Celestron #44301 User manual

Mini HandHeld
digital Microscope
INSTRUCTION MANUAL
MODEL #44301
ENGLISH

1
IntroductIon
Congratulations on your Celestron microscope purchase. Your new
microscope is a precision optical instrument made of high quality materials
to ensure durability and long life, and is designed to give you a lifetime of
pleasure with minimal maintenance.
This microscope can be used for virtually anything that traditional microscopes
are used for: Hobbyists, Educators, Medical Labs, Industrial Inspection,
Engineering Applications, Teachers, Students, Science Applications, Doctor’s
Offices, Police Agencies, Government Testing, and general use by consumers.
Before attempting to use your microscope, please read through the
instructions to familiarize yourself with the functions and operations to
make usage easier for you. See the microscope diagram to locate the parts
discussed in this manual.
The microscope provides powers from 15x to 30x (powers with a 19”
monitor). It is ideally suited for examining solid objects such as coins, stamps,
rocks, relics, insects, plants, skin, gems, circuit boards, various materials, and
many other objects. You can also examine specimen slides.
With the included software, you can observe the magnified images or capture
video or take snapshots with Microsoft Windows 7, XP and Vista operating
systems. You can also use the microscope with most image capture software
that you may have on Windows 7, XP & Vista Os’s. If you are using a MAC,
you can take videos and snapshots but you need image/photo capture
software for MAC (like a combination of iChat with Photo Booth, etc.). You will
also need a CD/DVD drive as well as an open USB port.
Note: This product was designed and intended for ages 13 and older!

2
USB
Cable
Snapshot
Button
Microscope
Focus
Ring

3
SpecIfIcatIonS — Model # 44301
Power 15 to 30x using a 19” Monitor
USB Cable 2.0 for power from a computer
Illuminator 6 White LEDs
Digital Camera 1.3MP CMOS Sensor – 1280x1024 pixel array
(snapshots up to 5MP with interpolation)
Weight and Dimensions 2.9 oz (82 g) 3.5” x 1.25” (89 mm x 32 mm)
Standard Accessories Included with your Microscope
• Digital Camera with USB Cable — Built-in
• LED Illuminator — Built-in
• CD-ROM — Digital Microscope Suite
• Instruction Manual

4
SettIng upYour MIcroScope
1. Carefully remove the microscope from the box and set it on a table, desk,
or other flat surface.
2. Remove the plastic bag covering the microscope.
MIcroScope operatIon
Viewing Objects and Slides — You can view coins,
stamps, currency, gems, plants, foods, circuit boards,
specimen slides, and many other things. You need
to read the information about focusing, power, and
illumination below before proceeding.
Focusing & Changing Power (Magnification) —
When the microscope is placed directly on/over the
object or slide; use the focus ring to obtain a sharp
focus. The focus ring takes some getting used to –
rotate past the focus and then back as you will see
how to obtain the best focus position. After some
usage the sharp focus position will be easy to find.
1. Always start with the higher power (30x) which
is obtained when the focus ring is on/over the
object. Focus should be sharp if using for the first time but if not you need
to turn the focus ring slightly to obtain a sharp focus.
2. If you hold the microscope slightly above the object the power will
decrease gradually to 15x as you move further away (up to about 14 mm).
You will have to refocus at each position.

5
Illumination —The LEDs of the microscope are automatically turned on when
the USB cable is inserted into the USB port on your computer. There is no
illumination adjustment on this microscope but you may be able to position
the microscope over the object you are viewing at different angles
(or positions) to give the optimum illumination.
uSIng the MIcroScope for VIewIng and/or IMagIng
Before using your microscope for viewing or imaging on your computer
screen, you will have to ensure the driver is recognized by your computer. Your
microscope is a “Plug and Play” type where the computer should automatically
recognize the driver type on Microsoft Windows 7, XP & Vista operating
systems as well as Apple MAC version 10.4.9 and later operating systems.
Plug the USB cable of the microscope into the USB port of your computer. Each
computer system will have slightly different messages. For example, on some
Vista OSs when plugged in the message may say “Installing Device Driver
Software” and shortly thereafter you may see a message “Your Devices Are
Ready to Use.” Just follow any instructions shown on the screen.
You will need to install the Digital Microscope Suite software (on Windows
OS’s) to actually view and/or image. Prior to doing this you will need to
unplug the USB cable until the installation is complete. You can also use most
other image/photo capture software that you may have on your Windows
system if you desire.
To use the microscope with MAC operating systems you will need to
have MAC Version 10.4.9 and higher – must use a MAC compatible
image/photo capture program (iChat with Photo Booth, etc). To find

6
Photo Booth on a Mac, go to your hard drive and click on Applications.
Choose Photo Booth from the list of applications. If a camera is already
attached to computer, Photo Booth will show up as your default.
You will need to change this to “Celestron Microscope.” You will
then be able to take photos with your microscope using the capture
button. Please note: Many keyboards on Macs have a USB port. The
microscope will not work through this USB port because it does not
have enough power. You will have to connect the USB directly to your
computer tower.
When viewing or imaging, you can change the orientation of the image on the
computer screen by rotating the microscope to the position you desire.
InStallIng the dIgItal MIcroScope SuIte (dMS)
Software
Your microscope comes with the Digital Microscope Suite CD-ROM which
allows you to use your microscope for visual purposes and for imaging with
your computer when using Microsoft Windows OS’s.
Before installing the software, remove the USB cable of the Digital Camera
from your computer and do not connect it until the software installation
is complete. Insert the CD-ROM into your CD-ROM drive and it should
automatically begin. Messages will appear (each operating system may show
something somewhat different) to guide you through the installation process.
If the software did not begin automatically, double click on “My Computer”
and right click the CD-ROM icon and it should start.

7
• You will see “Files Currently on the CD” and notice “Digital Microscope
Suite” as a folder. Double click on it and then among the choices double
click on “Setup” (InstallShield Setup Launcher).
• InstallShield Wizard will appear. Next, select the default choices,
“Next,”etc. until “Finish” is seen and click on it.
Your software was properly installed. You will have a desktop icon called
“Digital Microscope Suite,” if not that will be the program you select from
your installed programs when you want to use the digital microscope.
uSIng the dIgItal MIcroScope SuIte (dMS)
Software
Plug in the USB cable of the Microscope to your computer and then start DMS.
The DMS contains basic image capture and organization for your photos
(snapshots) and videos. Click on the DMS icon to begin.
The software is very intuitive and easy to use. You can change settings
by using File and Settings – the Video Device should have as a default
“Celestron Digital Microscope,” if not please change it so the DMS will
function properly.
You can take snapshot images by using the snapshot button on the
microscope (only with Windows OS’s) or you can also use the keyboard by
clicking enter on “Capture an Image.” For videos you need to start/stop on
the icon shown on the screen. If the image delays or starts/stops, you should
lower the video resolution in the “Settings.”

8
Measuring Function — DMS has a simple measuring function which measures
the distance between two points in millimeters. Click the “Measure” button
on the bottom right of the screen. Click where you want your starting point
and then click again to set the ending point and it will display the distance
between the two points. You can adjust either point by dragging the pin. You
can click “Clear” to start over.
The measurement function works accurately when the microscope is directly
on the object.
You are now ready to begin your digital adventure!

9
care, MaIntenance, and warrantY
Your microscope is a precision optical instrument and should be treated with
care at all times. Follow these care and maintenance suggestions and your
microscope will need very little maintenance throughout its lifetime.
• Store the microscope in a dry and clean place.
• Be very careful if using your microscope in direct sun light to prevent
damage to the microscope or your eyes.
• Never point the microscope towards the sun or the camera can be
damaged and cease working.
• Clean the outside surfaces with a moist cloth.
• Blow dust off the optical surfaces with a camel’s hair brush or an air blower.
• Never disassemble or clean internal optical surfaces. This should be done
by qualified technicians at the factory or other authorized repair facilities.
• Do not disassemble or take apart the microscope or damage can occur.
• When handling glass specimen slides, use care as the edges can be sharp.
Your MIcroScope haS atwo Year lIMIted warrantY.
pleaSe VISIt the celeStron webSIte for detaIled
InforMatIon on all celeStron MIcroScopeS at
www.celeStron.coM.
