Centrometal HPCU360iCM User manual

1
CONTROL UNIT
HPCU360iCM
FOR HEAT PUMPS
Technical manual for control unit
ISSUE: 1.2_EN
11-2020
* Devices are not included in the standard equipment of the control unit.
HPnet300CM*
HPxTouchCM*
HPx40CM*
HPx2kCM*

ELECTRIC DEVICE UNDER VOLTAGE!
Before any action related to the power supply (cables
connection, device installation etc.) check if the control unit is
not connected to the power mains!
Installation should be done by a person with appropriate
electrical qualifications. Improper cables connection could
result in the control unit damage.
The control unit can’t be used in steam condensation
conditions and can’t be exposed to water.

TABLE OF CONTENTS
1RECOMMENDATIONS REGARDING SAFETY ........ 4
2GENERAL INFORMATION .................................... 5
3INFORMATION ABOUT DOCUMENTATION......... 5
4STORAGE OF DOCUMENTATION......................... 5
5APPLIED SYMBOLS .............................................. 5
6DIRECTIVE WEEE 2012/19/UE............................. 5
USER SETTINGS ............................................ 7
7THE CONTROL UNIT DESCRIPTION...................... 8
7.1 THE CONTROL UNIT CONTROL ................................. 8
7.2 THE CONTROL UNIT OPERATION .............................. 8
7.3 PRESET TEMPERATURE SETTINGS ............................. 8
7.4 HEATING/COOLING CIRCUIT SETTINGS ...................... 9
7.5 DHW SETTINGS................................................... 9
7.6 TIME SCHEDULES ................................................. 9
7.7 OPERATING MODES SETTINGS................................. 9
7.8 USER SETTINGS.................................................. 10
7.9 COOPERATION WITH ROOM PANEL AND ROOM
THERMOSTAT ................................................................ 11
7.10 COOPERATION WITH THE INTERNET MODULE........... 11
INSTALLATION AND SERVICE SETTINGS....... 13
8HYDRAULIC SCHEMES ....................................... 14
9TECHNICAL DATA .............................................. 16
10 CONDITIONS OF STORAGE AND TRANSPORT ... 16
11 THE CONTROL UNIT INSTALLATION .................. 16
11.1 INSTALLATION REQUIREMENTS.............................. 16
11.2 INSTALLATION OF CONTROL PANEL......................... 16
11.3 INSTALLATION OF MODULE................................... 17
11.4 TEMPERATURE SENSORS INSTALLATION .................. 17
11.5 TEMPERATURE SENSORS CHECK............................. 18
11.6 CONNECTING PUMPS .......................................... 18
11.7 CONNECTING MIXER SERVO.................................. 18
11.8 OUTPUT TEST.................................................... 19
11.9 CONNECTION OF ROOM PANEL OR ROOM THERMOSTAT19
11.10 CONNECTING THE INTERNET MODULE .................... 19
11.11 WEATHER CONTROL SETTINGS .............................. 19
11.12 STABILIZATION OF ROOM TEMPERATURE................. 20
12 CONNECTING ELECTRICAL SYSTEM................... 20
12.1 CONNECTING THE WIRES ..................................... 22
12.2 ELECTRICAL SCHEME ........................................... 23
13 SERVICE MENU –STRUCTURE........................... 24
14 DESCRIPTION OF SERVICE PARAMETERS .......... 25
15 REPLACING COMPONENTS ............................... 28
15.1 MAINS FUSE REPLACEMENT.................................. 28
15.2 CONTROL PANEL REPLACEMENT ............................ 28
15.3 EXECUTIVE MODULE REPLACEMENT ....................... 28
16 FIRMWARE UPDATE.......................................... 28

4
1Recommendations regarding safety
Requirements concerning safety are listed in
particular sections of this instruction. Apart
from them it in necessary to fulfill the
following requirements.
•The control unit can be assembled
only by qualified installer and in
accordance with currently valid
standards and regulations.
•Prior to starting the assembly, repairs
or maintenance and during the
execution of any connection works, it
is necessary to switch off the mains
supply and make sure that no
terminals no electrical wires are under
voltage.
•After turning off the control unit
terminals of the control unit can be
under a dangerous level of voltage.
•The control unit can be utilized only in
accordance with its intended use.
•Additional automatics should be used
in order to protect central heating and
DHW system against the results of
control unit failure or software errors.
Particularly control automatics which
reduce DHW temperature in order to
protect users against burns.
•Values of programmed parameters
must be set in accordance with a
particular building and hydraulic
system.
•The control unit is not an intrinsically
safe device. It means that in case of
failure it can be a source of sparks or
high temperature which surrounded
by ashes or flammable gases can
cause fire or explosion.
•Modification of the programmed
parameters should be made only by a
person who read this manual.
•Use only in heat and cooling system
made in accordance with currently
valid regulations.
•Electrical system including the control
unit should be 3-wired and protected
with fuse selected in accordance with
used loads.
•The control unit cannot be used with
damaged housing.
•Never make any modifications in
control unit structure.
•The control unit consists of two
components: control panel and main
module. Replaced component must be
compatible.
•Keep children away from the control
unit.

5
2General information
The HPCU360iCM control unit is intended for
a heat pump control and for controlling of
space heating and cooling, and for domestic
hot water (DHW) preparation as well.
3Information about documentation
The control unit manual is divided into two
parts: for user and serviceman. Yet, both
parts contain important information,
significant for safety issues, hence the user
should read both parts of the manual.
Device producer is not responsible for any
damages caused by failure to observe these
instructions.
4Storage of documentation
This assembly and operation manual, as well
as any other applicable documentation,
should be stored diligently, so that it was
available at any time. In the case of removal
or sale of the device, the attached
documentation should be handed over to the
new user.
5Applied symbols
In this manual the following symbols are
used:
- useful information and tips,
- important information, failure to
observe these can cause damage of
property, threat for human and
household animal health and life.
Caution: the symbols indicate important
information, in order to make the manual
more lucid. Yet, this does not exempt the
user from the obligation to comply with
requirements which are not marked with
symbol.
6Directive WEEE 2012/19/UE
Purchased product is designed and made of
materials of highest quality. The product
meets the requirements of the Directive
2012/19/EU of 4 July 2012 on waste
electrical and electronic equipment
(WEEE), according to which it is marked by
the symbol of crossed-out wheeled bin (like
below), meaning that product is subjected to
separate collection.
Responsibilities after finishing a period of
using product:
•dispose of the packaging and product at
the end of their period of use in an
appropriate recycling facility,
•do not dispose of the product with other
unsorted waste,
•do not burn the product.
By adhering obligations of waste electrical
and electronic equipment controlled disposal
mentioned above, you avoid harmful.
