Certa CTSIWAVINVB User manual

1000W/2000W POWER INVERTER
(12V-240V)
CTSIWAVINVB

•Please do not operate the inverter with wet hands.
•Keep out of reach of children.
•The temperature of the shell will be high after operating for a long time; do not
touch it due to risk of burns.
•Do not put metal into the inverter in order to avoid electric shock.
•Do not touch the metal of the socket while inserting the plug into the socket.
•Keep the inverter away from explosives.
•Keep all AC electricity away from the inverter; it will damage the inverter and may
cause an electric shock.
1. Fan
2. DC input
“+” terminal 3. Earth stud
4. DC input
“-“ terminal
5. Power light
(Green light)
6. Fault light
(Red light)
7. AC output socket 8. USB port 9. ON/OFF Switch
SAFETY & WARNINGS
OVERVIEW

Connecting in the incorrect manner will destroy the power inverter as well as the electrical
equipment. Follow the following steps in sequence and be sure to follow the instructions
accurately.
1. When using outside car or exceeding 200W:
oWhen using outside a car or exceeding 200W, please use the battery clip
cable to connect with the battery.
oThe battery clip cables have a red and black cable. Connect the red
cable with "+” and fix it into place, connect the black cable with and fix it
into place.
oConnect the clip on the red cable with “+” terminal of the battery and
connect the clip on the black with the terminal. Do not reverse or it will
destroy the power inverter.
oTurn on the power inverter, the green light will on; insert the plug of the
electric equipment into the AC socket of the inverter.
2. Only use for class II appliances. Do not use for the following:
oAll electric appliances that exceed the rated power of the inverter.
oGenerally capacitive load and perceptual load appliances including air
conditioners, high power electric drills, fridges, microwave ovens and
blenders.
oAppliances that have strict requirements on power supply, such as
precise equipment, using ordinary power inverters with this kind of
equipment will affect the measuring data.
3. Do not use the USB port for the following:
oUSB is only for charging; it does not have a data exchange function.
oBefore charging, check carefully if the charging current of the appliance is
under the inverter's current. If it exceeds the charging current of the
inverter, do not use or it may destroy the USB port.
oSome devices must be charged with their original charger; do not charge
them with the USB port of the inverter or the device may be damaged
OPERATION

4. Use the inverter in a well-ventilated area and make sure the fan is not blocked. Do
not place the inverter in rain or in a humid environment, keep it dry. In order to
maintain a long lifespan of the inverter, operate it under 85% of the related power.
5. The inverter has low input voltage protection, input over-voltage protection,
overload protection, over-heat protection and short circuit protection. If these
protections trigger, the inverter will stop working and must be turned off and on
again before continuing use.
6. The fan will work when the load exceeds 30% of the related power of the inverter,
or when the inside temperature of the inverter exceeds 60°C.
7. Using extension cables:
oUse of extension cables between the inverter and the battery is not
recommended, as it will cause loss of DC electricity and affect the
performance of the inverter.
oIf using an extension cable, it is suggested to use a high-quality cable to
reduce the loss of electricity.
8. Other matters:
oThis is modified sine wave inverter; when measuring the voltage, use
precise equipment.
oWhen supplying power to an audio system, radio or TV, the appliance
may experience interference. This is normal and not a cause for concern.
oWhen using in cars, stop using the inverter while the engine has stopped.
oDo not disassemble the inverter. This unit contains no user-serviceable
parts.

DC input
DC 12V (DC11-15V)
AC output
AC 210V-240V
Output frequency
50 ± 3Hz
USB output
DC 5V MAX 2100mA
Continuous power
1000W
Peak power
2000W
Output wave
Modified sine wave
Efficiency ≥80%
No load current
12V input
≤0.4A
Input low voltage alarm
12V input
DC 10.2 - 10.8V
Input low voltage shutdown
12V input
DC 9.2-9.8V
Input over voltage shutdown
12V input
DC 15 - 16V
Overload shut down
1100W-1350W
Fuse
12V input
40A x3
Operating temperature
-15-+25°C
Cooling method
Fan
Accessories 1x battery clip cable
1x earth wire
SPECIFICATIONS

Function
State description
Solution
LED light
Alarm
AC output
Input low
voltage
alarm
Green on
Red off Alarm AC output
Stop using and recharge the
battery or replace with new
batteries.
Input low
voltage
shut down
Green on
Red on Alarm No AC output
Stop using and recharge the
battery or replace with new
batteries.
Input over
voltage
shut down
Green on
Red on No Alarm No AC output
Stop using and recharge the
battery or replace with new
batteries.
Overload
protection
Green on
Red on No Alarm No AC output
•Reduce the load to the
rated power.
•Restart inverter manually.
•Wait for 1-3 minutes to
recover automatically.
Overheat
shut down
Green on
Red on Alarm No AC output
Stop using, cool the inverter
and wait for the temperature to
drop before using.
Output
short circuit
Green on
Red on No Alarm No AC output
Stop using, check the
connecting cable and loads.
Restart after troubleshooting.
Disposal
This marking indicates that this appliance should not be disposed with other
house-hold wastes. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources.
TROUBLESHOOTING

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
