CHALET E Series Assembly instructions

DVD PLAYER
-If Equipped
The DVD player is connected to the
TV and plays through the TV stereo
speakers or the deluxe sound rear radio
speakers in the lounge area of the coach.
Provide 12V Power
The TV and DVD player operate on
12-volt DC current.
• Turn on the 12-Volt
Master Power (TV)
switch, located in the
video cabinet near the
TV.
NOTE: When the TV is
notinuse,theTVMaster
Power switch should be
turned off to avoid drain on the 12-
volt house battery.
Set TV Sound Output
• Use the TV Menu button to set TV
audio output to Variable Audio
Output.(SeeTVowner’smanualfor
instructions.) This will connect TV
stereo sound output to the deluxe
speakers in the lounge area.
• Volume is adjusted with the TV
remote or volume buttons.
Set TV Video Input
• Turn TV and DVD player On.
• PresstheSOURCEbuttonontheTV
or TV remote to select “INPUT 1.”
• TheTVscreenwilldisplaytheDVD
player logo when the correct input is
selected.
Play DVD
• Insert DVD into player. DVD will
begin to load automatically. TV
screen will typically show
“READING” or LOADING”.
• The DVD may load directly to the
main title/menu screen or it may
begin to play previews. You may be
able to skip previews if desired by
pressing the NEXT button until you
see the main menu screen.
• Whenthemainmenuscreenappears,
use the arrow buttons on the DVD
remote to select the desired entry or
presstheENTERorPLAYbuttonson
theremote(or“Play”buttononDVD
player) to begin playing the feature.
• Volume is adjusted with the DVD
remote (or volume buttons on DVD
player).
Further Information
Forfurtherinformationandoperating
instructions, see the manufacturer’s
information included in your InfoCase.
ENTER
NEXT
ENTER
T/F
ENTER
PLAY/PAUSE
Continued—

Audio-Video System
Basic Operation
Guide
Part No. 161501-11-018
1102100322
Copyright 2010 Winnebago Industries, Inc.
All rights reserved.
E-Series Class-A
NOTE: See your InfoCase for specific
operating guides for audio and
video components.
