Cisco Video Surveillance 6400E IP Camera Installation Guide
OL-32282-01
1
Overview
This chapter describes the Cisco Video Surveillance 6400E High-Definition IP Camera, and includes the
following topics:
•Introduction, page 1-1
•Package Contents, page 1-2
•IP Camera Physical Details, page 1-3
Introduction
The Cisco Video Surveillance 6400E IP camera offers 1080p HD resolution with superb image quality.
The 6400E is a high-end bullet camera with outdoor-specific features, such as concealed wiring to
prevent tampering, which makes it the camera of choice for applications such as parking lots, gas
stations, and building entrances.
The 6400E boasts high-definition 2-megapixel (1920 x 1080) resolution, allowing for the delivery of
extremely detailed images and coverage six times larger than a VGA camera. To maximize the benefit
of the 2-megapixel sensor, the 6400E employs several innovative technologies for optimized bandwidth
efficiency. Furthermore, multiple video streams can be delivered simultaneously in different resolutions,
frame rates, and image qualities for viewing on different platforms to meet different needs or bandwidth
constraints. The 6400E also offers activity adaptive streaming support that dynamically allocates
bandwidth according to the video content and trigger state.
Aimed at outdoor surveillance, the 6400E features auto-iris capability to protect the lens from damage
induced by direct sunlight. To adapt to light changes throughout the day, the camera is furnished with an
automatic IR-cut filter and IR illuminators for superior image quality around the clock. The 6400E also
comes with an IP67- and IK10-rated housing that offers protection against rain and dust to ensure
functional operation in all types of weather conditions. For easy management and protection against
tempering and vandalism, the 6400E is also equipped with a mounting bracket that conceals all cables
within the bracket.
With other advanced features such as 802.3af compliant PoE and micro SD/SDHC card for onboard
storage, the 6400E is a full-fledged surveillance solution for outdoor environments.

1-2
Cisco Video Surveillance 6400E IP Camera Installation Guide
OL-32282-01
Chapter 1 Overview
Package Contents
Package Contents
The Cisco Video Surveillance 6400E IP Camera package includes the following items:
•Cisco Video Surveillance 6400E IP camera (1)
•Sun shield (1)
•Standoff screws (M3X/4-20) (2)
•Screws (M3 x 8) (2)
•Screws (M4 x P07) (2)
•Screws (1/4 x 32mm) (3)
•Thumb screw (M5 x P0.8) (1)
•Gasket (3)
•Wall mount bracket (1)
•Mounting plate (1)
•Wall anchors (3)
•8mm wrench (1)
•L type hex key (allen wrench) (1)
•Double sided tape (1)
•Rubber pad (1)
•Waterproof connector assembly for RJ45 Ethernet enclosure (1)
•Waterproof connector assembly for power and I/O cables (1)
•Silica gel packet (1)
•Mounting plate alignment sticker (1)
•Extra set of labels (3)
•Cisco documentation pointer card (1)
•Cisco RoHS document (1)

1-3
Cisco Video Surveillance 6400E IP Camera Installation Guide
OL-32282-01
Chapter 1 Overview
IP Camera Physical Details
IP Camera Physical Details
Front View
Figure 1-1 and the table that follows describe the front view of the 6400E IP camera.
Figure 1-1 Front View of IP Camera
1Single reflector illuminator
LEDs (SRLEDs)
IR LEDs that enhance the video image when the IP camera is
running in night mode
2Varifocal lens IP camera lens that changes focus as the focal length changes
3Light sensor Senses the level of ambient light to determine when to switch
day/night mode

1-4
Cisco Video Surveillance 6400E IP Camera Installation Guide
OL-32282-01
Chapter 1 Overview
IP Camera Physical Details
Back View
Figure 1-2 and the table that follows describe the back view of the 6400E IP camera.
Figure 1-2 Back View of IP Camera
1General Purpose I/O (GPIO)
terminal block
GPIO terminal block that is used to connect external input and
output devices. For more information, see Figure 1-3.
2SD/SDHC card slot The IP camera is compliant with Micro SD/SDHC (up to 32GB)
and other preceding standard SD cards.
3Video output switch Switches the video output between to following standards:
•NTSC 60Hz (up)—switches camera operation to the
National Television System Committee (NTSC) standard.
•PAL 50Hz (down)—switches camera operation to the
Phase Alternating Line (PAL) standard.
4Focus assist button Used in conjunction with an analog display to fine tune the IP
camera focus.
5Reset button Reboots the IP camera or resets it to a default state. Depending
on how long you depress the reset button, you can do either of
the following:
•Reset—Press and release the reset button. Wait for the IP
Camera to reboot.
•Restore—Press and hold the reset button for about
30 seconds. All settings will be restored to factory default.
2
3
4
5
6
7
1

1-5
Cisco Video Surveillance 6400E IP Camera Installation Guide
OL-32282-01
Chapter 1 Overview
IP Camera Physical Details
General Purpose I/O Terminal Block
Figure 1-3 shows the GPIO terminal block pin locations and descriptions.
Figure 1-3 GPIO Terminal Block Pin Locations and Descriptions
Note The maximum output load from pins 7 and 8 is 400mA.
6Audio/Video out (green) Allows the connection of an optional Y cable or mini cable with
BNC connector. You can connect a video monitor to the mini
cable with BNC connector. Both cables are included in the
optional audio/video cables accessory kit can be purchased
from Cisco (Cisco part number CIVS-AVCABLE).
Note Support for audio will be in future releases.
7Microphone In (pink) Connection for an external microphone.
Pin Description
112VDC-
212VDC+
324VAC
424VAC
5DI-
6DI+
7DO-
8DO+
87654321

1-6
Cisco Video Surveillance 6400E IP Camera Installation Guide
OL-32282-01
Chapter 1 Overview
IP Camera Physical Details
