
Graphic Interface View
Set Value Digital Soft Keyboard View
State/Set Value Line Interface View
----------------------------------------------- 21
---------------------------------------------------------------- 22
------------------------------------------- 23
-------------------------------------------------------- 24
-------------------------------------------------------------- 25
------------------------------------------------------------ 27
----------------------------------------------------------------------- 28
------------------------------------------------------------------ 29
-------------------------------------------------------- 30
--------------------------------------------- 31
----------------------------------------------- 32
----------------------------------------------- 33
CHAPTER 3 Operation and Application
Connect the Power Supply
Add Water
Insert the Test Humidity Probe
Replace Desiccant
Set Humidity
Power On/Off
Run
Program
Run Program
Analog Signal Measurement
Current Measurement
Voltage Measurement
----------------------------------------------- 31
------------------------------------------------------------- 32
----------------------------------------------------------------- 33
--------------------------------------------------------- 34
-------------------------------------------------------------- 35
------------------------------------------------------- 36
----------------------------------------------------------------- 37
----------------------------------------------------------- 38
-------------------------------------------------------------- 39
---------------------------------------------------------- 40
---------------------------------------------------------- 41
------------------------------------------------------------ 42
-------------------------------------------------------------------------- 43
CHAPTER 4 System Setting
Main System Setting Interface
Network Setting
Serial Setting
Calibration Setting
Control Setting
Storage Management
Time Setting
Brightness Setting
Sound Setting
Language Setting
System Information
System Upgrade
Help
CHAPTER 5 Product Information
Specification
Technical Specification
General Specification
--------------------------------------------------------------- 45
----------------------------------------------- 45
------------------------------------------------ 45

---------------------------------------------- 14
------------------------------ 15
-------------------------------- 16
Graphic Interface View
Set Value Digital Soft Keyboard View
State/Set Value Line Interface View
----------------------------------------------- 21
---------------------------------------------------------------- 22
------------------------------------------- 23
-------------------------------------------------------- 24
-------------------------------------------------------------- 25
------------------------------------------------------------ 27
----------------------------------------------------------------------- 28
------------------------------------------------------------------ 29
-------------------------------------------------------- 30
--------------------------------------------- 31
----------------------------------------------- 32
----------------------------------------------- 33
CHAPTER 3 Operation and Application
Connect the Power Supply
Add Water
Insert the Test Humidity Probe
Replace Desiccant
Set Humidity
Power On/Off
Run
Program
Run Program
Analog Signal Measurement
Current Measurement
Voltage Measurement
----------------------------------------------- 31
------------------------------------------------------------- 32
----------------------------------------------------------------- 33
--------------------------------------------------------- 34
-------------------------------------------------------------- 35
------------------------------------------------------- 36
----------------------------------------------------------------- 37
----------------------------------------------------------- 38
-------------------------------------------------------------- 39
---------------------------------------------------------- 40
---------------------------------------------------------- 41
------------------------------------------------------------ 42
-------------------------------------------------------------------------- 43
CHAPTER 4 System Setting
Main System Setting Interface
Network Setting
Serial Setting
Calibration Setting
Control Setting
Storage Management
Time Setting
Brightness Setting
Sound Setting
Language Setting
System Information
System Upgrade
Help
CHAPTER 5 Product Information
Specification
Technical Specification
General Specification
--------------------------------------------------------------- 45
----------------------------------------------- 45
------------------------------------------------ 45

------------------------------------------------------------------- 51
------------------------------------------------------- 46
------------------------------------------------------------ 47
------------------------------------------------------ 49
Product Dimensions
Packing Details
Quality Certifications
CHAPTER 6 Services
Warranty
Appendix
1. Communication Protocol
2. FAQ
CHAPTER 1
Safety and Cautions

------------------------------------------------------------------- 51
------------------------------------------------------- 46
------------------------------------------------------------ 47
------------------------------------------------------ 49
Product Dimensions
Packing Details
Quality Certifications
CHAPTER 6 Services
Warranty
Appendix
1. Communication Protocol
2. FAQ
CHAPTER 1
Safety and Cautions

23
Before installing and using this equipment, please read the chapter for instructions on
Safety and Cautions
Please use the equipment according to the rules in the manual, or the provided protection will be damaged and can
not be used in safety.
1. General Principle
Safety and Cautions
HG600 Mobile Humidity Generator is a precision instrument. Non-professional maintenance personnel of the company,
please do not conduct repair and modification. Due to man-made causes of equipment work abnormalities, damage or
indirect economic losses, the Company shall not be liable.
Check to confirm if follow the safety precaution. Before connecting the power supply and choosing the suitable
voltage in the fuse module, please confirm all the equipment are connected.
2. Before Connecting the Power Supply
The standard power cord for the instrument is a three-core power cord that connects the live, ground, and neutral
wires respectively. Interruption of the protection (ground protection terminal) connection will result in a potential
shock hazard and cause personal injury.
3. Connect the Equipment to the Ground
Do not use the device in the environment of explosion,inflammable gas, steam, smog. Working temperature
-10 °C~40 °C; Storage temperature -20 °C~70 °C; Maximum humidity 10%~95%RH (non-condensing). Do
not use the device beyond the working environment.
4. Working Environment
Only the qualified and trained professionals who know the potential risk can open the cover of device. Before
opening the device cover, be sure that the electricity is cut off.
5. Do not disassembly the cover of device
If not professional maintenance personnel from ZOGLAB, please do not do the maintenance, change components, or
do the adjustment for the device. If there is something wrong with the device, please contact the supplier for
repairing or changing.
6. Do not Adjust the Device
When the device is in malfunction or damage, please stop operation immediately and avoid misoperation, wait for
maintenance from serviceman.
7. Device Damage
If water inside the device by accident, please cut off the electricity immediately; if the device can not work normally,
please return it to the sales agency or the factory for maintenance.
8. Water Inside the Device
When the device is end of life, please send the e-waste back to us to support the electrical environmental protection.
9. WEEE Electrical Environmental Protection WEEE
CHAPTER 1 Safety and Cautions CHAPTER 1 Safety and Cautions

23
Before installing and using this equipment, please read the chapter for instructions on
Safety and Cautions
Please use the equipment according to the rules in the manual, or the provided protection will be damaged and can
not be used in safety.
1. General Principle
Safety and Cautions
HG600 Mobile Humidity Generator is a precision instrument. Non-professional maintenance personnel of the company,
please do not conduct repair and modification. Due to man-made causes of equipment work abnormalities, damage or
indirect economic losses, the Company shall not be liable.
Check to confirm if follow the safety precaution. Before connecting the power supply and choosing the suitable
voltage in the fuse module, please confirm all the equipment are connected.
2. Before Connecting the Power Supply
The standard power cord for the instrument is a three-core power cord that connects the live, ground, and neutral
wires respectively. Interruption of the protection (ground protection terminal) connection will result in a potential
shock hazard and cause personal injury.
3. Connect the Equipment to the Ground
Do not use the device in the environment of explosion,inflammable gas, steam, smog. Working temperature
-10 °C~40 °C; Storage temperature -20 °C~70 °C; Maximum humidity 10%~95%RH (non-condensing). Do
not use the device beyond the working environment.
4. Working Environment
Only the qualified and trained professionals who know the potential risk can open the cover of device. Before
opening the device cover, be sure that the electricity is cut off.
5. Do not disassembly the cover of device
If not professional maintenance personnel from ZOGLAB, please do not do the maintenance, change components, or
do the adjustment for the device. If there is something wrong with the device, please contact the supplier for
repairing or changing.
6. Do not Adjust the Device
When the device is in malfunction or damage, please stop operation immediately and avoid misoperation, wait for
maintenance from serviceman.
7. Device Damage
If water inside the device by accident, please cut off the electricity immediately; if the device can not work normally,
please return it to the sales agency or the factory for maintenance.
8. Water Inside the Device
When the device is end of life, please send the e-waste back to us to support the electrical environmental protection.
9. WEEE Electrical Environmental Protection WEEE
CHAPTER 1 Safety and Cautions CHAPTER 1 Safety and Cautions

5
CHAPTER 2
About HG600
About HG600
HG600 is a Two-flow Mobile Humidity Generator. Based on semiconductor thermostat and ultrasonic humidification fogging
technology, various humidity environment can be generated within the set temperature range. Built-in pump circulation and
mixing fan allow quick response to reach the set humidity value. Since its stabilization time is less than 10 minutes, HG600
can complete calibration and verification work in a short time.
Reasonable structural design can quickly respond and generate the required humidity stably with better uniformity.
CHAPTER 2 About HG600

5
CHAPTER 2
About HG600
About HG600
HG600 is a Two-flow Mobile Humidity Generator. Based on semiconductor thermostat and ultrasonic humidification fogging
technology, various humidity environment can be generated within the set temperature range. Built-in pump circulation and
mixing fan allow quick response to reach the set humidity value. Since its stabilization time is less than 10 minutes, HG600
can complete calibration and verification work in a short time.
Reasonable structural design can quickly respond and generate the required humidity stably with better uniformity.
CHAPTER 2 About HG600

67
Power interface
Power switch
Support handle
Connect power cable
Power on/off
Move main body of the device
LCD Main work screen, touch operation interface
Sealing buckle Open or close the traveling case
Communication/signal interface area Data communication/acquisition or signal generation
Explosion-proof traveling case
Fit 12/15/18mm diameter probe
Chamber cover
Water add/drain port Add water and drainage
①
②
③
④
⑤
⑥
⑧
⑨
⑦
Dryer chamber cover Open the dryer chamber to change dryer
10
11 Handle Move whole instrument
Protect instrument
Structure and Function Description
Overall View Overall Function Description
Component Name Functional Description S/N
CHAPTER 2 About HG600CHAPTER 2 About HG600
1
4
3
2
6
5
8
7
10
11
9

67
Power interface
Power switch
Support handle
Connect power cable
Power on/off
Move main body of the device
LCD Main work screen, touch operation interface
Sealing buckle Open or close the traveling case
Communication/signal interface area Data communication/acquisition or signal generation
Explosion-proof traveling case
Fit 12/15/18mm diameter probe
Chamber cover
Water add/drain port Add water and drainage
①
②
③
④
⑤
⑥
⑧
⑨
⑦
Dryer chamber cover Open the dryer chamber to change dryer
10
11 Handle Move whole instrument
Protect instrument
Structure and Function Description
Overall View Overall Function Description
Component Name Functional Description S/N
CHAPTER 2 About HG600CHAPTER 2 About HG600
1
4
3
2
6
5
8
7
10
11
9

8
COMMUNICATION
SIGNAL
0~1V
4~20mA
7
5
4
23
1
COM1 COM2 USB LAN
TX D
RX D
SGND
TTL-T
TT L- R
24V
5V
GND
A
B
6
①
②
③
④
⑤
⑥
⑦
9
COM1 Digital probe communication interface, support RS232/RS485
USB-A
USB-B
LAN
0~10V measuring interface Connect 0~10V output probe
4~20mA measuring interface Connect 4~20mA output probe
USB-A communication interface supports data export
USB-B type communication interface supports upper computer communication
Ethernet communication interface
COM2 Upper computer communication interface, support RS232/RS485
Interface Area View Interface Area Function Description
Component Name Functional Description S/N
CHAPTER 2 About HG600CHAPTER 2 About HG600

8
COMMUNICATION
SIGNAL
0~1V
4~20mA
7
5
4
23
1
COM1 COM2 USB LAN
TX D
RX D
SGND
TTL-T
TT L- R
24V
5V
GND
A
B
6
①
②
③
④
⑤
⑥
⑦
9
COM1 Digital probe communication interface, support RS232/RS485
USB-A
USB-B
LAN
0~10V measuring interface Connect 0~10V output probe
4~20mA measuring interface Connect 4~20mA output probe
USB-A communication interface supports data export
USB-B type communication interface supports upper computer communication
Ethernet communication interface
COM2 Upper computer communication interface, support RS232/RS485
Interface Area View Interface Area Function Description
Component Name Functional Description S/N
CHAPTER 2 About HG600CHAPTER 2 About HG600

10
Function operation area
Shortcut keys
Set value display area
11
Device Information line Display Bluetooth, WiFi, battery, instrument name, current year, month, date and Time
Reference display area
Status line
Set value display area
Function operation area
Shortcut keys
Displays the humidity and temperature values of the built-in reference
Display target humidity and temperature control value; click this area to input target value
Program and start operations
The shortcut keys from left to right are: [storage key] to check the storage status;
[lock key] to lock the current humidity value; [screenshot key] to intercept the current
screen; [day/night switch key] for day and night mode switch; [set key] to enter the
system setting; [screen lock key] to prohibit touch screen operation
Display start, configuration, and other status information
Device Information line
LCD Display and Function Description
Main Interface View Main Interface Function Description
Component Name Functional Description
CHAPTER 2 About HG600CHAPTER 2 About HG600
Reference display area
Status line

10
Function operation area
Shortcut keys
Set value display area
11
Device Information line Display Bluetooth, WiFi, battery, instrument name, current year, month, date and Time
Reference display area
Status line
Set value display area
Function operation area
Shortcut keys
Displays the humidity and temperature values of the built-in reference
Display target humidity and temperature control value; click this area to input target value
Program and start operations
The shortcut keys from left to right are: [storage key] to check the storage status;
[lock key] to lock the current humidity value; [screenshot key] to intercept the current
screen; [day/night switch key] for day and night mode switch; [set key] to enter the
system setting; [screen lock key] to prohibit touch screen operation
Display start, configuration, and other status information
Device Information line
LCD Display and Function Description
Main Interface View Main Interface Function Description
Component Name Functional Description
CHAPTER 2 About HG600CHAPTER 2 About HG600
Reference display area
Status line

12
Temperature measured value
Add Water
Set value
Start/Stop
Program
Humidity control progress
Standard measured value
Status line
13
Status line
Humidity control progress Display the relative difference between the current measured humidity value and the set value
Reference measured value Display the measured humidity value
Temperature measured value Display the measured temperature value
Start/Stop Start and stop operations
Program Conduct program control, setting step and holding time for easy readings; setting
calibration points, stabilization time and error judgments for automatic calibration
Add Water Click this button to add water; long press this button to pop up the drainage operation
reminder to perform drainage operation
Set value Display target humidity control value; click this area to enter target value
Display start, configuration, and other status information
Humidity Function Interface View
The upper part of the main interface is the humidity function interface.
Component Name Functional Description
Humidity Function Interface Description
CHAPTER 2 About HG600CHAPTER 2 About HG600
Voltage
Current Measuring current
Measuring probe

12
Temperature measured value
Add Water
Set value
Start/Stop
Program
Humidity control progress
Standard measured value
Status line
13
Status line
Humidity control progress Display the relative difference between the current measured humidity value and the set value
Reference measured value Display the measured humidity value
Temperature measured value Display the measured temperature value
Start/Stop Start and stop operations
Program Conduct program control, setting step and holding time for easy readings; setting
calibration points, stabilization time and error judgments for automatic calibration
Add Water Click this button to add water; long press this button to pop up the drainage operation
reminder to perform drainage operation
Set value Display target humidity control value; click this area to enter target value
Display start, configuration, and other status information
Humidity Function Interface View
The upper part of the main interface is the humidity function interface.
Component Name Functional Description
Humidity Function Interface Description
CHAPTER 2 About HG600CHAPTER 2 About HG600
Voltage
Current Measuring current
Measuring probe

Graphic Interface View
Display of the humidity curve
Humidity low limit
Humidity high limit
Number key
ESC (back key)
Delete key
Enter key
Control the humidity low limit. The humidity low limit can be changed by “pressure limit” in the control parameter.
Control the humidity high limit. The humidity high limit can be changed by “pressure limit” in the control parameter.
Number input keys
For canceling, exiting, returning and other operation controls.
Delete a character.
Confirm the current input value.
Remind state When the input target humidity value exceeds the high and low limits, the red bottom will appear for reminder.
Humidity low limit
Number key
Humidity high limit
ESC (back key)
Delete key
Enter key
Remind state
Set Value Digital Soft Keyboard View
Component Name Functional Description
14 15
Min:5Max:90
