Chard IM-15SS Quick reference guide

Use and Care Instructions
Ice Maker with
water dispenser
Durable, high-quality stainless steel nish
• Laconceptionuniqueutiliseunpotàeaude5gallonsdestyle«
refroidisseurd’eau»pourfournirdelaglaceoudel’eaufroide.*
• Vouschoisissezentredepetits,moyensougrandscubes
• Lespetitsetmoyenscubessontidéauxpourlesboissons
• Lesgrandscubessontidéauxpourlesglacières
• Lecorpssolideenacierinoxydableassureunaspectattrayant
etdeladurabilité
•Uniquedesignuses“watercooler”-style
vegallonwaterjugtoconveniently
supplyiceorcolddrinkingwater.*
•Choosefromsmall,medium,
orlargecubes
•Smallormediumcubesgreatfordrinks
•Largecubesgreatforcoolers
•Ruggedstainlesssteelbodyensures
goodlooksanddurability
*waterbottlenotincluded
*Bouteilled’eaunoncomprise

1
IMPORTANT SAFETY INSTRUCTIONS……………………………………………….…2
PREPARING YOUR ICE MAKER FOR USE
IMPORTANT SAFETY TIPS…………………………………………………………………….3
GETTING TO KNOW YOUR UNIT… …… …… …… …… …… …… …… …… …… …… …… …… …… …… …… …… …… …… …… …… …. .. .4 4
OPERATING PROCEDURES & MAINTENANCE………………………………………5
UNPACKING YOUR ICE MAKER… …… …… …… …… …… …… …. .… …… …… …… …… …… …… …… …… …… …… …… …… …… …… …… …. .. .. .5 5
CONNECTING YOUR ICE MAKER… …… …… …… …… …… …. .… …… …… …. .… …… …… …… …… …… …… …… …… …… …… …… …… …. .. .. .6 6
CLEANING AND MAINTAINING YOUR ICE MAKER… …. .… …… …… …… …… …… …… …… …… …… …… …… …… …… …… …. .. .6 6
USING YOUR ICE MAKER……………….……..………………………………………...7
TROUBLESHOOTING… …… …… …… …… …… …… …… …… …… …… …. .… …… …… …… …… …… …… …… …… …… …… …… …… …… …… …… …… …8 8
TECHNICAL PARAMETERS & CIRCUIT DIAGRAM……………………..….………..9
After Sales Service………………………………………………………………………….10
TABLE OF CONTENTS
TABLE OF CONTENTS

2
DANGER
!
WARNING
Your safety and the safety of others are very important.
We have provided many important safety messages manual and your appliance.
Always read and obey all safety massages.
This is the safety alert symbol:
!
All safety messages will follow the safety alert symbol and the word “DANGER” or “WARNING”.
These words mean:
You can be killed or seriously injured if you don’t immediate follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance
of injury, and tell you what can happen if the instructions are not followed.
IMPORTANT SAFETY INSTRUCTIONS
!

3
When using electrical appliances, basic safety precautions should be followed to reduce the
risk of fire, electric shock, and injury to persons or property. Read all instructions before using
any appliance.
Do not operate this，or any other appliance with a damaged cord.
Connect to properly polarized outlets only. No other appliance should be plugged into the
same outlet. Be sure that the plug is fully inserted into the receptacle.
Do not run the power cord over carpeting or other heat insulators. Do not cover the cord.
Keep cord away from traffic areas, and do not submerge in water.
We do not recommend the use of an extension cord, as it may overheat and become a risk
of fire. If you must use an extension cord, use No.14AWG minimum size and rated no less
than 1875 watts.
Unplug the ice maker before cleaning or making any repairs or servicing.
Exercise caution and use reasonable supervision when appliance is used near children.
Do not use your ice-maker outdoors. Place the ice-maker away from direct sunlight and
make sure that there is at least 4 inches of space between the back of your unit and wall.
Keep a minimum distance of 4 inches on each side of your unit free.
Do not use other liquid to make the ice-cube other than water.
Do not clean your ice maker with flammable fluids. The fumes can create a fire hazard or
explosion.
Do not tip over.
If the ice maker is brought in from outside in wintertime, give it a few hours to warm up to
room temperature before plugging it in.
WARNING: This appliance must be earthed.
IMPORTANT:
The wires in this mains lead are colored in accordance with the following code:
Green or Green with a strip yellow: Grounding
White: Neutral
Black: Live
To avoid a hazard due to instability of the appliance, it must be placed at a even or flat
surface.
PREPARING YOUR ICE MAKER FOR USE
IMPORTANT SAFETY TIPS

4
UNIT
SMART CORE FOR
THE WATER BOTTLE
ICE CUBE BASKET
OPERATION PANEL
WATER DRAIN CAP
(Need to be pop up by the button
near the operation panel)
COLD WATER FAUCET
AIR OUTLET
Can be pulled out
BUTTON TO POP UP
THE WATER FAUCET
OPERATION PANEL
Small Size of
Ice-cube Light
Medium Size of
Ice-cube Light
Large Size of
Ice-cube Light
Water Dispensing Button
ICE-FULL Indicating Light
Means that there is no
water in the unit
WATER Indicating Light
POWER Indicating Light
Use to start or stop
the unit
Use to select the desired
size of the ice-cube.
ON/OFF Button
SELECT Button
GETTING TO KNOW YOUR UNIT

5
1. Remove the exterior and interior packaging. Check that ice scoop is included. If any parts
are missing, please contact our customer service.
2. Clean the interior with lukewarm water and a soft cloth. Take out the ice basket and clean
it .
3. Find a location for your ice maker that is protected from direct sunlight and other sources of
heat (i.e.: stove, furnace, radiator). Place the ice maker on a level surface. Maker sure that
there is at least 4 inches of space between the back and sides of your ice maker and the
wall.
4. Allow one hour for the refrigerant fluid to settle before plugging ice maker in.
5. The appliance must be positioned so that the plug is accessible.
6. Before placing water bottle on the unit, be sure that the drain plug on the back is tightly
fastened.
7. Hold the water bottle vertically and upside down (over the unit) and place the water bottle
into the SMART CORE for the water bottle. Apply slightly pressure in order to pierce the
bottle cap with the spigot. This unit accepts two, three or five gallon water bottle with
pierceable sealed caps.
PLACE BOTTLE
VERTICALLY
STRAIGHT DOWN
OPERATING PROCEDURES & MAINTENANCE
UNPACKING YOUR ICE MAKER

6
DANGER
* Improper use of the grounded plug can result in the risk of electrical shock. If the
power cord is damaged please call our customer service.
1. This unit should be properly grounded for your safety. The power cord of this appliance is
equipped with a three-prong plug which mates with standard three prong wall outlets to
minimize the possibility of electric shock.
2. Plug your appliance into an exclusive, properly installed, grounded wall outlet. Do not under
any circumstances, cut or remove the third (ground) prong from the power cord. Any
questions concerning power and/or grounding should be directed toward a certified
electrician.
3. This appliance requires a standard 110~120 volt, 60Hz electrical outlet with three-prong
ground.
Before using your ice maker, it is strongly recommended to clean it thoroughly.
1. Take out the ice basket.
2. Clean the interior with diluted detergent, warm water and a soft cloth.
3. Then use the water to rinse the inside parts, and drain out the water by unplugging the
drain cap on the side.
4. The outside of the ice maker should be cleaned regularly with a mild detergent solution and
warm water.
5. Dry the interior and exterior with a soft cloth.
6. When the machine is not in use, open water drained cap to drain water completely from
water reservoir.
CONNECTING YOUR ICE MAKER
!
CLEANING AND MAINTAINING YOUR ICE MAKER

7
MAKING THE ICE -CUBE
1. Press “ON/OFF” on the control panel to begin the ice making cycle.
2. Select the size of the ice cube by pressing the “Select” button.
3. The ice making cycle lasts 6 to 15 minutes, depending on the size of the ice cube selection
and the ambient temperature. And during the extreme temperature, the lasting time maybe
vary a lot.
4. If water pump can’t inject water, the ice maker will stop automatically, and the “ADD
WATER” indicator will be on on the operation panel. Please check the water bottle and
replace a new bottle full of water.
Press “ON/OFF” button again to start the unit again.
And if the new bottle full of water is replaced and the “ADD WATER”indicater is still on
because of water pump not working properly, please check the two water filter:
A. The water filter is located in the bottom of water tank, first check it is blocked or not.
Otherwise clean it.
B. The water filter is displayed in following figure. Realease the clipper and take
down the water pipe, then take out the water filter and clean it, then install back
and use the clipper to fasten the water pipe again.
WATER PIPE
TOP COVER
WATER FILTER
CLIPPER
Allow the refrigerant liquid inside the compressor at least 3 minutes to settle before
restarting.
5. The ice maker automatically stops working when the ICE light on the operarion panel is on
means that ice basket is full.
ENJOY THE COLD WATER
The cold water can be enjoyed only after the ice-making have worked for more than half hour.
1.Press the button to pop up the cold water faucet.
2. Press the “WATER”Water Dispensing Button on the operation button to dispense the
cold water to your cup. Release pressing till your cup is full of the cold water.
USING YOUR ICE MAKER

8
Push this button to
let the cold water
faucet pop up.
PROBLEM
POSSIBLE CAUSE
SOLUTION
“WATER” indicator is on.
Lack of Water.
Stop the ice maker, replace with a
new bottle full of water, and then
restart it.
One of two water filter is
blocked.
Check both of water filter and
clean it.
“ICE” indicator is on.
The ice basket is full of the
ice-cube.
Pull the ice basket and empty it.
Ice cubes stick together.
The ice cycle is too long.
Stop the ice maker, and restart it
when the ice blocks melt. Select
the small ice button.
Water temperature in inner
tank is too low.
Change the water in the inner
Tank. Temperature of water is
better set between 45℉-90℉.
Ice making cycle is normal
but no ice is made.
Ambient temperature or
water temperature in inner
tank is too high.
Please run the ice maker below
90℉and pour colder water into
tank.
Refrigerant liquid leakage.
Verify by a qualified technician.
Pipe in the cooling system
is blocked.
Verify by a qualified technician.
TROUBLESHOOTING

9
M
Mo od de el l
H
HZ ZB B- -1 15 5/ /B BF F
D
De es sc cr ri ip pt ti io on n
I
Ic ce e m ma ak ke er r u us si in ng g b bo ot tt tl le ed d w wa at te er r, , w wi it th h c co ol ld d w wa at te er r d di is sp pe en ns si in ng g f fu un nc ct ti io on n
P
Po ow we er r R Ra at ti in ng g
1
11 15 5V V~ ~, , 6 60 0H Hz z
I
Ic ce e- -m ma ak ki in ng g
R
Ra at te ed d C Cu ur rr re en nt t
2
2. .6 6A A
I
Ic ce e- -h ha ar rv ve es st t
R
Ra at te ed d C Cu ur rr re en nt t
3
3. .5 5A A
R
Re ef fr ri ig ge er ra an nt t
R
R1 13 34 4a a 1 10 02 2g g
D
De es si ig gn n P Pr re es ss su ur re e
H
Hi ig gh h S Si id de e 2 29 90 0P Ps si ig g
L
Lo ow w S Si id de e 8 88 8P Ps si ig g
E
En nc cl lo os su ur re e
S
St ta ai in nl le es ss s s st te ee el l o or r c co ol ld d r ro ol ll le ed d s sh he ee et t m me et ta al l s st te ee el l w wi it th h p pl la as st ti ic c c co ov ve er r
D
Di im me en ns si io on n
3
35 57 7m mm m( (W W) )* *4 42 23 3m mm m( (D D) )* *4 45 52 2m mm m( (H H) )
N
Ne et t W We ei ig gh ht t
1
19 9. .3 3K Kg g
TECHNICAL PARAMETERS
CIRCUIT DIAGRAM
TECHNICAL PARAMETERS & CIRCUIT DIAGRAM

10
SENSOR FOR ICE
FULL DETECTING
SENSOR FOR
CONTROLING FAN MOTOR
ICE WATER
DETECTING SWITCH
MICRO SWITCH
MAIN CONTROL PCB
M7C
S
OPERATION PCB
ICE-FULL
L
LED
LED
LED
Water
Faucet
LED
POWER
NO-WATER
LED
Set
Button LED
ON/OFF MCU
T1
T2
MICRO SWITCH FOR
FAUCET DETECTING
PUMP For
Water Faucet
ELECTRICAL DIAGRAM
FOR ICE-MAKER
POWER
SUPPLY L
G
N
Relay
Relay
AC-L
COMP
AC-N
Yellow
PUMP
RelayRelay Relay Relay
FAN MOTOR
MOTOR
VALVE FA
Blue
Solenoid
Valve For
Ice-melting
Blue
S
M
Overload
Protector
CBlack
Comp
Black
WATER
PUMP
3
1
PTC
Startor
White
2Black
Red
SM
Black
FAN
MOTOR
Motor For
Ice shovel
rotation
White
Black
Black
Black
Model: HZB-15/BF
If you have the question, please contact our service telephone number.
After Sales Service
