Central Pneumatic 99612 Installation manual

L.E.D. AIR ANGLE
DIE GRINDER
99612
SET UP AND OPERATING INSTRUCTIONS
Distributed exclusively by Harbor Freight Tools®.
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright©2008 by Harbor Freight Tools®. All rights reserved. No portion of this manual or any artwork
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Manual Revised 11h

SKU 99612 For technical questions, please call 1-800-444-3353. Page 2
SAVE THIS MANUAL
Keep this manual for the safety warn-
ings and precautions, assembly, operat-
ing, inspection, maintenance and cleaning
procedures. Write the product’s serial
number in the back of the manual near the
assembly diagram (or month and year of
purchase if product has no number). Keep
this manual and the receipt in a safe and
dry place for future reference.
Safety Alert Symbol and Signal
Words
In this manual, on the labeling,
and all other information provid-
ed with this product:
This is the safety alert
symbol. It is used to alert
you to potential personal
injury hazards. Obey all
safety messages that
follow this symbol to avoid
possible injury or death.
DANGER indicates
a hazardous
situation which, if not
avoided, will result in death or
serious injury.
WARNING
indicates a
hazardous situation which, if
not avoided, could result in
death or serious injury.
CAUTION, used
with the safety
alert symbol, indicates a
hazardous situation which, if
not avoided, could result in
minor or moderate injury.
NOTICE is used to
address practices
not related to personal injury.
CAUTION, without
the safety alert
symbol, is used to address
practices not related to
personal injury.
IMPORTANT SAFETY
INSTRUCTIONS
INSTRUCTIONS PERTAINING
TO A RISK OF INJURY TO
PERSONS
WARNING – When using tools, basic pre-
cautions should always be followed,
including the following:
General
a. To reduce the risks of injury to
persons, read all the instructions
before using this Die Grinder.
Work area
a. Keep the work area clean and well
lighted. Cluttered benches and dark
areas increase the risks of injury to
persons.
b. Keep bystanders, children, and
visitors away while operating the
Die Grinder. Distractions are able to
result in the loss of control.
Personal safety
a. Stay alert. Watch what you are do-
ing and use common sense when
operating this Die Grinder. Do not
use while tired or under the inu-

SKU 99612 For technical questions, please call 1-800-444-3353. Page 3
ence of drugs, alcohol, or medica-
tion. A moment of inattention while
operating increases the risk of injury.
b. Dress properly. Do not wear loose
clothing or jewelry. Contain long
hair. Keep hair, clothing, and
gloves away from moving parts.
Loose clothes, jewelry, or long hair
increases the risk of injury as a result
of being caught in moving parts.
c. Avoid unintentional starting. Be
sure Control Lever (4) is not de-
pressed before connecting to the
air supply. Do not carry with your
nger on the Control Lever (4) or con-
nect the Die Grinder to the air supply
with the Control Lever (4) depressed.
d. Do not overreach. Keep proper
footing and balance at all times.
Proper footing and balance enables
better control of the Die Grinder in
unexpected situations.
e. Use safety equipment. A
dust mask, non-skid safety
shoes and a hard hat must
be used for the applicable
conditions. Wear heavy-duty work
gloves during use.
f. Always wear eye protec-
tion. Wear ANSI-ap-
proved safety goggles.
g. Always wear hearing
protection when using
the Die Grinder. Pro-
longed exposure to high
intensity noise is able to cause hear-
ing loss.
h. Risk of Electric Shock. This tool
is not provided with an insulated
gripping surface. Contact with a
″live″ wire will also make exposed
metal parts of the tool ″live″ and
shock the operator.
Tool use and care
a. Use clamps or another practical
way to secure and support the
workpiece to a stable platform.
Holding the work by hand or against
the body is unstable and is able to
lead to loss of control.
b. Do not force the Die Grinder. Use
the correct tool for the application.
The correct tool will do the job bet-
ter and safer at the rate for which the
tool is designed.
c. Do not use the Die Grinder if the
Control Lever (4) does not turn the
tool on or off. Any tool that cannot
be controlled with the switch is dan-
gerous and must be repaired.
d. Disconnect the Die Grinder from
the air source before making any
adjustments, changing acces-
sories, or storing. Such preventive
safety measures reduce the risk of
starting unintentionally. Release the
Control Lever (4) and detach the air
supply. Safely discharge any residual
air pressure before leaving the work
area.
e. Store the idle Die Grinder out of
reach of children and other un-
trained persons. Any tool is danger-
ous in the hands of untrained users.
f. Maintain the tool with care. Keep
a cutting or grinding tool sharp and
clean. A properly maintained tool,
with sharp cutting edges and clean
grinding surfaces reduces the risk of
binding and is easier to control.

SKU 99612 For technical questions, please call 1-800-444-3353. Page 4
g. Check for misalignment or bind-
ing of moving parts, breakage of
parts, and any other condition that
affects this tool’s operation. If dam-
aged, have the Die Grinder serviced
before using. Many accidents are
caused by poorly maintained tools.
There is a risk of bursting if the tool is
damaged.
h. Use only accessories that are
identied by the manufacturer for
the specic tool model. Use of an
accessory not intended for use with
the specic tool model, increases the
risk of injury to persons.
Service
a. Service to this Die Grinder must be
performed only by qualied repair
personnel.
b. When servicing this tool, use only
identical, authorized, replacement
parts.
c. Use only the lubricants supplied
with the tool or specied by the
manufacturer.
Air source
a. Never connect to an air
source that is capable of
exceeding 200 psi. Over
pressurizing the tool may
cause bursting, abnormal operation,
breakage of the tool or serious injury
to persons. Use only clean, dry,
regulated compressed air at the rated
pressure or within the rated pressure
range as marked on the tool. Always
verify prior to using the tool that the
air source has been adjusted to the
rated air pressure or within the rated
air-pressure range.
b. Never use oxygen, carbon dioxide,
combustible gases or any bottled
gas as an air source for the tool.
Such gases are capable of explosion
and serious injury to persons.
SAVE THESE
INSTRUCTIONS.
SYMBOLS AND
SPECIFIC SAFETY
INSTRUCTIONS
Symbol Denitions
Symbol Property or statement
noNo-load speed
.../min Revolutions or reciprocation per
minute
PSI Pounds per square inch of pressure
ft-lb Foot-pounds of torque
BPM Blows per minute
CFM Cubic Feet per Minute ow
SCFM Cubic Feet per Minute ow at
standard conditions
NPT National pipe thread, tapered
NPS National pipe thread, straight
WARNING marking concerning Risk
of Eye Injury. Wear ANSI-approved
eye protection.
WARNING marking concerning Risk
of Hearing Loss. Wear hearing
protection.
WARNING marking concerning Risk
of Respiratory Injury. Wear NIOSH-
approved dust mask/respirator.
Chart continued in next column.

SKU 99612 For technical questions, please call 1-800-444-3353. Page 5
Symbol Denitions
Symbol Property or statement
WARNING marking concerning Risk
of Explosion.
Specic Safety Instructions
1. WARNING:
To prevent serious injury:
2. Wear ANSI-approved safety goggles
during set up and use.
3. Accessories must be rated to at least
20,000 RPM.
4. The warnings and precautions dis-
cussed in this manual cannot cover
all possible conditions and situations
that may occur. It must be under-
stood by the operator that common
sense and caution are factors which
cannot be built into this product, but
must be supplied by the operator.
5. WARNING: Some dust created by
power sanding, sawing, grinding, drill-
ing, and other construction activities,
contains chemicals known [to the
State of California] to cause cancer,
birth defects or other reproductive
harm. Some examples of these
chemicals are:
• Lead from lead-based paints
• Crystalline silica from bricks and
cement or other masonry products
• Arsenic and chromium from chemi-
cally treated lumber
Your risk from these exposures var-
ies, depending on how often you do
this type of work. To reduce your
exposure to these chemicals: work in
a well ventilated area, and work with
approved safety equipment, such as
those dust masks that are specially
designed to lter out microscopic
particles. (California Health & Safety
Code § 25249.5, et seq.)
WARNING: The brass components
of this product contain lead, a chemi-
cal known to the State of California
to cause birth defects (or other repro-
ductive harm). (California Health &
Safety code § 25249.5, et seq.)
6. Only use with accessories rated to
handle the forces exerted by this tool
during operation. Other accessories
not designed for the forces gener-
ated may break and forcefully launch
pieces.
7. Attach all accessories properly to the
tool before connecting the air sup-
ply. A loose accessory may detach or
break during operation.
8. Obey the manual for the air compres-
sor used to power this tool.
9. Install an in-line shutoff valve to allow
immediate control over the air supply
in an emergency, even if a hose is
ruptured.
10. Use this tool with both hands only.
Using tools with only one hand can
result in loss of control.
11. Do not lay the tool down until it has
come to a complete stop. Moving
parts can grab the surface and pull
the tool out of your control.
Vibration Precautions
This tool vibrates during use. Re-
peated or long-term exposure to vibra-
tion may cause temporary or permanent
physical injury, particularly to the hands,
arms and shoulders. To reduce the risk of
vibration-related injury:

SKU 99612 For technical questions, please call 1-800-444-3353. Page 6
1. Anyone using vibrating tools regu-
larly or for an extended period should
rst be examined by a doctor and
then have regular medical check-
ups to ensure medical problems are
not being caused or worsened from
use. Pregnant women or people
who have impaired blood circulation
to the hand, past hand injuries, ner-
vous system disorders, diabetes, or
Raynaud’s Disease should not use
this tool. If you feel any medical or
physical symptoms related to vibra-
tion (such as tingling, numbness, and
white or blue ngers), seek medical
advice as soon as possible.
2. Do not smoke during use. Nico-
tine reduces the blood supply to the
hands and ngers, increasing the risk
of vibration-related injury.
3. Wear suitable gloves to reduce the
vibration effects on the user.
4. Use tools with the lowest vibration
when there is a choice between dif-
ferent processes.
5. Include vibration-free periods each
day of work.
6. Grip tool as lightly as possible (while
still keeping safe control of it). Let
the tool do the work.
7. To reduce vibration, maintain tool as
explained in this manual. If abnormal
vibration occurs, stop immediately.
SAVE THESE
INSTRUCTIONS.
FUNCTIONAL DESCRIPTION
Specications
Maximum Air
Pressure 90 PSI
Air Inlet 1/4” -18 NPT Female
Maximum
Speed* 20,000 RPM
Air Consumption 3 CFM @ 90 PSI
Batteries (3) LR44 Button
Batteries (Included)
Light Single Clear 5mm OD
LED Bulb
Light Activation Push Button, Two
Position
* Maximum speed at stated maximum air pressure. Ex-
cess air pressure is hazardous and may cause the tool
to exceed stated maximum speed.
Components and Controls
Figure 1
Control Lever (4)
Clamp Nut (32)
Air Inlet (1) On/Off Button for LED (37)

SKU 99612 For technical questions, please call 1-800-444-3353. Page 7
INITIAL TOOL SET UP/
ASSEMBLY
Read the ENTIRE IMPORTANT
SAFETY INFORMATION
section at the beginning of this
manual including all text under
subheadings therein before set
up or use of this product.
Note: For additional information regarding
the parts listed in the following pages,
refer to the Assembly Diagram near
the end of this manual.
Unpacking
When unpacking, check to make sure
that the item is intact and undamaged. If
any parts are missing or broken, please
call Harbor Freight Tools at the number
shown throughout the manual as soon as
possible.
• This air tool may be shipped with a
protective plug covering the air inlet.
Remove this plug before set up.
Air Supply
TO PREVENT
EXPLOSION:
Use only clean, dry, regulated,
compressed air to power this
tool. Do not use oxygen,
carbon dioxide, combustible
gases, or any other bottled
gas as a power source for this
tool.
1. Incorporate an in-line oiler, shut-off
valve, regulator with pressure gauge,
and lter for best service, as shown in
the diagram above. An in-line shut-
off valve is an important safety
device because it controls the air
supply even if the air hose is rup-
tured.
Note: If an automatic oiler system is not
used, add a few drops of Pneumatic
Tool Oil to the airline connection be-
fore operation. Add a few more drops
after each hour of continual use.
2. Attach an air hose to the compres-
sor’s air outlet. Connect the air hose
to the air inlet of the tool. Other com-
ponents, such as a connector and
quick coupler, will make operation
more efcient, but are not required.
WARNING! TO PREVENT SERIOUS
INJURY FROM ACCIDENTAL
OPERATION:
Do not install a female quick
coupler on the tool. Such a coupler
contains an air valve that will allow
the air tool to retain pressure and

SKU 99612 For technical questions, please call 1-800-444-3353. Page 8
operate accidentally after the air
supply is disconnected.
Note: Air ow, and therefore tool perfor-
mance, can be hindered by under-
sized air supply components.
3. The air hose must be long enough
to reach the work area with enough
extra length to allow free movement
while working.
4. Make sure the tool’s throttle or switch
is in the off position; refer to Opera-
tion section for description of con-
trols.
5. Close the in-line safety valve be-
tween the compressor and the tool.
6. Turn on the air compressor according
to the manufacturer’s directions and
allow it to build up pressure until it
cycles off.
7. Adjust the air compressor’s output
regulator so that the air output is
enough to properly power the tool,
but the output will not exceed the
tool’s maximum air pressure at any
time. Adjust the pressure gradually,
to set the right pressure range.
8. Inspect the air connections for leaks.
9. If the tool will not be used at this
time, turn off and detach the air sup-
ply, safely discharge any residual air
pressure, and release the Control
Lever (4) to prevent accidental opera-
tion.
Note: Residual air pressure should not be
present after the tool is disconnected
from the air supply. However, it is a
good safety measure to attempt to
discharge the tool in a safe fashion
after disconnecting to ensure that the
tool is disconnected and not pow-
ered.
OPERATING INSTRUCTIONS
Read the ENTIRE IMPORTANT
SAFETY INFORMATION
section including all text under
subheadings therein before set
up or use of this product.
Inspect tool before use, looking
for damaged, loose, and
missing parts. If found, do not
use tool until repaired.
Tool Set Up
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Release the Control Lever (4),
detach the air supply, safely
discharge any residual air
pressure in the tool, before
performing any inspection,
maintenance, or cleaning
procedures.
TO PREVENT SERIOUS
INJURY:
Do not adjust or tamper with
any control or component in a
way not specically explained
within this manual. This can
result in tool failure or other
serious hazards.
NOTE: Grinding attachments (tools) are
necessary for using this Die Grinder.
They are not included but are avail-
able at Harbor Freight Tools.

SKU 99612 For technical questions, please call 1-800-444-3353. Page 9
Grinding Attachment Installation
1. Select the grinding attachment appro-
priate to your needs.
2. Select the Collet (31) that has the
correct diameter (either 1/4” or 1/8”).
3.
Figure 2
Clamp Nut (32)
Collet (31)
Insert the Collet (31) into the Clamp
Nut (32). See Figure 2.
4. Thread the Clamp Nut (32) onto the
Chuck Casing (29) a few turns.
5.
Figure 3
Clamp Nut (32) with Col-
let (31) attached.
Grinding Attachment
(not supplied)
Switch (ON/OFF) (37)
Insert the shaft of the grinding attach-
ment (not supplied) through the ared
end of the Collet (31). See Figure 3.
6. Place Wrench (35) onto the at
edges of the Chuck Casing (29), hold
steady.
7.
Wrench (35) Wrench (36)
Figure 4
Chuck
Casing
(29)
Clamp Nut (32)
Tighten
Place Wrench (36) onto the at edges
of the Clamp Nut (32) and tighten in
counterclockwise motion. See Fig-
ure 4.
Work Piece and Work Area Set Up
1. Designate a work area that is clean
and well-lit. The work area must not
allow access by children or pets to
prevent injury and distraction.
2. Route the air hose along a safe route
to reach the work area without creat-
ing a tripping hazard or exposing the
air hose to possible damage. The air
hose must be long enough to reach
the work area with enough extra
length to allow free movement while
working.
3. Secure loose workpieces using a vise
or clamps (not included) to prevent
movement while working.

SKU 99612 For technical questions, please call 1-800-444-3353. Page 10
4. There must not be hazardous ob-
jects (such as utility lines or foreign
objects) nearby that will present a
hazard while working.
General Operating Instructions
1. If an automatic oiler is not used, add
a few drops of Pneumatic Tool Oil
to the airline connection before use.
Add a few drops more after each
hour of continual use.
2. This Die Grinder has a variable
speed control. By squeezing the
Control Lever (4) you can control the
speed of the action. Squeeze more
for higher speed and less for slower
speed.
3. If you are working in tight areas
where light is a premium, switch on
the LED Light (38) by pushing the
Switch (37). When (or if) light is not
needed be sure to turn off by de-
pressing the Switch (37).
4. To begin, grip the Die Grinder rmly.
Start grinding by squeezing the Con-
trol Lever (4) gently before you touch
the Die Grinder to the work surface.
5. Allow the grinding attachment (not
included) to do the work. Do not use
excessive force against the surface
you are grinding. If you place too
much pressure on the workpiece
and the Die Grinder stalls, immedi-
ately release the Control Lever (4)
and pull the Die Grinder away from
the work surface. If the tool requires
more force to accomplish the task,
verify that the tool is receiving suf-
cient, unobstructed airow (CFM) and
increase the pressure (PSI) output of
the regulator up to the maximum air
pressure rating of this tool (90PSI).
6. CAUTION! TO PREVENT TOOL
AND ACCESSORY FAILURE,
RESULTING IN INJURY:
Do not exceed the tool’s maximum
air pressure rating of 90 PSI.
If the tool still does not have sufcient
force at maximum pressure and
sufcient airow, then a larger tool
may be required.
7. To prevent accidents, when nished
working, release the Control Lever
(4), detach the air supply, safely dis-
charge any residual air pressure.
8. Clean external surfaces of the tool
with clean, dry cloth, and apply a thin
coat of tool oil. Then store the tool
indoors out of children’s reach.
TROUBLE SHOOTING
Problem Possible
Causes
Possible Solutions
Die
Grinder
not
achieving
full RPM
speed
1. Problem
with air supply.
2. Faulty
regulator on
compressor.
3. Obstructed
Control Lever
(4).
1. Check air
hoses and replace
if necessary.
NEVER repair air
hoses.
2. Check regulator
and replace if
needed.
3. Clean around
Control Lever (4)
to ensure free
movement.
Grinder
is not
shaving
metal fast
enough
1. Grinding
attachment
is not coarse
enough.
1. Change
grit of grinding
attachment.
Higher numbers,
more coarse.
Smaller numbers,
less coarse.

SKU 99612 For technical questions, please call 1-800-444-3353. Page 11
USER-MAINTENANCE
INSTRUCTIONS
Procedures not specically
explained in this manual
must be performed only by a
qualied technician.
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Release the Control Lever (4),
detach the air supply, and
safely discharge any residual
air pressure before
performing any inspection,
maintenance, or cleaning
procedures.
TO PREVENT SERIOUS
INJURY FROM TOOL
FAILURE:
Do not use damaged
equipment. If abnormal
noise, vibration, or leaking
air occurs, have the problem
corrected before further use.
TO PREVENT EXPLOSION:
Lubricate the tool only
with specied lubricants.
Lubricate the air inlet
using only pneumatic tool
oil. Lubricate the internal
mechanism using only
white lithium grease. Other
lubricants may damage the
mechanism and may be
highly ammable, causing an
explosion.
Cleaning, Maintenance, and
Lubrication
Note: These procedures are in addition to
the regular checks and maintenance
explained as part of the regular op-
eration of the air-operated tool.
1. Daily - Air Supply Maintenance:
Every day, perform maintenance on
the air supply according to the com-
ponent manufacturers’ instructions.
The lubricator’s oil level needs to be
maintained and the moisture lter
must be regularly drained. Perform-
ing routine maintenance on the air
supply will allow the tool to operate
more safely and will also reduce wear
on the tool.
2. Weekly - Grease Lubrication:
Lubricate the internal mechanism of
the tool, using white lithium grease
through the grease ttings.
3. Quarterly (every 3 months) - Tool
Disassembly, Cleaning, and In-
spection:
Have the internal mechanism
cleaned, inspected, and lubricated by
a qualied technician. If the Vanes
(19) need replacement, all vanes
should be replaced as a set.
Battery Replacement
1. Remove the Switch (37) by turning
it counterclockwise until it releases
from the top of the Angle Head (26).
2. Turn the Die Grinder over and the
three Batteries (40) will drop out of
the Battery Compartment.
3. Replace the used Batteries with new,
fresh Batteries identical to the Batter-
ies that were removed. Use caution

SKU 99612 For technical questions, please call 1-800-444-3353. Page 12
and place new batteries in correct
polarity positions matching the old/
used batteries.
4. NOTE: Always dispose of old, used
batteries in accordance with all local,
state and federal regulations. NEV-
ER incinerate batteries. NEVER mix
old and new batteries.
5. Replace the Switch (37) by threading
it onto the top of the Angle Head (26).
PLEASE READ THE FOLLOWING
CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR
HAS PROVIDED THE PARTS LIST AND
ASSEMBLY DIAGRAM IN THIS MANUAL AS
A REFERENCE TOOL ONLY. NEITHER THE
MANUFACTURER OR DISTRIBUTOR MAKES
ANY REPRESENTATION OR WARRANTY OF
ANY KIND TO THE BUYER THAT HE OR SHE
IS QUALIFIED TO MAKE ANY REPAIRS TO THE
PRODUCT, OR THAT HE OR SHE IS QUALIFIED
TO REPLACE ANY PARTS OF THE PRODUCT.
IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT
ALL REPAIRS AND PARTS REPLACEMENTS
SHOULD BE UNDERTAKEN BY CERTIFIED
AND LICENSED TECHNICIANS, AND NOT BY
THE BUYER. THE BUYER ASSUMES ALL RISK
AND LIABILITY ARISING OUT OF HIS OR HER
REPAIRS TO THE ORIGINAL PRODUCT OR
REPLACEMENT PARTS THERETO, OR ARISING
OUT OF HIS OR HER INSTALLATION OF
REPLACEMENT PARTS THERETO.
Record Product’s Serial Number Here:
______________________________.
Note: If product has no serial number,
record month and year of purchase
instead.
Note: Some parts are listed and shown for
illustration purposes only, and are not
available individually as replacement
parts.
PARTS LIST
No # DESCRIPTION Q’TY
1Inlet 1
2End Cap 1
3 Housing 1
4 Control Lever 1
5 Spring Pin 1
6 Bushings 1
7 Valve 1
8 O-Ring 1
9 Spring 1
10 Speed 1
11 O-Ring 1
12 O-Ring 1
13 Valve Screw 1
14 Ball Bearing 2
15 Rear End Plate 1
16 Ball 3
17 Cylinder 1
18 Rotor 1
19 Vanes 4
20 Bushings 1
21 Front End Plate 1
22 Ball Bearing 2
23 Nipple 1
24 Bevel Gear 1
25 Nut 1
26 Angle Head 1
27 Bevel Gear 1
28 Key 1
29 Chuck Casing 1
30 Bearing Cap 1
31 Collet 1
32 Clamp Nut 1
33 O-Ring 1
34 O-Ring 1
35 Wrench 11MM 1
36 Wrench 17MM 1
37 Switch (ON/OFF) 1
38 LED 1
39 LED Seat 1
40 Batteries 3

SKU 99612 For technical questions, please call 1-800-444-3353. Page 13
ASSEMBLY DIAGRAM

SKU 99612 For technical questions, please call 1-800-444-3353. Page 14
90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability
standards, and warrants to the original purchaser that this product is free from defects in materials
and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to
damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside
our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance. We
shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special
or consequential damages arising from the use of our product. Some states do not allow the exclusion
or limitation of incidental or consequential damages, so the above limitation of exclusion may not apply
to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection veries the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specic legal rights and you may also have other rights which vary from state to
state.
