Celsius CELDH150 User manual

1. Use only the voltage specified on the rating label of
the appliance.
2. Keep all objects at least 1 metre from the front,
sides and rear of the appliance.
3. This appliance is intended for household use only
and not for commercial or industrial use.
4. Indoor use only.
5. Use this appliance only as described in this
manual. Any other use is not recommended by the
manufacturer and may cause fire, electric shock or
injury.
6. The common cause of overheating is deposits of
dust or fluff in the appliance. Ensure these deposits
are removed regularly by unplugging the appliance
and vacuum cleaning the air vents and grills.
7. Always unplug appliance when not in use.
8. When the appliance has been unpacked, check it
for transport damage and ensure all parts have
been delivered. If parts are missing or the
appliance has been damaged, contact the Celsius
Customer Services Team.
9. If your appliance does not work, or is not working
properly, contact the place of purchase or the
Celsius Customer Services Team.
10. Do not connect the appliance to mains supply until
completely assembled and adjusted.
11. Ensure hands are dry before handling the plug or
main unit.
12. Do not locate the appliance directly below any
power socket outlet.
13. Ensure appliance is on a flat, stable, heat-resistant
surface.
14. Do not operate with cord set coiled up as a heat
build up is likely, which could be sufficient to
become a hazard.
15. Carry out regular checks of the supply cord to
ensure no damage is evident.
16. Do not operate this appliance with a damaged
cord, plug or after the appliance malfunctions or
has been dropped or damaged in any manner.
Return to a qualified electrical person for
examination, electrical service or repair.
17. Do not twist, kink or wrap the cord around the
appliance, as this may cause the insulation to
weaken and split. Always ensure that all cord has
been removed from any cord storage area and is
unrolled before use.
18. It is recommended that this appliance is plugged
directly into the wall socket. Power boards are not
rated to supply power to high wattage appliances.
19. A correctly specified, undamaged extension cord
may be used with this appliance provided it is used
in a safe manner.
20. Do not remove plug from power socket until the
appliance has been switched off.
21. Do not remove plug from power socket by pulling
cord; always grip plug.
22. Switch off and use handle provided when moving
23. Do not place appliance close to radiant heat
source.
24. Never use the appliance to dry clothes.
25. Do not insert or allow foreign objects to enter any
ventilation or exhaust opening, as this may cause
an electric shock, fire or damage to the appliance.
26. Do not sit on the appliance.
27. Do not use abrasive cleaning products on this
appliance. Clean with a damp cloth (not wet) rinsed
in hot soapy water only. Always remove plug from
the mains supply before cleaning.
28. Do not operate in areas where petrol, paint or other
flammable liquids are used or stored.
29. This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities or lack of experience and
knowledge, unless they are supervised or have
been given instruction concerning the use of the
appliance by a person responsible for their safety.
30. Children should be supervised to ensure that they
do not play with the appliance.
31. Do not use this appliance in the immediate
surrounds of a bath, a shower, or a swimming pool
or other liquids. The appliance must not be
immersed in any liquids.
32. There are no user serviceable parts installed in the
unit.
33. Do not place the unit in wardrobes or other
enclosed spaces as this may cause fire hazards.
34. This unit is not supposed to be used in or around
locations where foodstuffs, works of art or delicate
articles of science, etc are stored.
35. It is important that you do not cover this appliance.
WARNINGS AND SAFEGUARDS
SUPPORT AND TECHNICAL ADVICE
Celsius –New Zealand
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[email protected]
Celsius –Australia
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[email protected]

COMPONENTS
This Dehumidifier is rated to extract 12L per day in an environment of 80% humidity and
temperature of 30°C. This is the world-wide standard for rating dehumidifiers. In New
Zealand we do not have climatic conditions with this humidity and high temperature.
Accordingly the extraction levels may be lower.
Control
Panel
Oscillating
Louvre
Water tank
Air intake
Handle
Control Panel
Automatic
Dehumidifying RH
Setting Wind Speed
Water Full
Ambient
Humidity
Dehumidifying
Timer
Continuous
Dehumidifying
Ambient
Temperature
Defrost

OPERATING YOUR DEHUMIDIFIER
Always choose a safe location for the Dehumidifier, keeping in mind the safety precautions
outlined. Ensure all packaging has been removed from the unit before use. This appliance
requires no installation, it should be used solely as a portable appliance.
WARNING: Keep all objects at least 1 metre from the front, sides and rear of the
appliance.
WARNING: Never leave this Dehumidifier unattended.
WARNING: In order to avoid overheating, do not cover the Dehumidifier.
Note: Leave the appliance to stand for one hour after transport or after the unit has been on
its side before connecting it to the mains supply to let the refrigerant settle. Ensure all
external windows and doors are closed before turning on the unit.
Ensure that the water container is positioned correctly. Plug into power supply, 2 beep
signals will be heard. To turn the Dehumidifier on, press the ON/OFF button. The blue
backlight will illuminate and turn off after 15 seconds. The LCD display will show the
working mode and status of unit. The LCD display shows the ambient humidity and
temperature. The oscillating louvre will open and the unit will start to run. The unit will be in
continuous dehumidify mode and will run continuously until turned off.
Press the “ON/OFF”button again, the unit will stop.
To switch between continuous dehumidifying mode and automatic dehumidifying modes,
press the MODE button until the “continuous dehumidifying”flashes on the electronic
display. Then press the SETTING button multiple times to set your desired humidity setting
from 40% to 80% RH (Relative Humidity) in 5% increments.
NOTE: When the sensor detects an ambient humidity level 1% lower than the set level the
compressor will turn off and the fan will continue to run. Once the ambient humidity level
increases to 5% higher than the set level the compressor will turn back on and continue to
dehumidify.
Within the continuous dehumidifying mode you can also set the desired fan speed to either
Low (L) or High (H). To do this, press the MODE button until the “Wind Speed”flashes on
the electronic display. Once it is flashing press the SETTING button to change the fan
speed.
This dehumidifier is designed to provide optimum performance at 35°C -15°C but it is still
effective down to 5°C. Ultimately the performance of this dehumidifier is dependant on the
amount of moisture or water vapour in the air.
Attention: This Dehumidifier is rated to extract 12L per day in an environment of 80%
humidity and temperature of 30°C. This is the world-wide standard for rating dehumidifiers.
In NZ we do not have climatic conditions with this humidity and high temperature.
Accordingly this product will not extract 12L per day, extraction levels will be lower.

MEMORY FUNCTION
If power supply is cut off when the appliance is running, it will automatically restart in the last
working mode once power is restored.
TIMER
If you would like to set the 24 hour timer you can do so by using the TIMER button. (Each
press of the button will increase the time set by 1 hour). There are two options when using
the timer function:
When the Dehumidifier is running, you can set the timer to turn off the unit after X amount of
hours. In order to do this, whilst the Dehumidifier is running press the TIMER button until the
desired length of time is displayed on electronic display
When the unit is off you can set the timer to turn the Dehumidifier on after X amount of hours.
In order to do this, whilst the Dehumidifier is off (but still plugged into a power outlet) press
the TIMER button until the desired length of time is displayed on electronic display
DEFROST
When the Dehumidifier is operating in low temperatures the unit will go into a defrost cycle.
This is to remove any ice that has accumulated on the interior of the unit as a result of its
operation. How often the Dehumidifier goes into its defrost cycle will depend on the
temperature and humidity in the room.
WATER DRAINAGE
When the water container is full:
An alarm signal will sound.
The compressor will stop automatically. This will also stop the dehumidification process.
Empty the water container and replace it in the correct position. The Dehumidifier will
continue dehumidifying when the compressor automatically starts (after three minutes). If
desired, it is possible to connect a drainage tube (not supplied) to the device for permanent
water drainage. If this option is desired you will need to purchase a suitable tube from your
local hardware retailer (Celsius does not hold tubes as spare parts).
Connect the drainage hose to the drain spout and ensure that the end of the hose is lower
than the drain opening, otherwise the water will not drain and flooding may occur. Also
ensure the water tank is in position (in the unit) otherwise the continuous drainage will not
operate. Place the end of the drainage hose in a drainage outlet. When you no longer wish
to use the permanent water drainage, disconnect the drainage tube from the device. Ensure
that the water container is positioned correctly.

CARE AND CLEANING
Do not attempt to dismantle the Dehumidifier. There are no user serviceable parts. For
service or repair, contact an authorised electrical service technician. To clean the air filter:
Switch the unit off and remove plug from socket. Remove the filter. Clean the filter with a
vacuum or with water. Dry the filter. Ensure the filter is completely dry before placing back in
the unit.
Never use unit without the air filter.
The exterior may be cleaned with a soft, dry cloth. If the device is extremely dirty wipe the
device with a slightly damp (not wet) cloth. Never spray the device with water.
To store the unit, remove the plug from the socket and empty the container. Allow the
Container and the Dehumidifier to dry completely. Clean the air filter. Store the device in a
dust-free location, preferably covered with a sheet of plastic.
Do not use this Dehumidifier with a programmer, remote-control system, separate Timer or
any other device that switches the Dehumidifier on automatically.
PROOF OF PURCHASE
To receive warranty retain receipt as proof of purchase.
TECHNICAL SPECIFICATION
Model No: CELDH150
Supply: 220-240VAC 50Hz
Wattage: 255W

Thank you for purchasing this Celsius product. Your product is warranted against faults and manufacture when used in
normal domestic use for a period of one year. In non-domestic use Celsius limits the voluntary warranty to three
months.
Celsius undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault
during the warranty period.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried out
by anyone other than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.
The benefits given to you by this warranty are in addition to other rights and remedies available to you under law in
relation to the goods or services to which this warranty relates.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).
One Year Warranty
Celsius One Year Warranty (IMPORTANT: Please complete and retain this warranty card)
Name
Address
Place Of Purchase Date Of Purchase
Name Of Product Model Number
Attach a copy of the purchase receipt to this warranty card
Celsius –New Zealand
PO Box 100-707
N.S.M.C
Auckland, 0745
Phone [phone]
Phone [phone]
www.celsius.co.nz
Celsius –Australia
PO Box 574
South Morang
Victoria, 3752
Phone [phone]
Phone [phone]
www.celsiusforhome.com.au
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.
