CDVI Mifare SOLARMW User manual

The installer’s choice
cdvigroup.com
SOLARMW
SOLARMB
13.56 Mhz Mifare®Readers - Wiegand
Lecteurs Mifare®13,56 Mhz - Wiegand
ENGLISH
EN
FRANCAIS
FR

2cdvigroup.com
Wiegand 26, 30 or 44 bit.
Direct connection or with the door controller
(INTBUSW).
PCB sealed in epoxy.
Audible and visual feedback.
30cm pigtail wire connection.
Versions available: white or black.
Dimensions (L x W x D): 130 x 90 x 28mm.
Technology: 13.56Mhz.
Input voltage: 12V dc.
Consumption: 220mA.
1] PRODUCT PRESENTATION
3] MOUNTING KIT
2] REMINDERS AND RECOMMENDATIONS
130
90
35
Foam seal 3x30
TF screw S5 Plastic
anchor Torx® bit 3x8
Torx®screw Varistor
SOLARMW(MB) 1 2 2 1 1 1
Important
To protect the device from
back-emf, do not forget to
install the varistor across
the
lock terminals, in parallel.
Suggested power supplies
ARD12 & BS60 (in case the
reader is powered neither
by the controller nor by the
reader controller INTBUSW).
These products must be
powered in 12Vdc and the
power supply should be
certied EN60950-1:2006/
A11:2009 standards and
should be designed to be a
low power supply source.
Recommended cables
4 twisted pairs 0.6mm (AWG 24).
This product is supplied
with a varistor.
The varistor must be
connected directly to the
locking system terminals
(electric strikes, electro-
magnet, or lock) operated
by the device. If the device
functions with several locking
systems, each one must
be tted with a varistor.
The varistor limits overload
produced by the strike coil,
known as self-effect or
back-emf. If you are using
a “Shear Lock”, electromagne
t
or other type of electric lock,
we recommend the use of
a dedicated power supply
for the lock.
For optimal
illumination,
do not fold
the cable
inside
the product.
CE Certication
Certication FCC CFR 47
part 15 compliance
WEEE
IP53
-25°C to +70°C
EN
SOLARMW-SOLARMB
13.56Mhz Mifare® Reader - Wiegand
INSTALLATION MANUAL

3cdvigroup.com
1 Measure and mark the center lines to determine the
reader position. Drill the xing screw holes (Diameter:
5mm). Drill the wiring access area (Diameter:
15mm).
2 Place the foam seal at the back of the reader. Take
care to begin from the bottom. (Sch. a). The foam
seal must be visible (about 2mm) on the top-back
of the reader (Sch. b).
4] MOUNTING
Make sure that there are no pieces missing from the mounting kit. Use the correct tools according to the
installation (drill, screwdrivers, tape measure,...) and follow the mounting instructions of the reader.
1
3
2
Sch. a
Sch. b
Sch. c
3 Insert the plastic plugs in the mounting holes, connect the cable (refer to wiring diagram on page 11), then fasten
the reader with the TORX® screw using the TORX® bit (Sch. c). Make sure that the varistor is connected across
the lock (refer to page 8 “Reminders and recommendations”).
Foam seal
EN
SOLARMW-SOLARMB
13.56Mhz Mifare® Reader - Wiegand
INSTALLATION MANUAL

4cdvigroup.com
When powered up
- Green LED illuminates for 1 second.
- RED LED illuminates for 1 second.
- Buzzer sounds for 1 second.
Operating mode
- Buzzer activated with 0V input.
- LEDs activated with 0V input.
C20
R19
C28
CR1
CR2
CR4
CR5
CR8
C55 C56
C57
C62 C63
C64
C65
C66
C67
C68
C69
C70
CR30
C73
C74
C75
CR6
C77
C78
C1
C2
C7
C8
C9 D2
D3
D6
1
L1
L2
L3
L4
L5
L8
R10
R11
R12
R13
R14
R15
R16
R17
R18
Q2Q4
R28
Q5
R29
Q6Q7 Q8
R30
R31R33 R34
R35
R1
R36 R37
R3
R38
R4
R39
R5
R6
R7
R8
R9
R40
R46
R48
R49
R50
R51R52
R53
R54
R55
R56
R57
R58
R59
R60
R61
R62
R63
R64
R65
R66
R67
R68
R69
R70
R71
R72
R73
R74
R75
R76
R77
R78
R80
C10
C13
C14
1 P3
C27
CR7
C76
CR9
CR28
CR20
CR27
CR21
CR29
CR19
I1
1
2
3
4
ONON
ONON
-
+
+ -
BZ3
P1
1
CR10
CR12
CR15
CR13
CR25
CR26
CR24
MM16
MM14
L7
MM3
MM10
CR11
CR3 MM1
MM15 C58
C6
+
-
R25
P2
C61
+
-
+
-
C24
C59
C25
CR22
CABLE
Red Input voltage 12V dc
Black 0V
Blue Clock
Green Data 0
White Data 1
Brown Buzzer input
Yellow Green LED input
Orange Red LED input
Input LED management
Green LED Red LED Status
OFF OFF Off
OFF ON red
ON OFF green
ON ON blue
1 2
OFF OFF
26 bits
1 2
ON OFF
30 bits
1 2
OFF ON
44 bits
1 2
ON ON
Non attribué
3
ON
Standard
Pulls up 12 V or 5 V
Open collector outputs:
OFFON
OFFON
OFFON
OFFON
OFFON
OFFON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
OFF= 5 V
ON = 12 V
Card Swiped (DIP3 = ON)
- Badge recognized: the orange
LED illuminates and the buzzer
activates for 150 milliseconds.
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
5] WIRING DIAGRAM
DIPSWITCH 1 & 2 POSITIONING
DIPSWITCH 3 POSITIONING
DIPSWITCH 4 POSITIONING
EN
SOLARMW-SOLARMB
13.56Mhz Mifare® Reader - Wiegand
INSTALLATION MANUAL

5cdvigroup.com
6] OUTPUT FORMATS 26, 30 AND 44 BIT WIEGAND
Chronograms
Open collector output with internal pulls up 1K at +5V or +12V according the ST4 position.
26-BIT WIEGAND OUTPUT
1 - First parity: 1-bit – even parity for the rst 12-bit
Code of the badge: 6 half byte represent the last 6 digit of the code (4bit = 1 digit of a code)
Each byte is transferred from bit 7 to bit 0.
2 - Second parity: 1 bit – odd parity for the last 12-bit.
Bit 1 Bit 2 to bit 25 Bit 26
Even Parity on bit 2 to bit 13 Data (24 bit)
Odd Parity on bit 14 to bit 25
Exemple: code of the badge is 0102166A37.
1 0001 0110 0110 1010 0011 0111 0
Parity 1 166A37 Parity 2
The code transmitted is in hexadecimal format 166A37
Parity 1: 0 if the number of 1 in bit 2 to bit 13 is even,
1 if the number of 1 in bit 2 to bit 13 is odd.
Parity 2: 0 if the number of 1 in bit 14 to bit 25 is odd,
1 if the number of 1 in bit 14 to bit 25 is even.
0 logic
\DATA1
\CLOCK
\DATA0
50 μs 50 μs
2ms 2ms
1 logic
EN
SOLARMW-SOLARMB
13.56Mhz Mifare® Reader - Wiegand
INSTALLATION MANUAL

6cdvigroup.com
30-BIT WIEGAND OUTPUT
1 - First parity: 1 bit – even parity for the rst 14-bit
Code: A code is formed from 7 half byte.
Each byte is transferred from bit 7 to bit 0.
2 - Second parity: odd parity for the last 14-bit.
Bit 1 Bit 2 to bit 29 Bit 30
Even Parity from bit 2 to bit 15 Data (28-bit) Odd Parity from bit 16 to bit 29
Example: EM badge hexadecimal code: 0100166A37.
1 0010 0001 0110 0110 1010 0011 0111 1
Parity 1 2166A37 Parity 2
The code transmitted is in hexadecimal format 2166A37.
Parity 1: 0 if the number of 1 in bit 2 to bit 15 is even,
1 if the number of 1 in bit 2 to bit 15 is odd,
Parity 2: 0 if the number of 1 in bit 16 to bit 29 is odd,
1 if the number of 1 in bit 16 to bit 29 is even.
44-BIT WIEGAND FORMAT OUTPUT
Data: 10 digit code number hexadecimal MSByte rst.
Each hexadecimal digit = 4 bit, MSBit rst.
LRC: 4 bit = OR restricted in between the digit of the data, MSBit rst.
Bit 1 to bit 40 Bit 41 to bit 44
Data MSBit rst LRC
Example A: EM badge hexadecimal code: 01001950C3.
0000 0001 0000 0000 0001 1001 0101 0000 1100 0011 0011
01001950C33
The code number of the card is: 01001950C3 in hexadecimal code.
EN
SOLARMW-SOLARMB
13.56Mhz Mifare® Reader - Wiegand
INSTALLATION MANUAL

7cdvigroup.com
7] LED MANAGEMENT ON CENTAUR SYSTEM
GREEN LED
SETTINGS
RED LED
SETTINGS
GREEN ACCESS ALLOWED
RED ACCESS DENIED
BLUE STAND-BY
LED
ACTUATION
EN
SOLARMW-SOLARMB
13.56Mhz Mifare® Reader - Wiegand
INSTALLATION MANUAL
8] NOTES

8cdvigroup.com
Wiegand 26, 30 ou 44 bits.
Connexion directe à la centrale ou via
le contrôleur de porte (INTBUSW).
Electronique résinée.
Signalisation lumineuse et sonore.
30 cm de câble.
Disponible en version : blanc ou noir.
Dimensions (L x l x H) : 130 x 90 x 28 mm.
Technologie : 13,56 Mhz.
Alimentation : 12 V DC.
Consommation : 220 mA.
1] PRÉSENTATION PRODUIT
3] ÉLEMENTS FOURNIS
2] RAPPELS ET RECOMMANDATIONS
130
90
35
Joint
d’étanchéité Vis TF
3x30
Cheville
plastique
S5
Embout
tournevis
TORX®
Vis TORX®
3x8 Varistance
SOLARMW(MB) 1 2 2 1 1 1
Recommandations
d’installation
Pour sécuriser l’installation,
n’oubliez pas de placer la
varistance sur le système
de verrouillage en parallèle
au niveau de l’alimentation.
Alimentations préconisées
ARD12 et BS60 (lorsque le
lecteur n’est alimenté ni par la
centrale, ni par le contrôleur
de porte, INTBUSW).
Nos alimentations sont
conforme aux exigences
de la norme EN60950-1 :
2006/A11 :2009 et construite
pour être une alimentation
limitée en puissance.
Câble préconisés
Câble 4 paires 6/10
ème
(AWG 24).
Ce produit est livré
avec une varistance.
Celle-ci doit être montée
directement sur les bornes de
lagâche(ventouse,moteur,…)
commandée par l’équipement.
Si l’appareil fonctionne avec
plusieurs gâches, chacune doit
être équipée de varistance.
La varistance limite les
surtensions provoquées par
le bobinage de la gâche –
effet de self. Dans le cas
où la ventouse utilisée est
du type “Shear Lock”, celle-ci
doit être alimentée par une
alimentation indépendante
du SOLARPW-SOLARPB.
Pour un
éclairage
optimal,
attention
de ne pas plier
le câble
à l’intérieur
du produit.
Certication CE
Certication FCC CFR 47
part 15 compliance
DEEE
IP53
-25°C à +70°C
FR
SOLARMW-SOLARMB
Lecteurs Mifare® 13,56 Mhz - Wiegand
MANUEL D’INSTALLATION

9cdvigroup.com
1 A l’aide du fond du lecteur, prenez les marques pour
xer le produit. Percez le support de montage au niveau
des marques (diamètres préconisés : Ø5 mm et Ø15 mm).
Grâce au schéma de câblage, prévoyez la sortie des câbles
cachés dans la surface ou à l’extérieur (moulure).
2 Placez le joint au dos du lecteur en commençant par
le bas. (g. a). Le joint doit dépasser d’environ 2 mm au
niveau du sommet de la partie arrière du lecteur (g. b).
4] MONTAGE
Après avoir vérié que le kit de montage est complet, vous allez pouvoir procéder à l’installation nale de votre
lecteur. Réunissez le matériel approprié (Perçeuse, tournevis, mètre,…) et suivez les recommandations de
montage qui correspondent au lecteur que vous allez installer.
1
3
2
g. a
g. b
g. c
3 Placez les chevilles dans les trous, connectez les ls aux borniers (voir schéma de câblage page 5), puis xez le
lecteur avec la vis TORX® grâce à l’outil TORX® (g. c). N’oubliez pas de placer la varistance au niveau du système
de verrouillage (Voir page 2 “Rappels et recommandations”).
Joint d’étanchéité
FR
SOLARMW-SOLARMB
Lecteurs Mifare® 13,56 Mhz - Wiegand
MANUEL D’INSTALLATION

10 cdvigroup.com
Mise sous tension
- Voyant vert pendant 1 seconde.
- Voyant rouge pendant 1 seconde.
- Avec bip pendant 1 seconde.
Fonctionnement
- Activation Buzzer par niveau 0 V.
- Activation voyants par niveau 0 V.
C20
R19
C28
CR1
CR2
CR4
CR5
CR8
C55 C56
C57
C62 C63
C64
C65
C66
C67
C68
C69
C70
CR30
C73
C74
C75
CR6
C77
C78
C1
C2
C7
C8
C9 D2
D3
D6
1
L1
L2
L3
L4
L5
L8
R10
R11
R12
R13
R14
R15
R16
R17
R18
Q2Q4
R28
Q5
R29
Q6Q7 Q8
R30
R31R33 R34
R35
R1
R36 R37
R3
R38
R4
R39
R5
R6
R7
R8
R9
R40
R46
R48
R49
R50
R51R52
R53
R54
R55
R56
R57
R58
R59
R60
R61
R62
R63
R64
R65
R66
R67
R68
R69
R70
R71
R72
R73
R74
R75
R76
R77
R78
R80
C10
C13
C14
1 P3
C27
CR7
C76
CR9
CR28
CR20
CR27
CR21
CR29
CR19
I1
1
2
3
4
ONON
ONON
-
+
+ -
BZ3
P1
1
CR10
CR12
CR15
CR13
CR25
CR26
CR24
MM16
MM14
L7
MM3
MM10
CR11
CR3 MM1
MM15 C58
C6
+
-
R25
P2
C61
+
-
+
-
C24
C59
C25
CR22
RACCORDEMENT
Rouge Alimentation 12 V DC
Noir 0 V
Bleu Clock
Vert Data 0
Blanc Data 1
Marron Entrée Buzzer
Jaune Entrée voyant vert
Orange Entrée voyant rouge
Commande des voyants
Voyant
vert Voyant
rouge Etat
OFF OFF éteint
OFF ON rouge
ON OFF vert
ON ON bleu
1 2
OFF OFF
26 bits
1 2
ON OFF
30 bits
1 2
OFF ON
44 bits
1 2
ON ON
Non attribué
3
ON
Standard
12 V ou 5 V Pour les sorties à collecteur ouvert,
il y a deux niveaux de sorties possibles :
OFF= 5 V
ON = 12 V
Présentation badge (DIP3 = ON)
- Badge lu : voyant orange et bip
pendant 0,15 seconde puis retour
suivant état activation en cours.
- Badge non lu : pas d’effet.
5] SCHÉMA DE CÂBLAGE
POSITIONNEMENT DIPSWITCH 1 & 2
Positionnement Dipswitch 3
Positionnement Dipswitch 4
OFFON
OFFON
OFFON
OFFON
OFFON
OFFON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
1
2
3
4
ONON
ONON
FR
SOLARMW-SOLARMB
Lecteurs Mifare® 13,56 Mhz - Wiegand
MANUEL D’INSTALLATION

11cdvigroup.com
6] FORMAT DE SORTIE WIEGAND 26, 30 ET 44 BITS
Chronogrammes
Sorties en collecteur ouvert avec pulls up internes de 1K au +5V ou +12V selon la position de ST4.
FORMAT WIEGAND 26 BITS
1 - 1
re
parité : 1 bit – parité paire des 12 premiers bits.
Code du badge : 3 mots d’un octet représentant les 6 derniers termes.
Chaque mot est transmis bit de poids fort en premier.
2 - 2
nde
parité : 1 bit – parité impaire des 12 derniers bits.
Bit 1 Bit 2 à bit 25 Bit 26
Parité paire sur bit 2 à bit 13 Donnée (24 bits)
Parité impaire sur bit 14 à bit 25
Exemple : pour un badge dont le code hexadécimal est 0102166A37.
1 0001 0110 0110 1010 0011 0111 0
Parité 1 166A37 Parité 2
Le code émis est 166A37 en hexadécimal
Parité 1 : 0 si le nombre de 1 dans bit 2 à bit 13 est pair,
1 si le nombre de 1 dans bit 2 à bit 13 est impair.
Parité 2 : 0 si le nombre de 1 dans bit 14 à bit 25 est impair,
1 si le nombre de 1 dans bit 14 à bit 25 est pair.
0 logique
\DATA1
\CLOCK
\DATA0
50 μs 50 μs
2ms 2ms
1 logique
FR
SOLARMW-SOLARMB
Lecteurs Mifare® 13,56 Mhz - Wiegand
MANUEL D’INSTALLATION

12 cdvigroup.com
FORMAT WIEGAND 30 BITS
1 - 1
re
parité : 1 bit – parité paire des 14 premiers bits.
Code du badge : 7 quartets représentant le code du badge.
Chaque mot est transmis bit de poids fort en premier.
2 - 2
nde
parité : 1 bit – parité impaire des 12 derniers bits.
Bit 1 Bit 2 à bit 29 Bit 30
Parité paire sur bit 2 à bit 15 Donnée (28 bits) Parité impaire sur bit 16 à bit 29
Exemple : pour un badge ayant le code hexa : 0100166A37.
1 0010 0001 0110 0110 1010 0011 0111 1
Parité 1 2166A37 Parité 2
Le code émis est 2166A37 en hexadécimal.
Parité 1 : 0 si le nombre de 1 dans bit 2 à bit 15 est pair,
1 si le nombre de 1 dans bit 2 à bit 15 est impair,
Parité 2 : 0 si le nombre de 1 dans bit 16 à bit 29 est impair,
1 si le nombre de 1 dans bit 16 à bit 29 est pair.
FORMAT WIEGAND 44 BITS
Données : 10 chiffres hexadécimaux (octet de poids fort en premier),
Chaque chiffre hexadécimal = 4 bits (bit de poids fort en premier).
LRC : 4 bit = OU exclusif entre les chiffres de la donnée (bit de poids fort en premier).
Bit 1 à bit 40 Bit 41 à bit 44
Code du badge LRC
Exemple A : pour un badge ayant le code hexa : 01001950C3.
0000 0001 0000 0000 0001 1001 0101 0000 1100 0011 0011
01001950C33
Le code émis est : 01001950C3 en hexadécimal.
FR
SOLARMW-SOLARMB
Lecteurs Mifare® 13,56 Mhz - Wiegand
MANUEL D’INSTALLATION

13cdvigroup.com
7] PARAMÉTRAGE DES VOYANTS SUR LE SYSTÈME CENTAUR
PARAMÉTRAGE
VOYANT VERT
PARAMÉTRAGE
VOYANT ROUGE
VERT ACCÈS AUTORISÉ
ROUGE ACCÈS REFUSÉ
BLEU EN ATTENTE
ÉTAT
VOYANTS
FR
SOLARMW-SOLARMB
Lecteurs Mifare® 13,56 Mhz - Wiegand
MANUEL D’INSTALLATION
8] NOTES

The installer’s choice
cdvigroup.com
Reference : G0301FR0437V03
Extranet : EXE-CDVI_IM SOLARMW-SOLARMB CMYK A5 EN-FR 02
All the information contained within this document (pictures, drawing, features, specications and dimensions)
could be perceptibly different and can be changed without prior notice.
*G0301FR0437V03*
CDVI Group
FRANCE (Headquarter/Siège social)
Phone: +33 (0)1 48 91 01 02
Fax: +33 (0)1 48 91 21 21
CDVI
FRANCE + EXPORT
Phone: +33 (0)1 48 91 01 02
Fax: +33 (0)1 48 91 21 21
CDVI AMERICAS
[CANADA - USA]
Phone: +1 (450) 682 7945
Fax: +1 (450) 682 9590
CDVI
BENELUX
[BELGIUM - NETHERLAND - LUXEMBOURG]
Phone: +32 (0) 56 73 93 00
Fax: +32 (0) 56 73 93 05
CDVI
TAIWAN
Phone: +886 (0)42471 2188
Fax: +886 (0)42471 2131
CDVI
SUISSE
Phone: +41 (0)21 882 18 41
Fax: +41 (0)21 882 18 42
CDVI
CHINA
Phone: +86 (0)10 62414516
Fax: +86 (0)10 62414519
CDVI
IBÉRICA
[SPAIN - PORTUGAL]
Phone: +34 (0)935 390 966
Fax: +34 (0)935 390 970
CDVI
ITALIA
Phone: +39 0321 90 573
Fax: +39 335 127 89 96
CDVI
MAROC
Phone: +212 (0)5 22 48 09 40
Fax: +212 (0)5 22 48 34 69
CDVI
SWEDEN
[SWEDEN - DENMARK - NORWAY - FINLAND]
Phone: +46 (0)31 760 19 30
Fax: +46 (0)31 748 09 30
CDVI
UK
[UNITED KINGDOM - IRELAND]
Phone: +44 (0)1628 531300
Fax: +44 (0)1628 531003
CDVI DIGIT
FRANCE
Phone: +33 (0)1 41 71 06 85
Fax: +33 (0)1 41 71 06 86
Toutes les informations mentionnées à titre indicatif sur le présent document (photos, dessins, caractéristiques
techniques et dimensions) peuvent varier et sont susceptibles de modications sans notication préalable.
Other manuals for Mifare SOLARMW
1
This manual suits for next models
1
Table of contents
Languages:
Other CDVI RFID System manuals
Popular RFID System manuals by other brands

Samsung
Samsung SSA-R2003 user manual

caenrfid
caenrfid R1280I Technical information manual

caenrfid
caenrfid Hardon mini R1271C Technical information manual

BlueBox
BlueBox IDTRONIC HF Communication protocol

caenrfid
caenrfid easy2read Slate R1260I Technical information manual

Point Mobile
Point Mobile RF750 user manual
