Century Travel Solutions Travel SolutionsTM Plus User manual

Instruction
Manual
English PM-1028AB 5/99
Do not use this product until
you read and understand
these instructions.

DEDICATED TO QUALITY

IMPORTANT INFORMATION
Need Help?
✔Read and understand stroller instruction manual before
using stroller.
✔Read and understand car seat instruction manual
before using car seat in a vehicle.
✔Use the SmartFit®Base provided with this product
only with a Century Assura™, SmartFit®, SmartFit®Plus,
SmartFit®Elite, SmartFit®Elite V or SmartFit® SupremeV
Infant Car Seat.
✔Never leave child unattended.
✔Use with only one (1) child at a time.
✔Do not use accessories other than those provided
by Century.
NOTE: All warnings and instructions apply whether
stroller is being used with or without child’s tray in the
use position.
Car Seat/Stroller Use:
Maximum Weight: 22 lbs. (10 kg)
Maximum Height: 27 inches (69 cm)
Stroller Use:
Maximum Weight: 40 lbs. (18.2 kg)
Maximum Height: 40 inches (101 cm)
Page:
1 Important Information
2 Warnings
3 Assembly
Opening Stroller
Front Wheel Assembly
Locking Footrest
Rear Wheel Assembly
Attaching Cup Holder
5 Car Seat/Stroller Use
Locking Or Unlocking Rear Wheels
Attaching Car Seat
Removing Car Seat
7 Stroller Use
Locking Or Unlocking Rear Wheels
Closing Child’s Tray Slot
Canopy Positions
Child’s Tray Use
Seat Back Positions
Securing Child With Harness
9 Folding
10 Maintenance
Cleaning Cup Holder
Cleaning Stroller
Dented Wheels
11 Replacement Parts
1
Safety First Checklist
Weight and Height Limits
Table of Contents
Save instruction manual
for future reference.
If you should have any problems with this product, call
toll-free 1-800-837-4044 from anywhere in the U.S. or
Canada or fax at 1-610-286-4555.
Or write us at: Century Products
P.O. Box 100
Elverson, PA. 19520-9974
Attention: Customer Service Department
Please have the following information available. See label
on stroller leg.
Model Number:
Manufacture Date:
Date of Purchase:

Failure to follow all warnings and instructions could result in serious injury or
death.
• Never leave child unattended, even when sleeping.
- Child may become entangled in harness straps and suffocate.
- Stroller may roll away and crash even with brakes engaged.
• Avoid serious injury from falling or sliding out. Always use seat belt.
• DO NOT pull or carry stroller on stairs or escalators with child in it.
• DO NOT lift car seat/stroller unit by car seat handle or car seat shell. Handle may break.
• DO NOT allow child to climb unassisted into stroller, play, hang or pull down on car seat or
stroller handle as stroller may tip over.
• DO NOT hang anything on handle or canopy. Stroller may become unstable and tip over.
• DO NOT jog with stroller. Push stroller at a normal walking speed only. Fast walking, jogging
or running can cause loss of control.
• DO NOT overload basket. Maximum basket weight is 10 lbs. (4.5 kg). Stroller may become
unstable and tip over.
• DO NOT use accessories other than those provided by Century.
WARNINGS
2

1Hold swivel wheel assembly
upright (Tab pointing down).
2Tilt stroller slightly back and
push wheel assembly onto leg
until it locks in place.
Repeat steps 1 and 2 for
opposite leg.
CAUTION: After wheel assembly is complete, pull on
wheels to check that they are locked in place.
1Stand stroller upright and
rotate lever to release latch.
2Spread handle and rear legs
until both Fold Locks “click”
into position.
ASSEMBLY
3
Opening Stroller
Front Wheel Assembly
Tab
Push footrest down so that
Cross Tube is centered between
three (3) Tabs on bottom of
footrest, and it snaps in place.
Locking Footrest
Tabs
1Remove axle protectors from ends of axle and discard.
2With stroller laying face down
on floor, slide brake lever brackets
onto rear legs until you hear a
click.
NOTE: Brake levers must face
rear of stroller.
Rear Wheel Assembly
Cross Tube
Fold Locks

4
ASSEMBLY continued
WARNING
Prevent a possible choking hazard, discard
axle protectors and polybag which contained
rear wheel parts.
CAUTION:
• Failure to install retainer cap may cause wheels to come
off of stroller.
• After wheel assembly is complete, pull on wheels to check
that they are locked into place.
Snap one end of cup holder
over stroller frame above
canopy, rotate down to
opposite side and snap in
place.
Attaching Cup Holder
WARNING
• To avoid burns, never put hot liquids in cup
holder.
• Avoid possible tipping, DO NOT place more
than 3 lbs. (1.4 kg) in cup holder.
Hub
Cap Retainer
Cap
Wheel
Retainer Wheel
Axle
3Secure Wheel to Axle as shown:
• Slide Wheel onto end of Axle with brake ribs facing in.
• Slide Wheel Retainer onto end of Axle. Make sure large
end of Wheel Retainer is towards Wheel. Wheel Retainer
should snap into groove on end of Axle.
• Snap wheel Retainer Cap over Wheel Retainer.
• Line up Hub Cap tabs with slots in Wheel and snap Hub
Cap in place.

1Set both rear brakes to prevent
stroller from moving.
2Position child’s tray in up position:
• Rotate child’s tray over lower
edge of seat.
• Push child’s tray into slots.
• Pull on child’s tray to be sure
it is securely locked.
1LOCKING:
Push down on both brake
levers.
2UNLOCKING:
Push up on both brake levers.
CAR SEAT/STROLLER USE
Locking Or Unlocking Rear Wheels
5
Attaching Car Seat
3Position stroller back support
in reclined position:
Squeeze both levers on sides of
seat back to release.
4With car seat handle in locked carrying position (upright)
insert car seat adapter Tongue into child’s tray Slot.
NOTE:
•Before attaching car seat, be sure to remove tongue of
child’s tray pad by pulling out red button and pulling
up on child’s tray pad.
• Car seat may be placed in child’s tray slot either
rear-facing or forward-facing.
Rear-facing Forward-facing
Tongue
Slot
Tongue
Slot
5Attach appropriate snaps to
secure car seat to stroller:
NOTE: Use of proper snaps
provide the snuggest
attachment to stroller frame.
Forward-facing
Snap
Rear-facing
Snap

1Set both rear brakes to prevent
stroller from moving.
2Be sure handle is locked in upright carrying position.
DO NOT lift car seat from child’s tray until you have heard
a “click” sound and have checked that handle is locked.
3Pull Red Button on front of
child’s tray out and lift car seat.
4After removing car seat, insert
Tongue of child’s tray pad into
child’s tray Slot.
CAR SEAT/STROLLER USE continued
WARNING
Avoid serious injury from falling or sliding
out:
• Always use waist and tummy pad to
restrain child, even when sleeping.
• Always be sure car seat handle is in locked
upright carrying position when lifting or
carrying child.
• Always make sure car seat is locked into
child’s tray before each use.
• Always be sure stroller is fully set up and
fold locks are engaged before using.
• Always be sure brakes are locked when
attaching and removing car seat from
stroller frame.
6
Removing Car Seat
Red Button
Slot
Tongue
6Pull up on car seat to be sure
it is locked in child’s tray.
NOTE: Car seat comes with a level indicator which is not
applicable when car seat is used in stroller frame.

1LOCKING:
Push down on both brake
levers.
2UNLOCKING:
Push up on both brake
levers.
Stroller may be used with Arm Bar up or down.
1For up position:
• Rotate arm bar over lower
edge of seat.
• Push arm bar into slots.
• Pull on arm bar to be sure
it is securely locked.
2For down position:
• Press arm bar Release Buttons
on sides of fold locks.
• Pull arm bar out until it
stops.
• Allow arm bar to drop
below seat.
Child’s Tray Use
Insert Tongue of arm bar pad
into child’s tray Slot.
STROLLER USE
Locking Or Unlocking Rear Wheels
7
Closing Child’s Tray Slot
WARNING
Prevent serious injury:
• Make sure child is clear of any moving
parts when you adjust stroller.
• DO NOT place parcels on top of canopy.
Canopy has two (2) positions: opened and closed.
Canopy Positions
Slot
Car seat and stroller can be
used together with both
canopies closed.
Tongue
Release
Button

STROLLER USE continued
WARNING
Avoid serious injury from falling or sliding
out:
• Always use waist and tummy pad to
restrain child, even when sleeping.
• To prevent child from standing or sliding
out of stroller, be sure waist and tummy
pad are SNUG and do not slip loose.
• Periodically check waist and tummy pad
to be sure they are snug around child.
8
Seat back has two (2) positions:
upright and reclined.
1For upright position:
Lift seat back forward until
back support pins hook into
seat back latches.
2For reclined position:
Release both levers on sides
of seat back.
Seat Back Positions Securing Child With Harness
Secure child with harness system:
• Unlock harness system by
pressing Tabs on both
buckles.
• Place waist straps around child’s
waist.
• Place tummy pad between
child’s legs.
• Snap buckle tongues into
buckles on each side of
tummy pad.
• Adjust waist straps to snugly
fit child.
Tabs

IMPORTANT:
• When folding stroller, turn
stroller front wheels to straddle
frame.
•DO NOT allow front wheels to
rest on frame. Doing so will
cause wheels to warp and
they will not roll correctly.
6Engage latch on side of stroller to
retain stroller in locked position.
1Set both rear brakes to prevent
stroller from moving.
2Remove car seat from stroller frame (see “To Remove
Car Seat” section).
3Position stroller back support
in reclined position:
Release both levers on sides
of seat back.
4Release quick snap fold locks
on each side by grasping
handle grips and pressing on
both buttons.
9
FOLDING
Folding Stroller 5Continue holding buttons in
and lift upward on handles
to fold stroller.
NOTE: This can be done with
child’s tray up or down. Child’s
tray will drop below seat when
folding.

10
MAINTENANCE
To remove cup holder, pull one end up, rotate over to
opposite side and pull other end up.
Wash cup holder in warm water and mild soap. DO NOT
USE abrasives, solvents, strong detergents, or household
cleaners: they can weaken plastic.
DO NOT place in dishwasher.
Cleaning Cup Holder
Sometimes wheels become “dented” from shipment or
from normal use. You may try the following procedure
for repairing the dented wheel before calling our
Consumer Relations Department:
Blow warm air from hair dryer over dented area for
1 to 3 minutes.
Dented Wheels
WARNING
Avoid serious injury or death.
• Periodically check anchoring straps beneath
seat pad to ensure they are secured to
frame.
• Periodically check and clean child’s tray slot.
If dirty, car seat adapter tongue will not
latch properly. Remove loose objects,
crumbs and any other debris from slot.
Seat and Frame:
• Wipe fabric and frame with damp cloth and mild
soap. DO NOT USE abrasives, solvents, strong
detergents, or household cleaners: they can weaken
plastic.
•DO NOT machine wash or dry seat pads that have
boards in them.
Comfort Pad:
• Comfort pad is removable and machine washable.
Machine wash in cold water, machine dry on cool
setting to prevent shrinkage. DO NOT wash with
other clothes.
• When replacing comfort pad, make sure all waist and
tummy pad are rethreaded through slots in comfort
pad.
• Loop front of comfort pad over leg rest and refasten
attachment strips.
Child’s Tray Slot:
• Clean child’s tray slot with mild soap and water.
DO NOT use household detergents.
Cleaning Stroller

11
REPLACEMENT PARTS
A. Front Wheel Assembly US $ 11.00 x _____ = $ ______
(11-94X)
B. Rear Wheel Kit Including US $ 5.00 x _____ = $ ______
Retainer and Cap (11-94X)
C. Hub Cap Set (2) (11-94X) US $ 1.00 x _____ = $ ______
D. Seat Pad (11-94X) US $ 16.00 x _____ = $ ______
E. Comfort Pad (11-94X) US $ 9.50 x _____ = $ ______
F. Canopy Pad with Window US $ 8.00 x _____ = $ ______
(11-94X)
G. Canopy Frame (11-94X) US $ 2.00 x _____ = $ ______
H. Cup Holder (11-94X) US $ 5.00 x _____ = $ ______
I. Basket (11-94X) US $ 7.00 x _____ = $ ______
J. Instruction Manual (11-94X) FREE x _____ = FREE
Parts List Price Quantity Total
NOTE: Prices subject to change.
Total Parts $ ______

Cardholder’s Name:
Card Number:
Card Exp. Date:
Check enclosed for $
SHIP TO:
Name:
Address:
City:
State: Zip:
Telephone No.:( )
Please make checks payable in U.S. Currency to:
CENTURY PRODUCTS
Or charge to VISA or MASTERCARD :
Total Parts $
Sales Tax $
Shipping & Handling $
Outside Continental USA $
Total $
MAIL BOTH PAGES OF ORDER TO:
CENTURY PRODUCTS
P.O. BOX 100
ELVERSON, PA. 19520-9974
ATTENTION: CUSTOMER SERVICE DEPARTMENT
FAX BOTH PAGES OF ORDER TO:
[phone]
Shipping & Handling
$ 0.01 to $ 5.00 = $ 4.00
$ 5.01 to $ 50.00 = $ 5.00
$ 50.01 to $200.00 = 10% of Order Total
$200.01 and over = 5% of Order Total
Outside Continental USA
$ 2.00 = AK, HI, PR, VI, Guam
$10.00 = Mexico
All others, call for quote.
Sales Tax
• California, Indiana, Maryland and
New York Residents Add Sales &
Applicable Local Taxes
• Ohio Residents Add 5.75% Sales Tax
• Pennsylvania Residents Add 6% Sales
Tax except for Philadelphia and
Allegheny Counties add 7% Sales Tax
• South Carolina Residents Add 5% Sales
Tax
REPLACEMENT PARTS ORDER FORM
We must have this information to process your order: see label
on leg of stroller.
Model No.:
Manufacture Date:
NOTE: If requested color is not available, a similar color
will be substituted.
PM-1028AB 5/99

Remember
We are here to help you!
For immediate help, call our Customer Service
Department at 1-800-837-4044
from anywhere in the U.S. or Canada
or fax at 1-610-286-4555.

Visit us at our Web site:
www.centuryproducts.com



Instruction
Manual
Para instrucciones en Español,
llamar al: 1-800-837-4044
Avoid injury or death -
Read and understand this manual!
Use rear-facing only!

TABLE OF CONTENTS
Important Information.....................................1
Warnings.........................................................2
Basic Information.............................................4
Vehicle Seat Belts............................................14
Shopping Cart Use......................................... 20
Additional Information....................................21
Height & Weight Limits.....................................5
Installation With Base..................................... 6
Installation Without Base................................7
Placing Child in Car Seat.................................. 8
Operations and Adjustments......................... 10
• Harness Tie
• Adjustable Handle
• Buckle System
• Removing Car Seat from Base
• Adjustable Base
• Changing Harness Strap Slots
• Changing Crotch Strap Positions
This instruction manual is for the SmartFit®;
SmartFit®Classic; SmartFit®Plus; SmartFit®PlusV;
SmartFit®Elite and SmartFit®Elite V Infant Car
Seats. Instructions for all models are the same
unless otherwise noted.
❃Before You Begin
❃Use
❃Special Information

IMPORTANT INFORMATION
No car seat can guarantee protection from
injury in every situation, but proper use helps
reduce the risk of serious injury or death.
Child restraints (car seats) could be recalled for
safety reasons. You must register this restraint
to be reached in a recall. Fill out the
registration card attached to car seat and mail
today or send your name, address, and the
restraint’s model number and manufacturing
date to:
Century Products
9600 Valley View Road
Macedonia, Ohio 44056-2096
or call 330-467-9671
For recall information, call the U.S Government’s
Auto Safety Hotline at 1-800-424-9393
(202-366-0123 in D.C. area).
✔Read and understand instruction manual
and car seat labels.
✔Use car seat rear-facing only.
✔Do not use in vehicle seat with air bag.
✔Secure children in back seat whenever
possible.
✔Never leave child unattended.
✔Install car seat securely.
✔Only use a SmartFit®base when using
car seat with a base.
✔Do not use after date shown on back of
car seat.
✔Do not allow anyone (babysitter, relatives,
etc.) to use car seat without first
understanding all instructions.
1
❃Registration Information
❃Safety First Check List

WARNINGS
DO NOT use rear-facing child restraint in
a vehicle seating position equipped with
an air bag. Child’s head and neck may
be seriously injured when an
inflating air bag hits back of child
restraint.
Never put a car seat in a front vehicle
seat unless recommended by vehicle
owner’s manual. National Highway
Traffic Safety Administration (NHTSA)
alerts vehicle owners that according to
accident statistics children up to age 12
are safer in the back seat. For vehicle’s
with front passenger side air bags, refer
to vehicle owner’s manual for child
restraint installation information.
If this car seat is in an accident, it must
be replaced. DO NOT use it again! An
accident can cause unseen damage and
using it again could cause serious injury
or death.
Failure to follow these instructions and
car seat labels can result in child striking
the vehicle’s interior during a sudden
stop or accident. Secure child restraint
with a vehicle seat belt as shown in this
manual.
Use this car seat rear-facing only.
Serious crippling injury or death can
result if infant faces front of vehicle.
Vehicle seat belt system MUST hold
car seat securely. Not all vehicle seat
belts can be used with a car seat. If
vehicle seat belt does not hold car seat
securely, read “Vehicle Seat Belts”
section.
2
