Char-Broil Trentino 04201101 User manual

42803987 (11-21-03)
THIS UNIT IS HEAVY. DO NOT assemble without helper.
Some parts may contain sharp edges - especially as noted in
manual. Wear protective gloves if necessary.
Read and follow all safety statements, warning, assembly
instructions and use & care directions before attempting to
assemble and cook.
Tools needed for
assembly:
Phillips screwdriver
Adjustable wrench
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill
you. It gives off carbon monoxide,
which has no odor. NEVER burn
charcoal inside homes, vehicles
or tents.
0420110101309400
BBQ and Grill

STOP!
Missing a part?
No need to go back to the store!
The store where you made your purchase
does not stock parts for this item. If you
need parts, whether they are missing or
damaged, call the Customer Service toll
free Help Line.
Call us and we will gladly ship
the part you need
FREE OF CHARGE.
Call Our Help Line
ITEM DESCRIPTION
55700473 LID KIT
55700474 LOWER BODY KIT
55700476 HANDLE KIT
55700477 SHELF SLAT KIT
55700478 VENT KIT
55700479 ASH DOOR KIT
55700480 WHEEL KIT
55700481 LOGO PLATE KIT
55700482 LEG KIT
55700483 BOTTOM SHELF KIT
40011231 CARTON
29000463 FIRE GRATE HANGER
29000461 FIRE GRATE
29000460 ASH DRAWER
49400006 COOKING GRATE (4)
40003010 TEMPERATURE GAUGE
29000453 LID STOP
45601070 LOCKING CASTER
45601080 NON-LOCKING CASTER
49400018 GRATE LIFTING TOOL
42000057 HARDWARE BAG
29100322 LEG END CAP
42803987 ASSEMBLY INSTRUCTIONS
PARTS LIST

With the aid of a helper, turn the
bottom shelf so that the flange is up,
and attach to inside holes near ends of
legs using four and
.
1/4-20x2” screws
1/4-20 flange nuts Do not fully
tighten screws until Step 5 is
complete.
2
1First, pick a suitable location to work. Open the carton and slit the corners. This will give you a protective work surface upon which
to start the assembly. During assembly, refer to page 10 for hardware identification.
Stand bottom assembly on end. Attach legs to one end using two and per leg.
Turn assembly upside-down to attach remaining two legs on opposite end.
1/4-20x2” screws 1/4-20 flange nuts Do not fully
tighten screws until Step 5 is complete.
Bottom assembly
Leg
Bottom shelf

3With the grill positioned as shown below, push the leg inserts into end of legs to your left. (Note: When grill stands upright, these
will be the right legs.) Slide the locking caster (with tab) into insert in front leg. Slide remaining caster into insert in rear leg.
4
Front leg
Insert into wheel, then slide onto bolt. Insert bolt into hole in end of rear leg and secure with .
Repeat this procedure to attach wheel to front leg.
axle bolt spacer large hitch pin
Rear leg
Locking caster
with tab
Leg
Insert
Axle boltWheelSpacerLarge hitch pin
Front leg
Rear leg

6
5Attach four shelf slats to each set of legs using two and per slat. Start at the
holes closest to the grill bottom and work outward. Push into ends of legs.
1/4-20x2-1/2” carriage bolts 1/4-20 flange nuts
end caps NOW FULLY TIGHTEN ALL SCREWS
FROM PREVIOUS STEPS.
End cap
Insert one end of lid stop wire into hole on side of grill bottom. With the aid of a helper, position grill lid so that opposite end of lid
stop wire can be inserted into hole in side of grill lid. Repeat procedure on left side of grill. Helper should continue to hold lid in
position until secured to grill bottom in next step.
Shelf slat
First
Second
Third
Fourth
Grill lid
Lid
stop
wire
Right side of grill bottom Right side of grill bottom

7
8
Handle
Attach spacers and handle to grill lid using two , and .1/4-20x3¼” screws 1/4” insulated washers 1/4-20 flange nuts
While your helper holds grill lid in position, secure lid to
hinge on grill bottom using eight and
.
#10-24x1/2” screws
#10-24 flange nuts
Spacer
Insulated Washer

9
10
Logo plate
Insert vent knob into side of grill lid from the outside. Inside the grill lid, slide a vent plate onto the knob stud followed by a spring
and a . Tighten just enough to allow vent to slide freely from side to side. Repeat on left side of grill lid.#10-24 hex nut
Vent plate
Attach the logo plate by inserting the two pins into the small holes on the front of the grill lid. F ress the
onto the pins until they are snug against the lid.logo plate clips
rom inside the lid, p
Spring
Vent knob
Logo plate clips

Install temperature gauge by placing the stem through the large hole in front of grill lid. Attach the nut provided until snug
against lid.
12
11
Temperature
gauge
Attach ash door frame to front of grill bottom using four and .#10-24x1/2” flat-head screws #10-24 flange nuts
Ash door
frame

14
13 Attach ask door to frame using two and .hinge pins small hitch pins
Ash door
Small hitch pin
Hinge Pin
Slide ash drawer into front of grill bottom.
Ash drawer

16
15 Attach two fire grate hangers to fire grate (hooks point inward toward grate). Lower into grill bottom and hang from tabs on
each side.
Fire grate
hanger
Place cooking grates into grill bottom. Use the grate lifting tool provided to lift hot cooking grates.
Cooking grates
Fire grate
