OWNER’S MANUAL & OPERATING INSTRUCTIONS
338cc
REPLACEMENT ENGINE
10006 Santa Fe Springs Road
Santa Fe Springs CA 90670
USA / 1-877-338-0999
www.championpowerequipment.com
SAVE THESE INSTRUCTIONS
Important Safety Instructions
are included in this manual.
MADE IN CHINA
REV 61151-20110328
61151
MODEL NUMBER
2YEAR
LIMITED WARRANTY
338cc

Have questions or need assistance?
Do not return this product to the store!
WE ARE HERE TO HELP!
Visit our website:
www.championpowerequipment.com
for more info:
• Product Info & Updates
• Frequently Asked Questions
• Tech Bulletins
• Product Registration
– or –
Call our Customer Care Team Toll-Free at:
1-877-338-0999

61151
TABLE OF CONTENTS
Introduction ............................ 1
Introduction .......................... 1
Replacement Engine .................... 1
Accessories .......................... 1
This Booklet .......................... 1
Manual Conventions....................... 2
Safety Rules ............................ 3
Controls and Features ..................... 5
Replacement Engine .................... 5
Parts Included ........................ 5
Assembly .............................. 6
Add Engine Oil ........................ 6
Add Engine Fuel ....................... 6
Connect Battery (not included) ............. 6
Operation .............................. 7
Engine Location ....................... 7
Starting the Engine ..................... 7
Stopping the Engine .................... 7
Maintenance and Storage ................... 8
Engine Maintenance .................... 8
Oil .............................. 8
Spark Plugs ........................ 8
Air Filter .......................... 8
Cleaning .......................... 8
Adjustments ........................ 9
Maintenance Schedule................. 9
Storage ............................. 9
Engine Storage ...................... 9
Specifications .......................... 10
Engine Specifications .................. 10
Fuel .............................. 10
Oil ............................... 10
Spark Plugs ......................... 10
Valve Clearance....................... 10
Keyway Shaft ........................ 10
Parts Diagram........................ 11
Parts List ........................... 12
Troubleshooting......................... 13
Warranty ............................. 14
Warranty Qualifications ................. 14
Repair/Replacement Warranty ............. 14
Do Not Return The Unit To The Place Of Purchase14
Warranty Exclusions. . . . . . . . . . . . . . . . . . . . 14
Normal Wear ...................... 14
Installation, Use and Maintenance........ 14
Other Exclusions .................... 14
Limits of Implied Warranty and Consequential
Damage .......................... 14
Contact Information.................... 14
Address .......................... 14
Customer Service ................... 14
Technical Service ................... 14
Emission Control System Warranty.......... 15
338cc
REPLACEMENT ENGINE

1REV 61151-20110328
ENGLISH 61151
INTRODUCTION
Introduction
Congratulations on your purchase of a Champion Power
Equipment engine. CPE designs and builds engines to
strict specifications. With proper use and maintenance,
this engine will bring years of satisfying service.
Replacement Engine
This unit is a gasoline driven, key-way shaft
replacement engine. It is designed to supply power for
air compressors, pumps, pressure washers, reel-type
lawn mowers, go-carts, agricultural and construction
equipment and other pulley-style applications.
Record the model and serial numbers as well as date and place of purchase for future reference. Have this information
available when ordering parts and when making technical or warranty inquiries.
Accessories
Champion Power Equipment manufactures and sells
accessories designed to help you get the most from your
purchase. To find out more, please visit our web site at:
www.championpowerequipment.com
This Booklet
Every effort has been made to ensure the accuracy and
completeness of the information in this manual. We reserve
the right to change, alter and/or improve the product and
this document at any time without prior notice.
Champion Power Equipment Support
Model Number
Serial Number
Date of Purchase
Purchase Location
1-877-338-0999
61151
For Oil Type see “Add Engine Oil” section. For Fuel Type see “Add Fuel” section.

REV 61151-20110328 2
61151 ENGLISH
MANUAL CONVENTIONS
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in minor
or moderate injury.
CAUTION
CAUTION used without the safety alert symbol
indicates a potentially hazardous situation which, if
not avoided, may result in property damage.
CAUTION
This manual uses the following symbols to help differentiate between different kinds of information. The safety symbol
is used with a key word to alert you to potential hazards in operating and owning power equipment.
Follow all safety messages to avoid or reduce the risk of serious injury or death.
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in death
or serious injury.
DANGER
WARNING indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
WARNING
If you have questions regarding your engine, we can
help. Please call our help line at 1-877-338-0999
NOTE
