CDA RC 9301 Operation instructions

Gas cookers
RC 9301 ..
Before operating this cooker,
please read these instructions carefully
Users Operating Instructions
Installation instructions
GB

2
Important:
This appliance is designed and manufactured solely for the cooking of domestic
(household) food and is not suitable for any non domestic application and there-
fore should not be used in a commercial environment.
The appliance guarantee will be void if the appliance is used within a non domes-
tic environment i.e. a semi commercial, commercial or communal environment.
Dea Custome
Thank you fo choosing one of ou appliances, ca efully designed and built by
ou specialist staff and tho oughly tested to satisfy you cooking equi ements.
We suggest that you ead this Inst uction Booklet so that you will unde stand
fully how to ope ate you appliance.
Please keep the booklet handy. You may wish to efe to it at a late date.
CDA

3
Contents
Model RC 9301 ..
Page Number
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Assembling the backguard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Features and technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Minute counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
How to use the hob burners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
How to use the gas oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
How to use the gas grill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Oven light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Rotisserie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Do’s and do not’s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Important notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Care and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
For the installer
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Fitting the adjustable feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Stability bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Provision for ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Gas installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Gas connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Conversion to Natural Gas or to LPG . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Lubrication of the gas taps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Electrical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Appliance servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

4
Congratulations on your purchase of this CDA cooker which has been carefully
designed and produced to give you many years of satisfactory use.
Before using this appliance it is essential that the following instructions are carefully
read and fully understood.
We would emphasise that the installation section must be fully complied with for your
safety to ensure that you obtain the maximum benefits from your appliance.
Fig. 1
Assembling the
backguard
■Remove the two spacers
“A” and the screw “B”
from the rear of the cook-
top.
■Assemble the backguard
as shown in figure 1 and
fix it by screwing the cen-
tral screw “B” and the
spacers “A”.
A
B
Declaration of CE conformity
✓ This cooker has been designed, constructed and marketed in compliance with:
- Safety requirements of EU Directive "Gas" 90/396/EEC;
- Safety requirements of EU Directive "Low Voltage" 2006/95/EC;
- Protection requirements of EU Directive "EMC" 2004/108/EC;
- Requirements of EU Directive 93/68/EEC.
Introduction
GB

5
Features and technical data
Fig. 2
2
43
1
1
2
Gas burners
1. Auxiliary burner (A) 1,00 kW
2. Semi-rapid burner (SR) 1,75 kW
3. Rapid burner (R) 3,00 kW
4. Triple-ring burner (TR) 3,50 kW
Note:
The electric ignition is incorporated in
the knobs.
The appliance has a safety valve system
fitted, the flow of gas will be stopped if
and when the flame should accidentally
go out.

6
Control panel
Fig. 3
12 34567
CONTROL PANEL - Controls description
1. Gas oven / gas grill control knob
2. Minute counter
3. Front left burner control knob
4. Rear left burner control knob
5. Front central burner control knob
6. Rear central burner control knob
7. Rear right burner control knob
8. Front right burner control knob
9. Oven light/rotisserie control knob
89
Minute counter
Minute counter
The minute counter is a timed acoustic
warning device which can be set for a
maximum of 60 minutes.
The knob (Fig. 4) must be rotated
clockwise as far as the 60 minute
position and then set to the required
time by rotating it anticlockwise.
Fig. 4

7
How to use the hob burners
Fig. 5
Hob burners
Each hob burner is controlled by a separate gas tap
operated by a control knob (fig. 5) which has 3
positions marked on the control panel, these are:
– Symbol : tap closed (burner off)
– Symbol : High (maximum)
– Symbol : Low (minimum)
Push in and turn the knob anti-clockwise to the
selected position.
Lighting of the hob burners
To ignite the burner, the following instructions are to be followed:
1 –
Press in the corresponding knob and turn counter-clockwise to the full flame position
marked by the symbol (fig. 5) and hold the knob in until the flame has been lit.
In the case of a mains failure light the burner with a match or lighted taper.
2 – Wait about ten seconds after the gas lighting before releasing the knob (starting
time for the valve).
3 – Adjust the gas valve to the desired power.
Important
If the burner flame should go out for some reason, the safety valve will automatically
stop the gas flow.
To re-light the burner, return the knob to the closed position, wait for at least 1
minute and then repeat the lighting procedure.
If your local gas supply makes it difficult to light the burner with the knob set to maxi-
mum, set the knob to minimum and repeat the operation.
The maximum aperture position permits rapid boiling of liquids, whereas the minimum
aperture position allows slower warming of food or maintaining boiling conditions
of liquids.
To reduce the gas flow to minimum, rotate the knob further anti-clockwise to point
the indicator towards the small flame symbol.
Other intermediate operating adjustments can be achieved by positioning the
indicator between the maximum and minimum aperture positions, not between the
maximum aperture and closed positions.
N.B. When the hob is not being used, set the gas knobs to their closed positions
and also close the cock valve on the gas bottle or the main gas supply line.

8
Burners Pan diameter
Auxiliary 12 ÷ 14 cm
Semi-rapid 16 ÷ 24 cm
Rapid 24 ÷ 26 cm
Triple-ring 26 ÷ 28 cm
Wok max 36 cm
do not use pans with concave or convex bases
Choice of burner
The burner must be chosen according to the diameter of the pans and energy
required.
Saucepans with handles that are excessively heavy in relation to the weight of the pan
are less safe as they are more likely to tip.
Pans which are positioned centrally on burners are more stable than those which are
offset.
It is far safer to position the pan handles in such a way that they cannot be accidentally
knocked.
When deep fat frying fill the pan only one third full of oil.
DO NOT cover the pan with a lid and DO NOT leave the pan unattended.
In the unfortunate event of a fire, leave the pan where it is and turn off all controls.
Place a damp cloth or correct fitting lid over the pan to smother the flames.
DO NOT use water on the fire.
Leave the pan to cool for at least 30 minutes.
Fig. 6

9
Correct use of triple-ring burner
The flat-bottomed pans are to be placed directly onto the pan-support.
To use the WOK you need to place the proper stand in order to avoid any faulty
operation of the triple-ring burner (Fig. 7 - 8).
IMPORTANT:
The special grille for wok pans (fig. 8) MUST BE PLACED ONLY over the pan-rest for
the triple-ring burner.
Fig. 7
WRONG
Fig. 8
CORRECT

10
How to use the gas oven
Lighting the oven gas burner
The thermostat allows the automatic control of the temperature.
The gas delivery to the oven burner is controlled by a two way thermostatic tap
(oven and grill burners) with flame-failure device.
To light the oven burner operate as follow:
1) Open the oven door.
2) Lightly press and turn the thermostat knob anti-clockwise to max position “ ”.
3) Press the knob right down to prime the electric ignition.
WARNING: Risk of explosion! The oven door must be open during this
operation.
In case of power cut, press the knob and immediately approach a lighted match to
the opening “A” (fig. 9). Never continue this operation for more than 15 seconds.
If the burner has still not ignited, wait for about 1 minute prior to repeating
the ignition.
4) Wait about 10/15 seconds after the burner
lighting before releasing the knob (time of
priming of the valve).
5) Close the oven door slowly and adjust the
burner according to the power required.
Should the flame of the burner
estinguish for any reason, the safety
valve will cut off automatically the gas
flow to the tap.
To re-start operation, take the knob to
the “ ” OFF position, wait for at least
1 minute and repeat operations as
above explained.
Oven
thermostat
The oven thermostat (fig.
10) is marked with num-
bers, these correspond to
the oven temperature, in
addition the “OFF” position
is shown by the symbol .
To choose the required oven
temperature, turn the con-
trol knob until its line mark is
level with the temperature
required on the control
panel (facia).
Fig. 10
A
Fig. 9

11
Oven cooking temperatures
MARK APPROX. HEAT OF TYPE OF DISH TO COOK
TEMP. OVEN
150 150°C Very cool Meringue cakes,
oven slow cooking items
• 165°C Cool or Milk puddings, very rich fruit
slow oven cakes, i.e., Christmas
180 180°C Cool or Stews, casseroles, braising,
slow oven rich fruit cakes, i.e., Dundee
• 195°C Warm oven Biscuits, rich plain cakes
i.e., Madeira. Low temp. roasting
210 210°C Moderate Plain cakes, Victoria
oven sandwich, raised meat pies
• 225°C Fairly hot Small cakes, savoury flans,
oven fish
240 240°C Hot oven Plain cakes and buns, swiss rolls,
fruit pies. High temp. roasting
• 245°C Moderately Bread and bread rolls etc., scones,
hot oven flaky and rough puff pastry,
yorkshire pudding
270 270 Very hot Sausage rolls, mince pies, puff
• 285 oven pastry, pizza
Browning ready cooked dishes

12
How to use the gas grill
Lighting the grill gas burner
The grill burner generates the infra-red rays for grilling.
To light the grill burner operate as follow:
1) Open the oven door.
2)
Lightly press and turn the thermostat knob clockwise to the position (fig. 12).
3) Press the knob right down to prime the electric ignition.
WARNING: Risk of explosion!
The oven door must be open during this operation.
In case of power cut, press the knob and put a lighted match to the right and left side of
the burner (fig. 11).
Never continue this operation for more
than 15 seconds. If the burner has still
not ignited, wait for about 1 minute
prior to repeating the ignition.
4) Wait about 10/15 seconds after the burner
lighting before releasing the knob (time of
priming of the valve).
5) Half-close the oven door slowly.
Should the flame of the burner estin-
guish for any reason, the safety valve
will cut off automatically the gas flow to
the tap. To re-start operation, take the
knob to the “ ” OFF position, wait for
at least 1 minute and repeat operations
as above explained.
Do not grill with oven door closed.
Always fit the heat shield supplied with the cooker under the front panel
before commencing operations (Fig. 13).
WARNING. The heat shield and the oven door reaches a very high temper-
ature whilst in use. Keep children away and allow to cool before removing.
Fig. 12
Fig. 11Fig. 11

13
Notes:
– The grill burner has only one setting, that is full-on
– It is important that the heat shield is fitted the correct way up, as shown in the figure
13.
Oven light
Fig. 14
The cooker is equipped with a light that
illuminates the oven to enable visually
controlling the food that is cooking.
This light is controlled by a switch knob
(fig. 14).
Fig. 13
IMPORTANT WARNING
For best results when using the grill, place the shelf on the second level and when
using the grill pan handle avoid contact with the heat shield which will be
HOT during use

14
This is used for spit roasting under the
grill and comprises:
– an electric motor fitted to the rear of
the oven
– a stainless steel skewer provided with
slide-out heatless handgrip and two
sets of adjustable forks
– a skewer support to be fitted in the
middle runner.
The rotisserie motor is operated by a
switch knob (Fig. 15).
Use of the rotisserie
– Insert the tray into the lowest rack holders of the oven and insert the rod support
into the intermediate rack holders.
– Put the meat to be cooked onto the rod, being careful to secure it in the center with
the special forks.
– Insert the rod into the side gear opening “P”
– Remove the grip “H” by turning it to the left.
– Insert completely the rotisserie support; the shaft “S” must be inserted in the spit
motor collar “G”.
The rotation direction of the rotisserie can be either clokwise or counter-clockwise.
Fig. 15
Fig. 16
G
S
H
P
Rotisserie

15
Do’s and do not’s
Do’s and do not’s
• Do not grill with oven door closed. Always fit the heat shield supplied with the cooker
under the front panel before commencing operations.
• Do read the user instructions carefully before using the cooker for first time.
• Do allow the oven to heat for one and a half hours, before using for the first time, in
order to expel any smell from the new oven insulation, without the introduction of
food.
• Do clean your oven regularly.
• Do remove spills as soon as they occur.
• Do always use oven gloves when removing food shelves and trays from the oven.
• Do not allow children near the cooker when in use.
• Do not allow fat or oils to build up in the oven trays, or oven base.
• Do not place cooking utensils or plates directly onto the oven base.
• Do not grill food containing fat without using the grid.
• Do not cover the grilling grid with aluminium-foil.
• Do not use the oven tray for roasting.
• Do not place hot enamel parts in water. Leave them to cool first.
• Do not allow vinegar, coffee, milk, saltwater, lemon or tomato juice to remain in con-
tact with enamel parts (inside the oven and on the oven tray).
• Do not use abrasive cleaners or powders that will scratch the surface of the stainless
steel and the enamel.
• Do not attempt to repair the internal workings of your cooker.
• Do remove the protective film before the first use.
• Fire risk! Do not store flammable material in the oven and in the storage compart-
ment.

16
Installation, and any demonstration, information or adjustments are not included in
the warranty.
The cooker must be installed by a suitably qualified and registered person in accor-
dance with the relevant Standards.
I portant notes
For your safety
The product should only be used for its intended purpose which is for the cooking of
domestic foodstuffs.
Under no circumstances should any external covers be removed for servicing or main-
tenance except by suitably qualified personnel.
Attention
The appliance gets very hot, mainly around the cooking areas. It is very impor-
tant that children are not left alone in the kitchen when you are cooking.
Oven door guard
The glass on the oven door reaches high temperatures during operation.
For child safety, a door guard can be fitted to prevent contact with the hot glass.
The door guard is supplied as an accessory at extra cost, if required.
Contact the After-Sales Service and indicate the model name of your product (see prod-
uct data plate - Mod. RC 9301 ..).

17
Care and aintenance
Cleaning the hob
Spillage on the hob can usually be removed by a damp soapy cloth. More obstinate
stains can be removed by rubbing gently with a soapy nylon (non metal) scouring pad
or mild household cleaner.
Important:
As a safety measure, before you start cleaning the cooker be sure to disconnect it from
the mains supply.
Do not use a steam cleaner because the moisture can get into the appliance
thus make it unsafe.
The use of suitable protective clothing/gloves is recommended when han-
dling or cleaning of this appliance.
WARNING
When correctly installed, your product meets all safety requirements laid down for this
type of product category.
However special care should be taken around the rear or the underneath of the appli-
ance as these areas are not designed or intended to be touched and may contain
sharp or rough edges, that may cause injury.
Flexible tube
From time to time, check the flexible tube connecting the gas supply to the cooker.
It must be always in perfect condition; in case of damage arrange for it to be replaced
by a suitably qualified and registered installer.
Gas taps
If a tap becomes stiff, do not force; contact your local Service Centre.

18
Changing the oven light
1. Disconnect the electrical power supply (for example, by switching off the main
power switch).
2. Unscrew the light cover
3. Fit a new bulb.
4. Refit the cover.
Note:
Use only bulbs designed to resist up to 300°C with the following characteristics: 230 V,
type E14 and same power (check watt power as stamped in the bulb itself) of the
replaced bulb
.
Enamelled parts
All the enamelled parts must be cleaned with a sponge and soapy water only or other
non-abrasive products.
Dry preferably with a microfibre or soft cloth.
Stainless steel, aluminium, painted parts and silk-
screen printed surfaces
Clean using an appropriate product. Always dry thoroughly.
Stainless steel surfaces: can be cleaned with an appropriate stainless steel cleaner.
IMPORTANT: these parts must be cleaned very carefully to avoid scratching and abra-
sion. You are advised to use a soft cloth and neutral soap.
CAUTION: Do not use abrasive substances or non-neutral detergents as these will
irreparably damage the surface.

19
Burners
They can be removed and washed only with
soapy water.
Detergents can be used but must not be
abrasive or corrosive.
Do not use abrasive sponges or pads.
Do not put in dishwasher.
After each cleaning, make sure that the
burner-caps, as well as the burners, have
been well wiped off and CORRECTLY
POSITIONED.
It is essential to check that the burner
flame distributor Fand the cap Chas been
correctly positioned (see fig. 17) - failure to
do so can cause serious problems.
Check that the electrode “S” (figs. 17-18) is
always clean to ensure trouble-free spark-
ing.
Check that the probe “T” (figs. 17-18) next
to each burner is always clean to ensure
correct operation of the safety valves.
Note:
The electrode “S” must be very carefully cleaned.
To avoid damage to the electric ignition do not use it when the burners are not
in place.
Triple ring burner
The triple ring burner must be correctly positioned (see figs. 18-19); the burner rib
must be located correctly in the burner base as shown by the arrow.
The burner correctly positioned must not rotate (fig. 19).
Then position the cap Aand the ring B(fig. 19).
A
Fig. 18 Fig. 19
B
F
T
S
C
Fig. 17
S
T

20
Storage compartment
– The storage compartment is accessible through the pivoting panel.
Attention: Do not store flammable material in the oven, or the storage
compartment.
Fig. 20
Fig. 21
Removal of the inner glass door panel
– The inner glass door panel can easily be removed for cleaning by unscrewing the
four screws (fig. 20).
– When re-assembly ensure that the inner glass is correctly positioned and do not
over tighten the screws.
Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven
door glass since they can scratch the surface, which may result in shattering
of the glass.
