FEATURES
Photo shows optional accessories installed.

2
Building Instructions for:
Introduction
Congratulations on your purchase of Century Helicopter Product's scale RC Robinson R22HP
helicopter model. Our helicopters that are simpler to build, easier to see and look fantastic.
Whether you are just beginning in helicopters, wanting to start in scale or an accomplished
pilot, Century offers a wide selection of helicopters to fulfill your dreams in scale. Century has
combined their world class helicopter mechanics with awesome fiberglass fuselages designed to
mount directly inside with little or no modifications.
Warning
This radio controlled model is not a toy! It is a precision machine requiring proper assembly and
setup to avoid accidents. It is the responsibility of the owner to operate this product in a safe manner
as it can inflict serious injury. It is recommended that if you are in doubt of your abilities, seek
assistance from experienced radio control helicopter modelers and associations. As the manu-
facturer, we assume no liability for the use of this product.
Pre-assembly Information
Upon opening the kit, all the major component parts are packaged in bags to correspond to
specific sections of the manual, greatly facilitating assembly. Various assemblies have been pre-
assembled, only requiring the final assembly and installation of the various sub-assemblies. The
screws and nuts required for each step are packaged in the same bag as the parts for that step. Be
careful not to lose any of the hardware when opening each bag. Care has been taken in filling and
packing of each bag. However mistakes do happen, if there is a parts shortage or any hardware
missing, please feel free to contact us at:
Century Helicopter Products
523 Sinclair Frontage Road
Milpitas, CA 95035 USA
Fax: [phone]
www.centuryheli.com
e-mail: [email protected]
CN1076 Robinson 22HP ARF 50 size Helicopter

3
This manual has been written for Century’s 50 size Robinson 22HP scale helicopter. This
manual should be reviewed before starting the assembly as there are a few complicated sections to
attach the various fiberglass components to the mechanics.
InstructionalDetail
Every attempt has been made to ease the assembly of your helicopter, at each step where there are
complex assemblies, there are detailed drawings, photos and written instructions to walk you
through each step. Remember to take a few minutes before each step to carefully examine the
instructions in order to become familiar with the parts and assembly sequence before beginning that
step.
Robinson 22HP Construction Manual
CN2015 Hardened Tip Hex Screw Driver Set
CN2026 Pitch Gauge with Paddle Gauge.
CN2034A 150 Curve Tip Ball link Pliers.
CN2052 Main Blade Balancer.
CN2054 Special Glow Plug Wrench Set.
CN2055 Ball Link Sizing Tool.
CN2070 Universal Flybar Lock.
CN2155 Piston Locking Tool.
CN2219 Ball Link Easy Driver.
CN2255 Control Rod Guage.
CNWI26555 5.5mm Nut Driver.
CNWI26570 7.0mm Nut Driver.
Screwdrivers - Slotted and Phillips head.
Long-Nosed Pliers, wide jaw pliers.
Allen Wrenches - 1.5mm, 2.0mm, 2.5mm.
( supplied in kit ) + 3.0mm
Appropriate Socket Wrench
(glow plug wrench for engine shaft nut)
Hobby Scissors, clear tape, masking tape
Double Sided Foam Tape ( 1/16" - 3/32" )
Foam Rubber ( radio packing )
JB Weld, Goop or Zap-a-Dap-a-Goo
Thread lock liquid (e.g. Locktite)
Hobby Grease ( Super Lube )
Oil to lubricate sliding shafts (Tri-Flow)
Recommended Tools&Accessories
Symbols used to help assist you in building the kit:
Apply
oil Apply
threadlock
Special
Attention
Full Scale
Drawing Repeat Steps
as specified
Apply JB
Weld
Partially
tighten
Purchased
Separately
Apply
Grease
Cut away
Shaded
Portion
Helpful
Tip
Hardware Description and Identification: M3x6 = 3x6mm and can refer to screws or ball bearings.
M3x6 Phillips Machine Screw
M - metric
3 - diameter
6 - length
M3x6 Self Tapping Screw
M - metric
3 - diameter
6 - length
M3x10 Socket Cap Screw
M - metric
3 - diameter
10 - length
3x7 Ball Bearing M - metric
3 - inside
7 - outside
Thetools andmaterials listedbelow are
theminimumneededto buildthehelicopter: Inaddition, thefollowingwillmakeassemblyandsetup
easier,and proveusefullaterin yourmodeltoolbox:
Removeoil
residue from
fasteners before applying
any threadlock agent.
Tap holes with
machine screws
before installing steel
balls in plastic.
Tap holes with
machine screws
before installing self tap
screws in plastic.
Tap holes with
machine screws
carefully in plastic holes
with bottoms.

4
#CN1076-13
RotorHeadYoke
#HI3181Damper
Rubberx2
Step 1 Rotor Head Block
Pressinthe Damper RubbersHeadBlock.Apply
Triflowoilorsimilarteflonoiltotheinsideofthe
dampers.Dampersshould be replacedonayearly
basis.
#HI3167E
Special Long Ball x 2
#HI3167G
Tie Bar x 2
#HI3167B
OffsetPlatex2
#HI3167E
M3x6ButtonHead
Socket Screw x 2
#HI3167F
Bearing Cup x 2
Notice that the two steel
balls are on the left side of
the rotor head.
#CNBB0840
4x8 Ball Bearing x 2
Step 2 Seesaw Assembly
Insertoneballbearingintoeach
bearingcupandinsert into the offset
plate. Applyonesmalldropofmedium
CAglueto the backsideofthe bearing
cupto secure totheoffset plate. Insert
oneballbearingintoeachtiebar.
Insertone M3x6 buttonheadscrew
throughtherightsideholeofthe offset
plateinto onetie bar. Make two
identicalsubassemblies.Notethatthe
bearingcupsfaceoutwardsfromthe
headblock. Insert one M3x15button
headscrewthroughthetie bar bearing,
slideonesteelspacerandcarefully
applythreadlock to the exposed
threadsandinsertintotherightsideof
theheadblock.Donot overtighten.
Repeatforthe second subassembly.
Oncecomplete,insert one M3x7
Specialballintotheleftsideofeach
offsetplatetocompletetheassembly.
#CNBB0730
3x7 Ball Bearing x 2
#HI3167G
Tie Bar Spacer x 2
#HI3167G
M3x15ButtonHead
Socket Screw x 2
Completed
RotorHead

Robinison 22HP Manual
5
Step4 FeatheringSpindle
&Blade GripAssembly
Applyteflonoiltothe rubber
dampers.InserttheFeathering
Shaftintothroughtheheadblock,
slideone M6X10 Washeron each
sideoftheshaft.Installtheblade
grip,notethedirectionofthe bell
mixerarmfollowedbyoneM8x13
Washer, one M6x12ThrustBall
Bearing(installthefirststeel
washer(large insidediameter)
followedbytheballrace,remem-
berto grease theball race, fol-
lowedby the second steelwasher
(smallerinside diameter))andone
M5Locknut. Tighten the locknut,
usingthe glowplugsocketwrench
onone nutwhileholdingtheother
withpliers,tightenthenutsuntil
bothblade gripsturnfreelywithout
anyexcessiveendplay.
AssemblePushrodIx2,measuring
28mmcenterto center andconnect
theseesawballtothe long ball on
thebellmixer.Makesureboth
pushrodsarethesamelength.
Step 3 Main Rotor GripAssembly
Inserttheslidetubeintothebellmixerarm
fromtheoffsetside,throughthe
oilitebearings(installedalready)
andsecure onto the blade grip
withoneM3x16Socket Cap
screw and M3x7 Flat washer.
Installonelongballandoneshortball(Tip2)
intotheBell Mixer. File the bolt flush to the
insideofthe blade grip mount.Installtwo
M6x13BallBearings into both ends of the
bladegripassembly. Completethe second
bladegripin exactly the same way.
#HI3184
MainRotor Blade
Grip x 2
#CNBB1360
6x13BallBearing x
4
#CNLR1016A
LongBall x 2
#CNLR1014
ShortBallx2
M3x16Socket
Screw x 2 & M3x7
FlatWasherx2
#HI3189
BellMixerArm
#HI3189
SlideTube
M5Locknut
x2
M6 x 10 Flat
Washer x 2
Topof blade
griphasbevel.
#HW3180A
Feathering
Shaft
M8x13Flat
Washer x 2
#CNBB1260T
6x12ThrustBall
Bearing x 2
ShortBall
LongBall
28mm Pushrod I x 2
28mmCenter to Center

6
Step5 FlybarControlYokeAssembly
UsinganavailableM3x12ButtonHeadScrew,
insertapproximately halfthelengthof thescrew
toformthreadsinto the smaller,taperedendsof
thecontrolarmsandthecontrol arm stand-offs.
AssemblePushrodA(115mmCenter to
Center)andpressoneball link end (withbend
inrod)onto each doublestuddedsteelball,
makingsurethatpressureisappliedfrom the
sideofthe balllinkwiththeCenturyname. All
balllinksaredesignedtobe installed in one
directiononly.Whileholdingoneflybarcontrol
arm,startthreadingthedoublestudded steel
ball. Whenit becomesdifficulttoturnwith
fingers,startthecontrolarm stand-off and usea
flatscrewdrivetoturntheslotintheend.
Completethesecondflybarcontrolarm.
Step6 Flybar &FlybarPaddleAssembly
SlideandcentertheFlybar through the seesawarm assembly. CarefullylookattheFlybarControlArm andnotice that
wheninstalledcorrectly, thesecuring set screw ison top. Insertone 4x6x0.5 washeragainst each bearingthentheflybar
controlarm.Insert one M3x12 ButtonHead SocketScrew intoeach FlybarControlArm,securingtheassembly
together,thetaperedstandoffneedstobeheldwithplierswhiletighteningthebuttonheadscrew.Looselytightenthe
M4x5SetScrewsintotheround aluminum inserts. Using a ruler,checkthedistance between the end of theflybar and
thecontrolarmand adjust until thelengths arethe same.Remove eachM4x5 SetScrew andlocktight inplace overthe
flatspotsontheflybar.Slide the FlybarWeight (Tip:the flatend ofthe weight touchesthe paddle)and thread onthe
FlybarPaddleuntilallthethreadsarecoveredontotheflybarandalign the paddles parallel. Again using the ruler,rotate
onepaddleor the other toget equaldistances, rememberleading
edgeof the paddles turnclockwise.Remove one set screw
ata time, applythreadlock (Tip1)
andtighten inplace.Usingtwo
M3x3Set Screwssecure the
weightsusingthreadlock.
Aligneachpaddle'A'tobeparallelwiththeflybar
controlarms'B'. Thisismadeverysimplewiththeoptional
pitchand paddle gaugeCN2026
#HI3176C
FlybarControlArm x 2
DoubleStudded Ballx2
Tapered Standoffx2
M3x12Button
Screwx 2 M4x6
Washer x 2
PushrodAx 2
115mm Center toCenter
Bentendinsertedintolinks on flybar yoke.
AA
B
A=B=A
M4x5Set
Screwx 2
#HW3173A
Flybar(packedwith
tailboom)
#HI3179A
Flybar Paddles &
Weightsx2
M3x3Set
Screwx 2
Leading Edge

Robinison 22HP Manual
7
Step8 CCPM(cycliccollective pitchmixing) SwashplateAssembly
Startingwith theinside race,apply threadlockandattachtwoshort balls (Tip1) directly acrossfrom eachother,
similarlyattachtwomediumballs to the remaining holes. Attachthree short balls(Tip2) to the outsiderace, each 120
degreesapart. Theextra location isusedforthe anti-rotation bracket assembledlater.
Step 7 WashoutAssembly
AttachtwoMedium Balls (Tip2)totheWashoutMixingArms( notethey areattached fromthe flatsideofthearm).
Usingoneslidetubeinserted from the flatside, secured usingone M3x16 ButtonHead Screw andone 3x7mmFlat
Washer perarm.Donot overtighten thearmasit is threadedinto theplasticwashout base.Alsonote, thescrewis
attachedontheleftwheninstalled later on the main shaft. Pressthe radius link onto the innershort balls on the
swashplate.
#HI3152C
WashoutArm
x2
#HI3152A
RadiusArmwith Pin x 2
#HI3152C
SlideTubex2
#CNLR1015
MediumBallx 2
M3x16Button
Head Screw x 2
M3x7Flat
Washer x 2
PreAssembled in Kit
#HI3146C
CCPMSwashplate
#CNLR1014
ShortControlBallx5
#CNLR1015
MediumControlBallx2
ShortControlBall
PlasticAnti-rotationpin&
M3x16Socket Screw

8
TheStartShaftGuide
Blocks are pre-
assembled.Slidethe
StarterShaft through
oneof the block
assemblieswiththe
M5x11BallBearing
facingupthenslidethe
M5FlatWasher,spring
andfinallytheM5x10
Collar.
M5x10
Collar
M2x5Self
Tapping Screw Spring
M2x5Flat
Washer
#CNBB1150
5x11 Ball Bearing x 2
#HI3007
StartShaftGuide
Blocks x 2 #HW3005A
StarterShaft
Set
Step10 StartingShaft &Hex Coupler
Afterslidingthetopbearingblockinplace,attachthe
hexstarteradapter CN0402 to thestartingshaftusing
threadlockonboth4x4mm set screws.Alignone set
screwtofitinto the machined indentationinthehard-
enedstartshaft. For addedstrengthapplya locktight to
theshaftbeforethehex coupler is attached.Apply
somelubricantontheshaftafterassemblyto ensure
smoothvertical movementinsidetheinnerracesof the
bearingswhenengaginganddisengagingthestart
system.Positionthe M5 collarsotheend of thestart
shaftclearsthefan,verifyafterinstallingthelower
frames.
#CN0402
HexStart
Adapter
M4x4Set
Screwx 2
(medhexkey)
M3x4Set
Screw
(smallhexkey)
HexStarterExtension (Optional Part #CN0426A)
Whenremovingthe hexstartextensionafterthe
enginehasstarted,it is recommended that youuse a
twostep procedure.
Step#1:Liftthehexextension upwards just enough
todisengagethestartshaftwhilekeepingtheexten-
sioninsertedinthe hex coupler (CN0402).
Step#2:After thecoupler hasstopped turning,then
removetheextensioncompletely.
EngineStart ProcedurewithHexCoupler
StarterShaft
Step 9 StartingShaft BearingBlocks
M5x10
Flat
Washer

Robinison 22HP Manual
9
M5x7x2Spacerx 2
#CNBB1350
5x13Ball
Bearings x 2
#HI3040
M2x12Pin
#HW3042
DriveShaft
#HI3040
CounterGear
55T
Assembletheenginecountergearassembly, start by pressingthe guide pin into the hole in the end of the Drive Shaft.
Inserttheshaft through the CounterGear (make sure thepin isfully seatedin therecessedsideofthe gear ) thenslide
thetwoM5x13 Ball Bearings.SlidetwoM5x7x2 spacersonto the shaft andslide theAlloy Drive Gear ontothe shaft
(similarlyforaddedstrength,threadlockcanbeappliedbetweenthetopoftheshaftandthedrivegear)aligningtheflat
spotontheshaft.Insertone M4x4 set screw (Tip1)intotheAlloy DriveGear and tightenin place usingthreadlock.
Testfit the gear assembly into one half of the upper
sideframes. Whileholding the piniongear,try to slide
thecounter gear upanddown on theshaft. Thegear
shouldnotslide up the shaft,if itdoes,readjustthetop
piniontoremovethe slop and re-tightenthe set screw
usingthreadlock. Itisimportantthatthereis no free
playbutthebearings are turning freely when as-
sembled.Asmallamount of red locktight can be
appliedto lock thetopof the countershaftto the
piniongear, but donot use onanyset screws.
Step 11 Counter GearAssembly
#CN1076-23
AlloyDriveGear12T
M4x4Set
Screw
1
Experttip,once allcomponentsareintheirfinalposition, using a
needleapplyonedropofbluethreadlockcarefully at the joint
betweeneachbearingandtheshaft. Warning,threadlockwill
damageabearing.
2

10
STEP 12 Main Gear & ShaftAssembly
TheMainGearis pre-assembled with theAuto-
RotationBearinginstalled. Insertthebottomendof
themainshaftthroughtheautorotationgearassem-
bly,aligntheholesand securetheMainShaftusing
one M3x16 Socket Cap Screw and one M3 Lock-
nut.
Completed
Main Gear &
MainShaft
#HI3056
MainGear
#CN1076-16
MainShaft
M3x16Socket
Cap Screw
M3Locknut
#HW3050
Auto-
Rotation
Bearing
Pre-
Assembled
Youcantemporarilyinsertmainshaft,mainshaft
bearingspacer & bearing,stopperand head
blockscrewtokeepthemfrom getting lost!
*Do notapplythreadlock here.*
#HW3059A
TailTransmission
OutputShaft
M3x4Set Screw
(smallhexkey)
Step13 Universal Coupler&Tail PinionGear
#CNBB1350
5x13Ball
Bearings x 2
#HW3057
TailRotorOutput
Gear #HW3059A
Tail Shaft Spacer
#HI3154
UniversalTail
DriveCoupler
M4x4Set
Screw(med
hexkey)
Insert one M4x4 Set Screw (Tip1)
usingthreadlockintothegear(make
suretheset screw ispositionedover
theflatspot).SlidetwoBallBearings
ontothe shaftandinstallintoonehalf
ofthe upperframes. Next add the
spacerand apply threadlocktothe
4x4mmsetscrewandinsertintothe
universaldrive coupleroverthelong
flatspotuntilthethereisnoend play in
theshaftandtightenthesetscrewin
place.

Robinison 22HP Manual
11
TailTransmission
OutputGearAssembly
from Step 13
CounterGear
Assembly
from Step 11
#HI3107
Upper Side Frame
MainGear
Assembly
from Step 12
M3x12SelfTapping
Screwsx 4
M4x4Set
Screw(med
hexkey)x2
#HW3054A
Mast
Stopper
#CNBB1980
8x19Ball
Bearing
StartShaft
Assembly
from Step 9
Note 1: Be careful when tightening the eight 3x12mm self tapping screws into the start shaft block assem-
blies as excessive force will strip out the plastic holes.
#CNBB1019
10x19Ball
Bearing
#HI3107A
M14x19
Washer
#HW3115B
CCPM Right Side Servo
Mount
Step 14 Upper Side Frames
Installtwo4x4mmSetScrews(do not applylocktight atthis time) in theMast Stopper (notethe raisedinner diameter
mustfacetheballbearing)andslidethe mast stopper on the mainshaft followed by one M10x19Ball Bearing and one
M14x19Spacer(the spacer mustbe installedontopof the bearing).Slide oneM8x19BallBearing onto the bottomof
themainshaft.
Aligntherightccpmsideservomountovertheholesfor the starter shaft assembly (observethecorrectdirection
oftheblockassemblies)andinsertfourM3x12SelfTapping Screws1 tosecureitinplace.Positionthemaingear/main
shaftassembly,(notetheorientationofthemaststopper) thecountergearassemblyandthetailtransmissionoutputshaft
assemblyinthedesignated locations (see diagrambelow)ontheupperrightsideframemakingsure the bearings arefully
seatedin the recesses.
Atthistimepreparetheservosbyinstallingtherubbergrommetsprovidedwiththeradiosystem. Waittoinstall
thebrasseyeletsuntiltheorientationtomounttheservo is known. The eyelets have a flange that shouldface the surface
thatthe servoflangeisbeingmountedagainst.

12
#HW3127
Longhex spacers x 2
M3x35Socket
Cap Screws x 4
M3Locknutx4
Step15 UpperFrameAssembly &FrontCCPM ServoMounts
Inserttwolonghexspacersatthespecifiedlocations in the diagram, note that thefront hex spacer is installedinto the
forward-mosthole. Attachtheleft side CCPM ServoMount using fourM3x12 SelfTappingScrews (Tip3)into the
startingshaftblocks.Installtheupperleftside frame, taking care that the bearings are aligned with the mating recesses
andsecuretheframeswith four M3x35 SocketCap Screws (Tip1)throughthemainshaftbearing block positions and
fourM3locknuts.Whilepushing DOWN onthe main shaft(make sure themain gear rotates),push the maststopper
againsttheupperballbearing, apply threadlock to theset screwsand tighten inplace. #HI3107
Upper Side
Frames L& R
M4x4Set
Screwx 2
#HW3115B
CCPM Servo
Mount(Right)
#HW3115B
ServoMount
Brace
AttachtheservomountbraceusingfourM3x10
SocketCap Screws andM3 Locknuts through
theholes onthe CCPM ServoMounts. Look at
theservo mount braceandnotice the twotabs
whenproperlyinstalledfaceforward. Attachthe
anti-rotationbracketto the front ofthe bracewith
one M3x10 Socket Cap Screw and a M3
Locknut(hold thelocknutwithpliersandtighten
theboltwiththeprovidedhex key).
#HW3115B
Anti-Rotation
bracket
M3x10Socket
Cap Screws x 4
&M3Locknuts
L
R
Step 16 CCPM Servo Mounts &Anti-
RotationBracket
M3x12SelfTapping
Screwsx 4

Robinison 22HP Manual
13
Step 17 Front CCPM Servo Mounts
InstallbothCCPMfrontservosatthistime,with the output shaft of
theservospositionedupwardsandtheservoflangeinsertedfrom
behindtheservomount. Usingthescrewsprovided, insert the
screwsfromtheservotopthroughthegrommets(insertthe
eyeletsbetweenthegrommetand the mount bracket) and
attachtheservo mount tabsfrom thebottomoftheservo.
M3x12mmand
M3Locknut
#HI3205
Servo
mounttabs
#HW3115B
RearServoMount
M3x35 Socket Cap
Screws x 5 & M3
Locknuts x 5
Step 18 Tail Boom Mount Plates & Clamps
Assemblethetailboomclampplatesoverlappingtherearof themain
mechanicswithan upwardslope.Startingfromthemechanics,insert
oneM3x35socket cap screwsthrough themountplateand insert into the
rearmostupperholeintherightside of the mechanics. Slide the second mount plate
ontothescrew from theleftandsecure using oneM3 locknut.InsertoneM3x35 socket screwthroughtherudder
mount,theninto the rear-mostlower holeand secure withone M3locknut fromtheotherside.Insert one M3x12
socketcapscrew through the fronthole inthe ccpmservo mountwiththeknotchkeyed to the upperside frames,slide
threeM3x7flatwasherstheninsertthrough the upper side frames,securing with one M3locknut. Insert one M3x35
socketcapscrewthroughthe frontmost upperhole inthe tail boomclamps, then throughthe center holeof the ccpm
servomountandinsertsecure with one locknut onthe other side.Attachthetailboomclamps using four M3x8 socket
screwsinsertedinto the top holesof themountsusingthreadlock.The M3x35 socketscrews atthe lowerpositioncan
beinsertedbutshouldbe left loose. Install the cabinmounts by threadingthe M3x40 threadedrod into onecabin mount
thenthreadingthrough themechanicsandattachingtheothermount throughthelowerforwardmosthole. Installonly,do
notthreadlockinplace until after the cabin ismounted.
M3x8 Socket Cap
Screws x 4
#CN1076-7Tail
Boom Clamp
Plates x 2
#CN1076-8Tail
Boom Mounts x 2
(Slot on bottom)
#CN1076-9 main Cabin
Side Mounts x 2 #HW3116ARudder
ServoMount
Step 19 Rudder and RearServo
Installtherearccpmservowith the output shaft posi-
tionedtowardsthefrontandtheservoflangepositioned
frombehindtheservomount. Insertthescrewsfrom
thethebottomof the grommets, throughthemount
(inserttheeyeletsbetweenthegrommetandthe
mountbracket)andattachthe servo mount
tabsfromthe top oftheservo.Install the rudder
servosimilarlywiththeoutput to the rear of the
helicopterandtheflangeon the left side of
themountwiththetabsonthe
bottomofthe servo.

14
Step20 Clutch,Fan& EngineMounting
#HW3011
Clutch
Shoes
M9x14 Flat
Washer
Engineball
bearing
exposed.
ThrustWasher
or M9x14 FW
Remove all parts from the engine
crankshaft until you can see the front
ballbearing,install the 9x14mm Flat
washer (or washer provided by
engine manufacturer), insert the Ball
Bearings into the clutch bell assembly
and place on the crankshaft. Clean
the threads (Tip 1) on the crankshaft,
engine nut and the clutch, carefully
apply threadlock on the engine
crankshaft threads nearest the
bearing (be careful not to get thread-
lock into the ball bearings) and on the
threads in the clutch. Thread the
clutch until the crankshaft can be
seen and insert the fan keying it to the
clutch. Wrap a cloth over the fan
(provides grip to the fan without
breaking the fins) and tighten until the
clutch stops, torque an additional 1/16
of a turn. Using a Piston Lock
[CN2155 Optional Part] makes this
easier. Secure the fan by placing one
6.5x13mm Washer and apply a liberal
amount of threadlock to secure the
nut that came with the engine from
the inside of the fan assembly. Again
only torque the nut 1/16th more.
#HI3009
CoolingFan
M5x13 Flat
Washer
Engine
Nut
(Optional Parts)
CN2153ThrottleExtensionfor
OS50SX-H
M3x16CS
Machine Screw x 4
Engine
Assembly
withFan
Secure the engine assembly on to the engine mount
(make sure the mount is installed with the engine
mount holes closest to the bottom of the engine, notice
it is recessed for the crankcase) using four 3x16mm
Socket Cap Screws using threadlock. The throttle
extension included will not work if using the optional
CN3059 Scale Muffler. It is necessary to purchase the
optional CN2153 throttle extension is to fit the throttle
linkage behind the muffer. If another muffler
is use, then the throttle extension provided
by the manufacturer will work. Remember
to set the carburator travel to get equal
through from full power to idle, leaving
another 10 percent to shut down the
engine.
During final assembly wipe all
traces of oil or grease from the
inside surface of the clutch
lining. Any grease here can
cause a meltdown.
#CNBB1812
M12 x 18
Ball
Bearing x 2
#HI3010A
Aluminum
Clutch Bell
Pre-Assembled in kit.
#HI3010B
Pinion
Gear26T
Step 21 Engine Mount & Throttle Lever
#HW3018A
EngineMount(46/50)
Note:Upright(Top)direction of mount.

Robinison 22HP Manual
15
Step 22 Fuel TankAssembly
Insertthetwopiecesofaluminumtubingthroughthelargecap,rubberstopperandsmallcap,bendthelongalumi-
numtubeupwardsandattach the short piece of fuelline and clunkto the shortstraight piece oftubing. Testfit the
assemblyintothe FuelTankand make surethat theclunk reachesthe endbutmovesfreelyand the vent tubeis near
thetopofthe tank but doesnot touch. Finallytighten thelong selftapping screwto sealthe tank. Installthe in-
cludedtie wrap aroundtheoutside of therubbercap.
Vent Tube - bent
Note: Thefueltankopeningisoff-centerandshouldbeinstalled
upwardstoalign close to thecarburetor.
Large
Cap
Small
Cap
Rubber
Stopper
90mm Fuel line inside
tank & Clunk
Pickup tube -
straight
FuelTank[HI3138A]
M2.5 x 18 Self
Tapping Screw
Makesurethemufflerboltsare
insertedintotheengine.
Step23 LowerFrameAssembly
#HW3112D
Lower Side Frames
#HI3138A
FuelTank
#HI3020A
Cooling Fan Shroud
Insertmufflerbolts
beforeassembly.
EngineAssembly
from Step 20
R
L
Attachthe right lowerframe (R) totheupper frame assemblywithtwo M3x12 SocketCap Screws (Tip1) andM3
Washers using threadlock. Slide the coolingFanShroudovertheengineheadandpositiontheengineassemblyintothe
upperframes while attaching thetwoM3x12Socket Cap ScrewsandlargeM3x11Washersthroughthe (R) side
frame(leavetheseloosefornow)intotheenginemount.Make sure the muffler bolts are inserted into theengine. Slide
thefueltankassemblythroughtheframeandattachtheleftlower side frame (L) to the upper side framesusing two
M3x12Socket Cap ScrewsandM3x7Washers usingthreadlock.Attachthe remainingtwoM3x12 SocketCap
ScrewsandtwoM3x11FlatWasherstotheenginemount.Positiontheengineassemblyandtightentheenginemount
boltswhenthereis a 1mm verticalgap between theclutch belland thecounter gear.Remove each bolt andapply
threadlocktothesescrewsnow.Afterthe engine in boltedin position, insert one M3x6 Phillipsself tapping screw to
securethecoolingfanshroud,becarefullnotto overtighten these screws to avoid stressingthe lower side frames.
M3x12Socket
Screwsx 4
M3x11Washer
x4
M3x6Phillips Self
Tap Screw x 2
OptionalCN2153throttle
extensioninstalled.

16
Assemblethe tailrotorinput
shaftbyslidingtwoBallBearings
ontothe shaft followed by the
largeBevelGear(B).Aligntheholes
onthegearwiththeholeinthe
shaftand press inone M2x12
pinandsecurewithone
M3x4 Set Screw (Tip 1)
usingthreadlock.
Noticethatthetailrotor output drive
shafthas2holes,onethroughthe
shaftand onedrilledpartiallyintothe
shaft.Slidethesmall bevel gear (A)
withtheteethfacingtheshaftfrom
theendwiththethrough hole and
positionthegearaligningtheholes.
PresstheM2x12steelpinthrough
andsecure with oneM3x4Set
Screw(Tip1) inserted fromthe end
oftheshaft usingthreadlock.Slide
theSpacerTube ontotheshaft and
positionagainst thegear.
2x12mmPin
#HW3073
TailRotor Drive
Shaft #HI3075
Small Bevel
GearA
M3x4Set
Screw
(smallhexkey)
#HW3074
SpacerTube
Holethrough
shaft
Step24 Tail OutputShaftAssembly
#HI3089
Tail Pitch Ball
Links x 2
M2x8Pin x 2
Thetail pitchplateandtail
pitchballlinksarepre-
assembled. (Note: apply
someJBweld to theoutside
ofthelockringto avoid the
assemblyloosening.) Apply
adrop of CAgluebetween
theedge ofthebrass tube
andtheplasticpitchplate.
Putthisassembly aside for
now.
#HI3087A
TailPitch Plate
Pre-Assembled
#CNBB1350
5x13Ball
Bearing x 2
#HW3070
TailGearboxInput
Shaft 2x12mmPin
M3x4Set
Screw
(smallhexkey)
#HI3075
Large Bevel Gear B
Step 25 Tail Pitch PlateAssembly
Step26 Tail InputShaftAssembly
#CNBB1060
6x10Ball
Bearing x 2

Robinison 22HP Manual
17
#HI3078
GearboxHousing
RightHand Side
(hasmountfortailbellcrank)
TailPitch Plate
Assembly
Slidetwo BallBearingson
eachsideof the tail rotor
outputshaft assemblyand
insertthroughtherightsideof
theTailRotorGearbox
Housing,makesure the
bearingisfullyseatedintothe
recess. Slidethe tail rotor
pitchplateassemblyon the
shaft.
#CNBB1150
5x11 Ball
Bearing x 2
Step 27 Tail GearboxAssembly
Small Bevel
GearA
Installthetailrotorhubonto the tail rotor drive
shaft,(positionthehubsotheholeisalignedover
theholeintheshaft) and
securewithoneM3x4
SetScrew (Tip1) using
threadlock. Thehubis
tappedfor two
holes,onlyuseone.
Installoneshortsteel ball into the upper righthole inthe tail rotorgrip (Tip2).
InsertoneM4x10BallBearingintothebladegripontheballside(makesurethebearingisfullyseatedflushintothe
grip). Slidethegripontothetail hub and slide one M4x9 Thrust BallBearing(installthefirststeelwasher(largerinside
diameter)followedbytheball race, remember togrease the ballrace, followedby the secondsteel washer (smaller
insidediameter)followedbyoneM3x5x0.5microwasherandfinally one M3x9 ThinBallBearing. Important,apply
redthreadlocktothethreads in the M3locknut (to avoid gettingthreadlock into thebearings)beforethreadingonto the
hub.Tightenthe locknut slowlyuntilthereisnoendplayandthe grip rotatessmoothly.
M3x4Set
Screw
(smallhexkey)
#HW3098A
SteelTailRotorHub
M3Locknut
#CNBB0930
M3x9ThinBall
Bearing
Step28 Tail RotorGripAssembly
#CNLR1013
SteelBall 2mmThread
#HI3096A
Tail Rotor Grip
#CNBB49T
M4x9ThrustBall
Bearing
Careful inspection of the thrust
races will reveal that the inside
holes are different in size. Correct
installation has the smallest race on
the outside.
(RedThreadlockhere)
#CNBB410
M4x10Ball
Bearing
#CNLR1003
M3x5x0.5
MicroWasher

18
#HI6099
TailRotor
Blades x 2
M3x20Socket
Cap Screw x 2
M3Locknutx2
Afterflyingthe model,ifavibrationisnoticedon thehorizontalfin,youcanremovethe complete tailrotor
assemblywiththehuband further balance it using a HighPointbalancer. Carefulsandingoftherotor
bladesisallthat is needed.
Leading Edge
Snaptheballonthe tail rotor grip intothe
adjoiningpitch sliderlinkonbothsides.
Installthetailrotorbladesshimmedwith
M3x10plasticwashersonbothsidesusing
two M3x20 socket cap screws and M3
locknuts. Notethedirection of theblades
onthediagram,theleadingstraightedgeof
theblade should beon the samesideas the
ballonthe blade grip. Totensionthe blade
bolt,startlooseandtightenuntilthe blade
holdshorizontalbutpivotsfreelywhen
moved.
Step 29 Tail BladeAssembly
#HI3096A
M3x10Plastic
Washer x 4
Insertthreetaildriveshaftguideson to the brass tail drivehousing (note that one guide hasa larger centerhole than the
others,slide this one tothecenter of thebrass tube), addthe remainingtwoontothe ends. Glue theguidesintoposi-
tionusingZapCaonthe brass tube. Insert the tailshaft guide assemblyinto the tailboomfrom the end withthe 2 holes
andpositiontheassemblycenteredinthetailboom(gentletappingwithawoodendowelwilleasytheinsertionof the
guides).
#HW3063A
Tail Drive ShaftSet
#HW3062A
Tail Boom
Drive
Housing
( brass )
DriveHousing
Ends x 2
Makesurethebrasstubingisgluedtothe plastic guides inside the tail boom.
Step 30 Tail Drive Shaft& PushrodGuides
DriveShaft
Support
Center x 1
Step 31 Tail Drive Shaft
#HW3063A
Tail Drive ShaftSet
Deepentheflat spot on
thetheround end ofthe
TailDriveShaft.
File
TailDriveShaft
ApplyGrease
Forextrasecurity,continuefilinguntiltheflat
spotis 1/3rd the thicknessof theshaft.Thor-
oughlygreasethetaildriveshaft(Tip1)and
insertthe newlyfiledendintothetailboom end
withtheslotsintothedriveshafthousing
assembly(ensuretheend with the new flat
spotexitsthetailboomendwiththeround
holes)and degrease both endsoftheshaft.
Attachtheuniversaltaildrivecouplerusing
twoM4x4setscrewsusinglocktight. #CN1076-12
Tail Drive Coupler-Male
M4x4Set
Screwx 2

Robinison 22HP Manual
19
M3x10Socket
Cap Screw
M3x12 Socket Cap
Screw
TailInputGear
Assembly
Tail Boom
Assembly
M3Locknut
x3
M4x4Set
Screwx 2
(medhexkey)
FlatSpot
Step 32 Tail GearboxAssembly
#HW3063A
Tail Drive ShaftSet
ApplyGrease
#HI3102A
TailRotor
Bellcrank
M3x6
Washer #CNLR1013
ShortBall
M3x16
Socket Cap
Screw
M3x25Socket
Cap Screw
Slide
Tube
Attachthetail input gearassemblyonto the drive shaftwithtwoM4x4 set screws(Tip1 - makesurethe flat spot is
alignedwithone of the setscrews andonly useONLYblue locktitehere) applyred locktitetothedriveshaft end and
insertintothegearboxinput shaft.Warning, do not usered locktiteonANYotherscrews because it ispermanently
bondedinplace.Positiontheoutput gear assembly into theright gear boxhalf (insure the 2 bevelgears are meshed
properlyandtheballbearingsarefullyseatedin their recesses) and liberally grease thegears before closing the gear-
box. Positionthe gear boxhalvesover the holesintheend of thetailboom and securewithone M3x10 socketcap
screwand M3 locknutat the endof the gearbox,one M3x12 socketcap screw withM3locknuts atthelower-center
ofthegearbox and oneM3x25socketcap screw atthefront-lowerposition securing with oneM3locknut.The other
twolocationsare left empyuntilthehorizontalandverticalfins are attached.
Grease to be used inside the tail gearbox should be a teflon or light lithium type of grease commonly
found in a hobbyshop. Do not use grease or any type of lubricant on the remaining gears on the
helicopter because they are exposed and can actually attract dirt and debris that can lead to a
failure.

20
Washout
Assembly
Slidetheswashplateoverthe main shaft. Slidethe nylon sleeveover the M3x15socket cap screwand insertit through
theanti-rotationbracketto the extra holein thefront ofthe swashplateand secureinplaceusingthreadlock.Do not
overtightenthisscrewasitwilldeformthenylonsleeve.Nextslidethewashoutassembly (makesurethepivotscrewis
positionedontheleftsideofthemain shaft) onto the main shaft andattach the radius arms (alsonotethatwhenproperly
installedthenumber1is on the insideof the radiusarm) tothe short steelballs on theinside raceof the swashplate.
Slidetheradiusguideontothemainshaftandaligntotheslots in the washout unit. Insert the M3x4 set screwinto only
onesideofthe washout guide but doNOT tightenat thistime. This willbe tightenedafter the rotorhead hasbeen
installedbecausethe exact position ofthe guidedepends ontherotorhead.
Nylonsleeveover
oneM3x15
Socket Cap
Screw
Thenextsectioncoverssettingthepushrodsandservosthatwillcontrolthehelicopter. Itisimportantat this time that
youreviewthe instructions providedwithyourradiothatcontrolstheccpmmixing for the3cyclicservos. Reviewing
theradioinstructionswillassistyouinbecoming familiarwiththefunctionsthataffecttheindividualservosandaffectthe
interactionofthethreeservosworkingtogethertocontroltheswashplate.
RadioSetup Procedure
1.Itis best to choosea newmodelmemory(ifavailable) and usethe Resetfeature toremoveanyprevioussettings or
mixes,rememberthisusuallyalsoreturns theradioconfigurationto singleservo.
2.Locateandactivatetheswashplate mixing for 1200ccpm(mostmanufacturerssetradios to single servo version by
defaultandwhen the data resetfeature isused).
3.Returnboththeaileronandelevatorsubtrimstoneutralalongwithanyhoverpitchknobstoneutral.
4.Adjust the servo reversingswitch tomake surethe servosare movingin thecorrect direction,together asthe collec-
tivestickis raised. If theservoreversingdoes not correctthemovementof a servo, thereisalwaysa travel adjust-
mentfunctioninside the swashplate mixingmenu. Changethedefaultsettingtobeopposite,forexample, if setto
+60then change to-60 and changeanyservos that areaffected.
5.After eachservohornis mounted, itiscriticalthat the hornbe90degrees to therespective pushrod.
Step 33 CCPM Radio Review & Setup
Step34 Swashplate,WashoutandWashoutGuide
Swashplate
Assembly
#CN1076-17
Washout
Guide
M3x4Set
Screw
