CEMEN FA-777S-10 User manual

FIRE ALARM EQUIPMENT
CEME FA-777S-10 2020 FIRE ALARM SYSTEM
Conventional Fire Alarm
Control Panel
1-10 Zone Detector
FA-777S-10FA-777S-10FA-777S-10FA-777S-10
Features
Model YA-CP100 (FA-777S-10) MADE IN CHINA
SHENZHEN USAFE INTELLINGENT
TECHNOLOGY CO., LTD
General
The Product have been designed to offer high standards of performance, reliability, design modern
and quality.
FCP FA-777S-10 can connect to 1-10 LED for zone detector, 1 zone alarm bell
External (key-switch operated)
Internal :
External indicators :
Internal indicators :
Outputs :
Ancillary connections for expansion modules will allow the following :
Fire Alarm Panel :
Reset / Resound / Test zone lamps / Evacuate
Silence alarm sounders
Silence fault sounders
One man detector test
Zone isolate
Revert to short-circuit : fire (no resistors in call points)
Sounder fault
Battery / power supply fault
Mains on
Zone fire
Zone fault
Open circuit zone fault
Short circuit zone fault
Zone isolated
Engineer test selected
Two sounder circuits (alarm relay contacts can be obtained by connecting a relay to a sounder circuit)
Repeater panels
Multiple sounder outputs
Connection to landlord panel
Front Panel : steel panel red color
Side and Back : steel panel white color
**FCP : Fire Alarm Control Panel

FIRE ALARM EQUIPMENT
CEME FA-777S-10 2020 FIRE ALARM SYSTEM
Instructlons
FA-777S-10 1-10 Zone Detector Fire Alarm Control Panel
FA-777S-10 1-10 Zone Detector
System Control and Indicator On Board
NORMAL CONDITION - The green MAINS ON light is lit - The Key switch is at NORMAL
ALARM CONDITION - the alarm sounders operate and the red FIRE lights flash - EVACUATE THE BUILDING
TO SILENCE ALARM SOUNDERS - Turn the key switch to ARM CONTROLS, then press the SILENCE ALARM SOUNDERS
button, the lights will go steady, and the FAULT SOUNDER will Sound, Do not Press the RESET/ RESOUND/ TEST ZONE
LAMPS button until you have identified the detector causing the alarm signal. When you have indentified the cause of the alarm
signal, press the RESET/ RESOUND/ TEST ZONE LAMPS button to re-arm the system. Pressing the button will RESOUND
the sounders, when the alarm still exists.
FAULT CONDITION - The FAULT SOUNDER sounds and a yellow FAULT light comes on. ldentity the fault light - Check that
the MAINS ON light is on and call the engineer.
TO SILENCE - The FAULT SOUNDER Turn the key switch to ARM CONTROLS and press the SILENCE FAULT SOUNDER
button. Press the SILENCE FAULT SOUNDERS to evacuate.
Turning the key switch to ARM CONTROLS and Pressing EVACUATE will always operate the alarm SOUNDERS.
TO TEST - the fault sounder and the zone lamps, turn the key switch to ARM CONTROLS and press the RESET/ RESOUND/
TEST ZONE LAMPS button.
For further information. please check the instruction manual.
1Key Switch Control
2Reset Resound Test Zone Lamps Switch
3 Silence Alarm Sounders Switch
4 Silence Fault Sounders Switch
5 Evacuate Switch
6 Sounder Fault Indicator (Yellow Color)
7 Battery Power Fault Indicator (Yellow Color)
8 Mains On Indicator (Green Color)
9 18 Zone Indicator
Zone Alarm (Red Color)
Zone Fault (Yellow Color)
Model YA-CP100 (FA-777S-10) MADE IN CHINA
SHENZHEN USAFE INTELLINGENT
TECHNOLOGY CO., LTD
12
3
6
7
8
4
59

CEMEN FA-777S-10 2020 FIRE ALARM BELL
FIRE ALARM EQUIPMENT
MODEL FA-777S-10 (1-10 Zone Detector)
BATTERY BACKUP 24VDC 1.2AH
POWER SPECIFICATION
MAINS SUPPLY VOLTAGE 230V + 10 % Va.c.50 / 60Hz
INTERNAL POWER SUPPLY 24-27 VDC
TOTAL OUTPUT CURRENT LIMITED TO 3000mA at 240 VAC
AUXILIARY POWER OUTPUT 24-27 VDC
MAINS SUPPLY MONITORED FOR FAILURE YES
BATTERY CHARGER MONITORED FOR FAILURE YES
BATTERIES MONITORED FOR DISCONNECTION AND FAILURE YES
DETECTOR CIRCUIT SPECIFICATION
NUMBER OF CIRCUITS 10
LINE FAULT MONITORED FOR OPEN CIRCUIT YES
LINE FAULT MONITORED FOR SHORT CIRCUIT YES (Can be disabled)
LINE FAULT MONITORED FOR DETECTOR REMOVAL Yes, if End of Line Monitor Unit fitted in place of End of Line Resistor
END OF LINE RESISTOR (SUPPLIED) VALUE 6800 , 5% TOLERANCE, 0.25W
DETECTOR CONTINUITY DIODES
Silicon 1N4001 or Schottky type
(required if End of Line Monitor Unit fitted to give detector removal
fault)
CALL POINT RESISTOR VALUE (NOT SUPPLIED) 470 to 680 , 0.5W
MAXIMUM NUMBER OF SMOKE DETECTORS PER ZONE 20 (maximum detector current = 2mA)
MAXIMUM NUMBER OF MANUAL CALL POINTS PER ZONE No limit
SOUNDER CIRCUIT SPECIFICATION
NUMBER OF CIRCUITS 2
END OF LINE RESISTOR VALUE 6800 , 5% tolerance, 0.25W
LINE FAULT MONITORED FOR OPEN CIRCUIT YES
LINE FAULT MONITORED FOR SHORT CIRCUIT YES
OUTPUTS FUSED AT 1.6 Amp
MAXIMUM TOTAL OUTPUT CURRENT ALL OUTPUTS 3000 mA
MAXIMUM NO OF BELLS @ 25 mA EACH BELL 120
MAXIMUM NO OF ELECTRONIC SOUNDERS @ 20 mA 150
AUXILIARY RELAY CONTACTS (DO NOT CONNECT MAINS VOLTAGES) 1A 32VDC max Voltage Free
FUSES - ALL FUSES COMPLIANT TO IEC (EN60127PT2)
MAINS TERMINAL BLOCK 630mA T 20mm
SOUNDER OUTPUTS 1.6A F 20mm
AUXILIARY OUTPUT 1A F 20mm
BATTERY FUSE 3A F 20mm
DOOR RETAINING MAGNETS DO NOT USE PANEL POWER SUPPLY AS YOU WILL
DRASTICALLY REDUCE BATTERY STAND - BY TIME
CONNECTION BLOCK
LARGEST ACCEPTABLE CONDUCTOR SIZE 2.5mm2
SMALLEST ACCEPTABLE CONDUCTOR SIZE 0.75mm2
DIMENSION
ENCLOSURE (WIDTH X HEIGHT X DEPTH) 415 X 270 X 105 mm
WEIGHT - WITHOUT BATTERIES + (PAPER BOX) 3800g + (600)
Specifications
