CDG FEITIAN R301-C11 User manual

Smart Card Reader
User’s Manual
FEITIAN R301-C11

1
 (Smart Card Reader) FEITIAN R301-C11
 Driver  Windows XP  Windows  Offline ( Windows 7 
Windows 8, 10 Driver)
Install Driver on Windows XP andWindows Offline. (no need to install driver for Windows 7
can connect to Internet and Windows8 ,10)
1.  Feitian.zip 2 FoldersWindows XP Windows 
Unzip Feitian.zip to 2 Folders separate to Windows XP andWindows .
2. FolderWindows XPWindows XP 
dpinst.exe
FolderWindows XP for installation on Windows XP operating System by double click
dpinst.exe


2
 (Smart Card Reader) FEITIAN R301-C11
3. Folder Windows 7Windows 7 
64 bit 32bit  Folder2 file 
WUDFUsbccidDriver.dllWUDFUsbccidDriver.inf
FolderWindows 7 for installation on Windows 7 operating System by separate into 64 bit or
32 bit files and folder consist of WUDFUsbccidDriver.dll andWUDFUsbccidDriver.inf
64 bit
For 64 bit operating system
32bit
For 32 bit operating system

3
 (Smart Card Reader) FEITIAN R301-C11
4.  WUDFUsbccidDriver.inf Install
Double click on WUDFUsbccidDriver.inf and selectInstall

4
 (Smart Card Reader) FEITIAN R301-C11

Light indicator status

Light indicator status

Explaination

Orange light is flashing

Computer detects Smart Card reader

Orange is turn on

Smart Card Reader is established

Blue and Orange light are turn
on

Card insert into Smart Card Reader

Blue and Orange light are
flashing

Retrieve data from card

Condition of Use
1. windows 7, windows 8, windows 1032 bit
64 bit
Computer must install windows 7, windows 8 and windows 10 and useable on 32 bit
operating system or 64 bit operating system.
2. Driver Windows XP Windows Offline ( Windows 7
Windows 8, 10 Driver)
Install Driver on Windows XP andWindows Offline. (no need to install driver for Windows
7 can connect to Internet and Windows8 ,10)

5
 (Smart Card Reader) FEITIAN R301-C11

Instructions for using an Smart Card Reader
1. USB 
Plug USB into Computer
2. 
Open an application
3. Windows Smartcard 


Insert card properly and wait until Blue and Orange light are turn on.

6
 (Smart Card Reader) FEITIAN R301-C11

Troubleshooting

Problem

Troubleshooting

Not found Smart Card Reader

Recheck Smart Card Reader.

Not found card
Smartcard 

Recheck Smart Card Reader and re-insert card again

Incorrect data from card

Re-insert card again

Basic maintenance methods
1. 
Use a clean cloth to wipe and do not use chemicals to wipe
2.  
Do not touch the water or keep it in wet place
