Celsicom Connect CC202 User manual
Thank you for purchasing a Celsicom Connect CC202!
First unpack everything in the box. In the box you will nd the base station
CC202, an antenna, rubber feet for mounting under the base station. Other ac-
cessories you may need, such as a power adaptor and a shielded network cable
can be found at your local dealer.
If you need a 2G/3G USB-modem (M2M) please contact your local dealer. Please
note that only Celsicom approved modems and SIM-cards can be used.
Connection of the CC202:
• Connect the antenna to connector (1).
• Connect a shielded network cable (2) to a router or a switch.
• If you’re using a USB-modem, connect it to the USB-port. (3)
• If you’re using wired sensors/adaptors, connect them to input BUS. (4)
• Connect a CE-approved power adaptor, 5V/1A, to DC-input (5)
• Connect the power adaptor to the AC wall socket.
After approx. 15 seconds the green LED (6) starts ashing, and when server con-
nection is established after about 20 seconds it will turn to a solid green light. If
you connect using a USB-modem (M2M) it may take 60-120 seconds to connect.
If the red LED (7) starts ashing, please consult our support pages at celsicom.se.
Please also note the LAN-requirements on the next page.
1
MODEM USB LAN CMD POWER BUS
2
5
6 7
LAN-requirements for connecting the CC202 to a local area network:
• DHCP assigned IP address (dynamic or static)
• Possibility to connect to IP 46.21.98.32/27 on port 80 & 220 TCP. Only out-
going trafc.
• Some Gigabit-switches may have to be set to the 100Mbit mode.
Contact your local dealer to get access to Celsicom cloud service, Celsiview.
After you have registered you log on to the cloud service at celsiview.se.
The base station registration steps below only apply if you haven't bought a
pre-registered base station:
Go to "My account" at celsiview.se and ll out the unit-ID located at the bottom
of the base station in the text eld "Base station ID" under "Register new base
station". Press button "Register". Now within 20 seconds press briey on the
CMD-button (8) on the rear panel of the base station.
A message "Base station is now registered!" appears. The base station is now
connected to your user account.
The CC202 should be mounted on the WM200 wall mount to achieve the best
connectivity with wireless sensors. Never mount the WM200 on a metal wall
unless a spacer of 20-30 cm is used. Also ensure that there is no other interfering
electronics/cables within 0,5 meter of the base station.
For better connection with wireless sensors the EA100 external antenna can be
used. (Accessorie)
Next step is to connect your sensors to the base station, this procedure can be
found in the user manual of each sensor.
34
Front panel
Rear panel
8
Made in Sweden
Made in Sweden
Made in Sweden
CC202 • User manual
