Pacific Z210 User manual

This operator’s book has important informaon for the use and safe operaon of this machine. Read this book carefully before starng the machine. Keep this
book and tell all operators to read the book. If you do not follow the instrucons, you can cause an injury or damage equipment, furniture or buildings.
For new books, please download your copy from our website www.pacicoorcare.com or write to:
Pacic Floorcare
2259 S. Sheridan Drive
Muskegon, MI 49442-6252
Carefully inspect all components to ensure that there is no concealed freight damage. If such damage is discovered, le a “CONCEALED DAMAGE REPORT” im-
mediately with the delivering carrier.
The contents of this manual are based on the latest product informaon available at the me of publicaon. Pacic reserves the right to make changes or im-
provements without noce.
Thank you for purchasing a Pacic Floorcare product. Warranty registraon will allow us to beer serve you over the lifeme of the product. For quick and
easy registraon, go to: www.pacicoorcare.com/Register Product.
PLEASE READ THIS BOOK
Z210 TRACTION DRIVE
AUTO SCRUBBER
PARTS & OPERATING MANUAL

2
SAFETY INSTRUCTIONS
1) You must have training in the operaon of the machine before using it. READ THE INSTRUCTION BOOK. If you do not understand any instrucon, ask your supervisor.
2) Make sure all labels, decals, warnings, cauons and instrucons are fastened to the machine.
3) Read the labels carefully on the machine. Do not cover them for any reason and replace them if damaged.
4) Do not operate this machine unless it is completely assembled and inspect the machine carefully before operaon.
5) Pay close aenon to other people and especially children while operang this machine.
6) Be a careful driver and do not strike shelving or scaolding, especially where there is a danger of falling objects.
7) Machines can cause an explosion when operated near ammable materials and vapors. Do not use this machine with or near fuels, grain dust, solvents, thinners, or other
ammable materials.
8) In case of re, use a powder exnguisher. Do not use water.
9) Do not use this machine as a means of transport.
10) Do not use acid soluons that could damage the machine or ooring.
11) Adjust your speed to the condions of the oor.
12) Do not turn the machine on an incline. Do not stop and leave the machine on a ramp or incline.
13) During any maintenance operaon disconnect the power supply from the machine.
14) Lead acid baeries generate gases that can cause an explosion. Read the instrucon manual supplied with the baery charger. Keep sparks and ames away from baer-
ies. NO SMOKING. Charge the baeries only in an area with good venlaon.
15) Do not use a charger if the power cord is damaged or a charger that is not matched to the machine.
16) Always wear eye protecon and protecve clothing when working near baeries. Remove all jewelry. Do not put tools or other metal across the baery terminals, or on
the top of the baeries.
17) Maintenance and repairs must be performed by authorized Service Centers only.
18) Keep the electrical parts of the machine dry. Do not wash the machine with direct water jets or high pressure, or with corrosive material. For storage, keep the machine in
a dry locaon.
19) Water soluons or cleaning materials used with this type of machine can leave wet areas on the oor surface. These areas can cause a dangerous condion for the opera-
tor or other persons. Always put CAUTION signs near the area you are cleaning.
20) Do not reach under shrouds with ngers, hands, or toes when machine is running.

SYMBOLS USED ON THE AUTOMATIC SCRUBBER
Water Valve Indicator
Brush Drive Motor Control Switch
Vacuum Motor Control Switch
Squeegee Li Lever Indicator
Baery Charge Indicator
Water Flow Control Indicator
Tracon Drive Speed Control
Forward - Reverse Tracon Drive Switch
3

MACHINE PREPARATION
1. UNPACKING THE MACHINE
a. Take o the outer packaging
b. The machine is fastened to the pallet with wooden wedges that block the wheels. Remove
e down straps
c. Using a ramp, pull the machine o the pallet
2. BATTERY INSTALLATION
a. Remove the squeegee hose from the recovery tank
b. Remove the vacuum cover by rotang it counterclockwise
c. Remove recovery tank by liing tank by li chain at the back of the tank and the drain hose
at the front of the tank
d. Place the baeries in the baery compartment
e. Connect the baery connector to the machine connector
f. Replace the recovery tank and reassemble the vacuum cover and squeegee hose
3. BATTERY CHARGE LEVEL INDICATOR
The baery indicator is digital with bars indicang the level of charge. The bars, which
appear on the display, show the approximate charge level. A full representaon of bars
represents a full charge and low number of bars remaining (red) represents low charge and the
baeries must be recharged.
NOTE: The brush motor automacally switches o aer the baery indicator light begins to ash. You will be
able run the vacuum motor and nish drying any wet areas.
4

MACHINE PREPARATION
4. SQUEEGEE ASSEMBLY INSTALLATION
The squeegee is assembled to the machine by liing the locking latches and sliding the
squeegee assembly onto the 2 posts at the rear of the squeegee swing arm. Push
the locking latches down. Lower the squeegee and install vacuum hose over vacuum
outlet on squeegee assembly. The hose should be located to the rear of the liing
cable
5. ADJUSTING SQUEEGEE HEIGHT
The height from oor to squeegee should be adjusted based on blade wear. Rotate the
adjusng knobs counter-clockwise to lower squeegee and clockwise to li it
NOTE: Rotate the right and le adjusng knobs unl the squeegee is posioned
parallel to the oor
6. ADJUSTING SQUEEGEE INCLINATION
During operaon the rear squeegee blade is most ecient when bent backwards
roughly 3/16ths to 5/16ths of an inch along its enre length. To increase the blade
bending in the center of the squeegee, lt the squeegee body backward by turning the
adjuster knob counter-clockwise. Conversely, turn the adjuster knob clockwise to
increase the bending at the outside edges of squeegee blade
5

6
MACHINE PREPARATION
7. RECOVERY TANK
Open the lid and conrm the following connecons are secure:
a. The vacuum cover is securely aached. Align the notches and rotate the cover clockwise to
close. The vacuum hose must also be aached
b. Conrm that the squeegee hose is properly connected
c. Conrm that the drain hose plug, which is located at the front of the machine, is
closed
8. SOLUTION WATER
Fill the soluon tank with clean water at a temperature not higher than 50°C / 122°F.
Add the proper concentraon of liquid detergent by following the manufacturer
instrucons. Excess foam in the recovery tank can damage the vacuum motor, so use
only the minimum amount of detergent necessary. Reassemble the cover
WARNING! Always use low foaming detergent. Adding anfoam liquid into the
recovery tank before cleaning will also help prevent foaming
NEVER USE ACID, BLEACH or AMMONIA
9. BRUSH INSTALLATION
a. Li the brush base by depressing the foot level at the rear of the machine
b. Place the brushes under the base. Align the brush lugs with the holes in the brush
plate. Insert the brushes into the plate and turn each brush so the lugs are pushed
toward their retaining springs, unl locked. The photo shows the direcons to rotate
the brushes to lock them into operang posion

10. SPLASH GUARD INSTALLATION
a. Wrap splash guard around the brush deck base
b. Place band clamp over the front band clamp stud
c. Pull band clamp around brush deck base and place and clamp spring over rear band clamp stud
d. Repeat process on opposite side of brush deck base
MACHINE OPERATION
1. Connect machine connector to the baery connector
2. Turn on the main power key switch. Baery charge indicator will illuminate indicang the charge level of
the baeries. If the indicator is ashing then the baeries need to be charged or a fault has occurred.
Call technical service if problem persists aer charging
3. Turn on the brush motor switch. Please note that the scrubbing brushes will not rotate unl the hand
switch lever is engaged
4. Turn on the water solenoid valve switch
5. Turn on the vacuum motor switch
7
MACHINE PREPARATION

MACHINE OPERATION
5. Adjust the ow rate of the cleaning soluon with lever. Moving the soluon ow control lever
downward increases the ow rate and raising the lever decreases the ow rate. There should be
enough soluon to wet the oor uniformly, but not so much that the water gets past the splash guard.
Remember that the correct soluon quanty depends on the type of oor, the dirt level and the
scrubbing speed
6. Release and raise the brush base li lever to lower the brush base
7. Lower the squeegee using the squeegee li lever
8. MACHINE MOTION
This machine is equipped with tracon wheel propulsion. To move machine forward, rock tracon
direconal switch forward and depress the handle switch lever. Adjust the forward speed with the
tracon drive speed control knob. During the rst few yards of operaon, check that the quanty of the
cleaning soluon is sucient to wet the oor and that the squeegee dries the oor surface. To move
machine in reverse, li the squeegee assembly with the squeegee li lever and rock tracon direconal
switch rearward and depress the handle switch lever
WARNING! Always li the squeegee when moving backwards
9. SCRUBBING
Depress the handle switch lever. The scrub brush will begin to rotate and soluon will begin to
ow. During the rst few yards of operaon, check that the quanty of the cleaning soluon is
sucient to wet the oor and that the squeegee dries the oor surface
WARNING! Always li the squeegee when moving backwards
8

10. OVER FILL PROTECTION
The machine is equipped with a oat that stops the vacuum exhaust air ow when the
recovery tank is full. Vacuum motor does not stop operang but the vacuum exhaust air ow
rate is greatly reduced. When this occurs, empty the recovery tank by removing the drain
plug on the drain hose and then empty the recovery tank
WARNING! Use gloves for protecon from contact with dangerous soluons
Aer nishing your work and before any type of maintenance is done, it is necessary to do the
following:
1. Close the water valve by raising the soluon ow control lever
2. Raise the brush base by stepping down locking the brush base li lever. To lock the lever move
your foot to the right while the lever is pressed down
3. Li the squeegee by raising the squeegee li lever and locking it by moving the lever to the le
WARNING! The squeegee blades can be damaged if the squeegee is not raised
during storage or transport
MACHINE OPERATION
UPON COMPLETION OF MACHINE USE
9

UPON COMPLETION OF MACHINE USE
5. Switch o main power key switch
6. Switch o the water solenoid valve switch
7. Switch o the brush motor switch
8. Switch o the vacuum motor switch
9. Transport the machine to the locaon where the recovery tank should be emped
10. Remove the drain hose at the front of the recovery tank
11. Remove the drain plug and empty the recovery tank
WARNING! Use gloves for protecon from contact with dangerous soluons
12. Remove the brush or pad driver and clean them with clear water
DAILY MACHINE MAINTENANCE
CLEANING THE RECOVERY TANK
1. Empty the recovery tank by removing the drain plug from the drain hose
WARNING: Use gloves for protecon from contact with dangerous soluon
2. Li the cover of the recovery tank
3. Take o the vacuum cover by rotang it counter clockwise
4. Remove the lter and its housing
5. Rinse the tank with clean water
10

2. CLEANING THE VACUUM FILTER
a. Li the cover
b. Take o the vacuum cover by rotang it counter-clockwise
c. Remove the lter and its housing
d. Use clear water to clean the walls and the boom of the lter
e. Remove the lter and its housing
f. Wash all components thoroughly
g. Reassemble repeang the above operaons in reverse
3. CLEANING THE SQUEEGEE
To obtain the best drying results, keep the squeegee clean. To clean the squeegee it is
necessary to:
a. Remove the vacuum hose from the squeegee
b. Li locking latches. Remove the squeegee assembly by pulling rearward
c. Clean the inside of the squeegee thoroughly
d. Clean the squeegee blades thoroughly
e. Reassemble
4. REPLACING THE SQUEEGEE BLADES
Check the squeegee blades for wear and if necessary, change them. To replace the squeegee
blades:
a. Remove the squeegee vacuum hose from its port
b. Li locking latches and pull squeegee assembly rearward
c. Release the band clamps by liing the band clamp latch
d. Remove squeegee blades
e. Rotate or replace the blades. Please note that the squeegee has 4 useable edges so you
may be able to rotate squeegee blades
f. To reassemble the squeegee, repeat the above operaons in reverse
DAILY MACHINE MAINTENANCE
11

DAILY MACHINE MAINTENANCE
5. BRUSH / PAD DRIVER REMOVAL
a. Li the brush base by depressing the foot level at the rear of the machine
b. The photo shows the direcons to rotate the brushes to unlock them from the auto
scrubber. Clean the brushes with clear water
WEEKLY MACHINE MAINTENANCE
1. CLEANING THE SQUEEGEE HOSE
To obtain the best drying results, keep the squeegee hose clean. To clean the squeegee
hose it is necessary to:
a. Take o the vacuum hose from its vacuum port on the squeegee
b. Remove the other end of the vacuum hose from the recovery tank
c. Wash the inner part of the hose with clean water
d. Reassemble
WARNING: Do not wash the hose that goes from the vacuum motor to the
vacuum cover
12

WEEKLY MACHINE MAINTENANCE
2. SOLUTION TANK CLEANING
a. Remove the ll cap from the soluon tank
b. Rinse with clear water
c. Remove the soluon tank drain hose and cap at rear of machine and empty the
soluon tank
WARNING: Use gloves for protecon from contact with dangerous soluon
3. IN-LINE FILTER CLEANING
a. Drain soluon tank
b. Turn o solenoid valve
c. Unscrew clear housing
d. Remove screen and clean with clear water
e. Reassemble
WARNING: Use gloves for protecon from
contact with dangerous soluon
13

WATER SOLENOID MAINTENANCE
In the event that the water solenoid begins to leak when turned o, debris must be cleared at
the valve seat. To gain access the water solenoid the scrub deck most be disassembled from the
liing arms. Remove the 3 bolts shown in the photo to release the scrub deck
TROUBLE SHOOTING GUIDE
1. INSUFFICIENT WATER TO THE BRUSHES
a. Make sure the soluon ow control valve is open
b. Conrm that there is water in the soluon tank
c. Make sure soluon dispensing tubes are not clogged or obstructed
d. Make sure inline soluon lter assembly is not clogged or obstructed
2. THE MACHINE DOES NOT CLEAN SATISFACTORILY
a. Check the condion of the brushes or pads and replace them if necessary
b. The brushes should be replaced whent he bristles reach a length of 5/8 inches (15 mm)
3. THE SQUEEGEE DOES NOT DRY THE FLOOR WELL
a. Check that the squeegee blades are clean
b. Adjust the inclinaon fo the squeegee
c. Conrm that the vacuum hose is correctly ed into its port in the recovery tank and free from obstrucons
d. Replace squeegee blades if worn
e. Check that the vacuum motor switch is on
f. Check the squeegee height adjustment (see “MACHINE PREPARATION” secon)
14

4. EXCESSIVE FOAM PRODUCTION
a. Check that a low foaming detergent has been used. If required, add a small quanty of defoamer liquid to the recovery tank. More foam is generated when a
oor is lightly soiled. Use less detergent if this is the case
TROUBLE SHOOTING GUIDE
15

23
22
17
18
17
16
15
24 25 26
19
20
15
21
27
8
7
28
44
43
42
41
40
20
38
39
15
38
37
36
35
34
33
32
29
31
30
13
11
14
13
12
11
10
6
9
13
29
27
13
8
7
6
5
2
4
3
2
1
16
Z210 TRACTION AUTO SCRUBBER - BRUSH DECK ASSEMBLY

17
ITEM PART # DESCRIPTION QTY NOTE ITEM PART # DESCRIPTION QTY NOTE
1964103 Hex Bolt-Full M8x45 Zinc 2 ZINC 23 843324 Fitting 1
2980684 M8 Washers Flat L Zinc 2 ZINC 24 849404 Solenoid Valve 1
3841102 Wheel Bushing 2 BRASS 25 843323 Fitting Barbed 1
4849701 Wheel 2 26 842003 Hose Clamp 1SS
5964335 Hex Bolt M5X16 Zinc 9 ZINC 27 849003 Tubing 1
6980685 M5 Washer Flat Zinc 18 ZINC 28 964239 Hex Bolt M8x25 Zinc 4 ZINC
7980679 M8 Washer Flat Zinc 10 ZINC 29 964225 Hex Bolt M5X20 Zinc 2 ZINC
8924033 NyLoc Hex Nut M8 Zinc 6 ZINC 30 888336 Spring 2 ZINC
9842303 Base Cover 1EPOXY PAINT 31 887350 Ring 2 ZINC
10 924032 M5 Nyloc Hex Nut Zinc 9 ZINC 32 881151 Bushing 1 ZINC
11 842006 Clamp - Band 2 SS 33 924055 Lock Nut M10 1 ZINC
12 843610 Splash Guard - Blue 1 34 980064 M10 Washer Flat Zinc 1 ZINC
13 920658 Nut Flange M5 Zinc 6 ZINC 35 888342 Spring 1 ZINC
14 848402 Stud Screw 1 SS 36 880550 Adjuster - Bolt 1 ZINC
15 980665 M6 Flat Washer Zinc 6 ZINC 37 881150 Bushing 1
16 920653 M6 Nyloc Hex Nut Zinc 2 ZINC 38 964116 Hex Bolt M6x20 Zinc 3 ZINC
17 842004 Hose Clamp 4SS 39 840302 Brush Base Idler Arm Adjuster 1 EPOXY PAINT
18 849010 Tubing 1 40 849801 Thrust Washer 1 ZINC
19 964423 Hex Bolt M6X12 Zinc 2 ZINC 41 846904 Pulley 1 ZINC
20 980672 M6 Lock Washer Zinc 3 ZINC 42 845003 Key - Motor Shaft 1
21 845604 Solenoid Valve Mount 1 ZINC 43 845201 Brush Motor 1
22 843306 Fitting Barbed 2 44 840904 Carbon Brush 2

18
1
2
3
4
5
6
7
6
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
8
30
29
24 35
19
20
36
20
31
38
39
40
41
23
24
25
26
27
28 31
32
23
24
33
34
Z210 TRACTION AUTO SCRUBBER - BRUSH BASE ASSEMBLY

19
ITEM PART # DESCRIPTION QTY NOTE ITEM PART # DESCRIPTION QTY NOTE
1964003 Screw Flat Head Torx Drive M8x45 1 ZINC 23 964116 Hex Bolt M6x20 Zinc 4 ZINC
2980668 Washer - Wide M16x56x3Thk 1 24 980665 M6 Flat Washer Zinc 8 ZINC
3840303 Idler Arm 1 EPOXY PAINT 25 964084 Hex Bolt-Full M8X50 Zinc 1 ZINC
4844301 Bearing Hub 1 ZINC 26 964246 Hex Bolt M8x35 Zinc 1 ZINC
5841101 Bushing 1 27 980679 M8 Washer Flat Zinc 2 ZINC
6980684 M8 Washers Flat L Zinc 2 ZINC 28 845102 Brush Base Dual Lift Link 1 EPOXY PAINT
7980666 Spring Washer M8x18 2 29 920653 M6 Nyloc Hex Nut Zinc 4 ZINC
8924033 NyLoc Hex Nut M8 Zinc 3 ZINC 30 846401 Left Spring Retaining Plate 1 ZINC
9964001 Hex Bolt M8x12 2 ZINC 31 964111 Hex Bolt M10X25 Zinc 1 ZINC
10 980058 Washer Star Lock M8 2 ZINC 32 924068 Hex Nut M10 Thin Zinc 1 ZINC
11 846402 Right Spring Retaining Plate 1 ZINC 33 845103 Brush Base Lift Link 1 EPOXY PAINT
12 848301 Brush Retaining Spring 2 ZINC 34 846602 Plate 1 ZINC
13 846903 Brush Clutch Pulley 1 35 848204 Spacer 2 ZINC
14 846001 Pipe 236 848201 Bearing Spacer 2 ZINC
15 920647 Hex Nut M20 Zinc 2 ZINC 37 847701 Brush Pulley Shaft 2 BLACK OXIDE
16 980667 Washer M20x39 Flat Zinc 1 ZINC 38 846902 Brush Clutch Pulley 1
17 841301 Brush Base Deck 1 EPOXY PAINT 39 881352 210 Brush Drive Belt 1
18 844302 Bearing Hub 1 ZINC 40 885950 Pad Driver 10 Inch 2
19 847301 Reataining Ring 50 mm 4 885955 Pads, 10 Inch Black - Case of 5
20 902033 Bearing 6 885956 Pads, 10 Inch Green - Case of 5
21 846905 Idler Pulley 2 ZINC 885957 Pads, 10 Inch Red - Case of 5
22 980503 M8 Washer XL Flat Zinc 2 ZINC 885958 Pads, 10 Inch White - Case of 5
41

20
1
2
2
2
3
4
5
6
6
7
7
7
8
8
8
14
9
9
10
11
11
12
12
12
13
13
14
14
14
15
16
17
18
19
20
21
22
23
24
25 26
27
28
41
13
30
31
32 33
34
35
36
37
20
38
39
40
42
Z210 TRACTION AUTO SCRUBBER - MAIN FRAME ASSEMBLY
