Channel Vision 6532 Manual

6532
1.3 Megapixel Mini Dome IP Camera w/POE
3
1

Table Of Contents
2

The 6532 is a 1.3 Megapixel Mini Dome IP Camera w/POE
Built-in web server allows a user to view high quality, real-time video with Internet Explorer browser.
Multi-Stream H.264, MJPEG and MPEG
Live video can be recorded to an NVR and played back remotely, as well as viewed from many mobile
phones and other devices.
Designed for large commercial projects with 100’s of cameras or a single family house requiring a camera at
the front door.
Android, iPhone & iPad app available from the respective store
4.2mm fixed focal length lens
Alarm trigger input and N.O. or N.C. switch on relay output
36 Camera CMS (Central Management software, included) will allow you to see all of your cameras
anywhere in the world in multiple locations at the same time
High definition 720P at 30FPS
Digital Wide Dynamic Range
Power Over Ethernet or 12vDC power supply
Vandal Proof dome
Micro SD card recording slot inside camera
6532 Features:
Channel Vision’s 6532 IP mini dome camera offers superior image quality with a 1.3 megapixel CMOS
sensor and has the ability to capture images up to 1280 x 800 pixels.
With H.264 compression, less bandwidth and storage space are used, while delivering full resolution at max
frame rate with faster speeds over the internet. Monitoring can be done anywhere an internet connection is
available even from a Smart-phone. The 6532 also features event triggered motion recording.
Model 6532
6532
•
•
•
•
•
•
•
•
•
•
•
•
•
3

Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions for future reference.
3. Heed all warnings.
4. Follow all instructions.
5. Clean only with a dry cloth.
6. Install in accordance with these instructions.
7 Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
that produce heat.
8. Do not defeat the safety purpose of the polarized-type plug. A polarized plug has two blades with
one wider than the other. The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete
outlet.
9. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point of exit from the apparatus.
10. Only use attachments/accessories specified by Channel Vision.
11. Unplug this apparatus during lightning storms or when unused for long periods of time.
12. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the inside of the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
13. The lightning flash with an arrowhead symbol within an equilateral triangle is intended to alert the
user to presence of uninsulated dangerous voltage within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
14. The exclamation point within an equilateral triangle is intended to alert the user to the presence
of important operating and maintenance accompanying the appliance.
15. Inside of apparatus shall not be exposed to dripping or splashing and objects filled with liquids.
CAUTION: To reduce the risk of electric shock,
do not remove the cover (or back). There are no
user-serviceable parts inside, refer servicing to
qualified service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISK OF ELECTRIC SHOCK
DO NOT OPEN !
4

The breakout cable on Channel Vision’s IP Cameras are used for motion detection, event triggering,
alarm notifications etc.
The provided interface connections are explained below.
1. Digital Input (GND+DI):
An alarm input for connecting devices that can toggle between an open and closed circuit, for example
PIRs, door/window contacts, broken glass detectors, etc. When a signal is received, the state changes
and the input becomes active.
2. Relay output (GND+DO)
A selectable output for a relay switch, for example LEDs, Sirens, etc.
Normally Open and Normally Closed can be selected via the Internet Explorer ActiveX control under
the “I/O Setting” section on the left.
3. Reset to factory default
To restore your IP camera to Channel Vision default settings, unplug the power supply from the
camera. Then, plug in power cable and press the “reset” button on the camera for 30 seconds. Once
30 seconds have passed, remove the electric wire and plug in the Ethernet cable. Use IP installer to
find the camera IP. (Default is http://192.168.1.200) Default username and password is “admin”
Cable Pin Out
PoE (Power Over Ethernet)
Pow Iuter np
Pow Iuter np
GNDGND
GNDGND
D.O.D.O.
D.ID.I
5
Power over Ethernet (PoE) is a technology that integrates power into a standard LAN infrastructure. It
enables power to be provided to the network device, such as an IP phone or a network camera, using
the same cable that is used for the network connection.
The PoE switch eliminates the need for power outlets at the camera locations and enables an easier
application of uninterruptible power supplies (UPS) to ensure 24 hours a day, 7 days a week operation.
The recommended requirement for a PoE switch is 802.3at, 30.0W.
The minimum requirement for a PoE switch is 802.3af 15W.
If using a PoE switch that does not meet these specifications, full functionality may not be supported.
WARNING: DO NOT CUT THE BREAKOUT CABLE.
CUTTING THE CABLE WILL VOID THE WARRANTY ON THE DEVICE.
To access the micro
SD card slot and
reset button, remove
the camera cover.
Eth re Co n re n t n ecto
(T 6BS n a d5 8 ta d r )
Eth re Co n re n t n ecto
(T 6BS n a d5 8 ta d r )

Camera Assembly
6
1. Use without conversion ring (left)
a. Use the three included screws to
secure the base of the camera to
the wall or ceiling. Screw on the
camera cover, as tight as possible.
2. Use with conversion ring (right)
a. Use three screws to lock conversion
ring onto the ceiling or wall.
b. Use the second set of three screws to
combine the base of the camera with
the conversion ring. The cable can
pass through the hole on the side of
the conversion ring.
c. Screw on the camera cover, as tightly
as possible.
Surface mount: (With conversion ring)
Typically used on a brick wall or in an
application that requires the breakout
cable to be fed out of the side of the
camera.
Flush mount: (Without conversion ring)
Typically used on a ceiling or where the
cable can be hidden under the camera.

Your IP Camera comes set to DHCP by default. This means that, just like your laptop computer or desktop PC, an IP
address is automatically assigned to the IP camera by your router. This, combined with UPnP (Universal Plug and
Play), will make the IP setup of the IP camera a quick and easy task to accomplish.
*For the best security, Channel Vision recommends you use a static IP setting and standard port forwarding.
1. Open IP installer. This is located on your software disk.
2. An IP address should already be assigned
In the example below, the router has assigned 192.168.1.199 to the IP Camera
3. Double click on the name of the IP Camera. This will open the IP camera in your default browser
Option One: Assigning an IP Address (DHCP)
7

Connecting To The IP Camera (DHCP)
5. The first time you connect to the camera via Internet Explorer, it will ask you to install the ActiveX control.
Internet Explorer 6, 7, 8, or 9 must be used to run this ActiveX control.
4. You will be prompted for a username and password.
The default username is ‘admin’
The default password is ‘admin’
Installing The ActiveX Control
8

1. Use the software, “IP Installer” to assign the IP address to your IP Camera.
You can find "IP Installer" in the supplied CD.
2. Execute IP Installer, located on your disk under the folder “Software”
3. If Windows prompts you to unblock IP Installer, you must select “unblock”
There are 3 options of IP configuration:
A. Fixed IP (Public IP or Virtual IP)
B. DHCP (Dynamic IP)
C. Dial-up/DSL (PPPoE)
"IP Installer" will search all IP Cameras connected to your LAN network.The user can
click “Search Device” to search again.
Double click the camera name to go directly to the camera
Option Two: Assigning an IP Address (Static)
9

Assigning an IP Address (Static) /cont
4. Click the start icon on your computer.
5. Type the word “run” and select enter on your keyboard.
6. Type in ‘cmd’ and press enter on your keyboard, or press ok.
7. Type in ‘ipconfig /all’ into the DOS prompt that appears. Press “Enter”.
8. Write down your computer’s IP address.
Do not use the same IP address as the computer in the IP Camera.
In the example below, the computer’s IP address is 192.168.1.74.
The IP address of the IP camera must be different than the IP address in the computer.
Each network-able device in your network has an IP address assigned.
The IP chosen for your IP Camera is not the same address as any other device on your network.
10

9. Copy/write down the following information from the DOS prompt.
A. Default Gateway (Example 192.168.1.1)
B. DNS Server (if 2 servers, use the first one, for example 192.168.1.9)
C. Subnet Mask (Example 255.255.255.0)
11
Assigning an IP Address (Static) /cont

To change numbers, select the appropriate area on IP installer
with your mouse, and type in the info.
7. Enter the information you wrote down into the IP camera network page
A. Default Gateway (Enter this number under “Gateway”)
B. DNS Server (Enter this number under “DNS 1”)
C. Subnet Mask (Enter this number under “Netmask”)
8. Giving the IP Camera a unique IP address.
Assign an IP address to the IP Camera by using the first 3 sets of numbers of your default gateway.
An IP address has 4 sets of numbers, each followed by a period.
For example, xxx.xxx.xxx.xxx
My default gateway is 192.168.1.1
For example, my IP Camera’s address will start with 192.168.1.xxx
9. Make sure you use a number different that your computer’s IP address.
(Generally between 2-250) This number needs to be out of the range of DHCP. DHCP is assigned with
your router, and can be checked by logging into the router.
My computer’s IP address is 192.168.1.74. 192.168.1.208 is used in the example below.
You must choose a number that is different from your computer’s IP.
If your IT technician has designated a static internal IP for your IP Camera, use that address.
10. To assign the port, choose a port between 5400-9000, and type it into “Port 1” If a specific port has
*Disclaimer: This is an example based on a general network setup.
All networks do not match these settings exactly, as all networks are different
Name
Fourth number (different than computer)
Select “Static”
Subnet Mask (same as computer)
Default Gateway (same as computer)
DNS Server 1 (same as computer)
DNS Server 2 (same as computer)
Port (A port between 9000-9999 is
recommended, but any network
port can be used)
First 3 sets of numbers
are same as the computer’s IP address
12
Assigning an IP Address (Static) /cont

Connecting To The IP Camera (Static)
1. The first time you connect to the camera via Internet Explorer, it will ask you to install the
ActiveX control. Internet Explorer 6, 7, 8, or 9 must be used to run this ActiveX control.
1. Open Internet Explorer. Type the IP address of the IP camera into the browser link window.
Also, make sure to type the port at the end of the link.
For example, I will type in http://192.168.1.199:9000
2. You will be prompted for a username and password.
The default username is ‘admin’
The default password is ‘admin’
Installing The ActiveX Control
13

When popup the following dialogue box, click “Yes”.
If the installation of the ActiveX control fails, for example the browser page says “done” but you do not see
your camera, please check the security settings for your IE browser. Follow the instructions below.
Configuring Internet Explorer
12
34
5
14

Live Viewing
Snapshot
Format: Year/Month/Day/Hour/Minute/Second/ Image Size/Frames Per Second
Controls the physical size of the streaming video on the browser screen
Controls the selection of the video
stream that is being viewed
Activates relay output
Shows the number of users
connected at any given time
Settings
Once you connect to your camera, you will see the following screen.
Below the icons and their functionality are defined.
15

1. This icon opens the settings menu
2. This icon takes a snapshot
3. This icon shows system time, video resolution, and video refresh rate
4. The bottom bar has an icon that allows you to select which stream
you want to view. Stream 1 is usually the larger, better quality stream.
Stream 2 is the smaller stream, generally used for mobile viewing
5. The bottom bar has an icon shows how many users are connected
to the IP camera.
6. This icon will control/activate the relay output on the camera
wire pigtail. A relay can activate lights, alarms, or anything that uses a contact
closure.
7. If you double click the video feed, it will make the video full screen.
To change video back to normal mode, press ‘Escape’ on your keyboard, or double
click anywhere in the video feed a second time.
8. If you right click on the video, you have access to several different functions.
A. Snapshot: Takes a snapshot
B. Record Start : Records video to your computer
C. Full Screen: Click to enter full-screen mode
D. Zoom: Digital Zoom. This is explained below
E. Frame BuffmSec: This changes the frame buffer rate
(Increasing the buffer rate will provide a smoother video stream)
Digital zoom
1. Select “Enable digital zoom”
2. Select the area of the screen you wish to zoom (up to 400%)
3. Select the zoom level
Live Viewing/cont.
1
3
2
A.
B.
C.
D.
E.
16

Configuration
1. Select this icon to enter the settings menu
2. Select this icon to go back to your live video feed
1
2
17

System Information:
Use the number scheme below for a description of each item:
1. MAC Address: (Media Access Control) address; This is a unique identifier assigned to IP devices for
communication with the network. Your IP camera is pre-set with a MAC address
2. Server name: Select to edit the camera name
3. LED Indicator: Select On/Off to toggle the blinking LED light in the camera
4. Language: Select a language to change the language of the ActiveX interface
5. Status Bar: Select On/Off to toggle the information bar (below the main video stream)
6. Time Stamp: Select Enabled/Disabled to turn the video timestamp on or off
7. Text: Select Enabled/Disabled to specify the name that can be displayed on the top left area of the screen
8. Server Time: This shows the current time on your IP camera
9. Date Format: Select to choose your desired date format
10. Time Zone: This shows your current time zone
11. NTP: The Network Time Protocol is a protocol for synchronizing the clocks of computer systems
12. NTP Server: If you have a NTP server, input it here
13. Update: If using an NTP server, select this drop down menu to choose the update interval
14. Time Shift: Time shift is used to compensate for the time it takes to server to process the sync request
for your time. This is usually not needed.
15. Synchronize with PC’s time: Select this to match your computer’s clock to your IP camera
16. Apply: Select this button to save your changes
System Configuration
1
3
2
4
8
10
12
9
11
13
14
15
16
5
6
7
18

User managment:
This IP camera supports 3 different types of users.
1. Administrator
2. General
3. Anonymous
Click “Yes” to allow anonymous user access
Click “Add/Set” to add a user
Click “Edit” to modify a user.
When you click edit, the following window will pop up:
(Shown below.)
Add the username and password, and click “OK” to save your new user.
User Management
19

System Update: This menu is used to perform the following functions:
1. Firmware Update: Channel Vision will update the firmware from time to time.
By registering your IP camera, you have access to all firmware improvements
and extended warranty options.
How? See the product page on www.channelvision.com
To load new firmware, press “Browse” and select the firmware.bin file.
2. Restart System: Select to restart system.
You can reset the IP camera to factory default settings if desired
If you backup your settings, you can load your backup file where it says “New Setting File”
3. Settings backup:
You can backup your settings by right clicking your
mouse on “Setting Download” and selecting
“Save Target As”. You may also load previously saved
settings files this way. When loading previously saved files,
click “Browse” and then “Upgrade”
System Update
20
