Charder Ms3400 User manual

-31-

Manufacturer’s Declaration of Conformity

This product has been manufactured in accordance with

the harmonized European standards, following the

provisions of the below stated directives:

93/42/EEC as amended by 2007/47/EC

Medical Device Directive

Please see separate document showing on sticker of device for

above CE marking.

Authorized EU Representative:

Manufactured by:

Charder Electronic Co., Ltd.

No.103, Guozhong Rd., Dali Dist.,

Taichung City, 412 Taiwan (R.O.C.)

FDA no.: D051882

IN-0988 [7011Q] 04/2016

-0-

MS3400/MS3400-1

Medical Scale

USER MANUAL

Please keep the instruction manual at hand all the time for future reference.

-1-

TABLE OF CONTENTS

PREFACE................................................................................................. 2

GENERAL INFORMATION .................................................................... 2

SAFETY INSTRUCTION ........................................................................ 2

ELECTROMAGNETIC COMPATIBILITY.............................................. 3

WARRANTY-LIABILITY........................................................................ 3

DISPOSING OF THE SCALE.................................................................. 4

EXPLANATION OF THE GRAPHIC SYMBOLS.................................... 5

EMC guidance and manufacturer's declaration.......................................... 7

SPECIFICATIONS ..................................................................................11

STANDARD ACCESSORIES ................................................................ 12

MEDICAL SCALE MODELS APPROVAL LIST................................... 13

POWER ADAPTOR STANDARDS ....................................................... 14

SCALE ASSEMBLY .............................................................................. 15

KEY FUNCTIONS................................................................................. 18

HOW TO USE HOLD FEATURE........................................................... 19

HOW TO USE BMI (Body Mass Index) ................................................. 19

USING TARE FUNCTION..................................................................... 19

CONNECTING AC ADAPTER.............................................................. 20

CALIBRATION PROCEDURE.............................................................. 21

ASSEMBLE WITH HM201M HEIGHT ROD........................................ 22

INSTRUCTION OF USING HM201M................................................... 23

ERROR MESSAGE................................................................................ 26

TROUBLESHOOTING.......................................................................... 27

NOTE

2. LCD display faulty

Possible hardware defects include: Uneven brightness in the LCD

display screen & texts color blurred, smeared rainbow screen,

incorrect decimal display

LCD P N broken or short circuit

PCB cooper foil broken & loosed welding

Unable to save or read data – C or transistor faulty, internal parts

broken.

LCD showing “ERRL” after switch on - Load cell damaged

Overload may cause the weigh to malfunction.

Software system crash

Resonator faulty

Load cells with faulty grinding standard.

Key buttons failure - Front key panel damaged or disconnected

3. Buzzer malfunction

Wrong welding of PVC wire

Key buttons & control panel damaged or disconnected.

-2-

PREFACE

Thank you for choosing CHARDER MEDICAL product. All features of this

product were designed to state of the art and are optimized for simple and

straightforward use. If you have any queries or experience any problems

not addressed in the operating instructions, please contact your CHARDER

MEDICAL service partner, or visit us on the Internet at

www.chardermedical.com

GENERAL INFORMATION

We strongly recommend you use the scales on flat and hard surface. Any

soft surface, like carpet will cause inaccuracy.

SAFETY INSTRUCTION

Before putting the device into use, please read with care the

information given in the Operating nstructions. They contain important

instructions for installation, proper use and maintenance of the device.

The manufacturer shall not be liable for damages arising out of failure to

heed the following instructions:

When using electrical components under increased safety

requirements, always comply with the appropriate regulations.

mproper installation will render the warranty null and void.

Ensure the voltage marked on the power supply unit matches your

mains power supply.

This device is designed for use indoors.

Observe the permissible ambient temperatures for use

These batteries should be kept away from small children. f swallowed,

promptly seek medical assistance.

Expected Service Life: 5 years

The device meets the requirements for electromagnetic compatibility.

Do not exceed the maximum values specified in the applicable

standards.

f you have any problem, contact your local CHARDER MED CAL service

partner.

ELECTROMAGNETIC COMPATIBILITY

ADVICE TO THE USER

This product is a sensitive electronic instrument and as such it may

temporarily be affected by Radio Transmitting Devices being used in close

proximity to it (such as Mobile Phones, Walkie Talkies, CB Radios, and

Radio Model Controllers). If it does exhibit symptoms such as the display

of erratic or erroneous data, try moving this product away from the source

of interference or switching off that source of interference whilst you are

using this product. If the problem persists then contact your local agent.

WARRANTY-LIABILITY

If a fault or defect is present on receipt of the unit which is within

CHARDER MEDICAL’s scope of responsibility, CHARDER shall

have the right to either repair the fault or supply a replacement unit.

Replaced parts shall be the property of CHARDER. Should the fault

repairs or replacement delivery not be successful, the statutory

provisions shall be valid. The period of warranty shall be two years,

beginning on the date of purchase. Please retain your receipt as

proof of purchase. Should your scale require servicing, please

contact your dealer or CHARDER MEDICAL Customer Service.

No responsibility shall be accepted for damage caused through

any of the following reasons: Unsuitable or improper storage or use,

2. Indicator showing “0000 ZERO SPAN out of range

ncorrect weighing result - Avoid damages by external environment

force such as free-drop to the ground, collision by external objects,

etc.

Proper re-calibration procedure required to correct the setting of

weighing accuracy.

nterference due to RF disturbance, ground vibration…etc.

Unstable platform feet adjustments according to bubble level

indication

ncorrect position or other external objects within weighing area

The weighing-scale is not put in a solid & firm ground area, such as

carpet floor or lawn.

3. Connection failure for data transmission to PC or printer

Wrong connection wires or faulty wires for transmission between

the digital indicator & load cells.

Wrong indicator models

Wrong internal wiring or wire broken

In case of the following defective mode occurs, it is suggested to contact

your nearest Authorized Dealer for further technician service & repair:

1. Power Switch-on failure :

Push-button faulty

Short circuit wires - Wire broken

Safety fuse burnt out

Wire connection problem

Main power adaptor faulty – Parts Replacement

TROUBLESHOOTING

Troubleshooting for defective modes:

Original purchaser can enjoy the benefits under the effective Warranty

against functional defects in material and workmanship subject to the

terms and conditions listed in our Warranty Program & Return Policy.

Our warranty service program includes the following:

1. Technician repair service under warranty or at a service

maintenance charge depending on the workmanship for the

defective functionality or cause of damage covered by the

warranty.

2. Parts replacement from the manufacturing factory under the

warranty or at a certain cost for the replaced parts plus the

workmanship charge if not covered under the warranty.

Before you contact our Authorized Dealer in your country for technician

repair service, please read through the following section carefully:

Self-checking Tips:

Some functional defects can be identified and maintained by

users as listed below:

1. Power-on failure

Check if the main power adaptor has not plugged onto the scale

properly

Check if the battery power is running low – Replace with new

batteries.

incorrect installation or commissioning by the owner or third parties,

natural wear, changes or modifications, incorrect or negligent

handling, overuse, chemical, electrochemical or electrical

interference or humidity, unless this is attributable to negligence on

the part of CHARDER MEDICAL.

If operating, climatic or any other influences lead to a major

change in conditions or material quality, the treaty for perfect unit

functioning shall be rendered null and void. If CHARDER provides

and individual warranty, this means that the unit supplied will be free

of faults for the length of the warranty period.

DISPOSING OF THE SCALE

This product is not to be treated as regular household waste, but

should be handed into an electrical/electronic equipment recycling

centre.

You can obtain further details from your local council, your

municipal waste disposal company or the firm which you purchased

the product.

EXPLANATION OF THE GRAPHIC SYMBOLS

SN-T13000001

Designation of the serial number of

every device, applied at the device.

(Number as an example)

“Please note the accompanying

documents“

or “Observe operating instructions”

Charder Electronic Co., Ltd.

No.103, Guozhong Rd., Dali Dist.,

Taichung City 412, Taiwan (R.O.C.)

Identification of manufacturer of

medical product including address

“Electro-medical appliance“

with attachment for type B

-26-

ERROR MESSAGE

Low Battery

If battery is running out of power, the

display shows . You should charge

the

scale.

Over Load

If the total load exceeds the maximum

capacity of scale, the display will show

the “Err” message. The weight must be

removed from the platform right away.



Under

Zero

If zero count is below the setting, the

display will show “Errl” message. The

scale will shut off if the status lasts 30

seconds.



Over Zero

If zero count is high than the setting

range, the display will show “Err”

message. The scale will shut off if the

status lasts 30 seconds.

-25-

3. Measured result can be read at the place pointed by arrow.

NOTE: Please fold the plate when pull down through the indicator

Dispose of old appliances

separately from your household

waste!l!

Instead, take them to communal

collection points.

Carefully read t

his operation manual

before setup and commissioning,

even if you are already familiar with

Charder scales.

Transport and storage temperature

limit indicating the upper and the

lower limit

(Transport and storage temperature

on packaging)

+60°C

-20°C

-7-

EMC guidance and manufacturer's declaration

Guidance and manufacturer’s declaration-electromagnetic emissions

The MS-3400-1 is intended for use in the electromagnetic environment specified below.

The customer or the user of the MS-3400-1 should assure that it is used in such an environment.

Emission test Compliance Electromagnetic environment-guidance

RF emissions

CISPR II Group 1 The MS-3400-1 uses RF energy only for its internal

function. Therefore, its RF emissions are very low and

are not likely to cause any interference in nearby

electronic equipment.

RF emissions

CISPR II Class B

Harmonic

emissions IEC

61000-3-2

Class A

Voltage

fluctuations/flicker

emissions IEC

61000-3-3

Compliance

The MS-3400-1 is suitable for use in all establishments,

including domestic establishments and those directly

connected to the public low-voltage power supply

network that supplies buildings used for domestic

purposes.

-24-

1. Fold the plate and press the tenon.

Pull down the plate while tenon has been pressed.

MEASURING UNDER 131 cm

-23-

INSTRUCTION OF USING HM201M

1. Pull out the rod.

2. Level the plate and start measuring.

MEASURING OVER 131 cm

-8-

Guidance and manufacturer’s declaration-electromagnetic immunity

The MS-3400-1 is intended for use in the electromagnetic environment specified below. The customer or the user of

the MS-3400-1 should assure that it is used in such an environment.

Immunity test

IEC 60601

test level Compliance level Electromagnetic

environment-guidance

Electrostatic

discharge (ESD)

IEC 61000-4-2

±6kv contact

±8kv air

±6kv contact

±8kv air

Floors should be wood,

concrete or ceramic tile. If floors

are covered with synthetic

material, the relative humidity

should be at least 30%

Electrical fast

transient/burst

IEC 61000-4-4

±2kv for power supply

lines

±1kv for input/output

lines

±2kv for power supply lines

±1kv for input/output lines

Mains power quality should be

that of a typical commercial or

hospital environment.

Surge IEC

61000-4-5

±1kv differential mode

±2kv common mode

±1kv differential mode

±2kv common mode

Mains power quality should be

that of a typical commercial or

hospital environment.

Voltage Dips, short

interruptions and

voltage variations

on power supply

input lines IEC

61000-4-11

<5%UT(>95% dip in

UT) for 0.5 cycle

40% UT(60% dip in UT)

for 5 cycles

70% UT(30% dip in UT)

for 25 cycles

<5% UT(>95% dip in

UT) for 5 s

<5%UT(>95% dip in UT) for

0.5 cycle

40% UT(60% dip in UT) for

5 cycles

70% UT(30% dip in UT) for

25 cycles

<5% UT(>95% dip in UT)

for 5 s

Mains power quality should be

that of a typical commercial or

hospital environment. If the user

of the MS-3400-1 requires

continued operation during

power mains interruptions, it is

recommended that the

MS-3400-1 be powered from an

uninterruptible power supply or

a battery.

Power frequency

(50/60Hz) magnetic

field IEC

61000-4-8

3A/m 3A/m The MS-3400-1 contains no

devices susceptible to magnetic

fields.

NOTE: UT is the a.c. mains voltage prior to application of the test level.

Guidance and manufacturer’s declaration-electromagnetic immunity

The MS-3400-1 is intended for use in the electromagnetic environment specified below. The customer or the user of

the MS-3400-1 should assure that is used in such and environment.

Immunity test

IEC 60601

test level Compliance

level Electromagnetic

environment-guidance

Conducted RF

IEC 61000-4-6

Radiated RF

IEC 61000-4-3

3 Vrms

150 KHz to 80 MHz

3 V/m

80MHz to 2.5GHz

3 Vrms

3 V/m

Portable and mobile RF communications

equipment should be used no closer to

any part of the MS-3400-1 including

cables, than the recommended separation

distance calculated from the equation

applicable to the frequency of the

transmitter.

Recommended separation distance:

d=1.2√p

d=1.2√p80MHz to 800MHz

d=2.3√p800MHz TO 2.5GHz

Where Pis the maximum output power

rating of the transmitter in watts (W)

according to the transmitter manufacturer

and dis the recommended separation

distance in metres (m).

Field strengths from fixed RF transmitters,

as determined by an electromagnetic site

survey,

should be less than the

compliance level in each frequency

range.

Interference may occur in the vicinity of

equipment marked with the following

symbol

NOTE1 At 80MHz and 800MHz, the higher frequency range applies.

NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and

reflection from structures, objects and people.

a. Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land

mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically

with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic

site survey should be considered. If the measured observed, additional measures may be necessary, such as

re-orienting or relocating the MS-3400-1.

b. Over the frequency range 150KHz to 80MHz, field strengths should be less than 3V/m.

-22-

ASSEMBLE WITH HM201M HEIGHT ROD

1. Fix the brackets. 2. Fix HM201M on the

brackets.

CALIBRATION PROCEDURE

1) Keep pressing ON/ZERO/OFF and press UNIT/WEIGHT 3

times simultaneously.

2) LCD display shows zero count value between 2000 to10000.

3) Press TARE, display shows “0”.

4) Press UNIT/WEIGHT to select calibration weight unit (kg/lb)

5) Load 200 kg or 500 lb.

6) Display will show span count value (kg: 8000 ~ 20000 / lb : 9100

~ 22650).

7) Press TARE, display will show “CAL”, and then show 200.0kg /

500.0 lb.

8) Remove the weight, and the calibration procedure is finished.

Recommended separation distance between

Portable and mobile RF communications equipment and the MS-3400-1

The MS-3400-1 is intended for use in the electromagnetic environment in which

radiated RF disturbances are controlled. The customer or the user of the

MS-3400-1 can help prevent electromagnetic interference by maintaining a

minimum distance between portable and mobile RF communications equipment

(transmitters) and the MS-3400-1 as recommended below, according to the

maximum output power of the communications equipment.

Separation distance according to frequency of transmitter

Rated

maximum

output power

of transmitter

150KHZ to 80MHZ

d=1.2√p

80MHZ to 800MHZ

d=1.2√p

800MHZ to

2,5GHZ

d=1.2√p

0,01

0,12

0,23

0,1

0,38

0,73

1,2

2,3

3,8

7,3

100

For transmitters rated at a maximum output power not listed above, the

recommended separation distance d in metres (m) can be estimated using the

equation applicable to the frequency of the transmitter, where p is the maximum

output power rating of the transmitter in watts (W) according to the transmitter

manufacturer.

NOTE1 At 80 MHz and 800 MHz, the separation distance for the higher

frequency range applies.

NOTE2 These guidelines may not apply in all situations. Electromagnetic

propagation is affected by absorption and reflection from structures, objects and

people.

-11-

SPECIFICATIONS

Model MS 3400 / MS 3400-1 (DP 2700)

Capacity 300 kg x 0.1 kg

Accuracy ±150g

Weight Unit kg / lb

Operating Temp. &

Humidity

+ 5°C ~ + 35°C

15% - 85% RH

Transport and Storage

Temperature & Humidity

- 20°C + 60°C

10% - 95% RH

LCD Display 1.0” LCD digital display

Dimension Platform size: 310 x 310 mm

Column Height: 900mm

Key Functions HOLD/BM , UN T/WE GHT , ON/ZERO/OFF ,

TARE

Power Supply 12V- 15V adapter

1.5V AAA battery * 6

Optional Accessories HM201M height rod 60 ~ 205 cm / 6ft 9inch

1. Place the tare object (additional loads or clothes) onto the

tread platform.

2. Press [TARE] key after the weight stabilizes and stable sign

displays. Remove the tare object from the platform first, so

the display will return to zero for the second time weighing of

the gross weight.

3. Place the gross object/person to be weighed (Including the

tare object on the tread platform)

4. The weighing result is the Net weight of the item / person.

5. To delete the saved tare value, remove the tare object from

the tread platform and press [TARE] key.

CONNECTING AC ADAPTER

Plug in AC adapter or put in batteries as power source.

(For rechargeable version)

Please connect to AC adapter to charge your scale for at least 14 hours

before first use.

Fully charged rechargeable batteries could provide approximately eight

hours of continuously use.

-19-

HOW TO USE HOLD FEATURE

By using the HOLD function the identified weight will be stored and is

shown on the display even if you stepped already off the scale.

1) Press ON/ZERO/OFF to turn on the scale.

2) Step on the scale, wait until stable zero symbol Oappears.

3) Press HOLD/BMI while subject is being weighed.

4) An arrow will blink and point HOLD mark on the panel.

5) Step off the scale, and the weight value will continue showing

on the display.

6) Press HOLD/BMI again to disable HOLD function.

HOW TO USE BMI (Body Mass Index)

1) Press HOLD/BMI for at least 3 seconds to enter BMI setting mode.

2) A pre-set height value (in centimeter) will show, and the first

digit will blink.

3) Press UNIT/WEIGHT to change the value.

4) Press HOLD/BMI to set next digit.

5) Input height value of weighed person digit by digit.

6) When input completed, press TARE, and 0.0kg will shown on

the display.

7) Step on the platform, and the display will show the weight and

BMI value alternately.

8) Step down and press HOLD/BMI to leave BMI setting mode.

USING TARE FUNCTION

[TARE] key function allows the user to deduct the excess weight of a

single tare object value (additional loads or clothes) from the display

reading, thus calculate the actual net weight of the object/ person.

STANDARD ACCESSORIES

No. Accessories Item Spec Qty

M4 Screw M4*0.7*15 3

M4 Screw M4*0.7*8 4

Bottom

Cover 1

-13-

MEDICAL SCALE MODELS APPROVAL LIST

The Medical Scales MS3400-1 listed below are the certified

models under the Council Directive

2007/47/EC

for standard of

safety, health protection and accurate metrology characteristics

of medical scales:

PRODUCT

DESCRIPTION

PRODUCT MODEL NO. CLASS

Medical Scale

MBF6000, MBF6010, MS21Neo, MS2320,

MS2501, MS3800, MS4610, MS4940, MS5410,

MS5710, MS3700-1, MS4900, MS5810,

MS5811, MS2350, MS2504, MS3830, MS3910,

MS4640, MS4910, MS5440, MS5730, MS6001,

MS5900, MS4200, MS4202L, MS2400,

MS3500, MS4400, MHS2500, MHS2600,

MHS2510, MHS2610, MS21neoV, MS6000,

MS6111, MS6110, MS4201

Height

Measurement

HM-80P , HM-80M , HM-200P , HM-200PW ,

HM101M, HM110M, HM201M, HM230M,

HM202P

-18-

KEY FUNCTIONS

INDICATOR MODEL NO.: DP 2700

Description:

TARE

Tare the weight of excess object in advance so that the user

can measure the net weight of the object / person at ease

without removing the tare object again.

ON/ZERO/OFF

Key to power scales ON, OFF and ZERO.

UNIT/WEIGHT

Key to switch kg or lb, and to change height value under BMI

mode.

HOLD/BMI

HOLD key and BMI (Body Mass Index) key

5. Complete

-14-

POWER ADAPTOR STANDARDS

AMP

VOLTAGE

DRAWING NO.: CE APPROVED TYPE NO.

/ MODEL NO.:

TYPE

9V DC 100mA

AD-038A REV 007 D41W1090100-13/1 EU

9V DC 100mA

AD-0484 REV 001 D35W090100-23/1 US

9V DC 100mA

AD-0484 REV 001 SP35-90100 US

9V DC 100mA

AD-037A REV 003 D41WK090100-13/2 UK

9V 200mA AD-8082A REV 001 UE05WCP-0900205PC AU

12V 2A AD-8057 REV 001

(AD-0520)

UE24WV-120200SPA EU

12V 2A AD-8058 REV 001 UE24WU-120200SPA US

12V 2A AD-8056 REV 001 UE24WB-120200SPA UK

12V 2A AD-8074 REV 001 UE24W4-120200SPAS AU

12V 1A N/A UE24WV-120100SPA EU

12V 1A N/A UE24WV-120100SPA UK

15V300mA AD-8079A UE05WCP-150030SPC EU

15V300mA AD-016D REV 001 D41W150300-13/1 US

15V300mA AD-8064 REV 001 MTP121UL-120100A US

15V300mA AD-8079B REV 001 UE05WCP-150030SPC UK

15V300mA AD-8079C REV 001 UE05WCP-150030SPC AU

15V 300mA AD-0420 REV 004 D41W 150300-13/1 EU

15V 300mA AD-0370 REV003 D41WK150300-13/2 UK

15V 300mA AD-0482 REV 004 D41WA150300-13/2 AU

SCALE ASSEMBLY

1. Plug the column into the column seat.

2. Screw in three M4*0.7*15 screws.

3. Arrange the cable along the gap in the column seat.

4. Cover the bottom cover and screw in four M4*0.7*8 screws

-31-

Manufacturer’s Declaration of Conformity

This product has been manufactured in accordance with

the harmonized European standards, following the

provisions of the below stated directives:

93/42/EEC as amended by 2007/47/EC

Medical Device Directive

Please see separate document showing on sticker of device for

above CE marking.

Authorized EU Representative:

Manufactured by:

Charder Electronic Co., Ltd.

No.103, Guozhong Rd., Dali Dist.,

Taichung City, 412 Taiwan (R.O.C.)

FDA no.: D051882

IN-0988 [7011Q] 04/2016

-0-

MS3400/MS3400-1

Medical Scale

USER MANUAL

Please keep the instruction manual at hand all the time for future reference.
