Channel Vision C-0332 User manual

Channel Vision Technology will repair or replace any defect in material or
workmanship which occurs during normal use of this product with new or
rebuilt parts, free of charge in the USA, for one year from the date of
original purchase. This is a no hassle warranty with no mail in warranty
card needed. This warranty does not cover damages in shipment, failures
caused by other products not supplied by Channel Vision Technology, or
failures due to accident, misuse, abuse, or alteration of the equipment. This
warranty is extended only to the original purchaser, and a purchase receipt,
invoice, or other proof of original purchase date will be required before
warranty repairs are provided.
Mail in service can be obtained during the warranty period by calling (800)
840-0288 toll free. A Return Authorization number must be obtained in
advance and can be marked on the outside of the shipping carton.
This warranty gives you specific legal rights and you may have other rights
(which vary from state to state). If a problem with this product develops
during or after the warranty period, please contact Channel Vision
Technology, your dealer or any factory-authorized service center.
Channel Vision products are not intended for use in medical, lifesaving, life
sustaining or critical environment applications. Channel Vision customers
using or selling Channel Vision products for use in such applications do so
at their own risk and agree to fully indemnify Channel Vision for any
damages resulting from such improper use or sale.
500-105 rev B
www.chann e l v i s i o n . c o m
234 Fischer Avenue, Costa Mesa, California 92626 USA
[phone] [phone] [phone] fax
email: [email protected]
1
C-0331
Central
VISION
CHANNEL
TM
OUT OUT OUT
OUT
OUT
IN OUT
OUT OUT
IN 2
1
12VDC
OUTOUT OUT
OUT
IN
OUT
OUT
OUT
OUT
Model C-0332
C VHA N N E L ISIO NTM
Central
C-0332
16 Port Amplified Splitter
1
1

2
The C-0332 is an amplified splitter system that allows an antenna
or CATV feed to be distributed to 16 different locations. The
system consists of one CVT-1/2PIA dual output amplifier and two
HS-8V 8-way splitters. These components are mounted inside a
metal bracket that enables the system to be easily installed in a
Channel Vision structured wire enclosure.
Features:
!
!
!
Allows 5-42MHz return path for interactive digital cable boxes
Unity gain output
DC and IR passing splitters
C-0331
Central
VISION
CHANNEL
TM
OUT OUT OUT
OUT
OUT
IN OUT
OUT OUT
IN 2
1
12VDC
OUTOUT OUT
OUT
IN
OUT
OUT
OUT
OUT
Model C-0332
C VHANN E L ISI O NTM
Central
Signal Input
(CATV/ Antenna)
Power supply input
Amplifier outputs
(Connect to splitter inputs)
Splitter inputs (Connect to amplifier outputs)
7
Diagonal lines on modulator channels only: Try moving the
modulator to another channel number. You may need to add a
low pass to remove cable company noise.
Diagonal lines on many channels (vanish when you remove
the CATV feed.) The RF amplifier is being overloaded by over-
strong cable signals. Add an attenuator to reduce the signal
strength.
Cable channels have interference when modulator is
connected: Reduce the modulator signal by using an
attenuator. Either a fixed or variable attenuator may be used.
Variable attenuator Fixed attenuator
0dB 20dB
Specifications:
Gain
Cable In to Out:
Reverse Gain
Out to Cable In:
Isolation Out / Cable In:
Flatness:
Noise Figure:
IR Passing:
RFI rejection:
Power supply:
(typical @25º C)
Unity
54MHz - 1000MHz
-14dB
5 - 42MHz
-80dB 450MHz - 1000MHz
± 1dB (all outputs terminated)
7dB (maximum)
All ports
-130dB in
12VDC @ 300mA (supplied)
(m imum)
Specifications subject to change without notice.
Troubleshooting

6
Channel Vision modulators allow you to create your own TV
channel for video devices so they can be easily distributed
through your home. Common uses include CCTV cameras,
DVD players, and satellite receivers.
The IR-4000 is the heart of the coax IR repeating system. It
allows power to be inserted on the coax and it provides an IR
emitter port to output the IR control signals. An IR engine is
built into the E2200IR, E3200IR, and E4200IR modulators.
The IR-4101 is an IR over coax receiver to be connected into
the system on each output where IR control is needed.
IR receivers detect the IR signal from your remote control and
convert them into pulses that can travel over a wire, in this
case coax cable.
For more information please go to www.channelvision.com.
Other Compatible Products
Modulators:
CVT1ub/uhf-II, CVT2ub/uhf-II, CVT3ub/uhf-II,
E1200, E2200IR, E3200IR, and E4200IR
IR coax engine:
IR-4000
IR over coax adaptor:
IR-4101
C VHA NN EL I SI ONT M
Input
IR-4000
IR coax engine
To IR coax
adaptor
IR emitter Pwr
3
Frequently Asked Questions
Why do I need a 5-42MHz return path?
What are DC passing splitters?
What is IR repeating?
How should I connect my cable modem?
Unlike conventional cable TV systems, new digital cable
systems require the cable box to have two-way
communication with the cable company. This means that
signals need to travel from the cable company to your
home and then from your home back to the cable
company. The frequency range between 5MHz and
42MHz has been reserved for the return communication
signals. Traditional RF amplifiers that were designed
before the advent of digital cable did not accommodate
this return communication and would not allow digital
cable boxes to function properly.
Some products utilize your existing coax cable to distribute
IR control signals throughout your home. This technology
requires a Direct Current (DC) voltage to be transmitted
over the coax wire. Conventional RF splitters will cause
this voltage to short out and disable the IR repeating
system. Most Channel Vision Splitters are DC passing and
will support this kind of IR repeating technology.
IR repeating systems allow you to use a handheld infra-
red remote to control devices that are located in another
room of your home. Channel Vision offers a variety of IR
repeating solutions, please visit www.channelvision.com
for a complete list.
Although the 5-42MHz return path provided by the
amplifier will allow the modem to communicate with the
cable company network, connecting your modem directly
to the amplified splitter is not recommended. Doing so
can allow the modem signal to be corrupted by noise
generated by TV sets that are connected to the other
outputs. See the diagram on the following page for the
recommended setup.

4
C-0331
Central
CHANNEL
OUT OUT OUT
OUT
OUT
IN OUT
OUT OUT
IN
12VDC
Model C-0332
C VHA N N E L I S I ON TM
Cable modem
Cable modems should
be fed ahead of the
CVT amplified splitter.
From Cable
company
Using a Cable modem
Useful Accessories:
Basic Setup
CATV or Antenna
For best results,
terminate unused
outputs.
Connect up to 16 TV sets
DC Block (model 3109)
These are often needed when installing
an IR repeating system (see diagram)
75 Ohm terminator (model 2101)
These are needed to terminate unused
TV outputs (see diagram)
HS-2
C-0332
5
C-0331
Central
VISION
HANNEL
TM
2
1
OUTOUT OUT
OUT
IN
OUT
OUT
OUT
OUT
Model C-0332
C VHA N N E L I S I ON TM
Central
C-0331
Central
VISION
CHANNEL
TM
OUT OUT OUT
OUT
OUT
IN OUT
OUT OUT
IN 2
1
12VDC
OUTOUT OUT
OUT
IN
OUT
OUT
OUT
OUT
Model C-0332
C V
HANN E L ISIO NTM
Central
Using a modulator and IR repeating system
Basic Setup
IR-3001 repeats IR pulses
IR-over-coax
receivers detect
remote control
IR pulses
IR systems need to have all unused outputs
connected to DC blocked terminators.
Up to 4 IR receivers can be powered by
one IR-4000.
IR-4000
IR-4101
IR-4101
HS-2
Filter
CATV or
Antenna
CVT2ub/uhf-II
modulator
C-0332
