PRODIGI
INSTALLATION, OPERATION AND MAINTENANCE MANUAL
Instruction manual
WARNING: Improper use of the system and its components can cause damage to property or persons.
WARNING: before use, carefully read the following user manual.
WARNING: through the interface devices available to the user it is possible to carry out only data
consultation activities, and it is not possible to carry out any configuration.

INSTALLATION GUIDE
2
Rev. 0/ 14-07-2020
Since1949,the CavagnaGroup hassupplied theworldwidegas controlindustry
with products of superior quality and value.
Ournewcomprehensivecatalogfeaturesacomplete lineofproductsand
accessories for the LPG gas containers.
Cavagna is a registered trademark.
© Copyright 2019 Cavagna North America, Inc.
TheCavagna Group began operationin1949 inNorthern Italy andcontinuesto growtoday.Sinceitsorigin, the
Group has become a world leader in the forging and machining of brass and stainless steel.
ForoverseventyyearstheGrouphassuppliedsafeproductsofsuperiorqualityandvalue.Technologicaladvancement
and sophisticatedworkingprocedureshaveallowedustorapidlycreatenewproductsandsolutionsforthegascontrol
industry.
The Cavagna Group produces a wide range ofproductsmeetinginternationalstandards including:
LPG Valves, Equipment and Regulators
Engineering and Services dedicated to the LPG industry
NaturalGasregulators fordomestic,commercial andindustrial useandmetering
ASME, Fork Lift, and Motor Fuel Tank Valves
Compressed Gases Cylinder Valves
Refrigeration Cylinder Valves
Regulation Equipment for Industrial Gases
Regulation Equipment for Medical Gases
Comprehensive Range of Welding and Cutting Equipment
CNG - AUTOGAS cylinder and filling valves
CNG - AUTOGAS systems
LPG Powered Equipment
Gas Meters
The Group’s design engineers and laboratory technicians closely cooperate with worldwide regulatory institutions,
both in the writingofinternationalperformance standardsandinthecreationofnew products.InNorth Americaour
products are recognized by AGA, ASME, CGA, IAS, and UL as conforming to ANSI, NFPA and other recognized
standards.
The Cavagna Group of companies has invested heavily in personnel, individual training, and robotic technology to
meet the quality standards required by our customers and the 145 countries we serve. With the establishment of
Cavagna North America in 1996 and our North American Distribution Center on the West Coast, we have further
expanded our service network to meet the demands of the globalmarketplace.
Our philosophy is to provide all of our customers with quality products, continuous innovation and superior service
in a competitive environment.

INSTALLATION GUIDE
3
Rev. 0/ 14-07-2020
Contents
IMPORTANT SAFETY AND COMPLIANCE INFORMATION .................................................................................. 4
USA, FCC, Part 15 spectrum compliance ....................................................................................................... 4
Canada, ISED spectrum compliance .............................................................................................................. 5
RF Exposure (FCC/ISED)................................................................................................................................. 5
Electromagnetic compatibility....................................................................................................................... 6
Intrinsic safety ............................................................................................................................................... 6
Lithium battery.............................................................................................................................................. 6
Transportation classification ......................................................................................................................... 6
Electrostatic discharge .................................................................................................................................. 6
Electrostatic ignition hazard.......................................................................................................................... 7
Device cleaning.............................................................................................................................................. 7
Do not drop ................................................................................................................................................... 7
Safety............................................................................................................................................................. 7
Product notification....................................................................................................................................... 7
INTRODUCTION ................................................................................................................................................. 9
SEALING AND ANTI-FRAUD.............................................................................................................................. 10
OPERATION...................................................................................................................................................... 12
SAFETY ............................................................................................................................................................. 14
INSTALLATION AND ACTIVATION (only utility)................................................................................................ 15
BUTTONS AND DISPLAY USE (utility and user)................................................................................................ 19
BATTERY MAINTENANCE (utility only)............................................................................................................. 24
SHUT-OFF VALVE ............................................................................................................................................. 27
MARKING AND TECHNICAL CHARACTERISTICS ............................................................................................... 29
DECLARATION OF CONFORMITY AND HARMONISED STANDARDS................................................................. 31

INSTALLATION GUIDE
4
Rev. 0/ 14-07-2020
IMPORTANT SAFETY AND COMPLIANCE INFORMATION
This section provides important information for your safety and product compliance.
USA, FCC, Part 15 spectrum compliance
This device complies with Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
Operation is subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference that may cause undesirable operation.
This device must be installed to provide a separation distance of at least 7.9 inches (20 centimeters) from all
persons to be compliant with regulatory RF exposure.
USA, FCC Class B-Part 15
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio or TV technician for help.
Modifications and Repairs
To ensure system performance, this device and antenna shall not be changed or modified without the express
approval of Mesura Metering. Per FCC rules, unapproved modifications or operation beyond or in conflict
with these instructions for use could void the user's authority to operate the equipment.
Comentado [GA1]: The part of compliance to american
Standards has to be verified by CNA

INSTALLATION GUIDE
5
Rev. 0/ 14-07-2020
Canada, ISED spectrum compliance
Compliance Statement Canada
This device complies with Innovation, Science and
Economic Development Canada (ISED) license-
exempt RSS standard(s). Operation is subject to
the following two conditions: (1) this device may
not cause interference, (2) this device must accept
any interference, including interference that may
cause undesired operation of the device.
Under Innovation, Science and Economic
Development Canada (ISED) regulations, this radio
transmitter may only operate using an antenna of
a type and maximum (or lesser) gain approved for
the transmitter by Industry Canada. To reduce
potential radio interference to other users, the
antenna type and its gain should be so chosen that
the equivalent isotropically radiated power
(e.i.r.p.) is not more than that necessary for
successful communication.
Dèclaration de Conformitè
Le présent appareil est conforme aux CNR
d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée
aux deux conditions suivantes: (1) l'appareil ne
doit pas produire de brouillage, (2) l'utilisateur de
l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le
fonctionnement.
Conformément à la réglementation d'Industrie
Canada, le présent émetteur radio peut
fonctionner avec une antenne d'un type et d'un
gain maximal (ou inférieur) approuvé pour
l'émetteur par Industrie Canada. Dans le but de
réduire les risques de brouillage radioélectrique à
l'intention des autres utilisateurs, il faut choisir le
type d'antenne et son gain de sorte que la
puissance isotrope rayonnée équivalente (p.i.r.e.)
ne dépasse pas l'intensité nécessaire à
l'établissement d'une communication
satisfaisante.
RF Exposure (FCC/ISED)
This equipment complies with radiation exposure
limits set forth for an uncontrolled environment.
This equipment should be installed and operated
with minimum distance 20 cm between the
radiator and your body. This transmitter must not
be co-located or operating in conjunction with any
other antenna or transmitter.
Cet équipement est conforme aux limites
d'exposition aux radiations dans un
environnement non contrôlé. Cet équipement do
it être installé et utilisé à distance minimum de 20
cm entre le radiateur et votre corps. Cet émetteur
ne doit pas être co-localisées ou opérant en
conjonction avec tout autre antenne ou
transmetteur.

INSTALLATION GUIDE
6
Rev. 0/ 14-07-2020
Electromagnetic compatibility
Caution: Use only approved accessories with this equipment. All cables must be high quality,
shielded, and correctly terminated. Unapproved modifications or operation beyond or in
conflict with these use instructions may void the authority's authorization to operate the
equipment.
Intrinsic safety
Warning: Substitution of components may impair intrinsic safety.
Lithium battery
Warning: Follow these procedures to avoid injury to yourself or others.
•The lithium battery may cause a fire or chemical burn if it is not disposed of properly.
•Do not recharge, disassemble, heat above 212°Fahrenheit (100°C Celsius), crush, expose to
water, or incinerate the lithium battery. Fire, explosion, and severe burn hazard.
•The battery used in this device may present a risk of fire or chemical burn if mistreated.
•Keep the lithium battery away from children.
Transportation classification
The Federal Aviation Administration prohibits operating transmitters and receivers on all commercial aircraft.
When powered and not in Factory ship mode, the Mesura Metering device is considered an operating
transmitter and receiver and cannot be shipped by air. All product returns must be shipped by ground
transportation.
Electrostatic discharge
Warning: Internal circuit components can be sensitive to electrostatic discharge.
Before installation, discharge electrostatic buildup by touching a metal pipe or other
earth-grounded metal object prior to touching the meter body, register housing, or
Mesura device.

INSTALLATION GUIDE
7
Rev. 0/ 14-07-2020
Electrostatic ignition hazard
Warning: Verify the area is not hazardous when installing, servicing, cleaning, or touching the
device.
Device cleaning
Warning: Clean only with a damp cloth.
Do not drop
Warning: While Mesura Metering meters are designed to withstand a drop, dropping the
meter may damage the device, impact the meter accuracy, and void the warranty.
Safety
The PRODIGI is an intrinsically safe object suitable for use in hazardous areas ………. The minimum installation
category is ………. The relevant UL standards for compliance with the EHSR (Essential Health and Safety
Requirement) requirements of the………….
Electrostatic discharges
This device is approved for installations in areas with a low risk of explosion (risk only for short periods). In
these areas, sparks produced by electrostatic discharges could still in extreme cases produce explosions. Even
if during normal operations there are no dangerous potentials on the apparatus, the use of dissipative socks
and a damp cloth (% > 65%) is required during installation/maintenance operations. Further information can
be found in ULxxxxxx.
Mesura Metering SRL declines all responsibility for the risks and consequences arising from non-compliance
with these requirements.
Product notification
Warning: These instructions are not intended to replace any utility or company- established meter
installation procedures. These instructions are provided for additional information when the Mesura meter
is installed. The meter installation must comply with all country, state, and local building and safety
regulations as well as federal regulations including the National Fire Protection Association (NFPA) Phamplets
54 and 58, including pertinent paragraphs of the codes are:
Each meter and service regulator, whetever inside or outside of a building must be in a readily
accessible location and be protected from corrosion and other damage.
Comentado [GA2]: This paragraph can be ceompleted
only after UL certification

INSTALLATION GUIDE
8
Rev. 0/ 14-07-2020
Each meter installed within a building must be located in a ventilated place and not less than 3 feet
from any source of ignition or any source of heat which might damage the meter.
The Gas Meter is rated for the following operating and storage temperature ranges. Use of the meter outside
of the listed temperature ranges is not recommended.
Operating ranges:
-Measurement -22° F (-30° C) to +131° F (55° C)
-Valve -13° F (-25° C) to +131° F (55° C)
Storage range:
--40° F (-40° C) to +158° F (70° C)
Direct customer inquiries as to the selection and application of gas meters to your local Cavagna Group sales
representative or Cavagna Group Support.
Cavagna Group does not endorse or warrant the completeness or accuracy of any third-party meter
installation procedures or practices, unless otherwise provided in writing by Cavagna Group.
Follow your company's standard operating procedures regarding the use of personal protection
equipment (PPE).
Adhere to guidelines issued by your company in addition to those given in this document when
installing or providing maintenance to the meters.
This product, as of the date of manufacture, is designed and tested to conform to all governmental
and industry safety standards as they may apply to the manufacturer.
The purchaser and user of this product must comply with all fire control, building codes, and other
safety regulations governing the application, installation, operation, and general use of this meter to
avoid leaking gas hazards resulting from improper installation, start-up, or use of this product.
To ensure safe and efficient operation of this product, Cavagna Group strongly recommends
installation by a qualified professional.
Comentado [GA3]: To be verified with UL

INSTALLATION GUIDE
9
Rev. 0/ 14-07-2020
INTRODUCTION
The PRODIGI family of products is designed to measure the volume of gas of the second or third family (UNI
EN 437) at a maximum working pressure of 7.2 psi, and a maximum flow rate of up to 211,8 ft3/h. The meter
is equipped with an ultrasonic measuring sensor, the performance is ensured by two lithium batteries
(described in the chapter "BATTERY MAINTENANCE"). The device, besides the volume measurement, allows
the remote reading and the remote control of the gas flow without the aid of external devices, but by means
of different transmission technologies that are indicated below. This document provides information on the
characteristics and use of the device, and is valid for all members of the family of PRODIGI products.
It is specified that the models listed below are identical from the point of view of construction, what varies
is the calibration procedure to which they have been subjected. Specifically, all four models PRODIGI,
PRODIGI 16, PRODIGI 25, PRODIGI 40 are intended exclusively for the measurement of natural gas (methane),
and differ only for the calibrated flow range.
While the PRODIGI LPG model is calibrated exclusively for the measurement of all types of LPG mixtures.
The different models differ in the following characteristics:
-Measured flow range
-Measured gas family
And they are classified according to the following scheme:
FORMAT -> PRODIGI XX
Here are the different models available:
XX -> identifies the measured flow range:
-PRODIGI16 -> 0,016 ÷ 2,5 m3/h (ex G16), NATURAL GAS
(Calibrated to measure from 0,016 m3/h to 2,5 m3/h, intended for natural gas measurement)
-PRODIGI 25 -> 0,025÷ 4 m3/h (ex G25), NATURAL GAS
(Calibrated to measure from 0,025 m3/h to 4 m3/h, intended for natural gas measurement)
-PRODIGI 40 - > 0,04÷ 6 m3/h (ex G40), NATURAL GAS
(Calibrated to measure from 0,04 m3/h to 6 m3/h, intended for natural gas measurement)
-PRODIGI -> 0,016÷ 6 m3/h, NATURAL GAS
-(Calibrated to measure from 0,016 m3/h to 6 m3/h, intended for natural gas measurement)
-PRODIGI LPG -> 0,016÷ 6 m3/h, LPG
-(Calibrated to measure from 0,016 m3/h to 6 m3/h, intended for the measurement of any type of LPG
mixture)
These models can be supplied with one of the following transmission technologies:
-NBIoT / LTE
-LoRa 915 MHz
Comentado [GA4]: 7.2 psi or 5 psi? To be defined with UL
Comentado [GA5]: 211 ft3/h or 254 ft3/h? to be defined
with UL

INSTALLATION GUIDE
10
Rev. 0/ 14-07-2020
SEALING AND ANTI-FRAUD
WARNING: Access to the electronics is not possible without the removal of a mechanical seal
(manufacturer seal).
WARNING: Do not damage or remove any type of seal/adhesive. In case of removal or damage, the meter
will loose its warranty and will have to undergo a new verification.
WARNING: Access to the battery will be intercepted and recorded in the gas meter register
WARNING: Attempts to tamper, the correct operation of the meter, it will be intercepted and recorded
in the gas meter register.
WARNING: Attempts to access the meter through the communication channels, by unauthorized
personnel are intercepted and recorded in the gas meter egister.
WARNING: Attempts to access the meter through communication channels made with incorrect
passwords or encryption keys are intercepted, listed and made available to the control center.
The seal is represented by the figure below:

INSTALLATION GUIDE
11
Rev. 0/ 14-07-2020
SEALING PLAN
Sealing with safety cap (not removable after insertion):

INSTALLATION GUIDE
12
Rev. 0/ 14-07-2020
OPERATION
The meters of the PRODIGI family are composed of:
1) A metal casing (stainless steel), which contains the following elements:
-Measuring sensor
-Flow shut-off valve
-Temperature sensor
2) A plastic casing:
-Management electronics and interface
-Data transmission module
-Power supply batteries ( 1 replaceable for communication, and 1 not replaceable for metrology)
1
2

INSTALLATION GUIDE
13
Rev. 0/ 14-07-2020
DATA MEASUREMENT AND RECORDING
The measurement is acquired through an ultrasonic sensor (static sensor), this is then processed by the
control electronics, saved in the volatile memory of the meter and sent to the gas company via the
transmission protocol.
The meters of the PRODIGI family are also equipped with a non-volatile memory on which the data is
recorded at a regular interval of 60 minutes.
PRODIGI meters implement the following services:
-Dynamic multi-tariff capacity
-Measurement and load profiles
-Data collection and recording
As far as data recording is concerned, the PRODIGI meters implement the following services:
-Detection and reporting of faults
-Functional requirements - Event logging
-Functional requirements - Diagnostics and alarms
DATA TRANSMISSION
The meters of the PRODIGI family are equipped with two communication interfaces, one local and one
remote.
LOCAL: The meter is equipped with an optical port according to EN 62056-21, and requires an external device
(Probe Zvei). The optical port is normally switched off, for activation follow the instructions in the chapter
"INSTALLATION AND ACTIVATION".
REMOTE: One of the following three types of communication aids can be mounted on the meter:
-NBIoT / LTE
-LoRa 915 MHz
BATTERIES
(Read chapter "BATTERY MAINTENANCE")
FLOW SHUT-OFF VALVE
(Read chapter "INTERCEPTING VALVE")

INSTALLATION GUIDE
14
Rev. 0/ 14-07-2020
SAFETY
-The PRODIGI is an intrinsically safe object suitable for use in hazardous areas ULxxxx. The
minimum installation category is ULxxxx. The relevant UL standards for compliance with the
EHSR (Essential Health and Safety Requirement) requirements of the ULxxxx. This equipment
is designed to comply with the requirements of the type of protection ULxxxx, ambient
temperature range -22° F (-30° C) to +131° F (55° C) and UL category xxxx.
ELECTROSTATIC DISCHARGES
This device is approved for installations in areas with a low risk of explosion (risk only for short periods). In
these areas, sparks produced by electrostatic discharges could still in extreme cases produce explosions. Even
if during normal operations there are no dangerous potentials on the apparatus, the use of dissipative socks
and a damp cloth (% > 65%) is required during installation/maintenance operations. Further information can
be found in ULxxxx.
During the installation or use of this instrument, it is advisable to implement protective
measures against electrostatic discharges.
Mesura Metering SRL declines all responsibility for the risks and consequences arising from non-compliance
with these requirements.
Comentado [GA6]: To be completed after UL certification
Comentado [GA7]: To be verified with UL
Comentado [GA8]: Must be compliant to UL standard

INSTALLATION GUIDE
15
Rev. 0/ 14-07-2020
INSTALLATION AND ACTIVATION (only utility)
CONNECTION TO THE PLANT
The meters of the PRODIGI family is suitable for installation in hazardous area classified ULxxx:
WARNING: POTENTIAL RISK OF ELECTROSTATIC CHARGES
The meters of the PRODIGI family answer to the requests of protection type: ULxxxx classification.: For use
in zone ? atmospheres therefore safe in case of interference-free operation.
Here are the dimensions of the meters of the PRODIGI family:
Comentado [GA9]: To be completed after UL certification

INSTALLATION GUIDE
16
Rev. 0/ 14-07-2020
MECHANICAL INSTALLATION
Warning: This product, as of the date of its manufacture, is designed and tested to conform to all
governmental or industry safety standards then existing as they may apply to the manufacturer. The
purchaser and user of this product are warned that compliance with all country, state, and local
codes required in order to avoid the hazards of leaking gas resulting from improper installation, start-
up, or use of this product, and further, that all fire control, building codes, or other safety regulations
established under public laws which regulate or govern the application, installation, operation, or
general use of this product, should be complied with. In order to ensure the safe and proper
operation of this product, the manufacturer recommends that a qualified technician following NFPA
54 standards to install this product such as:
-Where they are not subjected to damage, such as adjacent to a driveway, under a fire escape,
in public passages, in coal bins, or where they will be subject to excessive corrosion or
vibration.
-Where they are not subjected to extreme temperatures, sudden extreme temperature
changes, or temperatures beyond those recommended by the manufacturer.
-In ventilated spaces readily accessible for examination, reading, replacement, or
maintenance.
WARNING: For proper use and safe operation, pay close attention to and follow the following
instructions when installing the device:
-The PRODIGI device must be connected to the system. Before connecting, make sure that at
least the section of the system upstream of the meter has been intercepted and therefore
there is no gas supply during the installation phase;
-Before connection, make sure that the maximum pressure of the system is lower than the
maximum pressure foreseen by the meter, which is fixed and equal to 7.2 psi;
-If necessary, use fittings to connect PRODUCTS to the pipeline (not supplied).
-When tightening the fittings, do not exceed a torque of 110Nm;
-PRODIGI only operates in a vertical position;
-PRODIGI is supplied with the shut-off valve in the "open" state for which it is ready to
dispense and measure the gas.
-Check that the customer's utilities are closed.
-Slowly load the PRODUCT with the pressure.
-After checking the tightness, slowly remove pressure from the PRODIGI meter.
Once the leak test has been successfully completed, the meter is ready for use.
Comentado [GA10]: 7.2 psi or 5 psi? To be defined with
UL

INSTALLATION GUIDE
17
Rev. 0/ 14-07-2020
ACTIVATION AND CONFIGURATION
1-ACTIVATION PORT OPTICS METER
Use the right button to move to the D screen of the display.
Press and hold the left button for 5 seconds until the icon appears.
2 - COMPILATION OF CONFIGURATION FIELDS
Optionally, the utility that installs the meter, has the ability to set the following parameters:
-Time zone
-Date of commencement of daylight saving time
-Date of end of daylight saving time
-Deviation applied to daylight saving time
-Enabling daylight saving time
-Date/Time
3- STATUS CONFIGURATION
Once you have entered the information listed in the previous point, you can confirm what
you have entered by means of a special command.
Confirmation of the configuration data generates an automatic change in status from NOT
CONFIGURED to NORMAL.
4- AFFILIATION
the Operation through a special command will send a dedicated data packet (data packet
pre-set in the software) to the concentrator, this will send the response to the meter, which
once received will be affiliated.
5- DEACTIVATION OF THE OPTICAL PORT
The optical port is automatically deactivated.

INSTALLATION GUIDE
18
Rev. 0/ 14-07-2020

INSTALLATION GUIDE
19
Rev. 0/ 14-07-2020
BUTTONS AND DISPLAY USE (utility and user)
PRODIGI has a user interface composed as follows:
-2 Capacitive buttons (Key A, Key B)
-One LCD display
Keyboard
For simplicity, we indicate with A, the left button and with B, the right button.
Button A: Enter
Button B:
-Pressure maintained for 3 seconds: Power on Display
-Single pressure: Screen feed
A
\
B

INSTALLATION GUIDE
20
Rev. 0/ 14-07-2020
Display
The display is a custom black and white LCD.
The display is switched on by pressing the right button (B) for 3 seconds. The display switches off
automatically after 20 seconds of inactivity.
Each screen is identified by a letter or a combination of letters among those identified by a red box in the
figure (Menu identifiers).
On each screen, if any, numerical values are displayed using 8 digits with 7 segments identified by a blue
frame in the figure. The unit of measurement of the displayed value is indicated by the symbols highlighted
in the green box.
There are also icons for signals and alarms identified by the orange box in the figure.
The symbols on the display for each group described above are detailed below
MENU
identifier
Description
Format
Unit of
measurement
Notes
T
Totalizer of volumes
5 full digits and 3
decimals
ft3
ID
Identification of
measuring point
14 numeric characters
(displayed with 7
scrolling
digits)
MENU identifiers
Numerical value
Unit of
Icons
Icons
