CHANCEE X06C User manual

X06C Floor Scrubber
Instruction Manual

We explore safer, higher-end and more user-friendly cleaning equipment
through technical advantage and idea innovation.

Preface
This instruction manual contains all the information that you need to use and
maintain the machine. Please read it carefully before getting started. Only with
correct operation and regular maintenance can the machine be kept in its best
working condition.
This instruction manual is an important part of the product and should be kept
together with the machine.
If this manual is lost, please contact us immediately and we will be glad to provide
you with a new one. All technical details included in this manual are property of
Anhui Chancee Technology Co., Ltd and are protected by law.
In this manual we use illustrations to show the components and functions of the
machine. It is possible that some of them contain details that are slightly different
from those of yours. However, all the instructions presented here still apply to your
product and should be followed strictly during the operation.
Some components of the product may be harmful or dangerous and we have tried
our best to include them in this manual. It is the user’s obligation to pay special
attention to them during the work. However, since it is impossible for us to point out
all potential dangers, we expect you to be extremely cautious during the work so as
to protect the machine, yourself and other people in the working area.
Only accessories from the original manufacturer can be used on the machine. Using
accessories from other sources may lead to low working efficiency or even accidents
in extreme cases.
We usually modify or improve our products to meet the latest market demand.
However, this is NOT suitable for machines that have been sold. We will NOT be
responsible for any injury or loss caused due to the user’s improper operation either.
If you have any question, complaint or suggestion, please feel free to contact us and
we will be at your service with all our knowledge and enthusiasm.
We wish you a pleasant experience with our product!

Components & Technical parameters
1
Chapter 1 General description
2/3
1.1 Contents and purposes
1.2 General instructions
1.3 Safety requirements for the batteries
1.4 General safety requirements
Chapter 2 Operating the machine
4/7
2.1 Buttons and pedals of the machine
2.2 Operation process of the machine
2.3 Cautions during the operation
Chapter 3 Regular inspection and replacement of damaged parts
8/11
3.1 Adjustment and replacement of the main brush
3.2 Adjustment and replacement of the side brushes
3.3 Replacement of the filter element
3.4 Adjustment of the height of the baffles
3.5 Replacement of the fuses
Chapter 4 Common problems and solutions
12
Chapter 5 Maintenance
13
Chapter 6 After-sale services
14
Warranty card
15
Contents

- 1 -
Components
①
Steering wheel
⑤
Clean water tank
⑨
Suction pipe
②
Sewage watching port
⑥
Pickup broom cover
⑩
Controlling panel
③
Clean water tank
⑦
Pickup broom
⑪
Sewage outlet
④
Sewage tank
⑧
Water inlet
⑫
Squeegee
Technical parameters
Category
Parameter
Category
Parameter
Cleaning width
410 mm
Battery capacity
12 V/36 Ah
Pickup broom
width
360 mm
Working time
1 h
Pickup broom
size
6.7 inches * 2
Suction motor
power
140 W
Squeegee width
450 mm
Pickup broom
power
120 W * 2
Working efficiency
1,250 m2/h
Total weight
13 kg
Clean water tank
capacity
5 L
Product size
1,050 * 440 * 360
(mm)
Sewage tank
capacity
8.5 L

- 2 -
Chapter 1 General description
1.1 Contents and purposes
Potential dangers during the use of the machine are listed in the following
sections. Since most accidents take place when safety rules are ignored, it is
necessary that you read them carefully and take precautions before getting
started. The best guarantee against any accident is a careful and cautious user,
which might be better than other precautions available. When using the
machine, pay special attention to the people in the working area, especially
children.
1.2 General instructions
Before any maintenance and repair, turn off the power and remove the key
from the general switch.
The machine can only be operated by qualified personnel. Children and
disabled people are strictly forbidden to use it.
Keep the battery away from sparks, flames and smoke.
Do NOT use the machine in places with dangerous, flammable or explosive
gases, liquids or water vapor.
The machine can be used to clean regular garbage. It must NOT be used to
clean silk ropes, belts, high-temperature sundries, accumulated water, or
flammable, toxic and harmful materials, so as to avoid entanglement and
burning of the brushes.
Keep loose clothing, hair, fingers and other parts of your body away from the
air vent and any moving part of the machine.
Turn off the power if you do not use the machine.
Do NOT use the machine in slopes with an inclination larger than the fixed
value.
Do NOT smoke when charging the battery.
Do NOT use the machine in very dirty places. Repeat the sweeping if there is
too much garbage.
The machine should be stored at a temperature between -10 °C and 40 °C.
The temperature of the working area should be between -10 °C and 40 °C, and
the humidity should be between 30% and 95%.
Do NOT use the machine as a means of transportation.
When the machine is not moving, stop the brushes to avoid damage to the
ground.
In the event of a fire, use a POWDER extinguisher rather than water.

- 3 -
When a failure is produced, make sure that it is NOT due to the lack of regular
maintenance.
If some spare parts need to be replaced, you can purchase them from the
original manufacturer or an authorized distributor.
To make sure that the machine is in the proper operating and safety condition,
the user or service center must abide by what is stated in Chapter III and
Chapter V.
Attention must be paid even when the machine is about to be dismantled and
scrapped. Since some harmful substances (such as batteries, waste oil, etc.)
have met the required standards, they should be sent to a specific center for
treatment.
1.3 Safety requirements for batteries
The battery must NOT be in a low voltage state; charge the battery as soon as
possible when the voltage is below 42 V;
To avoid electric leakage, keep the battery dry and clean;
Do NOT put metallic objects (such as tools) on the battery to prevent it from
being short-circuited and burned;
The charging room should be well ventilated;
When the key switch is in the position “ON”, do NOT install or remove the
battery;
Before installing or removing the battery, disconnect first the negative wire (-)
and then the positive wire (+). When rewiring, pay special attention to the
polarity of the battery, as wrong connection would probably damage electrical
components;
Avoid direct contact between the positive and the negative electrodes, because
it would cause a large current short circuit, high heat or even a fire.
1.4 General safety requirements
In addition to what is mentioned in this manual, the general safety
requirements must also be observed. Even if you have used a similar product
before, we recommend that you read this manual carefully so that you can
save much time as well as take precautions to protect the machine and
yourself. It is vital that you become familiar with all the accessories and
components before turning on the machine. Read our instructions carefully so
that you will not be confused when you get started.

- 4 -
Chapter 2 Operating the machine
2.1 Buttons and pedals of the machine
2.1.1 Key controlling buttons of the machine
2.1.2 Charging the batteries
2.1.3 Adding water to the water tank
2.2 Operating the machine
2.2.1 Preparation work
①Pickup broom button
②Water pump button
③Pickup broom speed adjusting
button
④Sewage level alarming light
⑤Suction motor
⑥Power display
A socket with a minimum diameter of
4 mm is required.
The charging room should be well
ventilated and away from sparks,
smoke and flammable or explosive
substances.
Do NOT use the machine during the
charging process.
The batteries should be charged for at
least 8 hours so that they will have
sufficient power during the work.
Before using the machine, add
clean water to the clean water
tank. Pay attention to the water
quality to prevent blockage of the
water pipe.

- 5 -
Before any operation, make sure that the switch is turned off, and then follow the
instructions below.
Align the squeegee fixing screws with the
holes on the squeegee and the bottom
plate, and tighten them with an Allen
wrench.
Insert one of the ends of the suction pipe
into the outlet hole of the sewage tank,
and the other end into the suction hole of
the squeegee.
Adjust the position of the squeegee
through the universal wheels on it.
Turn on the switch and the current voltage
of the batteries will be displayed on the
screen. If the voltage is lower than 36 V or
the last bar of the screen is flashing, please
charge the batteries as soon as possible.
Note: the squeegee has been adjusted well by the original manufacturer.
2.2.2 Starting the machine
Turn on the general switch, the
suction button, the pickup broom
button and the pump switch, and
then adjust the spin speed of the

- 6 -
pickup broom.
Hold the steering wheel and push
the machine forward; keep the
machine running smoothly.
The sewage tank is equipped with a sewage level sensor. When the sewage
level reaches its position, the alarm will be triggered and the user should
discharge the sewage immediately.
2.2.3 Turning off the machine
Turn off the suction motor, pickup broom motor and pump switch.
Turn off the general switch.
Use the universal wheels to lift the pickup broom and the squeegee.
2.2.4 Stopping the machine
Release the accelerator pedal to stop the machine.
Press the stop button and all sweeping functions are stopped, and the main
brush and side brushes are raised.
Turn the start switch to the "OFF" position.
2.3 Cautions
2.3.1 General instructions
When the pickup broom is rolling, do NOT leave the machine in the same place
for a long time, because this would leave unnecessary marks on the ground.
When adding water to the water tank, pay attention to the water quality or
blockage will be generated.
When the sewage level reaches the highest position and the alarm is triggered,
discharge the sewage tank immediately.
Before adding clean water, discharge the sewage tank first or the total weight
of the machine will be increased and the working time will be reduced.
If you need to wash heavily polluted floor, you can add a certain amount of
low-foam detergent to the clean water tank. In this case the use of defoamer is
indispensable, or foam will be sucked into the suction motor and cause it to be
burnt.

- 7 -
In order for the machine to be in its best condition, the sewage tank should be
discharged and washed once the work is finished.
In winter or very cold regions, empty the clean water tank once the work is
finished, because water may freeze and cause the tank to be cracked.
If the machine is not about to be used within 30 days, please fully charge the
batteries, disconnect the battery cords and store the machine in a dry and
clean storage place.
2.3.2 Discharging the sewage tank
Turn off the general switch and make sure that the machine is stopped.
Discharge sewage.
You can wash the sewage tank with clean water.
2.3.3 Discharging the clean water tank
Turn off the general switch and make sure that the machine is stopped.
Empty the clean water tank.
You can wash the tank with clean water.

- 8 -
Chapter 3 Regular inspection and replacement of
damaged parts
3.1 Regular check items
Check items
Time interval (h)
3
50
100
200
500
1
Battery power
2
Carbon brush of the motors
3
Is the brush entangled?
4
Are there impurities in the water tank?
5
Buttons and electric components
6
Is the brush worn?
7
Is the squeegee worn?
8
Are the impurities in the filter?
9
Is the sealing strip cracked?
10
Is the water pipe cracked?
11
Are the wheels and tires worn?
3.2 Replacement of the pickup broom
Park the machine on the flat
ground, and put the pickup broom
face up.
Hold the pickup broom and lift it
upward to remove it.

- 9 -
Align the new pickup broom with
the magnetic hoop and move the
plate close to the hoop. Then the
new pickup broom will
automatically be installed.
3.3 Replacement of the squeegee strip
Use an Allen wrench to remove the fixing nuts of the squeegee.
Remove the rear wheels and the depression bar of the squeegee, and then
remove the front and rear strips of the squeegee.
Install the new strips.

- 10 -
3.4 Maintenance of the batteries
The machine is powered by a 36 V acid-lead battery and the system voltageis 36 V.
The power of the battery will gradually decrease during the work. When the
last bar of the display is flashing, the power is insufficient and charge the
battery immediately.
When maintaining the battery, please wear gloves to avoid contact with acid
substances.
Check whether the battery cords are worn or loose, and replace them if
necessary.
The battery should be kept dry and clean, and there should be no dust on its
surface, since it is extremely harmful to the battery and may even cause it to
be burnt in severe cases.
3.5 Removal and installation of the suction motor
The removal of the suction motor
1. The suction motor in located below
the water tank. Before removing it,
discharge the clean water tank and
the sewage tank.
Caution!!
In order for the battery to have a long service life, charge it immediately each
time after using the machine; deep discharge is strictly prohibited, as it would
reduce the capacity of the battery and shorten its service life.
When charging the battery, first insert the battery, and then plug it into the
mains; when the battery is fully charged, first cut off the mains, and then pull
it out.
If you do not need to use the machine for a long period of time, please
charge the battery fully and disconnect the positive pole.

- 11 -
2. Turn off the general switch and
make sure that the machine is
powered-off.
3. Loosen the water tank fixing nuts
and take out the water tank.
4. Loosen the suction motor fixing nuts
and take out the suction motor.
Installation of the suction motor
1. Align the suction motor installation
holes with the water tank fixing nuts
and tighten the motor with nuts.
2. Connect the suction motor with the
wire of the machine.
3.6 Removal and installation of the sewage level sensor
Note: the sewage level sensor is located inside the sewage tank; when the sewage
level is too high, the switch of the sensor will be triggered and the machine will
automatically be stopped.
Remove the insulating tape and the leakage protection cover, cut the sensor
wires and unscrew the plastic nuts of the sensor to remove it.
When installation the sensor, pay attention to the polarity of the wires.

- 12 -
Chapter 4 Common problems and solutions
The batteries cannot
be charged.
The charger fails.
Replace the charger.
The charging port is
oxidized.
The suction motor does
not work.
The fuse is blown.
Replace the fuse.
The brush plate motor
does not work.
The fuse is blown.
Replace the fuse.
No water outlet is
produced.
The clean water pipe is
blocked.
Clean the water pipe.
There are impurities in the
filter cover.
Clean the filter cover.
The electromagnetic valve
fails.
Check the electromagnetic
valve.
Loud noise is produced.
The squeegee is in the
wrong position.
Adjust the height of the
universal wheels of the
squeegee.
The suction motor is
broken.
Replace the suction
motor.
The brush plate
The brush plate drops
often.
Improper operation.
The brush plate buckle is
worn.
Replace the buckle.
The water suction
efficiency is low.
The floating ball cage is
blocked.
Clean the floating ball
cage.
The suction pipe is
blocked.
Clean the suction pipe.
The sealing of the sewage
tank is cracked.
Replace the sewage tank.
The strip of the squeegee
is cracked.
Replace the strip.

- 13 -
Chapter 5 Maintenance
Regular maintenance is necessary in order for the machine to be in its best
condition, as well as to extend its service life and ensure the operator’s safety. The
time interval of maintenance can be changed under certain circumstances, but this
must be determined by a professional technician.
When performing maintenance, make sure that the machine is turned off and the
key is removed from the switch.
5.1 Operating conditions
Temperature: -10 °C ~ 40 °C
Relative humidity: 5%~70%
No electricity-conductive and explosive gases or dust are presented
No corrosive gases or vapor are presented
Well ventilated indoor environment
5.2 Maintenance timetable
Items
Upon
receiving
Every
10h
Every
50h
Every
100h
Every
200 h
Every
500h
Height ofthe pickup brooms
Are the pickup brooms
entangled?
Belt of the main brush
Dust suction motor and
filterelement
Baffles
Dust-vibratormotor
Are all nuts and screws
tightened?
Degree of wear of the brake
Degree of wear of the
brushes
Are all the driving chains
tightened?

- 14 -
Chapter 6 After-sale services
6.1 General description
Seven-day guaranteed return, fifteen-day guaranteed replacement, one-year
warranty for the whole machine, 6-month warranty for damaged parts, and no
warranty for consumables (calculated from the next day after receiving the
machine).
The delivery receipt and purchase invoice are certificates for warranty and
must be kept properly.
6.2 Contents of warranty
Category
Contents
Warranty period
The entire
machine
Sheet metal parts, batteries, motors,
controllers, accelerator pedal, relay, charger,
spray gun, high-pressure pump, brake
assembly
1 year
Damaged
parts
Shock attenuator, inner springs, wheels,
nozzles, lights, bearings, universal wheels,
fuses
6 months
Consumables
Side brush, main brush, filter element, baffle,
conveyor belt, sealing strip, high pressure
water pipe
No warranty
6.3 Cases not covered in the warranty
The operator fails to perform maintenance according to the instruction manual,
resulting in damage or failure.
The surface and/or the structure of the machine are obviously damaged due to
improper operation.
Disassembly or modification not approved by the original manufacturer.
Damage due to weather or force majeure.
The warranty is expired or the machine has been used for more than 1,500
hours.

- 15 -
Warranty Card
用户名
User’s name
联系电话
Tel
通讯地址
Address
票据号
Bill No.
购买时间
Date of purchase
机身编号
Serial number
产品型号
Type of product
日期
Date
更换配件：
Accessories to be replaced:
故障描述：
Fault description:

- 16 -
Anhui Chancee Technology Co., Ltd.
Direction: 11 Qiaowan Road, Heifei, Anhui, China
Website: www.chanceeglobal.com
