Channel Vision A0503 User manual

Channel Vision Technology will repair or replace any defect in
material or workmanship which occurs during normal use of this
product with new or rebuilt parts, free of charge in the USA, for two
years from the date of original purchase. This is a no hassle warranty
with no mail in warranty card needed. This warranty does not cover
damages in shipment, failures caused by other products not supplied
by Channel Vision Technology, or failures due to accident, misuse,
abuse, or alteration of the equipment. This warranty is extended only
to the original purchaser, and a purchase receipt, invoice, or other
proof of original purchase date will be required before warranty
repairs are provided.
Mail in service can be obtained during the warranty period by calling
[phone] toll free. A Return Authorization number must be
obtained in advance and can be marked on the outside of the shipping
carton.
This warranty gives you specific legal rights and you may have other
rights (which vary from state to state). If a problem with this product
develops during or after the warranty period, please contact Channel
Vision Technology, your dealer or any factory-authorized service
center.
500-157 revA
A0503
REMOTE CONTROL
CVHANNEL ISION
ZONE
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
4
5
6
ABCD
PAGE
ANS/END
MON
DND
MODEL
A0503

2
The is the installer’s master remote for Channel Vision’s whole-
house intercom system. It is designed to control every possible function
of the intercom. Installers can use this remote to teach a learning remote
control the IR codes needed for their specific system.
A0503
Features:
!
!
!
Easily controls your whole-house intercom system
No programming necessary
Compatible with: P-0930 and ST-2000
Page
Activates paging function
of the intercom station
Ans/End
Answers or Ends an
incoming call on the
intercom station
Mon
Activates monitor
function of the
intercom station
DND
Activates DND
function of the
intercom station
Station Call Buttons
The intercom system can have up to 4 hubs with 6 stations each,
providing a total of 24 possible stations (or Zones). The 6 station
call buttons on the ST-2000 are always Zone A. When the
ST-2100 station expanders are used, Zone B, C,&DontheA0502
remote will control their 6 call buttons.
CVHANNEL ISION
ZONE
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
4
5
6
ABCD
PAGE
ANS/END
MON
DND
MODEL
A0503
3
Using the A0503 remote control...
The A0503 is designed to allow you to control your intercom system without
having to touch the buttons on the intercom station. Simply point the A0503
remote control at the IR sensor located at the bottom of the ST-2000 and press
the desired button on the remote control.
ST-2000 with three ST-2100 expanders attached
CVHANNEL ISION
ZONE
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
4
5
6
ABCD
PAGE
ANS/END
MON
DND
MODEL
A0503
1
2
3
4
5
6
A
1
2
3
4
5
6
1
2
3
4
5
6
BCD
ST-2000
Monitor
DND Answer/End
Page
ST-2000
Monitor
DND Answer/End
Page
Room 1
Room 2
Room 3
Room 4
Room 5
Room 6
Room 7
Room 8
Room 9
Room 10
Room 11
Room 12
Room 13
Room 14
Room 15
Room 16
Room 17
Room 18
Room 19
Room 20
Room 21
Room 22
Room 23
Room 24
MON PAGE
ANS/END
MODEL
A0503
DND
BCD
