FSP201 Module
Quick Start Guide
1000-5133
Rev. 1.0
December 2023

FSP201 Module Quick Start Guide 1000-5133
Confidential and Proprietary · Unauthorized Reproduction Prohibited
Copyright © 2015 –CEVA®, Inc. 3
Documentation Control
History Table
Version
Date
Description
1.0
December 6, 2023
Initial Release

FSP201 Module Quick Start Guide 1000-5133
Confidential and Proprietary · Unauthorized Reproduction Prohibited
4 Copyright © 2023 –CEVA®, Inc. Rev. 1.0
Disclaimer and Proprietary Information Notice
The information contained in this document does not represent a commitment
on any part by CEVA®, Inc., or its subsidiaries (collectively, "CEVA").
CEVA makes no warranty of any kind with regard to this material, including,
but not limited to implied warranties of merchantability and fitness for a
particular purpose whether arising out of law, custom, conduct, or otherwise.
Additionally, CEVA assumes no responsibility for any errors or omissions
contained herein, and assumes no liability for special, direct, indirect, or
consequential damage, losses, costs, charges, claims, demands, fees, or
expenses, of any nature or kind, which are incurred in connection with the
furnishing, performance, or use of this material.
This document contains proprietary information, which is protected by U.S.
and international copyright laws. All rights reserved. No part of this
document may be reproduced, photocopied, or translated into another
language without the prior written consent of CEVA. All product names are
registered trademarks of CEVA®, Inc. and/or its subsidiaries, or, of its
applicable suppliers if so stated.

FSP201 Module Quick Start Guide 1000-5133
Confidential and Proprietary · Unauthorized Reproduction Prohibited
Copyright © 2015 –CEVA®, Inc. 5
Support
CEVA® makes great efforts to provide a user-friendly software and
hardware development environment. Along with this, CEVA provides
comprehensive documentation, enabling users to learn and develop
applications on their own. Due to the complexities involved in the
development of DSP applications that might be beyond the scope of the
documentation, an online Technical Support Service has been established.
This service includes useful tips and provides fast and efficient help, assisting
users to quickly resolve development problems.
How to Get Technical Support:
●FAQs: Visit our website http://www.ceva-dsp.com or your company's
protected page on the CEVA website for the latest answers to
frequently asked questions.
●Application Notes: Visit our website http://www.ceva-dsp.com or your
company's protected page on the CEVA website for the latest
application notes.
●Email: Use the CEVA central support email address ceva-
[email protected]. Your email will be forwarded automatically to
the relevant support engineers and tools developers who will provide
you with the most professional support to help you resolve any
problem.
●License Keys: Refer any license key requests or problems to
[email protected]. For SDT license keys installation information,
see the SDT Installation and Licensing Scheme Guide.
Email: [email protected]
Visit us at: www.ceva-dsp.com

FSP201 Module Quick Start Guide 1000-5133
Confidential and Proprietary · Unauthorized Reproduction Prohibited
6 Copyright © 2023 –CEVA®, Inc. Rev. 1.0
Table of Contents
1. INTRODUCTION .................................................................................................. 7
1.1 Scope.........................................................................................................7
1.2 Audience ....................................................................................................7
1.3 Related Documents ......................................................................................7
1.4 Overview ....................................................................................................7
2. HARDWARE ......................................................................................................... 8
2.1 Introduction ................................................................................................8
2.2 Connections ................................................................................................8
2.2.1 Host Interface Mode Selection...................................................................9
2.2.2 Module Pinout .........................................................................................9
2.3 Mechanical................................................................................................10
2.3.1 Sensor Orientation ................................................................................10
2.3.2 Module Dimensions................................................................................10
2.3.3 Module Recommended PCB Footprint .......................................................11
3. GLOSSARY......................................................................................................... 12
List of Figures
Figure 2-1: FSP201 Module with BMI088 ..........................................................................8
Figure 2-2: FSP201 Module Orientation ..........................................................................10
Figure 2-3: FSP201 Module Dimensions (Component side) ...............................................10
List of Tables
Table 2-1: Host Interface Selection .................................................................................9
Table 2-2: Module Pinout ...............................................................................................9
Table 2-3: FSP201 Module PCB Footprint........................................................................11
Table 3-1: Acronyms ...................................................................................................12

FSP201 Module Quick Start Guide 1000-5133
Confidential and Proprietary · Unauthorized Reproduction Prohibited
Copyright © 2015 –CEVA®, Inc. 7
1. Introduction
1.1 Scope
This document describes the features and operation of the FSP201 Module.
1.2 Audience
This document is intended for anyone who wants to evaluate the FSP201.
1.3 Related Documents
The following documents are related to the information in this document:
1000-4819 FSP201 Datasheet, CEVA, Inc.
1000-3625 SH-2 Reference Manual, CEVA, Inc.
1000-4906 FSP201 Simple Calibration User Guide, CEVA, Inc.
1000-3535 Sensor Hub Transport Protocol
1000-4868 Schematic, FSP201 Module
1.4 Overview
The FSP201 is a 6-axis IMU processor, integrating CEVA's high-
performance sensor hub software stack, to provide heading and orientation
outputs. When connected to one of several supported sensors, it performs all
the accelerometer and gyroscope sensor fusion processing necessary to
produce stable and accurate heading and orientation outputs. This document
is intended to provide information about the FSP201 Module to facilitate
customer evaluation.

FSP201 Module Quick Start Guide 1000-5133
Confidential and Proprietary · Unauthorized Reproduction Prohibited
8 Copyright © 2023 –CEVA®, Inc. Rev. 1.0
2. Hardware
2.1 Introduction
The FSP201 Module includes the FSP201 sensor hub processor with either
the Bosch BMI088 or ST Micro LSM6DSR 6-axis sensor.
Figure 2-1: FSP201 Module with BMI088
2.2 Connections
The FSP201 communicates with the host system over a UART or I2C
interface. The UART interface can be either in UART-RVC mode or in
UART-SHTP mode. The I2C interface is in I2C over SHTP mode.
In UART-SHTP or I2C-SHTP modes, the FSP201 uses the Sensor Hub
Transport Protocol (SHTP) to communicate with a system or application
processor. The SHTP protocol is documented in the Sensor Hub Transport
Protocol [4], allowing a customer to potentially develop their own host
software if they choose to do so.
In UART-RVC mode, the FSP201 transmits heading and sensor information
at 100Hz.
The host protocol selection is made with the PS0 and PS1 signals. The
module’s default configuration is UART-RVC mode.

FSP201 Module Quick Start Guide 1000-5133
Confidential and Proprietary · Unauthorized Reproduction Prohibited
Copyright © 2015 –CEVA®, Inc. 9
2.2.1 Host Interface Mode Selection
The module can be configured for any of the following host interface options.
The PS pins are set for UART-RVC mode by default. To select a different
interface mode just terminate the PS per the table below. For example, to
select I2C-SHTP mode you will need to pull PS0 pin low. Interface selection
is done at startup time, please see the FSP201 Datasheet (1) for more
information.
PS1
PS0
Mode
0
0
I2C over SHTP
0
1
UART-RVC *
1
0
UART over SHTP
1
1
reserved
*module’s default
Table 2-1: Host Interface Selection
2.2.2 Module Pinout
Pin
Signal Name
Mode
Description
Module Connections
1
Vdd
Power
Power
Connect to 1.6V-3.6V
2
GND
Power
Ground
Ground
3
NC
not connected
leave floating
4
NC
not connected
leave floating
5
H_INTN_RED
Output
Host interface interrupt or
calibration status
6
H_BOOTN
Input
Bootloader select
7
H_PS1
Input
Host interface protocol select 1
Pulled high 10k ohm to Vdd
8
GND
Power
reserved, do not connect
Ground
9
H_PS0_WAKEN
Input
Host interface protocol select 0,
wake
Pulled low 10k ohm to ground
10
RSV
Reserved
reserved, do not connect
leave floating
11
H_SDA_TXD_GRN
Input/Output
Host I2C data, Host UART Tx
data, or calibration status
12
H_SCL_RXD
Input
Host I2C clock, Host UART Rx
data
13
RSV
Reserved
reserved, do not connect
leave floating
14
H_SA0
Input
Host I2C Address select
Pulled low 10k ohm to ground
15
RSV
Reserved
reserved, do not connect
leave floating
16
NC
not connected
leave floating
17
NC
not connected
leave floating
18
H_NRST
Input
Reset, Active low
Pulled high 10k ohm to Vdd
Table 2-2: Module Pinout

FSP201 Module Quick Start Guide 1000-5133
Confidential and Proprietary · Unauthorized Reproduction Prohibited
10 Copyright © 2023 –CEVA®, Inc. Rev. 1.0
2.3 Mechanical
2.3.1 Sensor Orientation
The module supports either the BMI088 or the LSM6DSR. The orientation
shown below is the same for either sensor installed.
Figure 2-2: FSP201 Module Orientation
2.3.2 Module Dimensions
The FSP201 Module is 20 x 25mm, 18 castellation pins (2mm pitch).
Figure 2-3: FSP201 Module Dimensions (Component side)

FSP201 Module Quick Start Guide 1000-5133
Confidential and Proprietary · Unauthorized Reproduction Prohibited
Copyright © 2015 –CEVA®, Inc. 11
2.3.3 Module Recommended PCB Footprint
Table 2-3: FSP201 Module PCB Footprint

FSP201 Module Quick Start Guide 1000-5133
Confidential and Proprietary · Unauthorized Reproduction Prohibited
12 Copyright © 2023 –CEVA®, Inc. Rev. 1.0
3. Glossary
Table 3-1 defines the acronyms used in this document.
Table 3-1: Acronyms
Term
Definition
SHTP
Sensor Hub Transport Protocol
RVC
Robot Vacuum Cleaner
