4 • 463232103
Key Qty Description Part #
A 1 Lid Plate(Double Wall) P00119456A
B 1 Heat Indicator P00601181A
C 1 Round Lid Handle P00203014B
D 2 Lid Handle Bracket P00303042E
E 2 Heat Insulating Spacer P06801002A
F 1 Logo Plate P00416019C
G 1 Warming Rack P01505007E
H 2 Cooking Grid P01615003E
I 3 Flame Tamer P01705005E
J 1 Tank holder screw P06222019B
K 3 Burner P02001031E
L 1 Burner Support Bracket P02203055A
M 3 Gas Collector Box with Electrode P02609002B
N 1 Electric Wire set P02615020A
O 1 Electric Ignitor (4 port) P02502024C
P 1 Bowl Side Panel, Left P00720033C
Q 1 Bowl Side Panel, Right P00721033C
R 1 Bowl Front Panel P00724046C
S 1 Bowl Rear Panel P00725044A
T 1 Rear Wind Shield P00728051A
U 1 Grease Draining Tray P02705364A
V 1 Grease Receptacle P02701041A
W 1 Gas Manifold P05003062A
X 3 Gas Valve for Main Burner P03222024B
Y 1 Heat Shield for Control Panel P03007032B
Z 1 Control Panel P02907091A
AA 3 Control Knob P03411111G
BB 3 Control Knob Seat P03413011A
CC 3 Spring P05504017E
DD 1 Side Shelf, Left P01106014B
EE 1 Side Shelf, Right P01107018B
FF 2 Bracket for Side Shelf LF, RR P01211005A
GG 2 Bracket for Side Shelf LR, RF P01213005A
HH 3 Tool Hooks P05529128A
I I 2 Front Panel, Side Shelf, Left P07503001A
JJ 1 Cart Bottom Shelf P01008005C
KK 2 Cart Side Panel P07601001A
LL 1 Cart Rear Panel P07701002A
MM 1 Door Bracket P03302001C
NN 2 Door Front Plate P04301002A
OO 2 Door Handle P00214006A
PP 2 Bowl Support Bracket P01303002B
QQ 1 Left Side Cart Leg, Front P00917005B
RR 1 Left Side Cart Leg, Rear P00918005B
SS 1 Right Side Cart Leg, Front P00912005B
T T 1 Right Side Cart Leg, Rear P00920005B
UU 4 Caster Seat P04507003A
VV 4 "3" Caster P05106003D
WW 1 Regulator with Hose (27") P03601004A
XX 1 AA Battery P05301001A
YY 1 Front Panel, Side Shelf, Right P07502002A
ZZ 1 Match Lighting Stick with Chain P05507031E
1 Caster Wrench P05515002C
1 Grate Lifter P05515014E
1 Hardware Pack P06004049A
1 Owner's Manual P80111072A
Parts List 463232103
• Necessarytoolsforassemblyofyourgrillinclude:
Phillips
®screwdriver,pliersandadjustablewrench.
Before Beginning Assembly
