Charcoal Kings SH253B User manual

Bluetooth BBQ Probe Quick Start Guide
SH253B
Thank you for purchasing the world's first inventi-
on of Bluetooth Barbecue Probe. It enables Blue-
tooth wireless connection between the probe and
the smart phone. You only need to download the
APP “Grill ProbeE” to monitor if the food is cooked
well. Once the grilled food reaches the preset
temperature, it will automatically alarm to make
your grilling process much easier.
1）Download APP
Scan the QR Code or download the Grill ProbeE
App available on App Store (for IOS) or Google
Play Store (for Android)
2）Charges probe
Keep the probe in the charger before use or the
battery is low.
The external power supply is connected to the
USB.Red Light on indicates charging in progress.
Each charging requires about
10 minutes.
Insert the probe into the food to be grilled.
Note: The insertion depth must beyond the safe
insertion line as shown below.
4APP operation
Using the probe
3
1Appearance
Bluetooth BBQ Probe
Charger
Indicator Light USB Port
1）APP Inerface
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
① Bluetooth connection status, click on the
bluetooth connection.
② Four channel numbers, click to view each
probe barbecue status.
③ Click to set the barbecue mode.
④ Click to view all the barbecue probes.
2Features
Stainless steel structured. The probe can monitor
temperature of both the food and oven.
Support BLE4.0 with transmission distance of 10
meters
Tracking temperature by Grill ProbeE APP
Allow 3 preset grilled modes: Recipes, Target
Temperature or Timer
Support 4 probes to be operated at the same time
Food temperature measurement range:0～100℃
Internal temperature measurement range of
oven:0～275℃
Fast charge for 10 minutes and the probe can be
operated for 4 hours
3）Insert probe into food
Oven Sensor
Food Sensor
Safe Insertion Line
11
12

Quick Start Guide
Download & Open the App Grill ProbeE. Take out
the probe from the charger followed by clicking
“ ” in the top right corner of the screen.
Then, select the probe from the list.
Bluetooth connection is connected when the screen
shows “ ” and show the channel number.
2）Connect the bluetooth
3）Disconnect the bluetooth
4）System Settings
5）Barbecue mode setting
1）Barbecue alarm
⑤ Time left
⑥ Food temperature
⑦ Barbecue mode
⑧ Start / Stop，click to start / stop the barbecue
process
⑨ Oven temperature
⑩ Low battery alarm, need to recharge the probe
System setting interface
Click to view a single probe barbecue
Click “ ” in the top right corner of the screen.
Then, Select the connected probe and click “ Y ”
to disconnect Bluetooth connection.
Temperature Unit：Celsius / Fahrenheit
Alarm Type：Ring,Vibration,Ring & Vibration
Three barbecue modes：Recipe,Timer,
Temperature.
Press “ START ” to start barbecue process.
Note： Each barbecue probe are independent
of each other, user must set barbecue mode each
probe individually.
When the grill food reaches the preset temperature,
the smartphone will alarm you the end of grilling
5Alarm
2）Bluetooth disconnection alarm
When the Bluetooth connection between the
smartphone and the probe is interrupted, an
alarm message will pop up to remind you to
keep the smartphone closer to the probe within
2 minutes so not affect your grilling process.
6Using the sealing cap
Note: Support maximum to 4 probes, can be
operate at the same time.
11
12
When the probe stays away from the mobile phone or
the oven temperature is below 50℃for ten minutes,
the probe will automatically turn off.Please press
“ON” button to restart the Bluetooth connection.
The communication distance is limited to 1 meter
when the probe is inside a metal shielded oven.
Dot not put probes without food into the barbecue oven.
Barbecue food should be lower than
100 ℃ . Oven
temperature should be lower than 275
℃ . If exceed this
limit, the probe will be permanently damaged. When this
happens, the user should quickly remove the probe.
This product works under high temperature. Improper
use will cause damage of the probe. In such circumsta-
nces, the manufacturer will not provide any warranty for
repair and/or replacement services.
process. At that time, please take out the food &
remove the probe from the oven immediately.
7Attention
When the barbecue is smoky,please put on the
sealing cap on top of probe handle.
After the top of probe handle is put on the sea-
ling cap,it can be cleaned under water.
Note: If no channel no. appear, put the probe back
to the charger & charging for 10 minutes.
