Celsius CELDH200 User manual

20LDEHUMIDIFIER
Model: CELDH200
OPERATING INSTRUCTIONS
This Dehumidifier is rated to extract 20L per day in an environment of 80% humidity and
temperature of 30°C. This is the world-wide standard for rating dehumidifiers.
In New Zealand we do not have climatic conditions with humidity and high temperature and
accordingly this product will not extract 20L per day. Extraction levels will be lower.

1. Use only the voltage specified on the rating
label of the appliance.
2. Keep all objects at least 1 metre from the
front, sides and rear of the appliance. Do not
place appliance close to radiant heat source.
3. Do not operate in areas where petrol, paint or
other flammable liquids are used or stored.
4. Do not insert or allow foreign objects to enter
any ventilation or exhaust opening, as this
may cause an electric shock, fire or damage
to the appliance. Do not sit on the appliance.
5. Do not operate this appliance with a damaged
cord, plug or after the appliance malfunctions
or has been dropped or damaged in any
manner. Return to a qualified electrical
person for examination, electrical service or
repair.
6. This appliance is intended for household use
only and not for commercial or industrial use.
7. Use this appliance only as described in this
manual. Any other use is not recommended
by the manufacturer and may cause fire,
electrical shock or injury.
8. The common cause of overheating is
deposits of dust or fluff in the appliance.
Ensure these deposits are removed regularly
by unplugging the appliance and vacuum
cleaning the air vents and grills.
9. Do not use abrasive cleaning products on this
appliance. Clean with a damp cloth (not wet)
rinsed in hot soapy water only. Always
remove plug from the mains supply before
cleaning.
10. Do not connect the appliance to mains supply
until completely assembled and adjusted.
11. Switch off and use handles provided when
moving.
12. Do not operate with cord set coiled up as a
heat build up is likely, which could be
sufficient to become a hazard.
13. Do not use an extension cord, power board or
external timer with this unit.
14. Do not remove plug from power socket until
the appliance has been switched off.
15. Do not remove plug from power socket by
pulling cord; always grip plug.
16. Always unplug appliance when not in use.
17. Do not locate the Dehumidifier directly below
any power socket during operation.
18. Do not twist, kink or wrap the cord around the
appliance, as this may cause the insulation to
weaken and split. Always ensure that all cord
has been removed from any cord storage area
and is unrolled before use.
19. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge, unless they are
supervised or have been given instruction
concerning the use of the appliance by a
person responsible for their safety.
20. Do not use this appliance in the immediate
surrounds of a bath, a shower, or a swimming
pool or other liquids. The appliance must not
be immersed in any liquids.
21. When the appliance has been unpacked,
check it for transport damage and ensure all
parts have been delivered. If parts are missing
or the appliance has been damaged, contact
the Celsius Customer Services Team.
22. If your appliance does not work, or is not
working properly, contact the place of
purchase or the Celsius Customer Services
Team. Repair work on the appliance by
unqualified persons can cause serious risk to
the user.
23. There are no user serviceable parts installed
in the unit.
24. Do not place the unit in wardrobes or other
enclosed spaces as this may cause fire
hazards.
25. This unit is not supposed to be used in or
around locations where foodstuffs, works of
art or delicate articles of science, etc are
stored.
26. Indoor use only.
27. Children should be supervised to ensure that
they do not play with the appliance.
28. Ensure Dehumidifier is on a flat, stable, heat-
resistant surface.
29. It is important that you do not cover this
Dehumidifier
WARNINGS AND SAFEGUARDS
Celsius –New Zealand
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[email protected]
Celsius –Australia
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[email protected]
SUPPORT AND TECHNICAL ADVICE

COMPONENTS
Water Tank
Handle
Control Panel
Filter
Continuous Dehumidify
Drain
Air Outlet
Front Cover
Air Guide Louvre
Power Cord
CONTROL PANEL

Always choose a safe location for the Dehumidifier, keeping in mind the safety precautions
outlined. Ensure all packaging has been removed from the unit before use. This appliance
requires no installation, it should be used solely as a portable appliance
OPERATION
Leave the appliance to stand for one hour after transport or after the unit has been on its side before
connecting it to the mains supply to let the refrigerant settle.
Ensure that the water tank is positioned correctly.
Plug into power supply; 1 beep signal will sound. To turn on the Dehumidifier, press the STANDBY
button.
The OPERATION light will illuminate.
The unit will be in FAN mode and will run continuously in this mode until turned off. The Relative
Humidity (RH) cannot be adjusted in this mode, it is preset at 55%.
Press the MODE button to toggle between FAN, LOW, HIGH, and AUTO.
In LOW and HIGH modes, your desired humidity can be set with the up and down arrows. The unit
ranges from 30% to 80% RH in 5% increments (or continuous; CO).
When the AUTO mode is set, the unit will run continuously; the RH cannot be adjusted in this mode.
Press the STANDBY button again to turn the unit off.
NOTE: When the sensor detects an ambient humidity level 1% lower than the current set level, the
compressor will turn off and the fan will continue to run. Once the ambient humidity level increases to
5% higher than the current set level, the compressor will turn back on and continue to dehumidify.
This Dehumidifier is designed to provide an optimum performance. It is not recommended to operate
in ambient temperature exceeding 35°C or lower than 5°C.
Ensure all external windows and doors are closed before turning on the unit.
CARE AND CLEANING
Do not attempt to dismantle the Dehumidifier. There are no user serviceable parts. For service or
repair, contact an authorised electrical service technician.
To clean the air filter: Switch the unit off and remove plug from socket. Remove the filter. Clean the
filter with a vacuum or with water. Air dry the filter. Ensure the filter is completely dry before placing
back in the unit.
Never use unit without the air filter in place.
The exterior may be cleaned with a soft, dry cloth. If the unit is extremely dirty wipe the device with a
slightly damp (not wet) cloth. Never spray the unit with water.
OPERATING YOUR DEHUMIDIFIER

TIMER
When the Dehumidifier is running, you can set the Timer to turn the unit off after 1-12 hours.
In order to do this, press the TIMER button and use the up and down arrows to set the length of time
(displayed in the LED display), after which you want the unit to switch off.
When your desired time is displayed press the TIMER button again. The LED screen will revert back
to the relative humidity setting and the TIMER light will illuminate on the control panel to indicate the
timer has been set.
The Timer will operate in any mode.
AIR GUIDE
When the appliance is on, press the air guide louvre manually to select the angle at which you want
the air to blow out from the unit.
Do not operate with the Air Guide Louvre closed.
DEFROST
When the Dehumidifier is operating in low temperatures (under 12°C) the unit will go into a defrost
cycle once an hour. This is to remove any ice that has accumulated on the interior of the unit as a
result of its operation. The DEFROST light will illuminate on the control panel when this occurs.
WARNING: Keep all objects at least 1 metre from the front, sides and rear of the appliance.
To store the unit, remove the plug from the socket and empty the container. Allow the water tank and
the Dehumidifier to dry completely. Clean the air filter. Store the device in a dust-free location,
preferably covered with a sheet of plastic.
IMPORTANT! NEVER COVER THIS DEHUMIDIFIER
Do not use this Dehumidifier with a programmer, remote-control system, separate Timer or any other
device that switches the Dehumidifier on automatically.

WATER DRAINAGE
When the water container is full:
An alarm signal will sound.
The Tank Full light will illuminate on the control panel.
The Dehumidifier will stop automatically.
Empty the water tank and replace it in the correct position; the Dehumidifier will continue
dehumidifying again.
It is possible to connect a drainage tube (not supplied) to the device for permanent water drainage.
If this option is desired, you will need to purchase a suitable tube from your local hardware retailer
(Celsius does not hold tubes as spare parts).
Connect the drainage hose to the drain spout and ensure that the end of the hose is lower than the
drain opening, otherwise the water will not drain and flooding may occur.
Also ensure the water tank is in position (in the unit) otherwise the continuous drainage will not
operate.
Place the end of the drainage hose in a drainage outlet.
When you no longer wish to use the permanent water drainage, disconnect the drainage tube from
the unit.

TECHNICAL SPECIFICATION
Model: CELDH200
Supply: 220-240VAC 50Hz
Wattage: 330-440W
Unit Capacity: 20L/day max (30°C/80%RH)
Tank Capacity: 2.0L
Refrigerant: R134a/180g
PROOF OF PURCHASE
To receive warranty retain receipt as proof of purchase. (Refer to back of booklet).
Problem Cause Solution
The Dehumidifier will not turn
on The power is not connected Insert plug into mains power supply and turn unit on
The Dehumidifier is not
extracting water
The water tank is full Remove the water tank and
empty water
The water tank is not in its
correct position Remove water tank and replace it correct position
The air filter is clogged Clean the air filter as per
instructions in user manual
The temperature or relative
humidity in the room is too
low
It is normal for the
Dehumidifier not to operate in
low humidity or low
temperatures
The Dehumidifier operates,
but reduces the relative
humidity in the room by small
amounts
The room which the
Dehumidifier is operating in is
too large
Recommend using a
Dehumidifier with a larger
capacity
There are too many sources
of humidity
Recommend using a
Dehumidifier with a larger
capacity
The room has too much
ventilation
Reduce the number of
ventilation sources (i.e. close
windows, doors, etc.
TROUBLESHOOTING

Thank you for purchasing this Celsius product. Your product is warranted against faults and manufacture when used in
normal domestic use for a period of one year. In non-domestic use Celsius limits the voluntary warranty to three
months.
Celsius undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault
during the warranty period.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried out
by anyone other than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.
The benefits given to you by this warranty are in addition to other rights and remedies available to you under law in
relation to the goods or services to which this warranty relates.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).
One Year Warranty
Celsius One Year Warranty (IMPORTANT: Please complete and retain this warranty card)
Name
Address
Place Of Purchase Date Of Purchase
Name Of Product Model Number
Attach a copy of the purchase receipt to this warranty card
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.
