CB Tech CB-As User manual

Installation Guide
CB-As
About the CB-As Drinking Water System
• The CB Tech CB-As Drinking Water System (CBAS) is designed for use
on the countertop next to the sink, below the sink, or inline with other
devices.
• If installation or operation assistance is required, please contact your
Dealer. If Dealer is unavailable, please contact CB Tech at 866.622.9373.
Before You Begin
Please read this manual before proceeding with the installation and use
of your system. Installation, operation, and maintenance requirements are
essential to the performance of your system – failure to follow any instructions
or operating parameters contained herein may lead to product damage
or product failure.
1

• Replacement lters can be purchased directly from your Dealer.
• Check for compliance with any state or local laws and regulations
before use.
• If you are installing with a Below Sink Kit (CBK1), proceed to section
Below Sink Installation (Pg 2).
• If you are installing with a Countertop Kit (CBK2), proceed to section
Countertop Installation (Pg 16).
• If you are installing the system inline with existing plumbing, proceed to
section Inline Installation (Pg 19).
Part Numbers
Below Sink Installation
Below Sink Kit (CBK1) Required
2
Item #
1
2
3
4
5
6
7
8
9
10
11
12
13
14
*The acrylic base (Item #12) is an optional part available for purchase.
Part #
MC652
MC780
MC741
MC741
011-50-3011
MC273
CBTAs
MC253
MC129
MC351S
MCB7-5D-18
011-25-4100
MC232
MC923LF
Part Description
Faucet assembly with blue tubing attached
Wing nut
Outlet adapter: connects to blue tubing
attached to faucet
Inlet adapter: connects to clear tubing
Housing top
Black rubber cushion (inside housing top)
Carbon Block Filter cartridge
V-band with knob
Bracket
O-ring
Housing bottom
Tall acrylic base*
Clear tubing: connects inlet adapter to
plumbing
Adapta valve

Below Sink Installation
Below Sink Kit (CBK1) Required
3
1/2” slip joint nut
riser
angle stop valve
threading adapter
Adapta Valve
3/8” conguration
14
Adapta Valve
1/2” conguration
threading adapter
riser
angle stop valve
14
water supply
line with
Adapta
Valve in 3/8”
conguration
water supply
line with
Adapta
Valve in 1/2”
conguration
A
B
OR
tubing
from faucet
v-band
knob
1
2
34
5
7
8
10
11
12
6
9
13

Below Sink Kit Components
Included with the Below Sink Kit are the following components:
1. Adapta Valve:Used to connect the DWS to the cold water line below
the sink. The 1/4” clear tubing connects the Adapta Valve to the 1/4”
inlet tting on the DWS housing.
2. Faucet:The faucet installs on top of the sink or counter. The 1/4” blue
tubing connects the faucet to the 1/4” outlet tting on the DWS housing.
Recommended Installation Tools
NOTE: Included with each install kit are the xtures and accessories needed to
install the system. If you determine that your particular plumbing conguration
requires xtures different from those included with your shipment, please
contact your Dealer.
The following tools are recommended to install your DWS for below-sink use:
1. Installing the faucet on a ceramic/porcelain sink:
• 3/8” Reversible Electric Drill
• 7/16” High Speed Steel Drill Bit
• 1/2” Masonry Drill Bit
• Hammer
• Center Punch
• 8” Adjustable Wrench
• Pliers/Locking Pliers
2. Installing the faucet on a stainless steel sink:
• Everything from list #1, plus 1/8” high speed drill bit
3. Installing the faucet on a granite countertop:
• everything from list #1, plus the following:
a. hammer
b. center punch
c. plumbers putty
d. 1/2” diamond drill bit for granite
4. Installing the Adapta Valve:
• 8” Adjustable wrench
• Wire cutter or knife
4

Drill the Faucet Hole (if necessary)
The faucet can be installed through a standard faucet hole or spray hose
hole in your sink, if one is available. If no hole is available, use the following
instructions to drill a faucet hole. If a faucet hole is already available, skip to
section Connect the Faucet (pg 6).
1. Select and mark the faucet mounting spot on the sink.
a. Conrm that there are no reinforcing ribs under the desired faucet
location.
b. If you have an extra hole in your sink for a spray hose, you may also
choose to disconnect the spray hose and use that existing hole for
the CB-As faucet.
2. Use the hammer to gently tap the center punch on
the sink location where the hole is to be drilled. This
creates an indentation to mark the drilling location.
3. If you have a porcelain, ceramic, or cast acrylic sink:
CAUTION: Porcelain, ceramic, and cast acrylic
surface materials are extremely hard and can easily
crack or chip. Use extreme caution when drilling. CB
Tech is not responsible for any damages resulting
from faucet installation.
a. Use the 1/2” carbide-tipped masonry drill bit to grind away a small
section of sink veneer down to the metal, clearing enough space to
allow drilling without damaging the rest of the sink surface veneer.
b. Carefully use the 7/16” high-speed steel drill bit to completely drill a
hole through the metal sink.
CAUTION: Do not allow the drill bit to “grab” the sink veneer, as this will
damage the surface.
4. If you have a stainless steel or metal sink:
a. Use the 1/8” high-speed drill bit to
drill a pilot hole.
b. Use the 7/16” high-speed drill bit to
completely drill a hole through the
metal sink.
5
carefully grind
away porcelain
mark the spot

5. If you have a granite countertop:
CAUTION: Granite surface materials are extremely hard and can
easily crack or chip. Use extreme caution when drilling. CB Tech is not
responsible for any damages resulting from faucet installation.
a. Place a towel or basin under the sink, directly under the location of
the intended faucet hole.
b. Using a snake of plumbers putty, form a circular “dam” around
the location of the intended faucet hole. Make the dam 5” in
diameter and 3/4” tall.
c. Fill the dam with cool tap water. The water will keep the drill bit from
overheating.
d. Use the 1/2” granite drill bit to drill the hole. Slowly grind away the
granite material.
Connect the Faucet
Proceed to the instructions for your faucet type:
1. For a standard faucet, proceed to section Installing the Standard
Faucet (Pg 6).
2. For a capacity-monitored faucet, proceed to section Installing the
Capacity Monitor Faucet (Pg 8).
Installing the Standard Faucet
NOTE: The blue plastic tubing is attached to the faucet.
1. From the sink / countertop:
a. Place the larger soft black rubber washer over the faucet hole.
b. Place the cover plate on top of the large washer.
c. Place the smaller soft black rubber washer on top of the cover plate.
d. Place the faucet base over the smaller soft black rubber washer
and atop the cover plate.
2. From under the sink:
a. Slide the hard plastic black washer (with the smaller side up)
upward over the blue tubing.
b. Slide the lock washer upward, below the hard plastic washer.
c. Slide the wing nut upward, below the lock washer.
d. Hand-tighten the wing nut to secure the faucet.
6

7
cover plate
countertop
plastic washer
wing nut
large black washer
lock washer
blue tubing
small black washer
Complete Faucet
Assembly with
Blue Tubing
(MC652)

Installing the Capacity Monitor Faucet
NOTE: In addition to the blue plastic tubing attached to the faucet. A
separate piece of blue tubing is included for connection between the
housing OUTLET port and the Filter Monitor Unit INLET port.
blue tubing
from faucet
black wire
from capacity
indicator plate
tubing for
housing
countertop
Capacity Monitor
Assembly
1
36
79
4
5
12
13
8
2
14
5
1515
11 10
8
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Faucets with Capacity
Monitor Include:
Spout
Faucet handle
Faucet base
Faucet stud
Blue tubing (attached to faucet)
Small rubber washer
LED Display Plate
Black wire (attached to LED display plate)
Large rubber washer
Black track washer
Hard plastic washer
Lock washer
Wing nut
Filter Monitor Unit
(2) Filter monitor adapters (MC744)

1. From the sink / countertop:
a. Place the large rubber washer (#9) over the faucet hole.
b. Place the LED Display Plate (#7) on top of the large rubber washer.
Feed the attached black cable down through the hole in the sink.
Rotate the LED Display Plate so that the indicator light will be easy
to see.
c. Place the small rubber washer (#6) on top of the LED Display Plate.
d. Place the faucet base (#3) over the small rubber washer and
LED Display Plate. Feed the faucet stud (#4) and blue tubing (#5)
down through the hole in the sink. The faucet stud should now be
accessible below the sink.
2. From under the sink:
a. Slide the black track washer (#10) (with the at side down) upward
over the threaded faucet stud. Guide the black wire (#8) through
the track to protect the wire and prevent it from becoming pinched
between the sink and the stud nut.
b. Slide the hard plastic washer (#11) upward over the blue tubing
(#5), black track washer (#10), black wire (#8), and faucet stud
(#4).
c. Slide the lock washer (#12) upward over the faucet stud, below
the hard plastic washer.
d. Screw on the stud wing nut (#13) below the lock washer.
e. Hand-tighten the wing nut to secure the faucet.
3. Prepare the Filter Monitor Unit (FMU)
a. Guide the black wire (#8) from under the sink to the Filter Monitor
Unit (#14), and plug it into the top of the FMU.
b. Open the FMU and pull out the battery holder. Insert two (2) AA
batteries (not included) into the battery holder, making sure to
match the + and – signs. Reinsert the battery holder.
c. Press and hold the check/reset button on the FMU for six (6)
seconds. You should hear a long audio sound, and the LED Display
Plate will ash red and then green several times.
d. Snap the cover back onto the FMU.
e. Peel off the paper backing from the hook-and-loop connector
strip, and attach one piece to the back of the FMU.
9

f. Select a clean, convenient mounting location on a wall beneath
the sink, allowing sufcient space for placement of the FMU. Peel
off the paper backing from the second hook-and-loop connector
strip and attach it to the desired wall location.
g. Attach the FMU to the wall using the two hook-and-loop connector
strips.
4. Prepare the Filter Monitor Unit
a. Attach the two lter monitor adapters (#15) to the FMU (#14), one
on each side.
b. Complete the installation after connecting the tubing.
5. Connect the Tubing from the Housing to the Filter Monitor Unit
NOTE: Complete this step only after
the CB-As tubing has been connected
in section Connect the Tubing to the
Housing (Pg 14).
a. Fully insert the blue plastic tubing
from the CB-As OUTLET into the
adapter (#15) on the INLET (#5)
side of the FMU; the tubing should
typically be inserted 5/8” into the
adapter. The inlet side is the side
from which the arrow points away
on the capacity ow device.
NOTE: When pushing the tubing
into the adapter, you will encounter
some resistance. This does not
mean that the tube is fully inserted.
Continue to push rmly until the
tubing is inserted as far as possible
(roughly 5/8” into the adapter).
6. Connect the Tubing from the Faucet to the Filter Monitor Unit
a. Fully insert the blue plastic tubing from the faucet into the adapter
(#15) on the OUTLET (#5) side of the FMU; the tubing should typically
10
5 5
OUTLET
to faucet
tubing
adapter
OUTLET
Pull to check that the tubing is secure.
Insert tubing and push until you feel
resistance - at this point, the tubing is not
fully inserted. Push rmly until the tubing
is inserted as far as it will go.
INLET
to housing
insert
14
5

be inserted 5/8” into the adapter. The outlet side is the side to which
the arrow points on the capacity ow device.
NOTE: When pushing the tubing into the adapter, you will encounter
some resistance. This does not mean that the tube is fully inserted.
Continue to push rmly until the tubing is inserted as far as possible
(roughly 5/8” into the adapter).
7. Changing the Batteries and Resetting the Capacity Monitor
a. Open the Filter Monitor Unit (FMU) and pull out the battery holder.
Remove and discard the used batteries.
b. Turn on the CB-As faucet and let the water ow for 2 to 3 seconds,
then turn off the faucet.
c. Insert two (2) AA batteries into the battery holder, making sure to
match the + and – signs. Reinsert the battery holder.
d. Press and hold the check/reset button on the FMU for six (6)
seconds. You should hear a long audio sound, and the LED Display
Plate will ash red and then green several times.
Connect the Adapta Valve
If your residence has a cold water supply line with a 3/8” or 1/2” slip joint
connection, you may use the Adapta Valve included with your system
to connect your DWS to the plumbing. The Adapta Valve assembly
(MC920LFASBL) includes both the valve and threading adapter.
When attaching the Adapta Valve to straight pipe threads, use Teon tape
on the threads. Wrap the tape around the pipe only once.
NOTE: The Adapta Valve must be installed on the cold water line only.
1. Using the 3/8” conguration:
a. The 3/8” conguration is used on a water supply line with a 3/8” slip
joint.
b. The 3/8” conguration is typically installed at the bottom of the riser
at the angle stop valve.
11

water supply line with Adapta
Valve in 3/8” conguration
riser
angle stop valve
threading
adapter
Adapta Valve
3/8”
conguration
water supply line with Adapta
Valve in 1/2” conguration
1/2” slip joint nut
riser
angle stop valve
3/8” slip joint nut
Water supply line before installation
Adapta
Valve
Threading
Adapter
Adapta Valve
1/2”
conguration
riser
angle stop valve
12
threading
adapter

2. Using the 1/2” conguration:
a. The 1/2” conguration can be used at either the top of the riser at
the faucet pipe or at the bottom of the riser at the angle stop valve.
b. Install the 1/2” conguration at the top of the riser on a water supply
line that does not have a slip joint nut at the angle stop valve.
c. Install the 1/2” conguration at the angle stop valve if there is a
1/2” slip joint nut there.
3. Shut off the cold water supply to the faucet by rotating the angle stop
valve clockwise until the water ow is off. Place a catch basin or other
container below the faucet to catch any residual water in the pipes.
4. Disconnect the cold water riser/supply line at the angle stop valve or
cold water faucet pipe. Use an 8” adjustable wrench to rotate the slip
joint nut counterclockwise until the riser/supply line and slip joint nut
detach from either the angle stop valve or the faucet pipe.
5. Connect the Adapta Valve to the pipe from which you removed the
slip joint nut.
a. Align the Adapta Valve to either the angle stop valve or cold water
faucet pipe, making sure that the rubber washer is in place in the
Adapta Valve.
b. Use an 8” adjustable wrench to rotate the connection clockwise
until tight. DO NOT OVERTIGHTEN.
6. Connect the cold water riser/supply line with the slip joint nut to the
Adapta Valve.
a. Align the slip joint nut to the Adapta Valve.
b. Use an 8” adjustable wrench to rotate the slip joint nut clockwise
until tight. DO NOT OVERTIGHTEN.
c. Make sure that the supply line does not block the shutoff valve
on the side of the Adapta Valve. If necessary, trim the supply line
before reconnecting.
7. Conrm that the Unit Shutoff Valve attached to the Adapta Valve is in
the OFF position by rotating the handle clockwise until it stops.
8. Proceed to section Connect the Tubing to the Housing (Pg 14).
13

Below Sink Kit Components
1. Connect the included Inlet adapter (MC738) to the system housing’s
labeled Inlet port. Rotate the adapter clockwise, rst by hand, then
using a wrench, to tighten onto the system.
2. Connect the included Outlet adapter (MC741) to the system housing’s
labeled Outlet port. Rotate the adapter clockwise, rst by hand, then
using a wrench, to tighten onto the system.
Connect Tubing to the Outlet Port
1. Using wire cutters or a knife, cut
(square cut) the tip end off of the
blue plastic tubing (either connected
to the faucet or a separate piece
included with the Capacity Monitor).
Do not use scissors.
2. Fully insert the tubing into the adapter
on the OUTLET port of the system
housing; the tubing should be inserted 5/8” into the adapter.
NOTE: When pushing the tubing into the adapter, you will encounter
some resistance. This does not mean that the tube is fully inserted.
Continue to push rmly until the tubing is inserted as far as possible
(roughly 5/8” into the adapter).
3. Pull on the tubing to make sure that it is securely connected.
Connect Tubing to the Inlet Port
1. Using wire cutters or a knife, cut
(square cut) the tip end off of the
clear plastic tubing connected to the
Adapta Valve. Do not use scissors. Do
not cut more than 1/2” off of the end
of the clear plastic tubing.
Connect the Tubing to the Housing
14
blue tubing
insert
OUTLET
adapter
INLET
adapter
clear tubing
insert

Connect the Tubing to the Housing 2. Fully insert the tubing into the adapter on the INLET port of the system
housing; the tubing should be inserted 5/8” into the adapter.
NOTE: When pushing the tubing into the adapter, you will encounter some
resistance. This does not mean that the tube is fully inserted. Continue to
push rmly until the tubing is inserted as far as possible (roughly 5/8” into the
adapter).
3. Pull on the tubing to make sure that it is securely connected.
Mount the System Under the Sink (Below Sink Kit ONLY)
1. Attach the metal bands to the mounting bracket:
a. Using a slotted (at-blade) screwdriver, loosen the connector
screw on each of the two metal bands so that the slotted side of
the bands separate from the connector screw.
b. Insert the slotted end of one metal band into one slot of the
mounting bracket.
i. Thread it across the curved back of the mounting bracket and
through the slot on the other side of the curved back.
ii. Thread the slotted end of the metal band back into the
connector screw and slightly tighten the screw to reconnect
the band into a circle.
c. Repeat step 1-b for the other metal band, using the second set of
slots framing the curved back of the mounting bracket.
15

Overview & Part Numbers
Countertop Intallation
Countertop Kit (CBK2) Required
Item #
1
2
3
4
5
6
7
8
9
Part #
MC6600ASBL
011-50-3011
MC273
MC253
CBTAs
MC351S
MCB880R
MC240N
MC700
Part Description
Hose and Diverter Valve
Housing top
Black rubber cushion (inside housing top)
V-band with knob
Carbon Block Filter cartridge
O-ring
Housing bottom
Short acrylic base
Standard adapters (see page 7)
16
2. Use the included screws and a Phillips-head screwdriver to fasten
the mounting bracket to the wall, ensuring it is oriented in an upright
position. The bracket is in an upright position when the larger holes on
each at mounting plate on the sides of the bracket are at the bottom.
3. Attach the system to the bracket:
a. Insert the system housing into the two metal bands so that the
metal bands wrap around the top half of the housing, above the
V-Band. The top half of the system housing has the Inlet and Outlet
adapters.
b. Tighten the connector screws on the metal bands to securely hold
the system housing to the mounting bracket. Wiggle the housing to
make sure it does not shift in the metal bands, and/or tighten the
metal bands appropriately.

2
8
3
5
4
7
6
1
hose
diverter
valve
17
Countertop Kit Components
Included with the Countertop Kit are the following key components:
1. Acrylic Base: Used to hold the CB-As upright on the countertop. The
CB-As is placed on the acrylic base with the ports and tubing facing
down, so that the tubing can feed through the openings at the side of
the acrylic base.
2. Diverter valve: Used to connect the dual-hose from the CB-As to the
existing sink faucet. The diverter valve comes pre-attached to the dual-
hose, and allows selection of ltered or unltered water from the faucet.
3. Dual-hose: Used to connect the diverter valve to the CB-As.

Connect the Diverter Valve
1. Remove the aerator or screen (if present) from the end of the faucet. If
facing the open end of the spout, rotate the aerator counter-clockwise
to loosen and remove.
2. Attach the diverter valve directly to the faucet spout. If the threads
of the diverter valve do not match the threads of the faucet, use one
of the included faucet adapters to connect the diverter valve and
faucet. If facing the open end of the spout, rotate the diverter valve
and/or adapter clockwise to tighten.
NOTE: When using a faucet adapter, the rubber washer in the adapter
always faces up toward the faucet.
a. If Your Faucet Has an Outside Thread (male connector):
For many faucets with an outside thread, the diverter valve can
attach directly to the faucet. If the diverter valve is too small to
attach to the faucet, attach the inside thread (female connector)
adapter, part# MC106, to the faucet, and then attach the diverter
valve to the adapter.
b. If Your Faucet Has an Inside Thread (female connector):
The diverter valve cannot directly connect to a faucet with a female
connector. Attach one of the outside thread (male connector)
adapters, part# MC107 or part# MC108, to the faucet, and then
attach the diverter valve to the adapter. MC107 is designed to t
larger faucets, and MC108 is designed to t smaller faucets.
Diverter Valve
Attachment
Diverter Valve Attachment
with adapter
*MC700 Adapters
Many installations do not
require an adapter
existing
faucet
bypass
lever
hose
diverter
valve
*MC106
*MC107
*MC108
*MC257
swivel
attachment
ring
18

c. If Your Faucet Requires More Room for the Diverter Valve Connection:
Some faucets, particularly sprayer hose faucets, require additional
room for the diverter valve connection. If this applies, attach the
long adapter, part# MC257, to the opening of the faucet spout/
sprayer, and then attach the diverter valve to the adapter. The CB-
As may need to be repositioned on the sink to allow enough room
for sprayer faucet use.
d. If the Adapters Do Not Fit Your Faucet:
Although the adapters included with your CB-As allow connections
with many standard faucets, they do not cover every type of
available faucet connection. If none of the adapters allow the
diverter valve to connect to your faucet, please contact your
Dealer, to request part# MC105, part# MC109, or part# MC719 as
possible adapter solutions.
NOTE: When connected properly, the hose from the diverter valve
should lead toward the back of the faucet and sink.
3. The diverter valve features a bypass lever with a button on the left and
right sides of the diverter valve. Press the left button to bypass the DWS
and select the unltered water spout (larger opening). Turn on your
faucet to let unltered water ow out of the diverter valve and to make
sure that the diverter valve is properly connected.
4. Turn off the faucet.
5. Proceed to section Connect the Tubing to the Housing (Pg 14).
19
The CB-As can be used inline for connection to refrigerators, water coolers,
or ice makers, so that all of the water from the cold water outlet or faucet is
ltered. CB Tech recommends that a professional plumber install the system
for inline use.
Inline Installation

1. Using a paper towel or cloth, dry off all connections and the system housing.
2. Make sure that all connections are tightly secured.
3. Remove any air and loose carbon from the system.
a. On a below-sink conguration:
i. Turn the water supply back on; rotate both the Adapta Valve
shutoff valve and either the water supply Angle Stop Valve or
water shutoff valve counter-clockwise to engage the ow of
water through the pipes.
ii. Turn the handle on the CB-As faucet to start the ow of ltered
water.
iii. Allow water to ow through the DWS and the faucet for 30
minutes. This purges any air and loose carbon from the system.
iv. Adjust the Angle Stop Valve or water shutoff valve so that the
water ow to the drinking water faucet does not exceed the
ow rate.
NOTE: It takes approximately 15 seconds to ll a quart at 1.0
gallons per minute ow rate.
b. On a countertop conguration:
i. Press the right button on the diverter valve to select the ltered
water spout. The water will ow through the DWS and emerge
from the smaller opening on the diverter valve.
ii. Allow water to ow through the DWS and ltered water spout
for 30 minutes. This purges any air and loose carbon from the
system.
iii. Press the left button to select the unltered water spout, and
then turn off the faucet.
4. Check all connections to make sure that there are no leaks.
5. Congratulations! Your system is now ready for use!
Prepare Your Drinking
Water System for Use
20
